Reiner jetStamp graphic 970 User manual

jetStamp graphic 970
EN
Short instruction

1
jetStamp graphic 970
A
1
2
3
4
5
6
7

2
jetStamp graphic 970
B
11
12
13
C
8
9
10
E
15
17
18
D
14
15
12
5
16
Ernst Reiner GmbH & Co. KG
Baumannstr. 16
78120 Furtwangen/Germany
Phone: [phone]
Fax: [phone]
Email: [e-mail]
www.reiner.de
© 2019 Ernst Reiner GmbH & Co. KG

7
jetStamp graphic 970
The LED indicator marks the selected setting and flashes in case of warnings.
On the setting functions (see “Online help of the PCset graphic software”).
fTo avoid malfunctions align the settings precisely with the LED indicator!
fTo activate Bluetooth, turn the setting wheel
7
to position Online/Bluetooth
(see “Online help of the PCset graphic software”).
Set Wheel
Clean
Online/Bluetooth
Functions
Print image 3
Print image 4
Print image 2
Print image 1
LED indicator
O
1
Trigger button
2
Battery compartment
3
Print carriage
4
Base station
5
Protective Nozzle Seal
6
LED indicator
7
Set wheel
8
Green charge display
9
Micro-USB socket
Operating Elements
10
Plug-in socket for external trigger
11
Folding print cartridge
12
Print cartridge
13
Lock print cartridge
14
Contact print cartridge
15
Nozzles
16
Sealing tip
17
Positioning aids
18
Print area
For detailed operating instructions and further information, see the online help of
the PCset graphic software, or the enclosed USB memory stick.

8
jetStamp graphic 970
Important Notes
Before commissioning of the jetStamp graphic 970, always read the operating instructions and
in particular the safety notes with care. This prevents mistakes in handling of the marking
device and connected safety risks to keep you safe and avoid damage to the device.
Safety Notes
WARNING Possible blinding in case of contact between ink and eyes.
fNever hold the jetStamp graphic 970 with its nozzles pointing at the face of persons!
CAUTION Possible tripping and damage to the device from device lines placed freely in
the room.
fPlace the device lines so that they do not pose any danger source!
Health risks if ink is swallowed.
fDon’t swallow!
fKeep cartridge out of the reach of children!
NOTICE Damage to the device due to improper transport.
fOnly use packaging that provides protection from impact and shock to the device!
Damage to the device by moisture.
fBefore commissioning, wait until device has reached room temperature and is
completely dry!
Safety Notes on Rechargeable Batteries
Rechargeable batteries are subject to wear. A longer service life than six months cannot be
warranted.
WARNING Possible explosion at contact with fire.
fNever throw rechargeable batteries into fire.
CAUTION Injuries from destruction of rechargeable battery jacket when using unsuit-
able rechargeable batteries or non-rechargeable batteries.
fUse only rechargeable batteries intended for the device!
Disposal
Defective or flat batteries
Flat batteries of rechargeable batteries must not be disposed of in the household
waste.
Electrical and electronic waste devices
Waste devices must not be disposed of in the conventional household waste. They
must be returned to a special collection point for recycling of electrical and electro-
nic devices.

9
jetStamp graphic 970
1. Preparation and Taking into Operation
1.1. Commissioning
The rechargeable batteries must be charged completely before the first use.
The charging time is approx. 3 hours. The rechargeable batteries are charged when the
green charge display
8
goes out.
Inserting rechargeable batteries Fig. A
Always replace all rechargeable batteries at once. Date, time and counter reading of the
numbering machine are retained when the rechargeable batteries are removed.
fOpen battery compartment
2
.
fPlace the textile ribbon flat across the compartment.
The textile ribbon serves simpler removal of the rechargeable batteries.
fEnsure correct polarity and insert the rechargeable batteries.
fClose battery compartment
2
.
Charge batteries Fig. C
Only connect the device to the PC when the PCset graphic-Software was installed.
Installation of the PCset graphic software installs the required USB drivers. The USB
drivers are automatically recognised and loaded when the device is connected to the
computer. The device driver installation fails if the device is connected without the
PCset graphic software being installed.
Charging at a USB hub without dedicated power supply is not possible.
fConnect the Micro-USB socket of the device
9
to the mains unit with the USB cable and
connect the mains unit to the mains.
Green charging indicator
8
lights up.
1.2. Inserting Printing Cartridge
Inserting printing cartridge Fig. A+ B+ D
Depending on ink type used, dierent Protective Nozzle Seals are required.
Use sealing of the enclosed printing cartridge.
fPut the jetStamp graphic 970 in the base station
4
.
fTurn the setting wheel
7
to position 1.
fKeep the trigger button
1
pushed and take the device from the base station
4
.
Print carriage
3
moves to the middle position.
fRelease trigger button
1
.

10
jetStamp graphic 970
fGently push the lock of print cartridge
13
to the right, until the print cartridge flap
11
can be opened.
fOpen print cartridge flap
11
.
fTake new print cartridge
12
from the packaging and remove protective film from the
nozzles
15
.
fPut the jetStamp graphic 970 on a fixed flat surface.
fInsert printing cartridge
12
.
fClose the print cartridge flap
11
.
fPush the trigger button
1
. Print carriage
3
moves to the home position.
1.3. Install PCset graphic Software
Installation is only possible with administrator rights on the computer.
fInsert PCset graphic USB memory stick into the drive.
fIf the installation programme does not start up automatically, start the file “setup.exe”.
fObserve the installation programme instructions.
1.4. Firmware update
The most up to date firmware for the jetStamp graphic 970 can be downloaded from the
REINER website (www.reiner.de).
1.5. Recognising and Removing Interferences
For more information, see the online help of the PCset graphic software, or the enclosed USB
memory stick.
All rights reserved. Translation, reprint and other reproduction of these operating
instructions, even in parts and no matter the form, shall require our express written consent.
We reserve the right to make content changes to these operating instructions without notice.

Technical modifications reserved | PC-970088-000-G | 07.2019
