Roxell KiXoo in line User manual

031800803395
IN LINE
EN ENGLISH
User's Guide
Translation of the original instructions

KIXOO IN LINE - USER'S GUIDE - EU ROXELL - 0318
0
TABLE OF CONTENTS
DISCLAIMER
GENERAL INFORMATION
GENERAL SAFETY RULES 3.......................................................
OPERATOR'S GUIDE 4............................................................
CLEANING 6.....................................................................
CLEANING AND DISINFECTING (NATURAL BEAK SMOOTHING) 7..............
MAINTENANCE INSTRUCTIONS 8..................................................
TROUBLE SHOOTING GUIDE 9....................................................
DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY
EC-DECLARATION OF CONFORMITY

ROXELL - 2313
DISCLAIMER : The original, authoritative version of this manual is the Dutch version produced by
ROXELL bvba. Subsequent changes to any manual made by any third party have not been reviewed nor authenticated by
Roxell. Such changes may include, but are not limited to, translation into languages other than Dutch, and additions to or
deletions from the original content. Roxell disclaims responsibility for any and all damages, injuries, warranty claims and/or
any other claims associated with such changes, inasmuch as such changes result in content that is different from the
authoritative Roxell--published Dutch version of the manual. For current product installation and operation information,
please contact the customer service and/or technical service departments of Roxell. Should you observe any questionable
content in any manual, please notify Roxell immediately in writing to: ROXELL bvba -- Industrielaan 13, 9990 Maldegem --
Belgium.

ROXELL - 0516
GENERAL INFORMATION
THESE INSTRUCTIONS MUST BE READ, UNDERSTOOD AND ALL POINTS OBSERVED BY THE
USER, THE RESPONSIBLE AND OPERATING PERSONNEL.
1. OBEY THE LEGAL REGULATIONS AND THE APPLICABLE RULES!
This concerns, among other things, the European directives transposed into national legislation and/or the laws,
safety and accident prevention regulations that apply in the user's country.
During assembly, operation and maintenance of the installation the legal regulations concerned and the applicable
technical rules must be obeyed.
2. INTENDED USE
The installation has been designed solely for intensive livestock use and has been developed according to the ap-
plicable rules of good workmanship. Extra loading of the product is therefore prohibited. Any other use is considered
to be improper use. The manufacturer is not responsible for damage resulting there from. The user bears sole re-
sponsibility.
3. NOT-INTENDED USE
All use different than described in point 2” intended use” is at the responsibility of the end user.
4. LIABILITY
The (Extended) Warranty will not apply if any of the following has occurred: failure to conduct incoming goods
inspection with regards to the Products, improper handling, transportation, modification or repair; accident, abuse
or improper use; improper assembly, installation, connection or maintenance (having regard to Roxell’s most
current assembly, installation, connection and maintenance manuals); force majeure; negligence, lack of
supervision or of maintenance on the part of customer; normal wear and tear; use of cleansing agents and
disinfectants that are excluded in Roxell’s most current use and maintenance manuals;use of cleansing agents and
disinfectants in violation with the instructions received from the suppliers; or use of the Products in an ATEX-
surrounding.
The (Extended) Warranty shall not apply in the event of a defectcaused either by materialsor accessories supplied
by or services rendered by Customer; or by an intervention by a person or entity which is not authorised or qualified
for carrying out such intervention. Furthermore, the (Extended) Warranty will only apply if the Products are used in
livestock houses and if all parts or components of the Products are supplied by Roxell.
Roxell will not be liable for any damages caused due to improper use, assembly, installation, connection or
maintenance of the Products. In this respect, the Customer expressly acknowledges that (i) all use, assembly,
installation, connection or maintenance must be donein accordance with Roxell’s most current assembly,
installation, connection and maintenance manuals and (ii) the electrical installation on which the Products must be
connected must be done in accordance with applicable local legislation on electrical installations. Furthermore, the
Products must be tested both mechanically and electrically in accordance with state of the art techniques and
applicable local legislation.
5. PERSONNEL QUALIFICATIONS
USER:
The person who uses a function or operation of a product for their work or who works on the product. The user must
be able to read the instructions for use and fully understand them. The user has knowledge of the functioning and
construction of the installation.
TECHNICALLY TRAINED PERSON:
An expert who can assemble and maintain the installation (mechanically/electrically), and resolve malfunctions.
Onthe basisof his/her technicaltrainingandexperience,he/shehas sufficientknowledgetobe able toassessactiv-
ities, recognise possible dangers and rectify dangerous situations.

ROXELL - 0516
6. INFORMATION ABOUT THE RESIDUAL RISKS - USED SAFETY SIGNS
There are three levels of danger, which you can recognize from the signal word
* DANGER
* WARNING
* CAUTION
The nature and source of the imminent danger and possible consequences of not obeying warnings is stated here!
DANGER
DANGER indicates a direct imminent dange
r
that can result in a serious or even
fatal accident if the safety measures are not respected.
WARNING
WARNING indicates a possible imminent danger that can result in a serious acci-
dent or damage to the product if the safety measures are not respected.
CAUTION
CAUTIONindicates possible, dangerous situations that can result in minor physical
injury or material damage if the safety measures are not respected.
This symbol refers to supporting information.
not allowed
allowed
7. STORAGE
Put all parts to be assembled in a room or at a location where the not yet assembled components are protected
against weather influences.
8. TRANSPORT
Depending on the size of the parts and according to local circumstances and local legislation, the parts of the ma-
chine have to be transported with a forklift.
The forklift must be operated by a qualified person and in accordance with the rules of good workmanship.
When lifting the load, always check if the center of gravity of the load is stable.

ROXELL - 0516
9. DISMANTLING
Dismantle the installation and its components in accordance with the environmental legislation of the country or the
local authorities applicable at that time. All functioning products and exchange parts must be stored and disposed of
in accordance with the applicable environmental regulations.
Environmental information for customers in the European Union
European directive 2002/96/EC amended by the Directive 2008/34/EC requires that equipment that
bears this symbol on the product or packaging must not be disposed of with unsorted household
waste. This symbol indicates that the product must be disposed of separately. Your are yourself re-
sponsible for the destruction of this and other electrical and electronic equipment via the disposal
channels designated for that purpose by the national or local government. The correct destruction
and recycling of this equipment prevents anynegative consequences for the environment and health.
For more information about destroying your old equipment, contact your local authorities or waste
disposal service.
Information about waste disposal - electrical/electronic material for companies
1. In the European Union
If you have used the product for commercial purposesand you want to dispose of it, contact Roxell who will give you
information about the return of the product. It is possible that you willhave to pay a disposal charge for the return and
recycling. Small products (and small quantities) can be processed by the local collection agencies.
2. In other countries outside the European Union
If you want to dispose of this product, contact the local authorities for information concerning the correct disposal
procedure.
10. THE LEVEL OF NOISE EMISSION
The noise level of the installation in operation does not exceed 70dB(A).
11. LOCK OUT TAG OUT – LOCK METHOD GENERAL
- Everyone needs his own lock and tag (label), which can’t be removed by other persons.
- Inform all persons who are influenced by the procedure.
- Localize all sources of energy (electric, hydraulic, pneumatic).
- Switch off.
- Lock out and tag out.
- Check if the source of energy is switched off.
- Remove any remaining energy.
12. USE PERSONAL PROTECTIVE EQUIPMENT.
Ensure you wear personal protective equipment (gloves, dust masks...).
13. SUFFICIENT LIGHTING - ILLUMINANCE
-A minimum illuminance of 200 lux is necessary during usage, maintenance and installation.
- Provide at the installation (portable) emergency lighting in case of power failure.
14. ELECTRICAL EQUIPMENT, CONTROL PANELS, COMPONENTS AND DRIVE
UNITS
- To operate control panels, there must be atleast70cmoffreespace.
- Control panels must always remain closed. The key of the control panel must be in possession of an au-
thorized person.
- The necessary measures must be taken by the user to keep out rats, mice and other vermin from the
control panels
- If electrical equipment, control panels, components and drive units are damaged, the system must be
stopped IMMEDIATELY!
- Electrical equipment, control panels, components and drive units should NEVER be sprayed with water or
other liquid!
- Electrical equipment, control panels, components and drive units should NEVER be covered with any ma-
terial.

ROXELL - 2517 KIXOO IN LINE - EU
3
KiXoo/Vitoo/Boozzter Nr: 008.../008.../002...
Automatisch pannen voedersysteem voor opfok en productie van slachtkuikenouderdieren.
Automatic pan feeding system for rearing and production of broiler breeders.
GENERAL SAFETY RULES
Winching systeem
Liersysteem voor voer- en drinklijnen
Winching system for feed and drink lines
Carefully read the following instructions before
USING the system
1. Beforeyoudoanyrepair,ormaintenance works, always disconnect the
electricity supply.
2. Ensure you wear personal protection equipment (gloves, dust masks).
3. The system starts automatically.
Never use your hands at dangerous locations (feed intake boots, drive units, control units
or outlet holes in the tubes) before you have completely switched off the transport system
andmadesurethatnobody can switch it on without your knowledge.
4. Never allow unauthorized persons to enter the house in your absence.
5. Be careful when lowering or winching up the feeding lines/circuits :
-stop immediately at the slightest hitch.
-never stay underneath when lowering or winching up the lines/circuit.
6. If the auger stalls : immediately switch off the system. Carefully read the trouble shooting
guide and strictly follow instructions. Contact a technically trained person.
An auger under tension can cause very serious injuries when released.
7. Regularly check the elbow/trough and/or tube connections. Tighten if necessary.
8. Regularly check that the control unit (pan) and/or the motor handy box are properly
closed.
9. Ensure that the hopper cover grill or cover on the 100 kg hopper closes properly.
10. Thestandardwinchingsystemisonly suitable for height regulation during the
flock's stay and winching up for cleaning (1x per flock). For more frequent winching,
use the daily winching components.
IMPORTANT
This SYMBOL will be used to draw your attention to matters that are
of GREAT IMPORTANCE for your SAFETY.
It means : WARNING - follow the safety instructions :
disconnect the current - re-read the safety rules.
In short : BE ALERT.IGNORING these instructions can cause
SERIOUS INJURIES or even DEATH.
DANGER

KIXOO IN LINE - USER'S GUIDE - EU ROXELL - 0715
4
0715 00804278
OPERATOR’S GUIDE
IN LINE
* Spread the litter evenly over the house floor.
* Set the inside grill in its LOW position. Make sure that all grills are completely opened (pos 50).
* Lower all pans into the litter.
* MakesurethatALL feed windows are completely opened.
* Fill all pans manually (M). Repeat this daily 2- 3 times, so that there is always fresh feed in the pan.
* Winch up the lines after 10- 14 days (pans about 1cm above litter) to close the feed windows.
* All switches in position automatic (A).
* When necessary, winch up the pans gradually into a higher position.
* You can create a DEEP pan (that prevents feed wastage) by setting the inside grill in position 70. Make
sure that the 4 clickfingers close well. The grill opening remains 50.
Set the counter at the required feed amount.
“1”= 10kg (6,5 ton weigher)
“1”= 25kg (13 ton weigher)
Reset the counter every day (if necessary
adjust) after the clock became inactive.
Set the starting time. Set activation time longer than the time to finish the meal.
Set the counter at
999999
REARING PERIOD “AD LIBITUM” REARING PERIOD “RESTRICTION”
3
12
9
6
0-1
MA0
Feed windows open Feed windows closed
Regularly fill all pans manually (M)
MA0
All switches (A)
0-1
6
9
12
3
Stop the lines as soon as all pans have
been filled !!!
CONTROL PANEL SETTINGS
* Change the grill opening (clockwise) according the age of the animals.
Height grill opening : 70 or 60. Width : 40- 50.
LAYING PERIOD
CLEANING
FIGURE 1.
Pan remover
FIGURE 2.
Let the pan rest on the
floor, so that it stays
stable and at its place!
Push the pan down with both
thumbs until it hinges out of the grill.
1
2
34
5
Order
REARING PERIOD
* The last day : run the tubes empty and let the birds empty the pans as much as possible.
*Winch up the lines to a working height of about 1m for easy cleaning.
* Collect the feed residues by opening all pans, and empty them.
* Protect electrical components against water.
* Clean the whole system by means of a high- pressure cleaner (max 100 BAR).
* When using aggressive detergents or disinfectants consult your supplier.

ROXELL - 0715 KIXOO IN LINE - -EU
5
RearingProduction
Age
(weeks) Feeding
regime Poultry perch system Position o
f
the feed
level ring Width of grill openin
g
1.
See fig.
Height of grill
opening
See fig. 5.
Suspension height of
the pan
70
1cm
FIGURE 1.
FIGURE 2.
FIGURE 3.
FIGURE 4.
40
FIGURE 5.
1
Ad libitum off
3-8
3-6
meal
pellets/crumbles
50
80 Into the litter
See fig. 2.
2
70
31cmabovethe
litter
See fig. 3.
4Mild
restriction
on
5off
Back of the birds =
edge of eating
opening
See fig. 4.
6
7
Severe
restriction
on
off
18
Dependent on the
animals.
40 - 42
19 on
60 or 70
20
21 off
22 off
23
24
Mild
restriction
on
25
off meal
pellets/crumbles
8-14
6- 12
Dependent on the
animals.
46 - 50
34
35
36 on
37
off
64
65
0715 00804278
OPERATOR’S GUIDE
IN LINE

KIXOO IN LINE -- USER'S GUIDE - EU ROXELL - 0511
6
* The last day : run the tubes empty and let the birds empty the pans as much as possible.
*Winch up the lines to a working height of about 1m for easy cleaning.
* Collect the feed residues by opening all pans, and empty them (FIG. 8./9.)
* Protect electrical components against water.
* Clean the whole system by means of a high--pressure cleaner (max 100 BAR).
* When using aggressive detergents or disinfectants consult your supplier.
CLEANING
Figure 8.
Pan remover
Figure 9.
Let the pan rest on the floor, so
that it stays stable and at its
place!
Push the pan down with both thumbs until it hinges
out of the grill.
1
2
34
5
Order

ROXELL - 0318 KIXOO IN LINE - USER'S GUIDE -EU
7
- Do not use any products that can lead to corrosion of galvanized steel.
- Always follow the prescriptions of the manufacturer of the cleaning and
disinfecting agent closely. Use the prescribed concentration and contacttime.
- Rinse carefully with pure water to remove all residues after cleaning and disinfecting.
- Rinse carefully between using different cleaning and disinfecting products.
- Remove all residual water from the feeding pans by letting the pans drip out after
cleaning and disinfecting and dry out before closing.
- Remove all residues after drying.
- Cleaning advice:
Clean using a mild alkaline agent (pH 8-10) e.g. pro-Rein (Cidlines) or
other according to the specifications of the manufacturer (concentration and contact
time).
- Disinfecting advice:
Disinfect using an agent based on glutaraldehyde and quaternary
ammonium compounds e.g. Virocid (Cidlines) or other according to the
specifications of the manufacturer (concentration and contact time).
CLEANING AND DISINFECTING
(NATURAL BEAK SMOOTHING)

KIXOO IN LINE - USER'S GUIDE - EU ROXELL - 0318
8
MAINTENANCE INSTRUCTIONS
DANGER
Switch of
f
the main switch first.
Use personal protective equipment.
3-monthly
6-monthly
Yearly
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
1. Power unit
- Make fan dust-free X
- Check possible damages to electrical wiring X
2. Poultry intake boot with sensor
- Check sensor X
3. 100kg hopper (lines)
- Check level switch X
4. Suspension
- Check operation of (central) winch X
- Check operation of (central) winch. Grease after cleaning. X
- Check connection of cable X
- Check connection of pulleys X
- Check suspension of tubes and motors X
- Keep suspension cord/cable in tension X
5. Poultry perch cable above the tubes/elbows
- Check cable X
6. Pans
- Check possible damages of pans X
7. Sensors/switches
- Check operation of safety switch or sensor. X
- Check electrical wiring X
8. Control pan
- Remove the pan and clean the inside tube X
- Clean (dry) sensor head and central tube X
- Check switch of control units X
9. Lines/circuits
- Check screws and bolts in the system after the first month and after
each batch. Tighten if necessary.
X
- Keep tubes level. X
- Remove all feed from the system when the system will be out of use for a
period.
X

ROXELL - 0318 KIXOO IN LINE - USER'S GUIDE - EU
9
TROUBLE SHOOTING GUIDE
Switch off the main switch first.
Use personal protective equipment.
DANGER
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
PROBLEM CAUSE CORRECTIVE ACTION
1.None of the feeder
lines run.
No current. Replace defective fuses or reset circuit breakers.
Check current supply to the house.
Defective time clock. Replace defective clock.
Time clock not properly set. Readjust tabs.
2.One/more lines do
not run.
Pans are empty
Wires from motor damaged. Measure current in motor wires. Replace wires if
defective.
Motor protection switched off. See points 3. & 4. Reset motor overload button.
Defective sensor in the control unit, or
sensor not properly adjusted.
Check the good operation of the sensor.
Replace if necessary.
Defective sensor/minimum switch
control unit or 100kg hopper.
Check control unit sensor or switch. Replace if
necessary.
3.Motor is often
overloaded.
Oil on auger overloads the motor. Clean the auger by running repeatedly 25kgs of
feed through the line.
Not enough current supply to the
motors.
Check current supply at motor location. Start the
motor. Measure start current on motors. Wiring
must be thick enough to guarantee good operation
of the system.
Object blocks the auger. Motor runs,
then stalls. Feed sticks to the tubes.
Check if there are no objects in the boot, the control
unit and the drop holes of the feeder pans. Remove
any objects.
4.Auger stalls. Anchor bearing worn out or broken. Replace bearing. Gently slide auger back into
thetubes.Don'tletitjumpback:yourfinger or
the bearing could be damaged.
Auger not enough stretched. Shorten the auger.
Object blocks the auger. Remove the object.
5.Tubes / boot wear
rapidly,
much noise when
system runs.
Auger kinked or bent at the wear
point.
Auger end overlaps the anchor end.
Make sure not to kink the auger when using
gripping pliers. Auger must not overlap the anchor
end.
6.Not enough feed
supplied to fill up
the lines.
Flex-Auger drop holes are too small
or point upwards.
Make holes wider/turn tubes with holes
downwards.
Flow regulator in boot of feed supply
system blocks passage of the feed.
Adjust flow regulator to get a higher capacity.
Flex-Auger capacity is too low. Check the capacity of the Flex-Auger according the
specifications.
Check the installation of the Flex-Auger.
Notenoughtimesetonthetimeclock. Extend operation time per meal.
7.Feed drops
directly on
the adjuster ring
of the grill.
Pan not installed over the hole. Remove the top support. Install the pan ass'y over
theholeandthelips.
8.Irregular distribu-
tion of the feed
along the feeder
line.
Bad indexing of tubes or no indexing
at all.
Check indexing.
Switch over to other feed disturbs the
indexing of the feeder tube. (Too
muchortoolittlefeedinfrontoratthe
back.)
1.Too much in front : turn the holes a bit higher.
2.Too little feed in front : turn the holes somewhat
lower.
Foreign object in auger. Remove foreign object.
Feeder tubes turned in relation to
each other.
Check according to the marks when installed.
Adjust if required and tighten clamps securely.

Inbouwverklaring betreffende niet voltooide machines (Richtlijn 2006/42/EG, Bijlage II.1.B)
Declaration of incorporation of partly completed machinery (Directive 2006/42/EC, Annex
II.1.B)
Fabrikant/Manufacturer:
Roxell, Industrielaan 13, 9990 Maldegem
Tel: [phone]
Fax: [phone]
Verklaart geheel onder eigen verantwoordelijkheid dat het product:
Declares on its own responsibility that the product:
KiXoo/Vitoo/Boozzter Nr: 008…/008…/002…
Automatisch pannen voedersysteem voor opfok en productie van vleeskuikenouderdieren.
Automatic pan feeding system for rearing and production of broiler breeders.
Waarop deze verklaring betrekking heeft, in overeenstemming is met:
- de volgende richtlijnen: 2006/42/EG (Machinerichtlijn); 2014/30/EU (Elektromagnetische
Compatibiliteit).
- de geharmoniseerde Europese Normen: EN ISO 13857:2008; EN 349:1993 + A1:2008; EN ISO
12100:2010; EN 60204-1:2006; EN 61439-1:2011; EN 61439-2:2011
Het is verboden bovengenoemd product in gebruik te stellen voordat de machine waarin het
wordt ingebouwd in overeenstemming met de bepalingen van de Machinerichtlijn is verklaard.
Tevens verbindt de fabrikant (of zijn gemachtigde) zich om op met redenen omkleed verzoek van de
nationale autoriteiten de relevante informatie over deze niet voltooide machine door te geven. De
wijze van doorgifte is digitaal. De wijze van informatieverschaffing laat de intellectueel-
eigendomsrechten van de fabrikant van de niet voltooide machine onverlet.
(NL)
Relating to this declaration is in accordance with
- The following directives 2006/42/EC (Machinery Directive); 2014/30/EU (Electromagnetic
Compatibility).
- The harmonised European standards: EN ISO 13857:2008; EN 349:1993 + A1:2008; EN ISO
12100:2010; EN 60204-1:2006; EN 61439-1:2011; EN 61439-2:2011
This product must not be put into service until the machinery into which it is to be
incorporated has been declared in conformity with the provisions of the Machinery
Directive.
The manufacturer (or its agent) also undertakes, at the duly reasoned request of the national
authorities, to provide the relevant information concerning this partly completed machinery. The
method of transmission will be digital. The manner in which the information is provided does not
prejudice the manufacturer’s intellectual property rights concerning the partly completed
machinery.
(EN)
Plaats, Datum / Place, Date : Maldegem, 01/01/2018
………………………………..
Dhr. Gino Van Landuyt
Managing Director
“This part may only be filled out if all built-in subparts are delivered by Roxell”
EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage I.1.A)
EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A)
Wij/We_________________________________________________
(naam installateur/name fitter)
_____________________________________________________________________
_____________________________________________________________________
(volledig adres en land/complete address)
Verklaren geheel onder eigen verantwoording de
Declare completely on own justification that
________________________________________________________
(naam machine/name machinery) (nummer CE-label/number CE-label)
In een installatie te hebben ingebouwd geheel volgens de Roxell-voorschriften en in
overeenstemming met de bepalingen van de Machinerichtlijn.
Has been incorporated in conformity with the provisions of the Machinery Directive and the
prescriptions of Roxell bvba.
________________________________________________________
(plaats, datum/place, date) (naam, handtekening/name, signature)
De EG-verklaring van overeenstemming / inbouwverklaring betreft uitsluitend de machine of niet
voltooide machine in de toestand waarin zij op de markt is gebracht, met uitsluiting van de later
bijvoorbeeld door de verdeler en/of installateur en/of eindgebruiker toegevoegde componenten en/of
verrichte bewerkingen.
The EC-declaration of conformity / declaration of incorporation relates exclusively to the machinery
or partly completed machine in the state in which it was placed on the market and excludes
components which are added and/or operations carried out thereafter for instance by the distributor
and/or the installer and/or the final user.
00802603
SPECIMEN

EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage II.1.A)
EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A)
Fabrikant/Manufacturer:
Roxell, Industrielaan 13, 9990 Maldegem
Tel: [phone]
Fax: [phone]
Verklaart geheel onder eigen verantwoordelijkheid dat het product:
Declares on its own responsibility that the product:
Winching system Nr: 00102368 / 00102087
Liersysteem voor voer- en drinklijnen; manueel en gemotoriseerd
Winching system for feed- and drink lines; manual and motorised
Nummer CE-label/number CE-label :______________________________________________
Waarop deze verklaring betrekking heeft, in overeenstemming is met:
- de volgende richtlijnen: 2006/42/EG (Machinerichtlijn); 2014/30/EU (Elektromagnetische
Compatibiliteit).
- de geharmoniseerde Europese Normen: EN ISO 13857; EN 349:1993 + A1:2008; EN ISO
12100:2010; gemotoriseerd: EN 60204-1:2006; EN 61439-1:2011; EN 61439-2:2011
-
- De EG-verklaring van overeenstemming / inbouwverklaring betreft uitsluitend de machine of niet
voltooide machine in de toestand waarin zij op de markt is gebracht, met uitsluiting van de later
door bijvoorbeeld de verdeler en/of installateur en/of eindgebruiker toegevoegde componenten
en/of verrichte bewerkingen.
(NL)
Relating to this declaration is in accordance with
- The following directives 2006/42/EC (Machinery Directive); 2014/30/EU (Electromagnetic
Compatibility).
- The harmonised European standards: EN ISO 13857:2008; EN 349:1993 + A1:2008; EN
ISO 12100:2010; motorised: EN 60204-1:2006; EN 61439-1:2011; EN 61439-2:2011
The EC-declaration of conformity / declaration of incorporation relates exclusively to the machinery
or partly completed machine in the state in which it was placed on the market and excludes
components which are added and/or operations carried out thereafter for instance by the distributor
and/or the installer and/or the final user.
(EN)
Plaats, Datum / Place, Date : Maldegem, 01/01/2018
………………………………..
Dhr. Gino Van Landuyt
Managing Director
00105502
SPECIMEN

ROXELL bvba, Industrielaan 13, B-9990 Maldegem (Belgium)
Tel. [phone] - Fax. [phone] - e-mail: [email protected] - www.roxell.com
ROXELL USA, Inc. - 720 Industrial Park Road - Anderson, MO 64831 (USA)
Phone [phone] - Fax. [phone] - e-mail: inf[email protected] - www.roxell.com
ROXELL Malaysia - No. 12 Jalan Anggerik Mokara31/48, Kota Kemuning - Industrial Park, 40150 Shah Alam, Selangor,
Malaysia - Tel: [phone] or [phone] - Fax: [phone] - A division of CTB Malaysia Sdn. Bhd.
(868715-X) - e-mail: [email protected]om - www.roxell.com
ROXELL Россия - ООО «Рокселл» ОГРН 1157746055026, 125167, Россия, г. Москва,
Ленинградский проспект, д. 37, корп. 9, пом. 653
Телефон: [phone] Факс: [phone] - Эл. адрес: info.russ[email protected] - www.roxell.com
