Roxell Boozzter User manual

00207108 *00207108*002-1020
Boozzter
TM
User Guide
EN ENGLISH
Original User Guide

BOOZZTER - USER'S GUIDE - EU ROXELL - 0318
0
TABLE OF CONTENTS
DISCLAIMER
GENERAL INFORMATION
GENERAL SAFETY RULES 5.......................................................
OPERATOR'S GUIDE 6............................................................
CLEANING AND DISINFECTING (NATURAL BEAK SMOOTHING) 7..............
MAINTENANCE INSTRUCTIONS 8..................................................
TROUBLE SHOOTING GUIDE 9....................................................
DAILY WINCHING - GENERAL SAFETY RULES 11....................................
DAILY WINCHING - TROUBLE SHOOTING GUIDE 12..................................
DAILY WINCHING - MAINTENANCE INSTRUCTIONS 12...............................
DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY
EC-DECLARATION OF CONFORMITY

DISCLAIMER : The original, authoritative version of this manual is the Dutch version produced by
Roxell bvba Subsequent changes to any manual made by any third party have not been reviewed nor authenticated by
Roxell. Such changes may include, but are not limited to, translation into languages other than Dutch, and additions to or
deletions from the original content. Roxell disclaims responsibility for any and all damages, injuries, warranty claims and/or
any other claims associated with such changes, inasmuch as such changes result in content that is different from the
authoritative Roxell- published Dutch version of the manual. For current product installation and operation information,
please contact the customer service and/or technical service departments of Roxell. Should you observe any questionable
content in any manual, please notify Roxell immediately in writing to: Roxell bvba - Industrielaan 13, 9990 Maldegem -
Belgium.

BOOZZTER - USER'S GUIDE - EU ROXELL - 2416
2
GENERAL INFORMATION
THESE INSTRUCTIONS MUST BE READ, UNDERSTOOD AND ALL POINTS OBSERVED BY THE
USER, THE RESPONSIBLE AND OPERATING PERSONNEL.
1. OBEY THE LEGAL REGULATIONS AND THE APPLICABLE RULES!
This concerns, among other things, the European directives transposed into national legislation and/or the laws,
safety and accident prevention regulations that apply in the user's country.
During assembly, operation and maintenance of the installation the legal regulations concerned and the applicable
technical rules must be obeyed.
2. INTENDED USE
The installation has been designed solely for intensive livestock use and has been developed according to the ap-
plicable rules of good workmanship. Extra loading of the product is therefore prohibited. Any other use is considered
to be improper use. The manufacturer is not responsible for damage resulting there from. The user bears sole re-
sponsibility.
3. NOT-INTENDED USE
All use different than described in point 2” intended use” is at the responsibility of the end user.
4. LIABILITY
The (Extended) Warranty will not apply if any of the following has occurred: failure to conduct incoming goods
inspection with regards to the Products, improper handling, transportation, modification or repair; accident, abuse
or improper use; improper assembly, installation, connection or maintenance (having regard to Roxell’s most
current assembly, installation, connection and maintenance manuals); force majeure; negligence, lack of
supervision or of maintenance on the part of customer; normal wear and tear; use of cleansing agents and
disinfectants that are excluded in Roxell’s most current use and maintenance manuals; use of cleansing agents and
disinfectants in violation with the instructions received from the suppliers; or use of the Products in an ATEX-
surrounding.
The (Extended) Warranty shall not apply in the event of a defect caused either by materials or accessories supplied
by or services rendered by Customer; or by an intervention by a person or entity which is not authorised or qualified
for carrying out such intervention. Furthermore, the (Extended) Warranty will only apply if the Products are used in
livestock houses and if all parts or components of the Products are supplied by Roxell.
Roxell will not be liable for any damages caused due to improper use, assembly, installation, connection or
maintenance of the Products. In this respect, the Customer expressly acknowledges that (i) all use, assembly,
installation, connection or maintenance must be donein accordance with Roxell’s most current assembly,
installation, connection and maintenance manuals and (ii) the electrical installation on which the Products must be
connected must be done in accordance with applicable local legislation on electrical installations. Furthermore, the
Products must be tested both mechanically and electrically in accordance with state of the art techniques and
applicable local legislation.
5. PERSONNEL QUALIFICATIONS
USER:
The person who uses a function or operation of a product for their work or who works on the product. The user must
be able to read the instructions for use and fully understand them. The user has knowledge of the functioning and
construction of the installation.
TECHNICALLY TRAINED PERSON:
An expert who can assemble and maintain the installation (mechanically/electrically), and resolve malfunctions.
On the basis of his/her technical training and experience, he/she has sufficient knowledge to be able to assess activ-
ities, recognise possible dangers and rectify dangerous situations.

ROXELL - 2416 BOOZZTER - -EU
3
6. INFORMATION ABOUT THE RESIDUAL RISKS - USED SAFETY SIGNS
There are three levels of danger, which you can recognize from the signal word
* DANGER
* WARNING
* CAUTION
The nature and source of the imminent danger and possible consequences of not obeying warnings is stated here!
DANGER
DANGER indicates a direct imminent dange
r
that can result in a serious or even
fatal accident if the safety measures are not respected.
WARNING
WARNING indicates a possible imminent danger that can result in a serious acci-
dent or damage to the product if the safety measures are not respected.
CAUTION
CAUTION indicates possible, dangerous situations that can result in minor physical
injury or material damage if the safety measures are not respected.
This symbol refers to supporting information.
not allowed
allowed
7. STORAGE
Put all parts to be assembled in a room or at a location where the not yet assembled components are protected
against weather influences.
8. TRANSPORT
Depending on the size of the parts and according to local circumstances and local legislation, the parts of the ma-
chine have to be transported with a forklift.
The forklift must be operated by a qualified person and in accordance with the rules of good workmanship.
When lifting the load, always check if the center of gravity of the load is stable.

BOOZZTER - USER'S GUIDE - EU ROXELL - 2416
4
9. DISMANTLING
Dismantle the installation and its components in accordance with the environmental legislation of the country or the
local authorities applicable at that time. All functioning products and exchange parts must be stored and disposed of
in accordance with the applicable environmental regulations.
Environmental information for customers in the European Union
European directive 2002/96/EC amended by the Directive 2008/34/EC requires that equipment that
bears this symbol on the product or packaging must not be disposed of with unsorted household
waste. This symbol indicates that the product must be disposed of separately. Your are yourself re-
sponsible for the destruction of this and other electrical and electronic equipment via the disposal
channels designated for that purpose by the national or local government. The correct destruction
and recycling of this equipment prevents any negative consequences for the environment and health.
For more information about destroying your old equipment, contact your local authorities or waste
disposal service.
Information about waste disposal - electrical/electronic material for companies
1. In the European Union
If you have used the product for commercial purposes and you want to dispose of it, contact Roxell who will give you
information about the return of the product. It is possible that you will have to pay a disposal charge for the return and
recycling. Small products (and small quantities) can be processed by the local collection agencies.
2. In other countries outside the European Union
If you want to dispose of this product, contact the local authorities for information concerning the correct disposal
procedure.
10. THE LEVEL OF NOISE EMISSION
The noise level of the installation in operation does not exceed 70dB(A).
11. LOCK OUT TAG OUT – LOCK METHOD GENERAL
- Everyone needs his own lock and tag (label), which can’t be removed by other persons.
- Inform all persons who are influenced by the procedure.
- Localize all sources of energy (electric, hydraulic, pneumatic).
- Switch off.
- Lock out and tag out.
- Check if the source of energy is switched off.
- Remove any remaining energy.
12. USE PERSONAL PROTECTIVE EQUIPMENT.
Ensure you wear personal protective equipment (gloves, dust masks...).
13. SUFFICIENT LIGHTING - ILLUMINANCE
-A minimum illuminance of 200 lux is necessary during usage, maintenance and installation.
- Provide at the installation (portable) emergency lighting in case of power failure.
14. ELECTRICAL EQUIPMENT, CONTROL PANELS, COMPONENTS AND DRIVE
UNITS
- To operate control panels, there must be atleast70cmoffreespace.
- Control panels must always remain closed. The key of the control panel must be in possession of an au-
thorized person.
- The necessary measures must be taken by the user to keep out rats, mice and other vermin from the
control panels
- If electrical equipment, control panels, components and drive units are damaged, the system must be
stopped IMMEDIATELY!
- Electrical equipment, control panels, components and drive units should NEVER be sprayed with water or
other liquid!
- Electrical equipment, control panels, components and drive units should NEVER be covered with any ma-
terial.

ROXELL - 2517 BOOZZTER - EU
5
KiXoo/Vitoo/Boozzter Nr: 008.../008.../002...
Automatisch pannen voedersysteem voor opfok en productie van slachtkuikenouderdieren.
Automatic pan feeding system for rearing and production of broiler breeders.
GENERAL SAFETY RULES
Winching systeem
Liersysteem voor voer- en drinklijnen
Winching system for feed and drink lines
Carefully read the following instructions before
USING the system
1. Beforeyoudoanyrepair,ormaintenance works, always disconnect the
electricity supply.
2. Ensure you wear personal protection equipment (gloves, dust masks).
3. The system starts automatically.
Never use your hands at dangerous locations (feed intake boots, drive units, control units
or outlet holes in the tubes) before you have completely switched off the transport system
andmadesurethatnobody can switch it on without your knowledge.
4. Never allow unauthorized persons to enter the house in your absence.
5. Be careful when lowering or winching up the feeding lines/circuits :
-stop immediately at the slightest hitch.
-never stay underneath when lowering or winching up the lines/circuit.
6. If the auger stalls : immediately switch off the system. Carefully read the trouble shooting
guide and strictly follow instructions. Contact a technically trained person.
An auger under tension can cause very serious injuries when released.
7. Regularly check the elbow/trough and/or tube connections. Tighten if necessary.
8. Regularly check that the control unit (pan) and/or the motor handy box are properly
closed.
9. Ensure that the hopper cover grill or cover on the 100 kg hopper closes properly.
10. Thestandardwinchingsystemisonly suitable for height regulation during the
flock's stay and winching up for cleaning (1x per flock). For more frequent winching,
use the daily winching components.
IMPORTANT
This SYMBOL will be used to draw your attention to matters that are
of GREAT IMPORTANCE for your SAFETY.
It means : WARNING - follow the safety instructions :
disconnect the current - re-read the safety rules.
In short : BE ALERT.IGNORING these instructions can cause
SERIOUS INJURIES or even DEATH.
DANGER

ROXELL - 0819
Boozzter - User's guide - EU
6
1Keep the number of birds/pan constant (10 animals/pan).
Use the shut-off-shell when removing pans from the system (< 10 animals/pan = remove pans).
2Keep the pans at the correct height : allow all the cockerels to eat .
3Keep the litter in good shape and level and remove superfluous/dirty litter.
4Take care that all the lines are suspended perfectly level.
5Adjust the eating speed by turning the adjuster ring. An eating time of 25 till 45 minutes is recommended.
The most common position of the adjuster ring is between 6 and 12.
6Only start to feed the cockerels when all the females have access to their feed.
6 WAYS TO GET A BETTER UNIFORMITY :
- do not use it constantly
- use as WARNING !
Order
1
CLEANING
* The last day : run the tubes empty and let the birds empty the pans as much as possible.
* Collect the feed residues by opening all pans, and empty them.
* Protect electrical components against water.
* Clean the whole system by means of a high-pressure cleaner (max. 100 Bar).
* When using aggressive detergents or disinfectants consult your supplier.
09701863 OPENING TOOL BOOZZTER PAN
Poultry perch system
2
2Let the pan rest on
the floor, so that it
stays stable and at
its place!
0819 00207027
Keep the Boozzter pans slightly
higher than the back of the males.
1
2
HOUSE CHART

ROXELL - 0318 BOOZZTER - USER'S GUIDE -EU
7
- Do not use any products that can lead to corrosion of galvanized steel.
- Always follow the prescriptions of the manufacturer of the cleaning and
disinfecting agent closely. Use the prescribed concentration and contacttime.
- Rinse carefully with pure water to remove all residues after cleaning and disinfecting.
- Rinse carefully between using different cleaning and disinfecting products.
- Remove all residual water from the feeding pans by letting the pans drip out after
cleaning and disinfecting and dry out before closing.
- Remove all residues after drying.
- Cleaning advice:
Clean using a mild alkaline agent (pH 8-10) e.g. pro-Rein (Cidlines) or
other according to the specifications of the manufacturer (concentration and contact
time).
- Disinfecting advice:
Disinfect using an agent based on glutaraldehyde and quaternary
ammonium compounds e.g. Virocid (Cidlines) or other according to the
specifications of the manufacturer (concentration and contact time).
CLEANING AND DISINFECTING
(NATURAL BEAK SMOOTHING)

BOOZZTER - USER'S GUIDE - EU ROXELL - 0318
8
MAINTENANCE INSTRUCTIONS
DANGER
Switch of
f
the main switch first.
Use personal protective equipment.
3-monthly
6-monthly
Yearly
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
1. Power unit
- Make fan dust-free X
- Check possible damages to electrical wiring X
2. Drive unit (circuits)
- Make fan dust-free X
- Check possible damages to electrical wiring X
- Clean gear housing X
3. 100kg hopper (lines)
- Check level switch X
4. Suspension
- Check operation of (central) winch X
- Check operation of (central) winch. Grease after cleaning. X
- Check connection of cable X
- Check connection of pulleys X
- Check suspension of tubes and motors X
- Keep suspension cord/cable in tension X
5. Poultry perch cable above the tubes/elbows
- Check cable X
6. Pans
- Check possible damages of pans X
7. Sensors/switches
- Check operation of safety switch or sensor. X
- Check electrical wiring X
8. Feed intake boot
-Clean X
- Check possible wear of plastic gear X
9. Lines/circuits
- Check screws and bolts in the system after the first month and after
each batch. Tighten if necessary.
X
- Keep tubes level. X
- Remove all feed from the system when the system will be out of use for a
period.
X

ROXELL - 0318 BOOZZTER -EU
9
TROUBLE SHOOTING GUIDE
Switch off the main switch first.
Use personal protective equipment.
DANGER
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
FOR ANY AUTOMATIC OPERATION, NONE OF THE YELLOW LAMPS SHOULD BURN !
PROBLEM YELLOW
LAMP
CAUSE CORRECTIVE ACTION
1. None of the
feeder lines
run.
NO No current. Check main switch and/or fuses and/or line
current.
2. FA bin to
weigher
does not run
NO a. Operation button not on ”ON” posi-
tion.
Adjust button.
NO b. Max. switch of weigher remains
activated.
Check Max. switch and repair or replace it if
necessary.
c. FA safety switch is activated. Disengage safety switch and find cause of
blockage.
YES d. Thermal-magnetic switch-off of
the FA.
Check fuses. Check adjustment of motor
protection. Reload motor protection and
check its proper operation.
3. FA weigher
to circuits
does not
run.
NO a. See 2.a.
b. Sensor remains activated. See
signal lamp sensor.
Check and repair.
NO c. See 2.b. and 2.c.
YES d. See 2.d.
4. FA weigher
to circuits
short cycles
NO a. Sensor not properly installed. Check.
b. Timer of sensor adjusted too low. Adjust timer on a higher value.
5. The circuit
does not
run.
NO Wrong programming of time clock or
counter or no programming at all.
Check programming.
YES
YES
a. Left or right hand motor of one or
more circuits switched-off without
being overloaded.
Check fuses. Check adjustment of motor
protection. Reload motor protection and
check its proper operation.
b. Left or right hand motor of one or
more circuits switched-off thermal-
magnetically (overloaded).
1. Toomuchfeedinthetubes. Have pans emptied by the birds. Check the
operation of the sensor in the control pan.
2. Connector intake boot/tube or
tube-elbow not properly
tightened.
Tighten connector correctly.
3. Auger coupling not properly in-
stalled.
Check auger couplings and replace if ne-
cessary.

BOOZZTER - USER'S GUIDE - EU ROXELL - 0318
10
PROBLEM YELLOW
LAMP
CAUSE CORRECTIVE ACTION
4. Auger kinked .
5. Wheel inside intake boot is
blocked.
6. Obstruction in the tube.
Replace damaged auger.
Disengage wheel or replace if necessary.
Find blocking spot and remove the obstruc-
tion. SEE NOTE* .
NOTE : IF THE AUGER OF THE CIRCUIT IS BLOCKED AS A RESULT OF ONE
OF THE ABOVE PROBLEMS, IT WILL BE UNDER SPRING TENSION, SO BE EX-
TREMELY CAREFUL AND PROCEED AS DESCRIBED BELOW THIS PAGE*
DANGER
6. The circuit :
- stops pre-
maturely.
- does not
stop in time.
a. Time set on time clock is not suffi-
cient.
Adjust time clock programming.
b. The sensor in the control pan is de-
fective or not properly adjusted.
Check the sensor operation and replace if
necessary
7. Auger runs
erratically.
a. When using the system for the first
time.
This is not a breakdown; it will be ok after a
couple of days.
b. Auger too short. Adjust auger length.
c. Auger kinked as a result of care-
less installation.
Replace kinked parts.
d. Auger coupling not properly in-
stalled.
See installation instructions. Replace coup-
ling if necessary.
e. Circuit too long. Check maximum length and install an extra
power unit if necessary.
f. Circuit not properly suspended
(loose or ineffective suspension).
Realign circuit. Check all suspensions and
readjust where needed.
* WHEN THE AUGER IS BLOCKED, PROCEED AS FOLLOWS :
1. Put the main switch in position ”Off”.
2. Locate the blocking spot precisely.
3. Reload the motor protection (left or right).
4. Find the cause and correct. (See page 9 : 3., 4., 5. or 6.).
5. Putmainswitchinposition”ON”.Thecircuit is ready for a new feeding cycle.
.SWITCH OFF THE MAIN SWITCH OF THE CENTRAL CONTROL
PANEL BEFORE YOU PROCEED WITH MANUAL CHECKS OR RE-
PAIRS OF AUGERS OR POWER UNITS !
DANGER

ROXELL - 0318 BOOZZTER - USER'S GUIDE - EU
11
1. PAY ATTENTION when WINCHING UP or PUTTING DOWN the poultry lines:
-STOP the handling in case of any malfunctioning.
-NEVER stand UNDERNEATH the load when winching up or putting down the
poultry lines.
2. NEVER ALLOW UNAUTHORIZED PERSONS ENTER the house during your ab-
sence.
3. DON'T wear loose clothing.
4. Only adults may control the motorized winch.
5. Only use the motorized winch for suspension of a ROXELL poultry line and cir-
cuits.
6. ALWAYS check the condition of the motorized winch and the cable before operat-
ing.
Aravelled, kinked or damaged cable must be replaced IMMEDIATELY.
Aloose or damaged daily winch must be replaced IMMEDIATELY.
7. ALWAYS check before use, if the cable is ok.
8. ALWAYS check before use, if the cable is not damaged.
9. NEVER touch the cable, the rotating parts of the motorized winch and the switches
of the switch assembly for automatic winch, when in use.
10. Only use the motorized winch when NOBODY is standing underneath the load.
11. ALWAYS look at the load while using the motorized winch in manual mode.
12. PREVENT that the load makes a shocking movement.
13. COVER the motorized winch during cleaning.
DAILY WINCHING
GENERAL SAFETY RULES
DANGER: Getting jammed may cause SERIOUS INJURIES.
Dagelijks lieren voor pluimvee
Daily winching for poultry
FORBIDDEN:NEVER use the motorized winch to lift persons.
IMPORTANT
DANGER
Carefully read the following instructions before
USING the system

BOOZZTER - USER'S GUIDE - EU ROXELL - 0318
12
DAILY WINCHING
TROUBLE SHOOTING GUIDE
Not respecting above-mentioned instructions can cause phys-
ical injury or material damage.
Switch off the main switch first.
Use personal protective equipment.
DANGER
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
SEE TO IT THAT YOU FIRST REMOVE EACH ELEMENT WHICH CAN OBSTRUCT
A SAFE OPERATION OF THE SYSTEM!
DANGER
PROBLEM CAUSE CORRECTIVE ACTION
1. Sensor doesn’t work. a. Defect of sensor. - Replace the sensor.
b. No power supply to sensor. - Restore power supply.
-Whennot ok, please ask a technically trained
person.
c. The housing is dirty. - Clean the motorized winch dry.
-Whennot ok, please ask a technically trained
person.
2. Winching up doesn’t
work.
a. Load is too heavy. - Limit the load till max. 300 kg.
b. Cable to load is blocked somewhere. - Release the cable.
c. Motor is broken. -Replacemotor.
d. Weight assembly is touching cleaning
switch.
- Winch can only go down.
e. Drop tubes to circuits are full. - Empty drop tubes manually.
3. Putting down the
load doesn’t work.
a. Cable to load is blocked somewhere. - Release the cable.
b. Feeding switch is touched. - Winch can only go up.
4. Motor doesn’t work. a. Motor is overloaded.
b. Motor is too warm.
- Check CCP./motor.
-Checkmotor.
5. Cable is damaged. a. Cable touches material. - Replace the cable and prevent wearing over
hard material.
b. Suspension should be done with single/
double diversion.
- Change suspension.
MAINTENANCE INSTRUCTIONS
Switch off the main switch first.
Use personal protective equipment.
DANGER
- Remove all dirt and dust after each batch or at least every 6 months.
- See to it that the winch turns fluently on the screw thread of the main shaft.
- Don’t use water to clean the motorized winch.
- Use grease to grease moving parts.
- Check suspension cable each batch or every 6 months.
- Check the feed/fill/clean switches of the switch assembly.
- Grease switch assembly and sliding plate.
- Remove dust and dirt from the switch assembly for motorized winching.

Inbouwverklaring betreffende niet voltooide machines (Richtlijn 2006/42/EG, Bijlage II.1.B)
Declaration of incorporation of partly completed machinery (Directive 2006/42/EC, Annex
II.1.B)
Fabrikant/Manufacturer:
Roxell, Industrielaan 13, 9990 Maldegem
Tel: [phone]
Fax: [phone]
Verklaart geheel onder eigen verantwoordelijkheid dat het product:
Declares on its own responsibility that the product:
KiXoo/Vitoo/Boozzter Nr: 008…/008…/002…
Automatisch pannen voedersysteem voor opfok en productie van vleeskuikenouderdieren.
Automatic pan feeding system for rearing and production of broiler breeders.
Waarop deze verklaring betrekking heeft, in overeenstemming is met:
-de volgende richtlijnen: 2006/42/EG (Machinerichtlijn); 2014/30/EU (Elektromagnetische
Compatibiliteit).
-de geharmoniseerde Europese Normen: EN ISO 13857; EN 349; EN ISO 12100; EN 60204-1;
EN 61439-1; EN 61439-2
Het is verboden bovengenoemd product in gebruik te stellen voordat de machine waarin het wordt
ingebouwd in overeenstemming met de bepalingen van de Machinerichtlijn is verklaard.
Tevens verbindt de fabrikant (of zijn gemachtigde) zich om op met redenen omkleed verzoek van de
nationale autoriteiten de relevante informatie over deze niet voltooide machine door te geven. De
wijze van doorgifte is digitaal. De wijze van informatieverschaffing laat de intellectueel-
eigendomsrechten van de fabrikant van de niet voltooide machine onverlet.
(NL)
Relating to this declaration is in accordance with
-The following directives 2006/42/EC (Machinery Directive); 2014/30/EU (Electromagnetic
Compatibility).
- The harmonised European standards: EN ISO 13857; EN 349; EN ISO 12100; EN 60204-1;
EN 61439-1; EN 61439-2
This product must not be put into service until the machinery into which it is to be
incorporated has been declared in conformity with the provisions of the Machinery
Directive.
The manufacturer (or its agent) also undertakes, at the duly reasoned request of the national
authorities, to provide the relevant information concerning this partly completed machinery. The
method of transmission will be digital. The manner in which the information is provided does not
prejudice the manufacturer’s intellectual property rights concerning the partly completed
machinery.
(EN)
Plaats, Datum / Place, Date: Maldegem, 01/01/2020
………………………………..
Dhr. Gino Van Landuyt
Managing Director
“This part may only be filled out if all built-in subparts are delivered by Roxell”
EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage I.1.A)
EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A)
Wij/We_________________________________________________
(naam installateur/name fitter)
_____________________________________________________________________
_____________________________________________________________________
(volledig adres en land/complete address)
Verklaren geheel onder eigen verantwoording de
Declare completely on own justification that
________________________________________________________
(naam machine/name machinery) (nummer CE-label/number CE-label)
In een installatie te hebben ingebouwd geheel volgens de Roxell-voorschriften en in
overeenstemming met de bepalingen van de Machinerichtlijn.
Has been incorporated in conformity with the provisions of the Machinery Directive and the
prescriptions of Roxell bvba.
________________________________________________________
(plaats, datum/place, date) (naam, handtekening/name, signature)
De EG-verklaring van overeenstemming / inbouwverklaring betreft uitsluitend de machine of niet
voltooide machine in de toestand waarin zij op de markt is gebracht, met uitsluiting van de later
bijvoorbeeld door de verdeler en/of installateur en/of eindgebruiker toegevoegde componenten
en/of verrichte bewerkingen.
The EC-declaration of conformity / declaration of incorporation relates exclusively to the machinery
or partly completed machine in the state in which it was placed on the market and excludes
components which are added and/or operations carried out thereafter for instance by the distributor
and/or the installer and/or the final user.
00802603
SPECIMEN

EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage II.1.A)
EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A)
Fabrikant/Manufacturer:
Roxell, Industrielaan 13, 9990 Maldegem
Tel: [phone]
Fax: [phone]
Verklaart geheel onder eigen verantwoordelijkheid dat het product:
Declares on its own responsibility that the product:
Winching system Nr: 00102368 / 00102087
Liersysteem voor voer- en drinklijnen; manueel en gemotoriseerd
Winching system for feed- and drink lines; manual and motorised
Nummer CE-label/number CE-label :______________________________________________
Waarop deze verklaring betrekking heeft, in overeenstemming is met:
-de volgende richtlijnen: 2006/42/EG (Machinerichtlijn); 2014/30/EU (Elektromagnetische
Compatibiliteit).
-de geharmoniseerde Europese Normen: EN ISO 13857; EN 349; EN ISO 12100;
gemotoriseerd: EN 60204-1; EN 61439-1; EN 61439-2
De EG-verklaring van overeenstemming / inbouwverklaring betreft uitsluitend de machine of niet voltooide
machine in de toestand waarin zij op de markt is gebracht, met uitsluiting van de later door bijvoorbeeld de
verdeler en/of installateur en/of eindgebruiker toegevoegde componenten en/of verrichte bewerkingen.
(NL)
Relating to this declaration is in accordance with
-The following directives 2006/42/EC (Machinery Directive); 2014/30/EU (Electromagnetic Compatibility).
-The harmonised European standards: EN ISO 13857; EN 349; EN ISO 12100;
motorised: EN 60204-1; EN 61439-1; EN 61439-2
The EC-declaration of conformity / declaration of incorporation relates exclusively to the machinery or partly
completed machine in the state in which it was placed on the market and excludes components which are
added and/or operations carried out thereafter for instance by the distributor and/or the installer and/or the
final user.
(EN)
Plaats, Datum / Place, Date: Maldegem, 01/01/2020
………………………………..
Dhr. Gino Van Landuyt
Managing Director
00105502
SPECIMEN


























































ROXELLbvba‐Industrielaan13,9990Maldegem(Belgium)
Tel.+3250729172‐[email protected]‐www.roxell.com

ROXELLUSAInc.‐ 720IndustrialParkRoad,AndersonMO64831(USA)
Tel.+14178456065‐[email protected]‐www.roxell.com

ROXELLMalaysia‐No.49,JalanPermata2/KS9,TamanPerindustrianAirHitam,41200Klang,Selangor(Malaysia)
Tel.+60331231767‐[e-mail]‐www.roxell.com

ROXELLРоссия‐ООО«Рокселл»ОГРН1157746055026
125167,Россия,городМосква,Ленинградскийпроспект,дом37,корпус9,помещение653
Телефон:+74959833015‐Адресэлектроннойпочты:info.russi[email protected]‐www.roxell.com
