Royal Sovereign CL-1223 User manual

Royal Sovereign CL-1223
13" Hot and Cold 2-Roller
Pouch Laminator
Instruction Manual

Royal Sovereign International, Inc.
CS-923/1223
LAMINATOR
Owner's Manual
Please read and retain these instructions.
To register your product, please go to www.royalsovereign.com USA.
Click the Customer Support Tab then Registration Tab.
www.royalsovereign.com
Página en Español 9
Page en Français 17

2
SAFETY INSTRUCTIONS
The safety recommendations outlined in this section should be read and understood before operating this machine. When using
this machine follow these basic safety precautions to reduce risk of fire, electric shock or injury. Keep this information for future
reference.
1. To prevent the possibility of a fire or injury, do not allow foreign articles inside the machine.
2. Do not attempt to laminate items that exceed total recommended material thickness.
3. Do not insert pouch film with the back end first. (Front of film: sealed side, Back of film: open side.) This may cause the
pouch to jam the rollers.
4. To prevent the possibility of electric shock, do not immerse the laminator in water or permit liquids inside the machine.
5. Because the laminator creates heat, keep out of the reach of children.
6. Do not cut pouches before inserting them into the laminator. This will cause the laminator to jam.
7. Do not laminate leaves, flower, clothes etc.
8. If the room temperature is low (under 18°C), the ready light may take longer to come on.
9. When unplugging the power plug, grip the plug to pull it out. Pulling the cord may result in electric shock, fire, or damage to
the machine.
10. Do not use the machine if the cord is damaged. This may result in electric shock, fire, or other hazards.
11. Do not place objects on the power cord and do not bend it excessively. This may result in electric shock, fire or other
hazards.
12. When not using the machine for long periods of time, unplug the power cord from the outlet.
13. The machine should be placed near the electrical outlet or the socket-outlet shall be installed near the equipment so that
the outlet is easily accessible.

CS-923/1223
3
CONTENTS
Box Contents 4
Parts 4
Controls 4
Features 4
Operation 5
Troubleshooting 6
Specifications 7
Warranty 8
Contact Information 8
Página en Español 9
Page en Français 17

4
BOX CONTENTS
Laminator
CONTROLS
FEATURES
Hot and Cold Lamination
The laminator can easily be adjusted to handle both hot and cold lamination pouch film.
Temperature Control
Rocker switch settings for different film thicknesses from 3~5 mil.
Ready Light
A green ready light clearly indicates when the machine has reached optimal temperature and is ready to laminate.
Fast speed
Laminates up to 9.8˝(250mm) per minute.
Standby indicator
(Green)
Power Light (Red)
Feed in
Feed out
Anti Blockage System button
Setting control ON / OFF Switch

CS-923/1223
5
OPERATION
The machine is operated by a rocker switch, located at the right hand side of the appliance.
There are 3 positions 3 mil, COLD, and 5 mil.
Hot Lamination
1. Place the machine on a flat, sturdy surface and press the power button to turn on the machine.
2. For hot laminating, the machine will take approximately 3-5minutes to warm- up, select the 80mic for 3mil film setting, hot
laminating can begin when the Green"ready" light come on.
NOTE: Standard temperature setting is based on 20lb/80g/m2copy paper thickness. when laminating thicker materials, the
temperature may not be high enough. in this case, please set rocker switch to 125mic to laminate 5mil film.
3. Place the item to be laminated into the laminating pouch.
4. Insert the pouch film into the front opening of the laminator. Make sure to place the sealed end of the pouch film in first.
5. The document or photo will then automatically feed out the through the back of the machine.
NOTE: Laminated items exiting the machine may be too hot to touch.
6. If the item is not completely laminated, repeat steps 4-5.
NOTE: Laminated items will be hot and will easily bend. To keep the item flat, place on a flat surface and allow to cool.
Before laminating important or unique documents,
always test a pouch through the laminator using a similar document.
Cold Lamination
1. Place the machine on a flat, sturdy surface and press the power button to turn on the machine.
2. For cold laminating, select the cold setting, the green ready light will come on and COLD laminating can begin(please note
you will need adhesive Cold Laminating Pouches). if the machine was previously used in hot mode, allow approximately 25
minutes to cool down.
3. Place the document to be laminated on the adhesive side of the cold film with the document face down, sealed end first.
4. Insert the document to be laminated into the front opening of the machine.
5. Remove paper liner from the cold film slowly while the document is being inserted into the machine.
--Turn the laminator to OFF after use, remove the plug from the power supply

6
TROUBLESHOOTING
Symptom Solution
Motor does not work. Check to make sure machine is plugged in. Check to make sure the power button is
turned on.
Pouches are not laminating correctly. Make sure that the machine is set to the correct hot setting.
The pouch is jammed. Please slide the ABS and pull out the pouch from the front of the machine.
If you are still having complications, please contact Royal Sovereign’s Service Center at 1-800-397-1025.

CS-923/1223
7
SPECIFICATIONS
Model Name CS-923 CS-1223
Power Supply Voltage 120V 60Hz / 220-240V 50Hz
Power Consumption (W) 265W 365W
# of Rollers 2
Laminating Hot Shoe
LED Color
Power/Ready
Machine Color white/gray
Speed 250mm
Maximum Entry Width
9" (230mm) 13" (330mm)
Pouch Mil Thickness
3~5mil (80~125mic)
Adjustable Temperature No
Warm-up Time (Min) 3-5 mins
Cold Lamination Yes
Unit Dimensions
(W x D x H)
13.8 × 5.7 × 2.9 (inch)
350 x 145 x74mm
17.4 × 5.7 × 2.9 (inch)
443 x 145 x 74mm
Unit Weight 1.15kg 1.63kg

8
LIMITED ONE YEAR WARRANTY
This warranty applies to repair or replacement of product found to be defective in material or workmanship for one year from the
date of the original purchase. This warranty is extended only to the original purchaser.
This warranty does not apply to damage resulting from abuse, misuse, or improper maintenance of damage that is attributable to
acts of nature. Royal Sovereign International, Inc. (and its affiliated companies) is not liable for incidental or consequential
damages of any nature. This limitation would not apply if you live in those areas that do not permit the exclusion or limitation of
incidental or consequential damages.
Defective products for warranty repair or replacement cannot be returned without a Return Authorization number. Please go to
www.royalsovereign.com USA-Customer Support Tab to make a request for an Office Product Return Authorization.
Defective products must be returned to Royal Sovereign International Consumer Return Department, freight prepaid, with proof of
purchase and Return Shipping and Handling payment (check or money order). Upon repair or replacement the product will be
returned to the customer.
Return defective product to the following address with a detailed description of the problem. If possible, pack in original carton.
Please prepay shipping charges.
For out of warranty service or frequently asked questions please go to www.royalsovereign.com USA- Customer Support Tab.
For sales of product, parts or accessories please visit us at www.royalfulfillmentcorp.com.
For service or sales please contact your local Royal Sovereign Office:
ROYAL SOVEREIGN INTERNATIONAL, INC. RS CANADA INC.
2 Volvo Drive Rockleigh, NJ 07647 USA 1025 Westport Crescent, Mississauga On L5T 1E8 CANADA
TEL : [phone] FAX : [phone] TEL : [phone] TF # : [phone]
FAX : [phone]
www.royalsovereign.com

Royal Sovereign International, Inc.
CS-923/1223
