Features
• cULus Listed Residential Sprinklers
• Available in pendent and horizontal sidewall orientations
• Decorative finishes available, including recessed
escutcheons and conical concealed cover plates
Product Description
Model F1Res Series sprinklers are residential sprinklers with a
3 mm glass bulb operating element. A variety of K-Factors as
well as recessed and conical concealed options are available
as detailed in this Bulletin.
The F1Res Series sprinklers are specially engineered for fast
thermal response to meet the requirements of UL 1626. They
are intended for installation in accordance with NFPA 13, 13R,
and 13D.
Application
The Model F1Res Series sprinklers cULus Listed Residential
sprinklers are intended for use in accordance with NFPA
13, NFPA 13R, or NFPA 13D. The Model F1Res residential
sprinklers are cULus Listed for use in residential occupancies
and residential portions of any occupancy, where permitted
by NFPA 13, NFPA 13R, or NFPA 13D. For NFPA 13R and
NFPA 13D applications, the design flow and pressure shall
not be less than the minimum flow and pressure specified
www.reliablesprinkler.com
Residential Sprinkler Summary
Sprinkler
Model
Sprinkler
Identification
Number (SIN)
Orientation
K-Factor
gpm/psi1/2
(lpm/bar1/2)
Thread Size
NPT or ISO7-1 Installation Options Max. Coverage Area
ft x ft (m x m)
F1Res30 R3511 Pendent 3.0 (43) 1/2 Pendent or Recessed 16 x16 (4.9 x 4.9)
F1Res49 R3516 Pendent 4.9 (71) 1/2 Pendent or Recessed 20 x 20 (6.1 x 6.1)
F1Res58 R3513 Pendent 5.8 (84) 1/2 Pendent or Recessed 20 x 20 (6.1 x 6.1)
F1Res76 R7618 Pendent 7.6 (109) 3/4 Pendent or Recessed 20 x 20 (6.1 x 6.1)
F1Res30 CCP R3511 Pendent 3.0 (43) 1/2 Conical Concealed or
Recessed 14 x 14 (4.3 x 4.3)
F1Res49 CCP R3516 Pendent 4.9 (71) 1/2 Conical Concealed or
Recessed 20 x 20 (6.1 x 6.1)
F1Res58 CCP R3513 Pendent 5.8 (84) 1/2 Conical Concealed or
Recessed 20 x 20 (6.1 x 6.1)
F1Res76 CCP R7618 Pendent 7.6 (109) 3/4 Conical Concealed or
Recessed 20 x 20 (6.1 x 6.1)
F1Res44 HSW R3531 Horizontal Sidewall 4.4 (63) 1/2 Recessed 16 x 20 (4.9 x 6.1)
F1Res44 SWC R3531 Horizontal Sidewall 4.4 (63) 1/2 Conical Concealed 16 x 20 (4.9 x 6.1)
F1Res58 HSW R3533 Horizontal Sidewall 5.8 (84) 1/2 Recessed 16 x 20 (4.9 x 6.1)
F1Res 58
HSWX RA3533 Horizontal Sidewall 5.8 (84) 1/2 Recessed 14 x 26 (4.3 x 7.9)
Table A
in the Listed Design Criteria tables in this Bulletin. For NFPA
13 applications, the design density shall be a minimum
of 0.1 gpm/sf (4.1 mm/min), but in no case shall the flow
and pressure be less than the minimum flow and pressure
specified in the Listed Design Criteria tables in this bulletin.
Model F1Res Series sprinklers are listed for use in wet
systems only.
cULus Listed
Model F1Res Series Glass Bulb
Residential Sprinklers
Bulletin 135 February 2020

Model F1Res30 Residential Pendent Sprinkler Components and Installation Dimensions Figure 1
* Model FV escutcheons are not for use in positively pressurized ceiling plenums.
Technical Specifications
Style: Pendent and Recessed Pendent
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 3.0 (43 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F2 Recessed
FV Recessed*
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
Model F1Res30 Residential Pendent Sprinkler & Models F2 & FV Escutcheon SIN R3511
Bulletin 135
February 2020
Page 2 of 15
www.reliablesprinkler.com
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum
Coverage Area(2)
ft. x ft.(m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
12 x 12 (3.7 x 3.7) 8 (30) 7.0 (0.48)
1 to 4 inches
(25 to 100 mm)
14 x 14 (4.3 x 4.3) 10 (38) 11.0 (0.76)
15 x 15 (4.6 x 4.6) 12 (45) 16.0 (1.1)
16 x 16 (4.9 x 4.9) 13 (49) 18.8 (1.3)
Table B
Model F1Res30 Residential Pendent Sprinkler Hydraulic Design Criteria
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res49 Residential Pendent Sprinkler Components and Installation Dimensions Figure 2
Model F1Res49 Residential Sprinkler & Models F1, F2, & FV Escutcheons SIN R3516
Technical Specifications
Style: Pendent and Recessed Pendent
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 4.9 (71 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass-bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F1 Recessed
F2 Recessed
FV Recessed*
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
Bulletin 135
February 2020
Page 3 of 15
www.reliablesprinkler.com
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
12 x 12 (3.7 x 3.7) 13 (49) 7.0 (0.48)
1 to 4 inches
(25 to 100 mm)
14 x 14 (4.3 x 4.3) 13 (49) 7.0 (0.48)
16 x 16 (4.9 x 4.9) 13 (49) 7.0 (0.48)
18 x 18 (5.5 x 5.5) 17 (64) 12.0 (0.83)
20 x 20 (6.1 x 6.1) 20 (76) 16.7 (1.15)
12 x 12 (3.7 x 3.7) 15 (57) 9.4 (0.65)
4 to 8 inches
(100 to 200 mm)
14 x 14 (4.3 x 4.3) 16 (61) 10.7 (0.74)
16 x 16 (4.9 x 4.9) 17 (64) 12.0 (0.83)
18 x 18 (5.5 x 5.5) 19 (72) 15.0 (1.03)
20 x 20 (6.1 x 6.1) 22 (83) 20.2 (1.39)
Model F1Res49 Residential Pendent Sprinkler Hydraulic Design Criteria Table C
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
* Model FV escutcheons are not for use in positively pressurized ceiling plenums.

Model F1Res58 Residential Pendent Sprinkler & F1, F2, & FV Recessed Escutcheons SIN R3513
Technical Specifications
Style: Pendent and Recessed Pendent
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 5.8 (84 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F1 Recessed
F2 Recessed
FV Recessed*
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
* Model FV escutcheons are not for use in positively pressurized ceiling plenums.
Model F1Res58 Residential Pendent Sprinkler Components and Installation Dimensions Figure 3
Bulletin 135
February 2020
Page 4 of 15
www.reliablesprinkler.com
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
16 x 16 (4.9 x 4.9) 16 (61) 7.6 (0.52)
1 to 4 inches
(25 to 100 mm)
18 x 18 (5.5 x 5.5) 19 (72) 10.8 (0.75)
20 x 20 (6.1 x 6.1) 22 (83) 14.4 (1.0)
Model F1Res58 Residential Pendent Sprinkler Hydraulic Design Criteria Table D
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res76 Residential Pendent Sprinkler & F1, F2, & FV Escutcheons SIN R7618
Technical Specifications
Style: Pendent and Recessed Pendent
Threads: 3/4” NPT or ISO7-1R3/4
Nominal K-Factor: 7.6 (109 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F1 Recessed
F2 Recessed
FV Recessed*
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
Model F1Res76 Residential Pendent Sprinkler Components and Installation Dimensions Figure 4
* Model FV escutcheons are not for use in positively pressurized ceiling plenums.
Bulletin 135
February 2020
Page 5 of 15
www.reliablesprinkler.com
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
18 x 18 (5.5 x 5.5) 21 (80) 7.6 (0.52)
1 to 4 inches
(25 to 100 mm)
20 x 20 (6.1 x 6.1) 23 (87) 9.2 (0.63)
Model F1Res76 Residential Pendent Sprinkler Hydraulic Design Criteria Table E
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.

Model F1Res30 CCP Conical Concealed Pendent & Model FP Recessed Escutcheon Pendent
Sprinkler SIN R3511
Technical Specifications
Style: Conical Concealed Pendent and
Recessed Pendent
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 3.0 (43 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
Recessed Escutcheons/Cover Plates
CCP Conical Concealed Plate 135°F (57°C)*
FP Recessed*
Sprinkler Wrenches
Model W4
Model F1Res30 CCP and FP Recessed Pendent Sprinkler Installation Dimensions Figure 5
*Note: Model FP escutcheons and CCP cover plates are not listed for use in positively pressurized ceiling plenums.
Bulletin 135
February 2020
Page 6 of 15
www.reliablesprinkler.com
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar) Deflector to Ceiling Distance
12 x 12 (3.7 x 3.7) 8 (30) 7.0 (0.48) 1/2 to 1 inch
(13 to 25 mm)
14 x 14 (4.3 x 4.3) 11 (38) 13.4 (0.92)
Model F1Res30 CCP Pendent & FP Recessed Pendent Sprinkler Hydraulic Design Criteria Table F
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
3. The sprinkler must be installed into a ceiling with the listed cover plate installed.

Model F1Res49 CCP Conical Concealed Pendent & Model FP Recessed Escutcheon Pendent Sprinkler SIN R3516
Technical Specifications
Style: Conical Concealed Pendent and
Recessed Pendent
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 4.9 (71 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
Recessed Escutcheons/Cover Plates
CCP Conical Concealed Plate 135°F (57°C)*
FP Recessed*
Sprinkler Wrenches
Model W4
Model F1Res49 CCP & FP Recessed Pendent Sprinkler Installation Dimensions Figure 6
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar) Deflector to Ceiling Distance
14 x 14 (4.3 x 4.3) 13 (49) 7.0 (0.48)
1/2 to 1 inch
(13 to 25 mm)
16 x 16 (4.9 x 4.9) 14 (53) 8.2 (0.57)
18 x 18 (5.5 x 5.5) 18 (68) 13.5 (0.93)
20 x 20 (6.1 x 6.1) 20 (76) 16.7 (1.15)
Model F1Res49 CCP Pendent and FP Recessed Pendent Hydraulic Design Criteria Table G
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
3. The sprinkler must be installed into a ceiling with the listed cover plate installed.
*Note: Model FP escutcheons and CCP cover plates are not for use in positively pressurized ceiling plenums.
Bulletin 135
February 2020
Page 7 of 15
www.reliablesprinkler.com

Model F1Res58 CCP Conical Concealed Pendent & Model FP Recessed Escutcheon Pendent Sprinkler SIN R3513
Technical Specifications
Style: Conical Concealed Pendent and
Recessed Pendent
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 5.8 (84 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
Recessed Escutcheons/Cover Plates
CCP Conical Concealed Plate 135°F (57°C)*
FP Recessed*
Sprinkler Wrenches
Model W4
Figure 7
Model F1Res58 CCP and FP Recessed Pendent Sprinkler Installation Dimensions
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow gpm
(l/min)
Pressure psi
(bar) Deflector to Ceiling
Distance
16 x 16 (4.9 x 4.9) 16 (61) 7.6 (0.52)
1/2 to 1 inch
(13 to 25 mm)
18 x 18 (5.5 x 5.5) 19 (72) 10.8 (0.75)
20 x 20 (6.1 x 6.1) 22 (83) 14.4 (1.0)
Model F1Res58 CCP Pendent & FP Recessed Pendent Hydraulic Design Criteria Table H
*Note: Model FP escutcheons and CCP cover plates are not for use in positively pressurized ceiling plenums.
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
3. The sprinkler must be installed into a ceiling with the listed cover plate installed.
Bulletin 135
February 2020
Page 8 of 15
www.reliablesprinkler.com

Figure 8
Model F1Res76 CCP and FP Recessed Pendent Sprinkler Installation Dimensions
Model F1Res76 CCP Conical Concealed Pendent and Model FP Recessed Escutcheon Pendent Sprinkler SIN R7618
Technical Specifications
Style: Conical Concealed Pendent and
Recessed Pendent
Threads: 3/4” NPT or ISO7-1R3/4
Nominal K-Factor: 7.6 (109 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
Recessed Escutcheons/Cover Plates
CCP Conical Concealed Plate 135°F (57°C)*
FP Recessed*
Sprinkler Wrenches
Model W4
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar) Deflector to Ceiling Distance
16 x 16 (4.9 x 4.9) 21 (80) 7.6 (0.52)
1/2 to 1 inch
(13 to 25 mm)
18 x 18 (5.5 x 5.5) 22 (83) 8.4 (0.58)
20 x 20 (6.1 x 6.1) 25 (95) 10.8 (0.75)
Model F1Res76 CCP Pendent & FP Recessed Pendent Hydraulic Design Criteria Table I
*Note: Model FP escutcheons and CCP cover plates are not for use in positively pressurized ceiling plenums.
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
3. The sprinkler must be installed into a ceiling with the listed cover plate installed.
Bulletin 135
February 2020
Page 9 of 15
www.reliablesprinkler.com

Model F1Res44 Horizontal Sidewall Sprinkler & Models FV & F2 Recessed Escutcheon SIN R3531
Technical Specifications
Style: Sidewall and Recessed Sidewall
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 4.4 (63 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F2 Recessed
FV Recessed
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
12 x 12 (3.7 x 3.7) 12 (45) 7.5 (0.52)
4 to 6 inches
(100 to 150 mm)
14 x 14 (4.3 x 4.3) 14 (53) 10.2 (0.70)
15 x 15 (4.6 x 4.6) 15 (57) 11.6 (0.80)
16 x 16 (4.9 x 4.9) 16 (61) 13.3 (0.92)
16 x 18 (4.9 x 5.5) 18 (68) 16.8 (1.16)
16 x 20 (4.9 x 6.1) 23 (87) 27.4 (1.89)
18 x 18 (5.5 x 5.5) 19 (72) 18.7 (1.29)
12 x 12 (3.7 x 3.7) 14 (53) 10.2 (0.7)
6 to 12 inches
(150 to 300 mm)
14 x 14 (4.3 x 4.3) 16 (61) 13.2 (0.91)
15 x 15 (4.6 x 4.6) 16 (61) 13.2 (0.91)
16 x 16 (4.9 x 4.9) 17 (64) 15.0 (1.03)
16 x 18 (4.9 x 5.5) 20 (76) 20.7 (1.43)
16 x 20 (4.9 x 6.1) 23 (87) 27.4 (1.89)
Model F1Res44 Horizontal Sidewall Sprinkler Hydraulic Design Criteria Table J
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
Model F1Res44 Horizontal Sidewall Sprinkler Installation Dimensions Figure 9
Bulletin 135
February 2020
Page 10 of 15
www.reliablesprinkler.com

Note:
(1) Not for installation where the maximum ceiling temperature exceeds 100°F due to cover plate temperature rating.
(2) 135°F SWC Conical Concealed Plate for 155°F (68°C) sprinklers
(3) 135°F SWC-2 (Slotted) Conical Concealed Plate for 175°F (79°C) sprinklers
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Ordinary Temperature Rating
155°F (68°C)
Intermediate Temperature Rating
175°F (79°C) Deflector to Ceiling
Distance
Flow
gpm (l/min)
Pressure
psi (bar)
Flow
gpm (l/min)
Pressure
psi (bar)
12 x 12 (3.7 x 3.7) 13 (49) 8.7 (0.60) 14 (53) 10.2 (0.7)
4 to 6 inches
(100 to 150 mm)
14 x 14 (4.3 x 4.3) 14 (53) 10.2 (0.7) 14 (53) 10.2 (0.7)
15 x 15 (4.6 x 4.6) 16 (61) 13.2 (0.91) – – – –
16 x 16 (4.9 x 4.9) 17 (64) 15.0 (1.03) – – – –
16 x 18 (5.5 x 5.5) 19 (72) 18.7 (1.31) – – – –
16 x 20 (4.9 x 6.1) 23 (87) 27.4 (1.89) – – – –
12 x 12 (3.7 x 3.7) 14 (53) 10.2 (0.7) – – – –
6 to 12 inches
(150 to 300 mm)
14 x 14 (4.3 x 4.3) 15 (57) 11.7 (0.81) – – – –
15 x 15 (4.6 x 4.6) 17 (64) 15.0 (1.03) – – – –
16 x 16 (4.9 x 4.9) 18 (68) 16.8 (1.16) – – – –
16 x 18 (4.9 x 5.5) 20 (76) 20.7 (1.43) – – – –
Model F1Res44 SWC Conical Concealed Horizontal Sidewall Sprinkler Hydraulic Design Criteria Table K
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
SWC
SWC-2
Bulletin 135
February 2020
Page 11 of 15
www.reliablesprinkler.com
Model F1Res44 SWC Conical Concealed Horizontal Sidewall Sprinkler SIN R3531
Technical Specifications
Style: Conical Concealed Sidewall
Threads: 1/2” NPT or ISO 7-1 R1/2
Nominal K-Factor: 4.4 (63 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass-bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C) (1)
Cover Plates
SWC Conical Concealed Plate(2)
SWC-2 (Slotted) Conical Concealed Plate(3)
Sprinkler Wrenches
Model W4
Model F1Res44 SWC Conical Concealed Horizontal Sidewall Sprinkler and Installation Dimensions Figure 10

Model F1Res58 Horizontal Sidewall Sprinkler & Models F2 & FV Recessed Escutcheon SIN R3533
Technical Specifications
Style: Sidewall and Recessed Sidewall
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 5.8 (84 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F2 Recessed
FV Recessed
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
12 x 12 (3.7 x 3.7) 16 (61) 7.6 (0.52)
4 to 6 inches
(100 to 150 mm)
14 x 14 (4.3 x 4.3) 18 (68) 9.7 (0.66)
15 x 15 (4.6 x 4.6) 19 (72) 10.7 (0.74)
16 x 16 (4.9 x 4.9) 21 (80) 13.2 (0.91)
16 x 18 (5.5 x 5.5) 25 (95) 18.6 (1.28)
16 x 20 (4.9 x 6.1) 29 (110) 25.0 (1.72)
12 x 12 (3.7 x 3.7) 22 (83) 14.4 (1.0)
6 to 12 inches
(150 to 300 mm)
14 x 14 (4.3 x 4.3) 22 (83) 14.4 (1.0)
15 x 15 (4.6 x 4.6) 24 (91) 17.1 (1.18)
16 x 16 (4.9 x 4.9) 26 (98) 20.1 (1.39)
16 x 18 (4.9 x 5.5) 31 (117) 28.6 (1.97)
Model F1Res58 Horizontal Sidewall Sprinkler Hydraulic Design Criteria Table L
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
Model F1Res58 Residential Horizontal Sidewall Sprinkler Installation Dimensions Figure 11
Bulletin 135
February 2020
Page 12 of 15
www.reliablesprinkler.com

Model F1Res58 HSWX Horizontal Sidewall Sprinkler & Models F2 & FV Recessed
Escutcheon SIN RA3533
Technical Specifications
Style: Sidewall and Recessed Sidewall
Threads: 1/2” NPT or ISO7-1R1/2
Nominal K-Factor: 5.8 (84 metric)
Max. Working Pressure: 175 psi (12 bar)
Material Specifications
Thermal Sensor: 3 mm glass bulb
Sprinkler Frame: Brass Alloy
Button: Copper Alloy
Sealing Assembly: Nickel Alloy with PTFE
Load Screw: Bronze Alloy
Deflector: Bronze Alloy
Finishes
(See Table N)
Sensitivity
Fast-response
Temperature Ratings
155°F (68°C)
175°F (79°C)
Recessed Escutcheons
F2 Recessed
FV Recessed
Sprinkler Wrenches
Model W2
Model W4 (Recessed)
Minimum Flow and Residual Pressure in Wet Pipe Systems(1)
Maximum Coverage Area(2)
ft. x ft. (m x m)
Flow
gpm (l/min)
Pressure
psi (bar)
Deflector to
Ceiling Distance
18 x 20 (5.5 x 6.1) 30 (114) 26.8 (1.85)
4 to 6 inches
(100 to 150 mm)
20 x 20 (6.1 x 6.1) 30 (114) 26.8 (1.85)
16 x 22 (4.9 x 6.7) 33 (125) 32.4 (2.23)
16 x 24 (4.9 x 7.3) 38 (144) 42.9 (2.96)
14 x 26 (4.3 x 7.9) 42 (160) 52.4 (3.63)
18 x 20 (5.5 x 6.1) 35 (133) 36.4 (2.51)
6 to 12 inches
(150 to 300 mm)
16 x 22 (4.9 x 6.7) 38 (144) 42.9 (2.96)
16 x 24 (4.9 x 7.3) 42 (160) 52.4 (3.61)
14 x 26 (4.3 x 7.9) 46 (174) 62.9 (4.34)
Model F1Res58 HSWX Horizontal Sidewall Sprinkler Hydraulic Design Criteria Table M
Notes:
1. For NFPA 13 installations the flow per sprinkler must be the greater of: (1) the flow listed in the table above or (2) the flow required to
achieve a minimum design density of 0.1 gpm/sq ft over the design area of the sprinkler.
2. For coverage area dimensions less than those listed above, use the minimum required flow for the next larger max. coverage area listed.
Model F1Res58 HSWX Residential Horizontal Sidewall Sprinkler Installation Dimensions Figure 12
Bulletin 135
February 2020
Page 13 of 15
www.reliablesprinkler.com

Model W4
Model W2
Installation
Models F1Res sprinklers are to be installed as shown in this
bulletin. Model F1, F2, FV, and FP recessed escutcheons are
the only recessed escutcheons to be used with Model F1Res
sprinklers. Not all F1Res sprinklers may be used with all
recessed escutcheons offered. Confirm listing of escutcheon
type for use with individual sprinklers. Use of any other
recessed escutcheon will void all approvals and warranties.
For installing Model F1Res sprinklers, use only the Model
W2 sprinkler Wrench; for installing Models F1Res Recessed
Pendent, Sidewall, Conical Concealed Pendent (CCP), and
Sidewall Concealed (SWC and SWC–2) sprinklers use only the
Model W4 sprinkler wrench. Use of wrenches other than those
specified may damage these sprinklers.
Installation of F1Res sprinklers in a wall or ceiling will require
a hole diameter of 2-1/4” (57 mm) for F1 or F2 recessed
escutcheons; or 2-5/8” (67 mm) for FP recessed escutcheons,
CCP, SWC, and SWC–2 cover plates.
Install F1Res HSW sprinklers with a ceiling to deflector
distance that complies with the hydraulic design criteria tables
in this bulletin. The flow arrow on deflector must point away
from near wall and “Top” marking must face the ceiling.
A ‘leak tight” sprinkler joint can be obtained with the following
torque:
• 1/2” NPT and ISO7-1R1/2: 8-18 ft-lbs (11 – 24 N-m)
• 3/4” NPT and ISO7-1R3/4: 14-20 ft-lbs (19 – 27 N-m)
Do not tighten sprinklers over maximum recommended torque.
This may cause leakage or impairment of the sprinklers.
Do not install any glass bulb sprinklers where the bulb is
cracked or there is a loss of liquid from the bulb.
Glass bulb sprinklers have orange bulb protectors to minimize
bulb damage during shipping, handling and installation.
Remove this protection at the time the sprinkler system is
placed in service. Removal of the protectors before this time
may leave the bulb vulnerable to damage. RASCO wrenches
are designed to install sprinklers when protectors are in place.
Remove protectors by undoing the clasp by hand. Do not use
tools to remove the protectors.
Table N
Standard Finishes Special Application Finishes
Sprinkler(1) F1, F2. FV, FP(3),
Escutcheons
CCP, SWC (Conical)
Cover Plates (1) Sprinkler (1) F1, F2. FV, FP(3), Escutcheons
CCP, SWC (Conical)
Cover Plates (1)
Bronze Brass -- Bright Brass Bright Brass Bright Brass
Chrome Plated Chrome Plated Chrome Plated Dull Chrome Dull Chrome Dull Chrome
White
Polyester (2)
White
Polyester White Paint Black Polyester (2)
Black
Polyester Black Paint
-- -- -- Custom Color
Polyester
Custom Color
Polyester Custom Color Paint
-- -- -- Electroless Nickel
PTFE (2) -- --
Notes:
(1) Paint or any other coating applied over the factory finish will void all approvals and warranties.
(2) cULus Listed Corrosion Resistant.
(3) The Model FP escutcheon assembly consists of an unfinished galvanized cup with a finished escutcheon ring.
Finishes
The Model W4 wrench includes two sets of jaws. One set of
jaws is equivalent to a Model GFR2 wrench and the other set
of jaws is equivalent to a Model W1 wrench. Use the smallest
of the two sets of jaws that will fit on the sprinkler’s wrench
flats. The Model W4 wrench is used in conjunction with the
installer’s nominal 1/2” square drive ratchet and nominal 5”
(125mm) long extension (not provided) as shown in Figure 13.
Model W4 Wrench Installation Example Figure 13
Bulletin 135
February 2020
Page 14 of 15
www.reliablesprinkler.com

P/N 9999970235
Maintenance
Reliable Model F1Res Sprinklers should be inspected and the
sprinkler system maintained in accordance with NFPA 25, 13,
13D, and 13R, as well as the requirements of any Authorities
Having Jurisdiction.
Prior to installation, sprinklers should remain in the original
cartons and packaging until used. This will minimize the
potential for damage to sprinklers that could cause improper
operation or non-operation.
Do not clean sprinklers with soap and water, ammonia
liquid or any other cleaning fluids. Remove dust by gentle
vacuuming without touching the sprinkler.
Replace any sprinkler which has been painted (other than
factory applied). Properly installed CCP, SWC, and SWC–2
cover plates will have an air gap that is required for proper
operation, do not seal the gap or paint the cover plates.
Replace any sprinkler which has been damaged, where
cracks are observed in the glass bulb, or when liquid has
been lost from the glass bulb.
A stock of spare sprinklers should be maintained to allow
quick replacement of damaged or operated sprinklers.
Failure to properly maintain sprinklers may result in inadvertent
operation or non-operation during a fire event.
Listings & Approvals
Listed by Underwriters Laboratories Inc. and UL Certified for
Canada (cULus)
Guarantee
For Reliable Automatic Sprinkler Company guarantee, terms,
and conditions, visit www.reliablesprinkler.com.
Patents
For patents applicable to products contained in this technical
bulletin, please visit www.r-s.co
Ordering Information
Specify the following when ordering:
Sprinkler
• Model (See Table A)
• Temperature Rating
• Threads (NPT or ISO7-1)
• Finish (See Table N)
Escutcheon or Cover Plate
• Model
• Finish (See Table N)
Sprinkler Wrench
• Model W2 (Pendent and HSW)
• W4 (Recessed and Concealed)
Bulletin 135
February 2020
Page 15 of 15
www.reliablesprinkler.com
