RiverRidge Somerset Spacesaver Quick start guide

ASSEMBLY INSTRUCTIONS
RiverRidge® Somerset Spacesaver
ITEM #: 06-040 White
ITEM #: 06-079 Gray
ADULT ASSEMBLY REQUIRED
This product requires assembly by an adult because of small parts. Care should be taken
in unpacking and assembling this item to keep small parts away from children. During assembly
children should be kept away from the product due to possible risk of injury.
WARNING SEE FULL WARNING ON PAGE 2
Young children can be seriously injured or killed if furniture tips over. Don’t use
this item for a TV stand or place heavy objects on top of item. Always use
angle-braces or anchors to secure furniture to the wall.

THIS SHELF UNIT WILL HOLD UP TO 25 POUNDS PER SHELF OR A TOTAL OF 75
POUNDS. DO NOT LOAD EACH SHELF WITH MORE THAN 25 POUNDS OR 75 POUNDS
TOTAL WEIGHT. IF OVERLOADED WITH MORE THAN 25 POUNDS PER SHELF OR 75
POUNDS TOTAL WEIGHT, SHELF MAY TIP FROM WALL AND CAUSE SERIOUS INJURY OR
DEATH.

PARTS LIST
NO
QTY
DESCRIPTION
1
1PC
Left Door
2
1PC
Right Door
3
1PC
Upper Right Side Panel
4
1PC
Upper Left Side Panel
6
1PC
Shelf
7
1PC
Top Board
8
1PC
Middle Connection Board
9
1PC
Upper Back Board
10
1PC
Middle Back Board
11
1PC
Lower Back Board
12
1PC
Adjustable Shelf
13
1PC
Right Support Board
14
1PC
Left Support Board
15
2PCS
Lower Section Top Cross Bar
16
1PC
Rear Lower Cross Bar
17
1PC
Lower Left Side Panel
18
1PC
Lower Right Side Panel

NO
PARTS
QTY
DESCRIPTION
A
16PCS
Wood Dowel
B
22PCS
Cam Bolt
C
22PCS
Cam Lock
D
18PCS
Screw (3x12mm)
E
4PCS
Hinge
F
2PCS
Magnet Plate
G
24PCS
Screw (2.5x12mm)
H
1 SET
Magnet With 2 Screws
I
4PCS
Shelf Holder
J
4PCS
Machine Screw (4x12mm)
K
2PCS
Handle
L
2PCS
Plastic Anchor
M
2PCS
Screw (4x30mm)
N
1PC
Plastic Connection Strip
O
4PCS
Screw (3.5x20mm)
P
2PCS
Adjustable Anchor Bracket
Q
2PCS
Screw (4x14mm)
TOOLS NEEDED FOR ASSEMBLY: FLAT & PHILLIPS SCREWDRIVER (NOT INCLUDED)
THE USE OF A POWER SCREWDRIVER IS NOT RECOMMENDED FOR ASSEMBLY
DO NOT USE ITEM IF ANY PARTS ARE MISSING OR DAMAGED
To order replacement parts at no cost to you, email [e-mail], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.

STEP 1
1. Attach 1 magnet plate (F) to left door (1) by inserting 1 screw (D) through hole on magnet
plate (F), then tighten to left door (1).
2. Attach 1 handle (K) to left door (1) by inserting 2 machine screws (J) through holes on left
door (1), then tighten to handle (K).
3. Repeat above steps to assemble another magnet plate (F) and handle (K) to right door (2).
STEP 2
1. Insert 2 wood dowels (A) into dowel holes on right support board (13) .
2. Screw 3 cam bolts (B) into cam bolt holes on right support board (13).
3. Attach 2 hinges (E) to right support board (13) by inserting 4 screws (D) through holes on
hinges (E), then tighten to right support board (13).
4. Repeat above steps to assemble left support board (14) and another 2 hinges (E).

STEP 3
1. Attach right support board (13) to upper right side panel (3) by inserting wood dowels
(A) into dowel holes and inserting cam bolts (B) into cam lock holes on upper right side
panel (3).
2. Insert 3 cam locks (C) into cam lock holes on upper right side panel (3), then rotate
clockwise to secure cam bolts (B) in place.
3. Repeat above steps to assemble upper left side panel (4) and right support board (14).
STEP 4
1. Screw 2 cam bolts (B) into cam bolt holes on upper left side panel (4) and upper right side
panel (3).
2. Insert 4 wood dowels (A) into dowel holes on upper left side panel (4) and upper right side
panel (3).
3. Attach shelf (6) to upper left side panel (4) by inserting cam bolt (B) and wood dowels (A)
into holes on shelf (6), then insert 1 cam lock (C) into cam lock hole on shelf (6) and rotate
clockwise to secure cam bolt (B) in place.
4. Attach upper right side panel (3) to shelf (6) by inserting cam bolt (B) and 2 wood dowels
(A) into holes on shelf (6).
5. Insert 1 cam lock (C) into cam lock hole on shelf (6), then rotate clockwise to secure cam
bolt (B) in place.

STEP 5
1. Attach magnet (H) to bottom of top board (7) by inserting 2 screws through holes on
magnet (H), then tighten to top board (7).
2. Insert 2 screws (Q) through sliding bracket (P) into holes on top board (7)
3. Screw 4 cam bolts (B) into cam bolt holes on top board (7).
4. Attach top board (7) to upper left side panel (4) and upper right side panel (3) by inserting
cam bolts (B) into cam lock holes on upper left side panel (4) and upper right side panel (3).
5. Insert 4 cam locks (C) into cam lock holes on upper left side panel (4) and upper right side
panel (3), then rotate clockwise to secure cam bolts in place.
STEP 6
1. Screw 4 cam bolts (B) into cam bolt holes on lower left side panel (17) and lower right side
panel (18).
2. Attach 2 lower section top cross bars (15) to lower left side panel (17) by inserting cam
bolts (B) into cam lock holes.
3. Insert 2 cam locks (C) into cam lock holes on lower section top cross bars (15), then rotate
clockwise to secure cam bolts (B) in place.
4. Attach rear lower cross bar (16) to lower left side panel (17) by inserting dowels into holes
on lower left side panel (17).
5. Attach lower right side panel (18) to lower section top cross bars (15) and lower cross bar
(16) by inserting cam bolts (B) into cam lock holes on lower section top cross bars (15) and
inserting dowels into dowel holes on lower section top cross bar (15) and lower right side
panel (18).
6. Insert 2 cam locks (B) into cam lock holes on lower section top cross bars (15), then rotate
clockwise to secure cam bolts (B) in place.

STEP 7
1. Screw 2 cam bolts (B) into cam bolt holes on middle connection board (8).
2. Insert 8 wooden dowels (A) into holes on lower left side panel (17), lower right side panel
(18) and lower section top cross bars (15).
3. Turn over middle connection board (8) and attach to pre-assembled lower left side panel
(17), lower right side panel (18) and lower section top cross bars (15) by inserting wood
dowels (A) into dowel holes and inserting cam bolts (B) into cam lock holes on the lower
left side panel (17), lower right side panel (18) and lower section top cross bars (15).
4. Insert 2 cam locks (C) into cam lock holes on lower left side panel (17) and lower right
side panel (18), then rotate clockwise to secure cam bolts (B) in place.
5. Screw 4 screws (O) through holes on lower left side panel (17) and lower right side
panel (18), then tighten to rear lower cross bar (16).

STEP 8
1. Screw 4 cam bolts (B) into cam bolt holes on middle connection board (8).
STEP 9
1. Attach upper assembled section to lower assembled section by inserting 4 cam bolts
(B) into cam lock holes on upper left side panel (4) and upper right side panel (3).
2. Insert 4 cam locks (C) into cam lock holes on upper left side panel (4) and upper right side
panel (3), then rotate clockwise to secure cam bolts (B) in place.

STEP 10
1. Attach upper back board (9) and middle back board (10) together by sliding into plastic
connection strip (N).
2. Attach upper back board (9) and middle back board (10) to cabinet by inserting 8 screws
(G) through holes on upper back board (9), and 4 screws (G) through holes on middle
back board (10), then tighten to cabinet.
3. Attach lower back board (11) to cabinet by inserting 8 screws (G) through holes on lower
back board (11), then tighten to cabinet.
4. Insert 4 screws (G) through holes on joint area of middle back board (10) and lower back
board (11), then tighten to cabinet.
STEP 11
1. Attach left door (1) to left side panel (4) by inserting 4 screws (D) through holes on hinges (E),
then tighten to left door (1).
2. Repeat above step to assemble right door (2).

STEP 12
Option #1: Securing to Drywall
1. Position spacesaver against wall in desired location. Using a pencil, make 2 small marks on
wall through holes on brackets (P). Move cabinet away from wall and screw 2 plastic anchors
(L) into wall on pencil marks.
2. Place cabinet against wall, insert 2 screws (M) through holes on brackets (P), then tighten
to plastic anchors (L).
Option #2: Securing to Drywall and Wood Stud
1. Position spacesaver against wall in desired location. Insert 2 screws (M) through holes on
brackets (P), then tighten through drywall and into wood stud.
*Tip: Anchor bracket (P) can be adjusted to correct distance from wall to cabinet as needed. Once adjusted,
be sure to re-tighten bracket inside cabinet for stability.
STEP 13
1. Insert 4 shelf holders (I) into holes on upper left side panel (4) and upper right side panel
(3) at desired shelf height.
2. Place adjustable shelf (12) onto shelf holders (I).

ATTENTION ADULTS: Cabinet should be checked periodically for damage or
loose screws/parts. Take appropriate action necessary to correct hazards such as
tightening of screws and taking any damaged parts away from children.
WARNING Please make sure your item is
secured to the wall, per assembly instructions.
CARE INSTRUCTIONS:
Wipe clean with a water dampened cloth. Wipe dry with clean cloth.
IMPORTANT:
Keep assembly instructions for future reference.

Enjoy your new RiverRidge® Spacesaver!
Thank you for purchasing this RiverRidge® Home item. We hope you
enjoy it and consider purchasing other RiverRidge® items.
To order replacement parts at no cost to you, email [email protected], call
1-(844)-223-5201 or order parts online at www.riverridgehome.com. Only valid in the United States.
If purchased outside of the United States, please contact retailer where purchased.
RiverRidge® is a registered trademark of Sourcing Solutions, Inc., Hudson, WI 54016
