Roxell Vitoo User manual

00803650 *00803650*008-0821
Vitoo
TM
User Guide
EN ENGLISH
Original User Guide

VITOO - USER'S GUIDE - EU ROXELL - 0318
0
TABLE OF CONTENTS
DISCLAIMER
GENERAL INFORMATION
GENERAL SAFETY RULES 3.......................................................
OPERATOR'S GUIDE 4............................................................
CLEANING AND DISINFECTING (NATURAL BEAK SMOOTHING) 6..............
MAINTENANCE INSTRUCTIONS 7..................................................
TROUBLE SHOOTING GUIDE 8....................................................
DECLARATION OF INCORPORATION OF PARTLY COMPLETED MACHINERY
EC-DECLARATION OF CONFORMITY

ROXELL - 0921
DISCLAIMER : The original, authoritative version of this manual is the English version produced by
ROXELL bv. Subsequent changes to any manual made by any third party have not been reviewed nor authenticated by
Roxell. Such changes may include, but are not limited to, translation into languages other than English, and additions to or
deletions from the original content. Roxell disclaims responsibility for any and all damages, injuries, warranty claims and/or
any other claims associated with such changes, inasmuch as such changes result in content that is different from the authoritat-
ive Roxell--published English version of the manual. For current product installation and operation information, please con-
tact the customer service and/or technical service departments of Roxell. Should you observe any questionable content in any
manual, please notify Roxell immediately in writing to: ROXELL bv -- Industrielaan 13, 9990 Maldegem -- Belgium.

General information
IMPORTANT: These instructions must be read, understood and all points observed by the user, the responsible and
operating personnel.
Obey the legal regulations and the applicable rules
This concerns, among other things, the European regulations and directives transposed into national legislation and/or
the laws, safety and accident prevention regulations that apply in the user's country.
During assembly, operation and maintenance of the installation the legal regulations concerned and the applicable
technical rules must be obeyed.
Intended use
The installation has been designed solely for intensive livestock use and has been developed according to the applicable
rules of good workmanship. Extra loading of the product is therefore prohibited. Any other use is considered to be
improper use. The manufacturer is not responsible for damage resulting therefrom. The user bears sole responsibility. The
manufacturer can determine from the system data whether the product was used in accordance with the specified use.
Not-intended use
All use different than described in Intended Use is at the responsibility of the end user.
Liability
The (extended) warranty will not apply if any of the following has occurred: failure by the customer to inspect the
delivered goods and report visible defects within 8 days of delivery with respect to the products, improper handling,
transportation, modification or repair; accidents, defective or improper use; improper or defective assembly, installation,
connection or maintenance (having regard to Roxell’s most current assembly, installation, connection and maintenance
manuals); improper modifications or manipulations of the operating system, hardware or any other software of the
product by the customer; force majeure; negligence, lack of supervision or of maintenance on the part of customer;
normal wear and tear; use of cleansing agents and disinfectants that are excluded in Roxell’s most current use and
maintenance manuals; use of cleansing agents and disinfectants in violation with the instructions received from the
suppliers; or use of the products in an ATEX- surrounding.
The (extended) warranty shall not apply in the event of a defect caused either by materials or accessories supplied by or
services rendered by the customer; or by an intervention by a person or entity which is not authorized or qualified for
carrying out such intervention. Furthermore, the (extended) warranty will only apply if the products are used in livestock
houses and if all parts or components of the products are supplied by Roxell.
Roxell will not be liable for any damages caused due to improper or defective use, assembly, installation, connection or
maintenance of the products. In this respect, the customer expressly acknowledges that (i) all use, assembly, installation,
connection or maintenance must be done in accordance with Roxell’s most current assembly, installation, connection
and maintenance manuals and (ii) the electrical installation on which the products must be connected must be done
in accordance with applicable local legislation on electrical installations. Furthermore, the products must be tested
both mechanically and electrically by the customer in accordance with state of the art techniques and applicable local
legislation.
Personnel qualifications
User
The person who uses a function or operation of a product for their work or who works on the product. The user must
be able to read the instructions for use and fully understand them. The user has knowledge of the functioning and
construction of the installation.
page 1
Roxell – – 0821 – General information

page 2
Technically trained person
An expert who can assemble and maintain the installation (mechanically/electrically), and resolve malfunctions. On
the basis of his/her technical training and experience, he/she has sufficient knowledge to be able to assess activities,
recognize possible dangers and rectify dangerous situations.
Storage
Put all parts to be assembled in a room or at a location where the not yet assembled components are protected against
weather influences.
Transport
Depending on the size of the parts and according to local circumstances and local legislation, the parts of the machine
have to be transported with a forklift.
The forklift must be operated by a qualified person and in accordance with the rules of good workmanship. When lifting
the load, always check if the center of gravity of the load is stable.
Dismantling
Dismantle the installation and its components in accordance with the environmental legislation of the country or the
local authorities applicable at that time. All functioning products and exchange parts must be stored and disposed of in
accordance with the applicable environmental regulations.
Environmental information for customers in the European Union
The European legislation requires that equipment marked with this symbol on the product or
packaging must not be collected with unsorted household waste.
This symbol indicates that the waste electrical and electronic equipment (WEEE) cannot be disposed
of in the regular household waste. We highly recommend that you bring your product to an official
collection point so that an expert can remove the waste electrical and electronic equipment. Inform
yourself of local legislation on separate collection of waste electrical and electronic equipment.
Respect the local regulations and never dispose of the product together with household waste.
Information about waste disposal - electrical/electronic material for companies
1. In the European Union
If you have used the product for commercial purposes and you want to dispose of it, contact Roxell, who will give
you information about the return of the product. It is possible that you will have to pay a disposal charge for the
return and recycling. Small products (and small quantities) can be processed by the local collection agencies.
2. In other countries outside the European Union
If you want to dispose of this product, contact the local authorities for information concerning the correct
disposal procedure.
The level of noise emission
The noise level of the installation in operation does not exceed 70 dB(A).
– General information Roxell – – 0821

LOTOTO = Lock Out - Tag Out - Try Out
Before you begin: Everyone needs his own lock and tag (label), which can’t be removed by other persons. Inform all the persons who
are influenced by the procedure.
1To block
- Localize all sources of energy (electric, hydraulic, pneumatic).
- Switch off.
- Take the relevant installation or process out of operation and lock it against reuse. You can do this by placing a
padlock or other blocking mechanism (Lock Out).
2To mark
Attach a sign, label or sticker to the padlock or blocking mechanism to reveal the nature and the expected duration of
the work to other persons (Tag Out).
3To check
- Check if the source of energy is switched off.
- Remove any remaining energy.
- Check that the installation or process is actually safe (Try Out).
Use personal protective equipment
Ensure you wear personal protective equipment (gloves, dust masks...).
Illuminance - sufficient lighting
•A minimum illuminance of 200 lux is necessary during usage, maintenance and installation.
•Provide at the installation (portable) emergency lighting in case of power failure.
Electrical equipment, control panels, components and drive units
•To operate control panels, there must be at least 70 cm of free space.
•Control panels must always remain closed. The key of the control panel must be in possession of an authorized
person. Only an electrically trained person (see above) shall carry out maintenance activities inside the control
panels.
•The necessary measures must be taken by the user to keep out rats, mice and other vermin from the control panels.
•If electrical equipment, control panels, components and drive units are damaged, the system must be stopped
immediately!
•Electrical equipment, control panels, components and drive units should never be sprayed with water or other
liquid!
•Electrical equipment, control panels, components and drive units should never be covered with any material.
page 3
Roxell – – 0821 – General information

page 4
Information about the residual risks - used safety signs
There are three levels of danger, which you can recognize from the following signal words:
•DANGER
•WARNING
•CAUTION
The nature and source of the imminent danger and possible consequences of not obeying warnings is stated here!
Symbol Meaning
DANGER indicates a direct imminent danger that can result in a serious or even fatal accident if
the safety measures are not respected.
WARNING indicates a possible imminent danger that can result in a serious accident or
damage to the product if the safety measures are not respected.
CAUTION indicates possible, dangerous situations that can result in minor physical injury or
material damage if the safety measures are not respected.
This symbol refers to supporting information.
Allowed
Not allowed
This symbol will be used to draw your attention to matters that are of great importance for
your safety. It means: warning - follow the safety instructions. Disconnect the current and
read the safety rules. In short: be alert. Ignoring these instructions can cause serious injuries
or even death.
– General information Roxell – – 0821

ROXELL - 2517 VITOO - EU
3
KiXoo/Vitoo/Boozzter Nr: 008.../008.../002...
Automatisch pannen voedersysteem voor opfok en productie van slachtkuikenouderdieren.
Automatic pan feeding system for rearing and production of broiler breeders.
GENERAL SAFETY RULES
Winching systeem
Liersysteem voor voer- en drinklijnen
Winching system for feed and drink lines
Carefully read the following instructions before
USING the system
1. Beforeyoudoanyrepair,ormaintenance works, always disconnect the
electricity supply.
2. Ensure you wear personal protection equipment (gloves, dust masks).
3. The system starts automatically.
Never use your hands at dangerous locations (feed intake boots, drive units, control units
or outlet holes in the tubes) before you have completely switched off the transport system
andmadesurethatnobody can switch it on without your knowledge.
4. Never allow unauthorized persons to enter the house in your absence.
5. Be careful when lowering or winching up the feeding lines/circuits :
-stop immediately at the slightest hitch.
-never stay underneath when lowering or winching up the lines/circuit.
6. If the auger stalls : immediately switch off the system. Carefully read the trouble shooting
guide and strictly follow instructions. Contact a technically trained person.
An auger under tension can cause very serious injuries when released.
7. Regularly check the elbow/trough and/or tube connections. Tighten if necessary.
8. Regularly check that the control unit (pan) and/or the motor handy box are properly
closed.
9. Ensure that the hopper cover grill or cover on the 100 kg hopper closes properly.
10. Thestandardwinchingsystemisonly suitable for height regulation during the
flock's stay and winching up for cleaning (1x per flock). For more frequent winching,
use the daily winching components.
IMPORTANT
This SYMBOL will be used to draw your attention to matters that are
of GREAT IMPORTANCE for your SAFETY.
It means : WARNING - follow the safety instructions :
disconnect the current - re-read the safety rules.
In short : BE ALERT.IGNORING these instructions can cause
SERIOUS INJURIES or even DEATH.
DANGER

VITOO -- USER'S GUIDE - EU ROXELL - 0110
4
00800854
OPERATOR’S GUIDE
0510
CONTROL PANEL SETTINGS
REARING PERIOD “RESTRICTION”
Feed windows open
REARING PERIOD “AD LIBITUM”
Feed windows closed
Set the counter at
999999
Regularly fill all pans manually (M) Set the starting time. Set activation time longer than the time to finish
the meal.
LAYING PERIOD
* Change the grill opening (clockwise) according the age of the animals.
Height grill opening : 80 or 70. Width : 40--50.
3
12
9
6
0--1
MA0
Control pan selection switch
“Skip a day”
MA0
III III
Feeding every day
III III
0--1
6
912 3
Stop the circuits as soon
as all pans have been
filled !!!
REARING PERIOD
III
Control pan selection switch
position feeding time
I
II
30 min.
30 min.
Control pan selection switch Control pan selection switchControl pan
selection switch
PositionI: the control pan switches on and off the circuits automatically until the daily feed
ration has been distributed.
Position II : the control pan is ”by--passed” and the circuits run continuously until the daily
feed ration has been distributed.
*Spread the litter evenly over the house floor.
* Set the inside grill in its LOW position. Make sure that all grills are completely opened (pos 50).
* Lower all pans into the litter.
* MakesurethatALL feed windows are completely opened.
* Fill all pans manually (M). Repeat this daily 2--3 times, so that there is always fresh feed in the pan.
* Winch up the lines after 10--14 days (pans about 1cm above litter) to close the feed windows.
* All switches in position automatic (A).
* When necessary, winch up the pans gradually into a higher position.
* You can create a DEEP pan (that prevents feed wastage) by setting the inside grill in position 80. Make
sure that the 4 clickfingers close well. The grill opening remains 50.
Set the counter at the required feed
amount.
“1”= 10kg (6,5 ton weigher)
“1”= 25kg (13 ton weigher)
Reset the counter every day (if
necessary adjust) after the clock
became inactive.
All switches (A)

ROXELL - 3919 Vitoo - User's guide - EU
5
Age
(weeks)
Feeding
regime
Position of the control pan selection Position of the feed level
ring = streamopening
beneath cone
12MM
Poultry perch
system
Suspension height of the pan
1
Ad libitum
III 14
off
into the litter :
feed windows open
2
off
1 cm above the litter :
feed windows closed
1CM
3on
4Mild
restriction
III
3-8
3-6
meal
pellets/crumbles
Do not use the feed level
ring above position 8 while
rearing breeders.
5off
Back of the birds = edge of eating opening
6
7
Severe
restriction
on
off
18
19 on
20
21
off
00800854
3919 HOUSE CHART

VITOO - USER'S GUIDE - EU ROXELL - 0318
6
- Do not use any products that can lead to corrosion of galvanized steel.
- Always follow the prescriptions of the manufacturer of the cleaning and
disinfecting agent closely. Use the prescribed concentration and contacttime.
- Rinse carefully with pure water to remove all residues after cleaning and disinfecting.
- Rinse carefully between using different cleaning and disinfecting products.
- Remove all residual water from the feeding pans by letting the pans drip out after
cleaning and disinfecting and dry out before closing.
- Remove all residues after drying.
- Cleaning advice:
Clean using a mild alkaline agent (pH 8-10) e.g. pro-Rein (Cidlines) or
other according to the specifications of the manufacturer (concentration and contact
time).
- Disinfecting advice:
Disinfect using an agent based on glutaraldehyde and quaternary
ammonium compounds e.g. Virocid (Cidlines) or other according to the
specifications of the manufacturer (concentration and contact time).
CLEANING AND DISINFECTING
(NATURAL BEAK SMOOTHING)

ROXELL - 0318 VITOO - USER'S GUIDE - EU
7
MAINTENANCE INSTRUCTIONS
DANGER
Switch of
f
the main switch first.
Use personal protective equipment.
3-monthly
6-monthly
Yearly
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
1. Power unit
- Make fan dust-free X
- Check possible damages to electrical wiring X
2. Drive unit (circuits)
- Make fan dust-free X
- Check possible damages to electrical wiring X
- Clean gear housing X
3. 100kg hopper (lines)
- Check level switch X
4. Suspension
- Check operation of (central) winch X
- Check operation of (central) winch. Grease after cleaning. X
- Check connection of cable X
- Check connection of pulleys X
- Check suspension of tubes and motors X
- Keep suspension cord/cable in tension X
5. Poultry perch cable above the tubes/elbows
- Check cable X
6. Pans
- Check possible damages of pans X
7. Sensors/switches
- Check operation of safety switch or sensor. X
- Check electrical wiring X
8. Control pan
- Remove the pan and clean the inside tube X
- Clean (dry) sensor head and central tube X
- Check switch of control units X
9. Feed intake boot
-Clean X
- Check possible wear of plastic gear X
10.Lines/circuits
- Check screws and bolts in the system after the first month and after
each batch. Tighten if necessary.
X
- Keep tubes level. X
- Remove all feed from the system when the system will be out of use for a
period.
X

VITOO - USER'S GUIDE - EU ROXELL - 0318
8
TROUBLE SHOOTING GUIDE
Switch off the main switch first.
Use personal protective equipment.
DANGER
ACTIONS IN GREY BACKGROUND MUST BE DONE BY A TECHNICALLY TRAINED PERSON.
FOR ANY AUTOMATIC OPERATION, NONE OF THE YELLOW LAMPS SHOULD BURN !
PROBLEM YELLOW
LAMP
CAUSE CORRECTIVE ACTION
1. None of the
feeder lines
run.
NO No current. Check main switch and/or fuses and/or line
current.
2. FA bin to
weigher
does not run
NO a. Operation button not on ”ON” posi-
tion.
Adjust button.
NO b. Max. switch of weigher remains
activated.
Check Max. switch and repair or replace it if
necessary.
c. FA safety switch is activated. Disengage safety switch and find cause of
blockage.
YES d. Thermal-magnetic switch-off of
the FA.
Check fuses. Check adjustment of motor
protection. Reload motor protection and
check its proper operation.
3. FA weigher
to circuits
does not
run.
NO a. See 2.a.
b. Sensor remains activated. See
signal lamp sensor.
Check and repair.
NO c. See 2.b. and 2.c.
YES d. See 2.d.
4. FA weigher
to circuits
short cycles
NO a. Sensor not properly installed. Check.
b. Timer of sensor adjusted too low. Adjust timer on a higher value.
5. The circuit
does not
run.
NO Wrong programming of time clock or
counter or no programming at all.
Check programming.
YES
YES
a. Left or right hand motor of one or
more circuits switched-off without
being overloaded.
Check fuses. Check adjustment of motor
protection. Reload motor protection and
check its proper operation.
b. Left or right hand motor of one or
more circuits switched-off thermal-
magnetically (overloaded).
1. Toomuchfeedinthetubes. Have pans emptied by the birds. Check the
operation of the sensor in the control pan.
2. Connector intake boot/tube or
tube-elbow not properly
tightened.
Tighten connector correctly.
3. Auger coupling not properly in-
stalled.
Check auger couplings and replace if ne-
cessary.

ROXELL - 0318 VITOO - USER'S GUIDE - EU
9
PROBLEM YELLOW
LAMP
CAUSE CORRECTIVE ACTION
4. Auger kinked .
5. Wheel inside intake boot is
blocked.
6. Obstruction in the tube.
7. Feed in front of the sensor in the
control pan.
8. Too much dust on the sensor in
the control pan.
Replace damaged auger.
Disengage wheel or replace if necessary.
Find blocking spot and remove the obstruc-
tion. SEE NOTE* .
Check if the control pan is empty.
Unmount the control pan and clean the
sensor.
NOTE : IF THE AUGER OF THE CIRCUIT IS BLOCKED AS A RESULT OF ONE
OF THE ABOVE PROBLEMS, IT WILL BE UNDER SPRING TENSION, SO BE EX-
TREMELY CAREFUL AND PROCEED AS DESCRIBED BELOW THIS PAGE*
DANGER
6. The circuit :
- stops pre-
maturely.
- does not
stop in time.
a. Time set on time clock is not suffi-
cient.
Adjust time clock programming.
b. The sensor in the control pan is de-
fective or not properly adjusted.
Check the sensor operation and replace if
necessary
7. Auger runs
erratically.
a. When using the system for the first
time.
This is not a breakdown; it will be ok after a
couple of days.
b. Auger too short. Adjust auger length.
c. Auger kinked as a result of care-
less installation.
Replace kinked parts.
d. Auger coupling not properly in-
stalled.
See installation instructions. Replace coup-
ling if necessary.
e. Circuit too long. Check maximum length and install an extra
power unit if necessary.
f. Circuit not properly suspended
(loose or ineffective suspension).
Realign circuit. Check all suspensions and
readjust where needed.
* WHEN THE AUGER IS BLOCKED, PROCEED AS FOLLOWS :
1. Put the main switch in position ”Off”.
2. Locate the blocking spot precisely.
3. Reload the motor protection (left or right).
4. Find the cause and correct. (See page 8 : 3., 4., 5. or 6.).
5. Putmainswitchinposition”ON”.Thecircuit is ready for a new feeding cycle.
.SWITCH OFF THE MAIN SWITCH OF THE CENTRAL CONTROL
PANEL BEFORE YOU PROCEED WITH MANUAL CHECKS OR RE-
PAIRS OF AUGERS OR POWER UNITS !
DANGER

Inbouwverklaring betreffende niet voltooide machines (Richtlijn 2006/42/EG, Bijlage II.1.B)
Declaration of incorporation of partly completed machinery (Directive 2006/42/EC, Annex
II.1.B)
Fabrikant/Manufacturer:
Roxell bv, Industrielaan 13, 9990 Maldegem
Tel: [phone]
Fax: [phone]
Verklaart geheel onder eigen verantwoordelijkheid dat het product:
Declares on its own responsibility that the product:
KiXoo/Vitoo/Boozzter Nr: 008…/008…/002…
Automatisch pannen voedersysteem voor opfok en productie van vleeskuikenouderdieren.
Automatic pan feeding system for rearing and production of broiler breeders.
Waarop deze verklaring betrekking heeft, in overeenstemming is met:
-de volgende richtlijnen: 2006/42/EG (Machinerichtlijn); 2014/30/EU (Elektromagnetische
Compatibiliteit);
-de geharmoniseerde Europese Normen: EN ISO 12100:2010; EN ISO 13854:2019;
EN ISO 13857:2019; EN IEC 60204-1:2005; EN IEC 61439-1:2011; EN IEC 61439-2:2011.
Het is verboden bovengenoemd product in gebruik te stellen voordat de machine waarin het wordt
ingebouwd in overeenstemming met de bepalingen van de Machinerichtlijn is verklaard.
Tevens verbindt de fabrikant (of zijn gemachtigde) zich om op met redenen omkleed verzoek van de
nationale autoriteiten de relevante informatie over deze niet voltooide machine door te geven. De
wijze van doorgifte is digitaal. De wijze van informatieverschaffing laat de intellectueel-
eigendomsrechten van de fabrikant van de niet voltooide machine onverlet.
(NL)
Relating to this declaration is in accordance with
-The following directives 2006/42/EC (Machinery Directive); 2014/30/EU (Electromagnetic
Compatibility).
-The harmonised European standards: EN ISO 12100:2010; EN ISO 13854:2019;
EN ISO 13857:2019; EN IEC 60204-1:2005; EN IEC 61439-1:2011; EN IEC 61439-2:2011.
This product must not be put into service until the machinery into which it is to be
incorporated has been declared in conformity with the provisions of the Machinery
Directive.
The manufacturer (or its agent) also undertakes, at the duly reasoned request of the national
authorities, to provide the relevant information concerning this partly completed machinery. The
method of transmission will be digital. The manner in which the information is provided does not
prejudice the manufacturer’s intellectual property rights concerning the partly completed
machinery. (EN)
Plaats, Datum / Place, Date: Maldegem, 01/01/2021
………………………………..
Dhr. Gino Van Landuyt
Managing Director
“This part may only be filled out if all built-in subparts are delivered by Roxell”
EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage I.1.A)
EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A)
Wij/We_________________________________________________
(naam installateur/name fitter)
_____________________________________________________________________
_____________________________________________________________________
(volledig adres en land/complete address)
Verklaren geheel onder eigen verantwoording de
Declare completely on own justification that
________________________________________________________
(naam machine/name machinery) (nummer CE-label/number CE-label)
In een installatie te hebben ingebouwd geheel volgens de Roxell-voorschriften en in
overeenstemming met de bepalingen van de Machinerichtlijn.
Has been incorporated in conformity with the provisions of the Machinery Directive and the
prescriptions of Roxell bv.
________________________________________________________
(plaats, datum/place, date) (naam, handtekening/name, signature)
De EG-verklaring van overeenstemming / inbouwverklaring betreft uitsluitend de machine of niet
voltooide machine in de toestand waarin zij op de markt is gebracht, met uitsluiting van de later
bijvoorbeeld door de verdeler en/of installateur en/of eindgebruiker toegevoegde componenten
en/of verrichte bewerkingen.
The EC-declaration of conformity / declaration of incorporation relates exclusively to the machinery
or partly completed machine in the state in which it was placed on the market and excludes
components which are added and/or operations carried out thereafter for instance by the distributor
and/or the installer and/or the final user.
00802603
SPECIMEN

EG-verklaring van overeenstemming (Richtlijn 2006/42/EG, Bijlage II.1.A)
EC-declaration of conformity (Directive 2006/42/EC, Annex II.1.A)
Fabrikant/Manufacturer:
Roxell bv, Industrielaan 13, 9990 Maldegem
Tel: [phone]
Fax: [phone]
Verklaart geheel onder eigen verantwoordelijkheid dat het product:
Declares on its own responsibility that the product:
Winching system Nr: 00102368 / 00102087
Liersysteem voor voer- en drinklijnen; manueel en gemotoriseerd
Winching system for feed- and drink lines; manual and motorised
Nummer CE-label/number CE-label :______________________________________________
Waarop deze verklaring betrekking heeft, in overeenstemming is met:
-de volgende richtlijnen: 2006/42/EG (Machinerichtlijn); 2014/30/EU (Elektromagnetische
Compatibiliteit);
-de geharmoniseerde Europese Normen: EN ISO 12100:2010; EN ISO 13854:2019; EN ISO 13857:2019;
gemotoriseerd: EN IEC 60204-1:2005; EN IEC 61439-1:2011; EN IEC 61439-2:2011.
De EG-verklaring van overeenstemming / inbouwverklaring betreft uitsluitend de machine of niet voltooide
machine in de toestand waarin zij op de markt is gebracht, met uitsluiting van de later door bijvoorbeeld de
verdeler en/of installateur en/of eindgebruiker toegevoegde componenten en/of verrichte bewerkingen.
(NL)
Relating to this declaration is in accordance with
-The following directives 2006/42/EC (Machinery Directive); 2014/30/EU (Electromagnetic Compatibility).
-The harmonised European standards: EN ISO 12100:2010; EN ISO 13854:2019; EN ISO 13857:2019;
motorised: EN IEC 60204-1:2005; EN IEC 61439-1:2011; EN IEC 61439-2:2011.
The EC-declaration of conformity / declaration of incorporation relates exclusively to the machinery or partly
completed machine in the state in which it was placed on the market and excludes components which are
added and/or operations carried out thereafter for instance by the distributor and/or the installer and/or the
final user.
(EN)
Plaats, Datum / Place, Date: Maldegem, 01/01/2021
………………………………..
Dhr. Gino Van Landuyt
Managing Director
00105502
SPECIMEN

ROXELLbv‐Industrielaan13,9990Maldegem(Belgium)
Tel.+3250729172‐[email protected]‐www.roxell.com
ROXELLUSAInc.‐ 720IndustrialParkRoad,AndersonMO64831(USA)
Tel.+14178456065‐[email protected]‐www.roxell.com
ROXELLMalaysia‐No.49,JalanPermata2/KS9,TamanPerindustrianAirHitam,41200Klang,Selangor(Malaysia)
Tel.+60331231767‐[e-mail]‐www.roxell.com
ROXELLРоссия‐ООО«Рокселл»ОГРН1157746055026
125167,Россия,городМосква,Ленинградскийпроспект,дом37,корпус9,помещение653
Телефон:+74959833015‐Адресэлектроннойпочты:info.russi[email protected]‐www.roxell.com
