RS PRO IDM201N User manual


INSTRUCTION MANUAL
IDM201N DIGITAL MULTIMETER
EN FRES

2
TABLE OF CONTENTS
SECTION 1 SAFETY INFORMATION 3
SECTION 2 INTRODUCTION 7
SECTION 3 SPECIFICATIONS 9
3.1 General Specications 10
3.2 Electrical Characteristics 11
SECTION 4 OPERATION 15
4.0 Setting Up The Instrument 16
4.1 Controls And Connectors 16
4.2 Preparation And Caution Before Measurement 20
4.3 Voltage Measurement 20
4.4 Current Measurement 20
4.5 Resistance Measurement 21
4.6 Audible Continuity Test 21
4.7 Diode Check 21
4.8 Capacitance Measurement 22
4.9 Frequency Measurement 22
SECTION 5 MAINTENANCE 23
5.1 Battery Installation Or Replacement 24
5.2 Meter Fuse Replacement 25
5.3 Mains Fuse Replacement 25
5.4 Attaching And Detaching The Carrying Strap 26

3
SECTION 1
SAFETY INFORMATION

4
Safety Information
Read and understand this Instruction Manual completely before using this instrument. Failure to observe the warnings and cautions in this Instruction
Manual may result in injury, death, or damage to the instrument and other equipment or property.
If this instrument is used in a manner not specied in these instructions, the protection provided by the instrument may be impaired.
WARNING
Examine the instrument and probes before use. Do not use the instrument if it is wet or damaged•
When using test leads or probes, keep your fingers behind the finger guards•
Remove the test lead from the instrument before opening the battery cover or instrument case•
Always use the correct terminals, switch position and range for measurements•
Never attempt a voltage measurement with the test leads inserted into the current input terminals•
Verify the instrument is operating correctly by measuring a known voltage before use. If in doubt, have the instrument serviced•
Do not apply more than the rated voltage, as marked on the instrument, between terminals or between any terminal and earth ground•
Do not attempt a current measurement when the open-circuit voltage is above the fuse protection rating•
Only replace a blown fuse with the correct type and rating as specified in this Instruction Manual•
Use caution when measuring voltages above 30V ac rms or 60V dc. These voltages pose a shock hazard•
To avoid incorrect readings that can lead to electric shock, replace the battery as soon as low battery indicator • appears in the display
Disconnect the circuit power and discharge all high-voltage capacitors before making resistance, continuity, diode or capacitance measurements•
Do not use the instrument in a Hazardous Area or around explosive gasses or vapours•
Wear suitable Personal Protective Equipment when working around or near hazardous Live conductors which could be accessible•
When this instrument is powered from a Mains power source, the Protective Conductor Terminal must be connected to Ground•
Before powering this instrument from a mains power source, ensure the mains input voltage selector is set to the correct position•

5
 CAUTION
Disconnect the test leads from the test points before changing the position of the function rotary switch•
Never connect the instrument to a source of voltage with the function rotary switch in Ω/• /A//Hz position
If possible, do not work alone, so assistance can be given if required•
Do not expose the instrument to extremes of temperature or high humidity•
When connecting the test leads to a circuit or device, connect the black lead before the red lead and disconnect the red lead before the black lead•
If the instrument is used near equipment that generates electro-magnetic interference, the display may be unstable or indicate incorrect measurements•
When measuring current using the 10A range, the maximum measurement duration is 30 seconds in any 10 minute period for currents greater than 10A •
The following symbols may appear on the instrument and in this Instruction Manual:
Risk of electric shock
Refer to Instruction Manual
Direct Current (dc)
Equipment protected throughout by double or reinforced insulation
Battery
Fuse
Earth
Alternating Current (ac)
Conforms to applicable EU directives


6

7
SECTION 2
INTRODUCTION

8
2. Introduction
The ISO-TECH IDM 201N Multimeter is a versatile and portable bench-type instrument suitable for workshop and laboratory based engineers and
technicians, as well as eld-service engineers who require a self-powered instrument for maintenance, test or repair activities. The instrument may be
powered from an ac mains supply between 90V ac and 263V ac, or by internal batteries as required. An integral compartment provides stowage space
for test leads, spare batteries and fuses. The instrument uses a 3½ digit (2000 count) backlit Liquid Crystal Display with annunciators, polarity and
automatic decimal point placement. The auto-range function may be disabled for convenience and Maximum/Minimum and data-hold functions can
also be selected if required. The measurement capabilities are as follows:
DC and AC voltages•
DC and AC current•
Resistance and continuity checking•
Capacitance and Diode testing•
Frequency •
Unpacking and Inspection
Unpack the multimeter and check the contents for damage. If any items are damaged or missing, contact the supplier.
The instrument is supplied with the following items:
1. The Digital Multmeter.
2. One pair of Test-leads (one red lead and one black lead).
3. This Instruction Manual.
4. One UK-style mains power cable.
5. One Schuko style mains power cable.
6. One Carrying-strap.
7. One pair of Alligator-clips (One red clip and one black clip)

9
SECTION 3
SPECIFICATIONS

10
3.1 General Specications
Display: 3-1/2 digit (2000 count), full annunciators, automatic polarity indication
Measurement Rate: 1.5 times per second
Over range Indication: OL is displayed for Ω, Hz,  functions. Actual value is shown for A, and V functions
Backlight: Electroluminescent panel
Operating Temperature: 0°C to 50°C
Storage Temperature: -30°C to 70°C (batteries removed)
Temperature Stability: 0.15 x (Spec. Accuracy) per °C, < 18°C or > 28°C
Relative Humidity: Maximum RH 80% for temperatures up to 31°C decreasing linearly to 50% RH at 40°C
Safety: EN (IEC) 61010-1:2001 specications
Maximum Voltage to Earth: 600V dc or ac peak to any terminal
Power Requirements: ac; 90 ~ 264V, 50/60Hz < 10VA, dc; Qty 6 x 1.5V AA LR6 or AM3 battery
Battery Life: 1200 hours without backlight (alkaline) or 80 hours with continuous backlight (alkaline)
Size (mm): 218(W) x 195(L) x 73(H) without carrying strap
Weight: 1.3 Kg without power cord
Mains Fuse: 80mA/250V, FAST, 5x20mm HBC Ceramic
Overload Protection: 1A 600V IR 10KA fuse (Bussmann BBS-1 or equivalent) for μA and mA input
15A 600V IR 10KA fuse (Bussmann KTK 15 or equivalent) for A input
Environment Conditions
The equipment was designed for use in the following environmental conditions:
Indoor use only.•
Maximum Altitude: 2000 meters.•
Installation Category (Measurement Category): IEC 61010-1, 600V CAT II, 300V CAT III.•
Pollution degree: 2•

11
NOTE:
Measurement Category l is for measurements performed on circuits not directly connected to mains. Examples include: Measurements on battery
powered equipment and specially protected (internal) mains-derived circuits.
Measurement Category ll is for measurements on circuits directly connected to the low voltage installation. Examples include: Household appliances,
portable tools and similar equipment.
Measurement Category lll is for measurements performed in the building installation. Examples include measurements on distribution boards,
junction boxes, socket-outlets and wiring and cables in the xed installation.
Measurement Category lV is for measurements performed at the source of the low-voltage installation. Examples include measurements on primary
overcurrent protection devices and electricity meters.
3.2 Electrical characteristics
Accuracy is ±(% reading + number of digits) at 23°C ± 5°C, less than 80% R.H.
(1) DC Volts
Range Resolution Accuracy Over voltage protection
200mV 100µV
± (0.5% + 2d) 1100V dc or
1100Vp-p
2V 1mV
20V 10mV
200V 100mV
600V 1V
Input Impedance: 10MΩ (over 1000MΩ in 200mV range).

12
(2) AC Volts
Range Resolution Accuracy Over voltage protection
200mV 100µV Unspecied
1100V dc or
1100Vp-p
2V 1mV
± (1.5% + 5d) 50Hz to 500Hz
20V 10mV
200V 100mV
600V 1V
Input Impedance: 10MΩ // less than 100pF.
AC Conversion Type: AC conversions are ac-coupled true rms responding and calibrated to the rms value sine-wave input.
(3) Resistance
Range Resolution Accuracy Over voltage protection
200Ω 0.1Ω ±(0.7% + 3d) *1
600V dc or
600V rms
2KΩ 1Ω
±(0.7% + 3d)20KΩ 10Ω
200KΩ 100Ω
2MΩ 1KΩ ±(1.0% + 3d)
20MΩ 10KΩ ±(2.5% + 3d) *2
Open circuit Voltage: -1.3V approx.
*1 < 10dgt rolling.
*2 < 100dgt rolling.
(4) Diode Check
Resolution Accuracy Max. Test Current Max. Open Current
Voltage
Overload protection
10mV ±(1.5% + 5d)
For 0.4V to 0.8V
1.5mA 3V 600V dc
or 600V rms
Internal beeper activates it the voltage of the circuit under test is less than 0.25V.

13
(5) Continuity
The internal sounder activates if the resistance of the circuit under test is less than 20Ω. It will then turn off if the resistance is increased beyond 50Ω.
Response time is approximately 50 msec. Overload Protection: 600V dc/ac rms max.
(6) Capacitance
Range Resolution Accuracy Over voltage protection
2nF *3 1pF ±(1.9% + 20d)
600V dc or
600V rms
20nF 10pF
±(1.9% + 8d)
200nF 100pF
2µF 1nF
20µF 10nF
200µF 100nF
2mF *1 1µF ±(1.9% + 8d) *2
*1 <100 dgt of reading rolling.
*2 The accuracy is specied with the backlight not activated.
*3 For accurate readings, do not use the mains power supply when measuring low-value capacitance.
*4 In order to ensure the best accuracy in measurement of a low value capacitance, note and subtract the stray capacitance
of the open-circuit test leads from subsequent measurements.
(7) Frequency
Range Resolution ** Sensitivity Accuracy Overload protection
2000Hz 1Hz
100mV rms *
0.01% ± 2d 600V rms
20KHz 10Hz
200KHz 100Hz
2MHz 1KHz 250mV rms
20MHz 10KHz 1V rms
* Less than 20Hz the sensitivity is 1.5V rms.
** Max. Sensitivity: <5 Vac rms.

14
(8) DC Current
Range Resolution Accuracy Voltage Burden
200.0μA 0.1µA
±(1.0% + 2d) 800mV max
2000μA 1µA
20.00mA 0.01mA
200.0mA 0.1mA
10A 10mA ±(1.5% + 4d) 1V max
10A Range: 30 seconds maximum for current greater than 10A.
(9) AC Current
Range Resolution Accuracy Voltage Burden
200.0μA 0.1μA
±(1.5% + 5d) 800mV max
2000μA 1μA
20.00mA 0.01mA
200.0mA 0.1mA
10A 10mA ±(2.5% + 5d) 1V max
Frequency Response: 50Hz to 500Hz
10A Range: 30 seconds maximum for current greater than 10A.
AC Conversion Type: AC conversions are ac-coupled true rms responding and calibrated to the rms value sine-wave input.
(10) Auto Power-off (APO)
If the instrument is not used for more than 10 minutes, it automatically turns the power off. The state of the instrument is stored and it can be turned on
again by pressing any button or changing the rotary switch position. If a button is pressed, the LCD displays the saved state; press the Hold button to
disable the hold state. The instrument will alarm 15 seconds before automatically turning power off, but any button press or rotary switch movement will
reset Auto Power-off.
(11) Disable Auto Power-off
To disable the auto power-off function, press and hold any button (except the Hold button) whilst turning on the instrument.

15
SECTION 4
OPERATION

16
4.0 Setting Up The Instrument
Connecting to the Mains power supply
 CAUTION: To avoid instrument damage, check the rear-panel voltage selection switch is set to the Mains power supply voltage in your area
(see below)
Mains supply voltage: Switch setting:
90 to 132V, 50/60 Hz±
198 to 264V, 50/60 Hz
4.1 Controls And Connectors
See Figure 1 for location of controls and connectors of the front panel.
1. Digital Display: The digital display has a 3-1/2 digit LCD readout (maximum reading 2000), with auto polarity, decimal point,
overrange, AC/DC, Ω / ,, MAX.MIN. and units indicators.
2. Rotary Switch: Select the Function and Range as required.
3. COM Input Terminal: Ground input connector.
4. VΩHz Input Terminal: Positive input connector for Volts, Ohms and Diode test, Capacitance and Frequency measurements.
5. mA Input Terminal: Positive input connector for low-current measurement.
6. A Input Terminal: Positive input connector for high-current measurement. The instrument can measure up to 20A. Maximum measurement duration
is 30 seconds in any 10 minute period for currents greater than 10A.
7. Back Light: Press the yellow button to toggle the LCD backlight on or off.
8. Hold Button: Press the HOLD button to toggle the Data Hold mode on or off. In the Data Hold mode, the annunciator is displayed and the display
is frozen. When the hold button is pressed the beeper emits a tone and the value being read is held on the display. In the MIN MAX
Recording mode, press the Hold button to freeze the readings. Press the Hold button again to release the hold function for
normal recording.

17
9. Function Button (Blue): Press this button to toggle between AC and DC for current measurements, or to toggle between Resistance and
Continuity Measurements, Frequency or ADP measurements.
10. Min Max Button: Press the MIN MAX Button to enter the MIN MAX Recording mode. The minimum and maximum values are then updated by the
present input. In the MIN MAX Recording mode, the minimum or maximum readings are stored in memory. The beeper emits a
tone when a new minimum or maximum value is over 2000 counts. In the MIN MAX Recording mode, press the Hold button to
stop the recording of readings and freeze the display. Press the Hold button again to restart recording.
11. Range button (Manual Range): The “Range” button is pressed to select manual ranging and to change ranges. When the “Range” button is
pressed once, the Autorange indicator turns off. Press the “Range” button to select the most appropriate range to
suit the measurement being made. Press the “Range” button and hold for 2 seconds to return to Autorange mode.
See Figure 2 for location of controls and connectors of rear panel.
1. Mains Power ON/OFF Switch: Push to the “1” position to turn on the a.c. power supply. Push to the “0” position to turn off the a.c. power supply.
2. Mains Power Connector: Input connector for mains power cable.
3. Mains Fuse: Provides protection for equipment during malfunction or overload.
4. Mains Voltage Selector: Permits the selection of various mains supply voltages.
CAUTION: Set the MAINS VOLTAGE SELECTOR to the correct voltage before operating the instrument from a mains power supply.

18
Figure 1. Controls and Connectors
10 11
9
874
5
3
2
1
6

19
Figure 2. Controls and Connectors
34
2 1

20
4.2 Preparation And Caution Before Measurement
1. Wait 30 seconds after turning on the instrument before making a measurement.
2. Set the rotary switch to the required function before connecting the probes to the circuit or equipment under test. Remove the test leads from the
circuit or equipment under test before changing the rotary switch position.
4.3 Voltage Measurement
1. Connect the BLACK test lead to the COM terminal and the RED test lead to the “VΩHz” terminal. Set the Rotary switch to the a.c. V
or d.c. V position.
3. Connect the test leads across the source or load under test. The polarity of the RED lead connection will be indicated at the same time as the
voltage is displayed. A buzzer will sound if the input voltage exceeds the maximum input voltage in either auto or manual range modes. In an
over-range condition, the MSD (most-signicant digit) of the LCD display ashes and the three least-signicant digits will indicate zero.
4.4 Current Measurement
 CAUTION: The instrument can measure up to 20A, but for currents greater than 10A the maximum measurement duration is 30 seconds
in any 10 minute period.
1. When measuring current of less than 200 mA, connect the BLACK test lead to the COM terminal and the RED test lead to the “mA” terminal.
When measuring current greater than 10A, connect the RED test lead to the “A” terminal. The instrument can measure up to 20A, but maximum
measurement duration is 30 seconds in any 10 minute period for currents greater than 10A.
2. Set the rotary switch to the range required (200μA - 200mA) for the current to be measured. Use the function button to select ac or dc mode
as required.
NOTE: If the current to be measured is not known, start at the highest range and reduce the range as required.
3. Connect the test leads in series with the circuit to be measured.
