RiverRidge 06-025 User manual

ASSEMBLY INSTRUCTIONS
RiverRidge® ELLSWORTH SINGLE DOOR
FLOOR CABINET W/SIDE SHELVES
ITEM #: 06-025 WHITE
ITEM #: 06-026 ESPRESSO
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don’t
use this item for a TV stand or place heavy objects on top of item.
Always use angle-braces or anchors to secure furniture to the wall.

Send requests for missing or damaged parts replacements by email to:
customer.serv[email protected]m or call toll free 1-(844)-223-5201 or order parts on line at
www.riverridgehome.com
THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75 POUNDS.DO
NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS. OVERLOADING WITH MORE THAN25
POUNDS PER SHELF OR 75 POUNDS TOTAL WEIGHT MAY CAUSE DAMAGE TO THE SHELF
AND MAY CAUSESERIOUS INJURY OR DEATH.

PARTS LIST
1
1PC
TOP BOARD
2
1PC
BOTTOM BOARD
3
2PCS
ARCH SHELF
4
1PC
REAR SUPPORT BOARD
5
1PC
CENTER SUPPORT PANEL
6
1PC
RIGHT SIDE PANEL
7
1PC
DOOR
8
1PC
SHELF
9
1PC
BACK BOARD
10
4PCS
LEG
11
1PC
TOP CROSS BAR
A
12PCS
CAM BOLT
B
12PCS
CAM LOCK
C
20PCS
WOOD DOWEL
D
1PC
KNOB

E
1PC
MACHINE SCREW 4x20mm
F
4PCS
PLASTIC HOLDER
G
2PCS
METAL PIN
H
1PC
MAGNET
J
1PC
MAGNET PLATE
K
1PC
SCREW 3x10mm
M
2PCS
WOOD SCREW 3x14mm
N
16PCS
LONG SCREW 4x20mm
P
2PCS
ANCHOR SCREW 4x40mm
Q
2PCS
PLASTIC ANCHOR
TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOTINCLUDED)
THE USE OF POWER SCREWDRIVER IS NOTRECOMMENDED

STEP 1
STEP 1
1. Insert 3 wood dowels (C) into dowel holes on top board (1).
2. Screw 6 cam bolts (A) into pre-threaded holes on top board (1).
STEP 2
STEP 2
1. Insert 3 wood dowels (C) into dowel holes on bottom board (2).
2. Screw 6 cam bolts (A) into pre-threaded holes on bottom board (2).

STEP 3
STEP 3
1. Insert 4 wood dowels (C) into dowel holes on arch shelf (3).
2. Repeat above step for other arch shelf (3).
STEP 4
STEP 4
1. Insert 2 wood dowels (C) into dowel holes on edge of rear support board (4).

STEP 5
STEP 5
1. Attach magnet (H) to center support panel (5).
2. Insert 2 screws (M) through holes on magnet (H) and tighten to center support panel
(5).
STEP 6
STEP 6
1. Insert 1 screw (K) through hole on magnet plate (J) and tighten to door (7).
2. Attach knob (D) to door (7) by inserting 1 machine screw (E) through hole on door (7) and
tighten to knob (D).
3. Insert 2 pins (G) into holes on each end of door (7).

STEP 7
STEP 7
1. Overturn bottom board (2) and attach one leg (10) to bottom board (2) by inserting 4
screws (N) through holes on leg (10) and tighten to bottom board (2).
2. Repeat above step to assemble other 3 legs.
STEP 8
STEP 8
1. Attach arch shelves (3) to rear support board (4) by inserting wood dowels into dowel
holes on rear support board (4).

STEP 9
STEP 9
1. Attach center support panel (5) to rear support board (4) and arch shelves (3) by
inserting wood dowels into holes on center support panel (5).
2. Insert 4 wood dowel (C) into holes on end of top cross bar (11).
3. Attached top cross bar to center support panel (5) by inserting wood dowel (C) into holes
on center support panel (5).
STEP 10
STEP 10
1. Attach rear support board (4), center support panel (5) and right side panel (6) to bottom
board (2) by inserting cam bolts into cam lock holes and inserting wood dowels into dowel
holes on rear support board (4), center support panel (5) and right side panel (6).
2. Insert wood dowel (C) on top cross bar (11) into holes on right side panel (6).
3. Insert 6 cam locks (B) into cam lock holes on rear support board (4), center support panel
(5) and right side panel (6) and rotate clockwise to secure cam bolts (A).

STEP 11
STEP 11
1. Slide in back board (9) to the grooves on center support panel (5), right side panel (6) and
bottom board (2).
STEP 12
STEP 12
1. Attach door (7) to assembled unit by inserting pin (G) into hole on bottom board (2).

STEP 13
STEP 13
1. Attach top board (1) to pre-assembled cabinet by inserting cam bolts into cam lock holes,
wood dowels into dowel holes and pin into holes on rear support board (4), center
support panel (5), right side panel (6) and door (7).
2. Insert 6 cam locks (B) into cam lock holes on rear support board (4), center support panel
(5) and right side panel (6) and rotate clockwise to secure cam bolts.
STEP 14
STEP 14
1. Insert 4 plastic holders (F) into holes on positions that you desire for the shelf and put
shelf (8) onto 4 holders (F).
2. Place drawing with hole positions on wall you desire to fix cabinet and drill 2 holes
through hole positions on drawing.
3. Insert 2 plastic anchors (Q) into holes on wall and attach cabinet in place by inserting 2
anchor screws (P) through holes on back top cross bar (11) and tighten cabinet to wall.

ENJOY YOUR NEW RiverRidge® CABINET NOW!
Attention Adults: Cabinet should be checked periodically for damage or loose screws/parts. Take
appropriate action necessary to correct hazards such as tightening of screws and taking any
damaged parts away from children.
Warning Please make sure your item is secured to the wall, per
assembly instructions.
Thank you for purchasing this RiverRidge® Home Products item. We hope you enjoy it and
consider purchasing other RiverRidge®items.
Send requests for missing or damaged parts replacements by email to:
customer.serv[email protected] or call toll free 1-(844)-223-5201 or order parts on line at
www.riverridgehome.com
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI54016.

INSTRUCCIONES DE ENSAMBLAJE
GABINETE DE PISO DE UNA PUERTA CON REPISAS LATERALES
ELLSWORTH RiverRidge®
ARTÍCULO N.°: 06-025 BLANCO
ARTÍCULO N.°: 06-026 CAFÉ ESPRESSO
REQUIERE QUE UN ADULTO REALICE EL ENSAMBLAJE
Este producto requiere que un adulto lleve a cabo el ensamblaje debido a las piezas pequeñas.
Debe tener cuidado al desempacar y ensamblar este artículo para mantener las piezas pequeñas
alejadas de los niños.
ADVERTENCIA VEA LA ADVERTENCIA COMPLETA
EN LA PÁGINA 2
Los niños pequeños pueden resultar gravemente heridos o muertos si el mueble
vuelca. No utilice este artículo como soporte para el televisor ni coloque objetos
pesado sobre él.
Siempre utilice abrazaderas de ángulo o anclajes para fijar el mueble a la pared.

Envíe las solicitudes de reemplazos de piezas faltantes o dañadas por correo electrónico a:
[e-mail] o llame sin costo al 1-(844)-223-5201 o bien pida las piezas en
línea en www.riverridgehome.com
ESTA UNIDAD DE REPISAS PUEDE GUARDAR HASTA 25 LIBRAS POR REPISA O UN TOTAL DE
75 LIBRAS. NO CARGUE CADA REPISA CON MÁS DE 25 LIBRAS. LA SOBRECARGA CON MÁS
DE 25 LIBRAS POR REPISA O 75 LIBRAS DE PESO TOTAL PUEDE OCASIONAR DAÑO EN LA
REPISA Y LESIONES GRAVES O LA MUERTE.

LISTA DE PIEZAS
1
1 PIEZA
TABLERO SUPERIOR
2
1 PIEZA
TABLERO INFERIOR
3
2 PIEZAS
REPISA DE ARCO
4
1 PIEZA
TABLERO DE SOPORTE
TRASERO
5
1 PIEZA
PANEL DE SOPORTE CENTRAL
6
1 PIEZA
PANEL DERECHO
7
1 PIEZA
PUERTA
8
1 PIEZA
REPISA
9
1 PIEZA
TABLERO TRASERO
10
4 PIEZAS
PATA
11
1 PIEZA
BARRA TRANSVERSAL
SUPERIOR
A
12 PIEZAS
PERNO DE ANCLAJE
B
12 PIEZAS
PESTILLO DE LEVA
C
20 PIEZAS
PASADOR DE MADERA
D
1 PIEZA
PERILLA

E
1 PIEZA
TORNILLO PARA METALES
4 x 20 mm
F
4 PIEZAS
RETENEDOR PLÁSTICO
G
2 PIEZAS
PASADOR DE METAL
H
1 PIEZA
IMÁN
J
1 PIEZA
PLACA DE IMÁN
K
1 PIEZA
TORNILLO 3x10mm
M
2 PIEZAS
TORNILLO DE MADERA
3x14mm
N
16 PIEZAS
TORNILLO LARGO 4x20mm
P
2 PIEZAS
TORNILLO DE ANCLAJE
4x40mm
Q
2 PIEZAS
ANCLAJE PLÁSTICO
HERRAMIENTAS NECESARIAS PARA EL ENSAMBLAJE: DESTORNILLADOR PLANO Y
PHILLIPS (NO INCLUIDO) NO SE RECOMIENDA EL USO DE UN DESTORNILLADOR
ELÉCTRICO

PASO 1
PASO 1
1. Inserte los 3 pasadores de madera (C) en los agujeros para los pasadores del tablero
superior (1).
2. Atornille los 6 pernos de anclaje (A) en los agujeros previamente roscados del tablero
superior (1).
PASO 2
PASO 2
1. Inserte los 3 pasadores de madera (C) en los agujeros para los pasadores del tablero
inferior (2).
2. Atornille los 6 pernos de anclaje (A) en los agujeros previamente roscados del tablero
inferior (2).

PASO 3
PASO 3
1. Inserte 4 pasadores de madera (C) en los agujeros para los pasadores de la repisa
de arco (3).
2. Repita el paso anterior para la otra repisa de arco (3).
PASO 4
PASO 4
1. Inserte los 2 pasadores de madera (C) en los agujeros para los pasadores del borde del
tablero de soporte trasero (4).

PASO 5
PASO 5
1. Fije el imán (H) al panel de soporte central (5).
2. Inserte 2 tornillos (M) a través de los agujeros en el imán (H) y apriételos contra el panel de
soporte central (5).
PASO 6
PASO 6
1. Inserte 1 tornillo (K) a través del agujero de la placa de imán (J) y apriete a la puerta (7).
2. Fije la perilla (D) a la puerta (7) al insertar 1 tornillo para metales (E) a través del agujero en la
puerta (7) y apriete la perilla (D).
3. Inserte 2 pasadores (G) en los agujeros de cada extremo de la puerta (7).

PASO 7
PASO 7
1. Dele vuelta al tablero inferior (2) y fije una pata (10) al tablero inferior (2) al insertar
4 tornillos (N) a través de los agujeros de la pata (10) y apriete al tablero inferior (2).
2. Repita el paso anterior para ensamblar las otras 3 patas.
PASO 8
PASO 8
1. Fije las repisas de arco (3) al tablero de soporte trasero (4) al insertar los pasadores de
madera en los agujeros para los pasadores en el tablero de soporte trasero (4).
