ROSE DISPLAYS ECONOFRAME WITH WINDOW MOUNTS User manual

35 Congress Street, Salem, MA 01970
Tel# [phone] Fax# [phone]
e-mail:[e-mail]
Parts
Instruction Sheet
Step 1
Locate the two split rails and the
solid rail that is the same length as
the split rails.
Insert corner brackets into side
EconoFrame rails. Insert two corner
brackets into each end of the solid
side rail. Insert one corner bracket
into each end of each split side rail.
Fig. 1 & Fig. 2
Note: Tension tabs on corner
brackets face towards outside of
frame.
Step 2
Slide the Window Mounts
into the top rail of the EconoFrame
rail. Fig. 3
Step 3
Finish assembling frame following the
sequence in Fig. 4.
Step 4
Insert poster. Fig 5
Note: For best performance when
first applied and occasionally
thereafter, press the middle of the
cup (on the cap) to “burp” extra
air out.
EconoFrame™
Instructions for Hanging
Incept-12.04.02
