Royal Sovereign Fremont 65H User manual

Fremont 65H
Royal Sovereign International Inc.
Owner's Manual
GRAPHIC LAMINATION
PRODUCTS
Please read and retain these instructions.
To register your product, please go to www.royalsovereign.com
www.royalsovereign.com

2
CONTENTS
1. Introduction 3
2. Safety Precautions 4
4. Installation 5
5. Product Identification 7
6. Control Panel 8
7. Using Foot Pedal 9
8. Loading Film 9
9. Threading Film 9
9.1 Laminting 10
9.2 Mounting 10
11. Maintenance 10
12. Troubleshooting 11
10. Adjusting the gap of both rollers 10
13. Specifications 12
14. Warranty 13

Graphic Lamination Products
1. INTRODUCTION
Thank you for choosing a Royal Sovereign laminator. It has been designed and
manufactured to provide years of continuous service.
For complete operating and maintenance information please read this manual
thoroughly. Upon receipt of your laminator, please inspect the box, the machine and all
other contents for shipping damage.
Damage should be brought to the immediate attention of the delivering carrier.
Model Fremont 65H

4
2. SAFETY PRECAUTIONS
Failure to comply with any of the following safety procedures could result in serious injury. Please read the instructions
carefully and keep for future reference.
1. Only a licensed electrician should install wiring and outlet for the laminator.
2. Ensure the unit is plugged into a properly grounded outlet with the correct voltage.
3. Once the air supply is connected to the laminator, make sure the pressure valve is set less than 0.6 MPa (87PSI).
This can be adjusted by the pressure regulating valve which is located inside the right-hand cabinet assembly.
4. Keep hands and clothing (i.e. Neckties) away from rollers. The rollers have pinch points that can trap body parts or
clothing and cause serious injury.
5. Keep flammable and wet objects away from the machine.
6. Place the laminator on a level surface, then adjust the casters to the locked position in order to keep the laminator steady.
7. Avoid excessive sunlight, humidity and extreme temperatures.
8. Ensure the unit is turned off, cooled, and unplugged from the outlet prior to moving and/or repairing.
9. Keep out of reach of children.
10. Only Royal Sovereign authorized maintenance and service technicians should make repairs.
11. Do not attempt to laminate items that exceed total recommended material thickness for the unit.
12. When cleaning the machine, don't use flammable sprays or materials.
13. Do not touch the rollers when they are hot or place foreign objects inside the machine.
14. Do not cover the surface of the machine until the machine has completely cooled.
15. If emergency happen, press emergency switch immediately.
16. Temperature of circumstance: 20°C ± 5°C; humidity of circumstance: < 95%(20°C ± 5°C).
17. Warning - Hazardous Moving Parts – Keep Fingers And Other Body Parts Away.

Fremont 65H
5
3. INSTALLATION
Note: The laminator should be installed by a trained service technician.
The laminator comes fully assembled. Upon arrival, thoroughly inspect the unit. It is imperative that any shipping damage
is reported and a claim is filed with the delivering carrier immediately upon receipt.
The laminator should be located in an area with adequate work space for feeding graphics and lamination materials.
Avoid placing the laminator in a dusty area or near sources of extreme heat or cold.
Once the laminator is in place, lock the casters into position. Always unlock the casters when moving to a different location.
ELECTRICAL REQUIREMENTS
Royal Sovereign recommends that a licensed electrician ensures proper power installation to your laminator in accordance
with electrical codes in your area.
120V UL 230V UL 240V UK
220V EU 220V AU

6
4. INCLUDED WITH LAMINATOR
Thoroughly inspect the parts and the unit. It is imperative that any missing parts are reported and a claim is filed with the
reseller immediately upon receipt of shipment.
Part Name Quantity Picture
Laminator 1
Owner's Manual 1
Spare Motor Fuse - FUSE(50T)
(6.3A) 1
Spare Main Power Fuse - FUSE(65TS)
10A/20A 1
Key 2
Fremont 65H
Royal Sovereign International Inc.
Owner's Manual
GRAPHIC LAMINATION
PRODUCTS
Pleaseread and retain these instr uctions.
Toregister your product, please go to www.royalsovereign.com
www.royalsovereign.com

7
5. PRODUCT IDENTIFICATION
1Film Tension Knob
9Shaft Feeder
2Shaft Release Liner
10 Air Intake
3Emergency Switch
11 Knob Speed Control
4Roller
12 Button
5Safety Sensor
13 Pressure Gauge
6Table Front
14 Pressure Regulating Valve
7Caster
15 Reversing Valve
8Foot Switch
16 Door Lock
17 Gap Adjustment
18 Knob Temp. Control
3
1
2
4
6
8
5
7
9
13
14
15
16
12
11
18
10
10
17
Fremont 65H

8
6. CONTROL PANEL
TEMP. To change the mode from cold to hot or oppositely. Temperature
for hot mode on upper roller is max .
REV To reverse the rollers, press and hold the button.
Speed Rotate the knob to control the roller’s speed from 0 to 6m/min.
Run/Stop To start or stop the rollers.
Pressure gage: To indicate the pressure of top roller from 0 to 1Mpa
Height control crank：To set the
height limit block(*Make sure the
upper roller is in the highest
location).
Height scaleplate: To indicate the
gap of the two laminating rollers.
(145Psi) pressure value.
Pressure regulating valve: To change the pressure of top roller from 0 to
0.6Mpa (87Psi) pressure value.
Reversing valve: To make the top roller go up and down.

Fremont 65H
9
7. USING FOOT PEDAL
Place the foot pedal on the floor in front of the machine. Once all correct settings are displayed,
you may use the foot pedal to operate the laminator for “Hands Free Operation.” To activate
the machine, press the foot pedal once and then release. Repeat to stop the rollers.
8. LOADING FILM
Royal Sovereign films are woundwith the adhesive side facing the inside of the roll
(adhesive in).
Loading laminate to the upper film shaft:
Remove the upper film supply shaft from the laminator and load the laminate through the film shaft. Center the film on
the shaft by referencing the centering markers supplied on the film shaft.
Note the direction of the laminate adhesive on the upper film shaft before loading onto the laminator.
9. THREADING FILM

10
1. Turn the power switch on (“I” position). The power switch is located on the rear left side of the unit.
2. Complete the steps as in the “LOADING FILM” section.
3. Load the roll of material to be laminated onto the bottom film supply shaft. Center with the laminate on the upper
film shaft by using the centering markers supplied on the film shaft.
4. Open the laminator rollers. Please refer to Section 10: Adjusting the space of both rollers.
5. Bring you material on the bottom supply shaft that needs to be laminated over the laminator feed table and slightly
into the open rollers.
6. Run you laminate from your upper supply shaft below the top idle bar and around the top laminator roller
so that it is past the laminator roller nip position.
7. Close the laminator rollers together by using the Reversing Valve.
8. Separate the laminate release liner from the laminate and tape to the upper Release Liner Shaft.
(Please reference 9. THREADING FILM for proper laminator webbing).
·Please Adjust the wheel to Change the roller pressure with different Material for the best Laminating quality.
1. Lay the decaled image face down on a flat surface. Carefully peel back and put a crease along the edge of the release
liner.
2. With the image facing up, align the image onto the board. Press firmly from the center out.
3. Adjust the pressure lever to ensure the proper opening.
4. Flip the image over the upper roller and hold on to the release liner.
5. Press the foot pedal once, and then let it go while slowly pulling the release liner as the board enters the main roller nip.
Press the foot pedal once again when the board has completely exited from the rear of the unit.
Trim the board if necessary.
11. MAINTENANCE
Cleaning the Body of the laminator
1. To clean the machine body, dampen a cloth with water only and gently wipe the machine clean.
10. Adjusting the gap of both rollers
Warning: Make sure the upper roller is at the highest location
when you adjust the crank.
Turn the crank clockwise to make the height limit-block go upward, inversely turn it counterclockwise to make the height
limit-block go downward.
9.1. Laminating
9.2. Mounting
