Ruijie RG-RSR77 Series User manual

RG-RSR77 Series Router
Quick Installation Guide V1.04

Copyright statement
Ruijie Networks©2000-2013
Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification,
transmission, translation or commercial use of this document or any portion of this document, in any form or by any means,
without the prior written consent of Ruijie Networks is prohibited.
, , , , ,
, ,, ,
, , are registered trademarks of Ruijie Networks.
Counterfeit is strictly prohibited.
Exemption statement
This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain
the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will
not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.

Preface
Thank you for using our products. This manual will guide you through the installation of the router.
Scope
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed
that the users are already familiar with the related terms and concepts.
Obtaining Technical Assistance
Ruijie Networks website: http://www.ruijienetworks.com
Online customer services: http://webchat.ruijie.com.cn
Customer service center: http://www.ruijie.com.cn/service.aspx
Customer services hotline: [phone]
BBS:
http://support.ruijie.com.cn
Customer services email: [email protected]
Related Documents
Documents Description
Configuration Guide Describes network protocols and related mechanisms that supported by the
product, with configuration examples.
Command Reference Describes the related configuration commands, including command modes,
parameter descriptions, usage guides, and related examples.
Hardware Installation and Reference Guide
Describes the functional and physical features and provides the device installation
steps, hardware troubleshooting, module technical specifications, and
specifications and usage guidelines for cables and connectors.
Documentation Conventions
The symbols used in this document are defined as follows:
This symbol brings your attention to some helpful suggestions and references.
This symbol means that you must be extremely careful not to do some things that may damage the switch or cause data
loss.

·
Contents
SAFETY WARNING .........................................................................................................................................................2
APPLICABLE SCOPE......................................................................................................................................................4
PRODUCT OVERVIEW....................................................................................................................................................4
SAFETY PRECAUTIONS FOR MOVEMENT..................................................................................................................4
PREPARATIONS BEFORE INSTALLATION..................................................................................................................5
INSTALLATION REQUIREMENTS..................................................................................................................................6
CHECKING BEFORE INSTALLATION ...........................................................................................................................7
FAN...................................................................................................................................................................................7
POWER SUPPLY .............................................................................................................................................................7
SYSTEM GROUNDING....................................................................................................................................................9
STATIC ELECTRICITY PREVENTION..........................................................................................................................10
COMMON TROUBLESHOOTING PROCEDURES.......................................................................................................10

·
Safety Warning
Power Supply Safety Warning
High leakage current, earth connection essential before connecting power supply.
Be sure that all cables are connected to the sockets that are grounding correctly.
There is more than one power input. Be sure that all power cables are pulled out
before you power down the system.
Static Electricity Protection Warning
Electrostatic sensitive device inside. Please wear the anti-ESD ring before
handling.
Laser Safety Warning
CLASS 1 LASER PRODUCT
Directly looking at the optical interfaces or fibers may damage your eyes.
Fan Safety Warning
Hazardous moving parts, keep fingers and body parts away.
Transportation Safety Warning
Weight may exceed 80Kg.
Don’tusethishandletoliftthechassis.
Heavy moving parts，Guard against slide when plugging in or out.
Maintenance Warning

·
Users are not allowed to repair the parts within the device. Please contact qualified
technical personnel if necessary.

·
Applicable Scope
It is intended for the users that have some experience in installing and maintaining network hardware and want to learn the above
information. At the same time, it is assumed that the users of this router are familiar with the related terms and concepts of Ethernet.
Product Overview
Designed with the distributed modular structure, RG-RSR77 series routers have the high-processing capability and greater access
density and support the dual master control warm backup and power redundant backup to provide users with abundant optional
modules. RG-RSR77 series routers can serve as core routers in the large-scale enterprise networks or convergence layer routers in
the large-scale industry networks.
RG-RSR77 series routers adopt the high-performance microprocessor technology and use the network operating system platform of
proprietary intellectual property rights developed by Ruijie Networks Co. Ltd. RG-RSR77 series support the BGP routing protocol, IP
multicast protocol and high forwarding rate and offer abundant QoS features, providing the comprehensive network solutions for users
in the industry such as telecom, private network, ISP, finance, taxation, police and railway and users in large/medium-scale enterprise.
RG-RSR77 series includes three routers: RG-RSR7704, RG-RSR7708 and RG-RSR7716.
Safety Precautions for Movement
RG-RSR77 series routers are large and heavy. When you handle them, please pay attention to the following requirements:
Turn off all power supplies and unplug all power cables before you move the routers.
Plug out power, fan and service modules to reduce the chassis weight before moving the router.
At least two people are needed to move the router. Do not attempt to move the router by one person only. Keep balance when
moving the router.
Grasp the bottom the chassis. Do not grasp the power system handle, fan handle and the back panel handle when you carry the
chassis. Those handles are used to install and remove corresponding parts, and they are unable to bear the whole chassis
weight. For the RSR7708 and RSR7716, you can use the two handles at the top of the chassis to carry.
The whole router weight may be higher than 80Kg during the movement.
To correctly move the RG-RSR77 series router, see the Figures (Note: In order to avoid the chassis weight increase and the
service card damage, do not insert the service cards when you move the chassis.)

·
Figure-1 Correctly Move the RG-RSR7704 Router Figure-2 Correctly Move the RG-RSR7708/16 Router
Preparations Before Installation
Temperature and Humidity Requirements
Operating Temperature 0ºC to 45ºC
Storage Temperature -40ºC to 70ºC
Relative Humidity 10% to 90%
Static Discharge Damage Prevention
Proper grounding of the device and floor.
Dust-free room.
Appropriate humidity.
Do not wear loose clothes or any other things that may be caught by the chassis during installation and maintenance, for instance,
necklace and ring.
Do not let any clothes touch a circuit board. An anti-static wrist strap can only prevent static electricity on humans from damaging
the circuit board, but cannot prevent static electricity on clothes.
Hold a circuit board by its edges. Do not touch any components or the PCB.
Always wear an anti-static wrist strap when you touch any module. For details, see Static Electricity Prevention.
System Grounding Requirements
A good grounding system is the basis for the stable and reliable operation of routers. It is the chief condition to prevent lightning stroke
and resist interference. Please carefully check the grounding conditions on the installation site according to the grounding
requirements, and perform grounding properly as needed. For details, see System Grounding.
Power Requirements
AC input voltage: 90VAC—264VAC, 47-63Hz
DC input voltage: -36VDC—-72VDC
RG-RSR7704 AC input power: no less than 500 W

·
RG-RSR7708 AC input power: no less than 1000 W
RG-RSR7716 AC input power: no less than 1500 W
RG-RSR7704 DC input power: no less than 500 W
RG-RSR7708 DC input power: no less than 1000 W
RG-RSR7716 DC input power: no less than 1500 W
Requirements of Installation Tools
Type Tools Remarks
Claw hammer and pliers Unpack wooden case and transportation
case.
Cross screwdriver, straight screwdriver, and
spanner
Disassemble chassis, power supply, fan
and modules.
Power supply cables, network cables, optical
fibers and distribution cables
Connect the interfaces.
Ruler, long tapeline, and marker pen Measure the installation position.
Common Tools
Bolts, diagonal pliers, and straps Mount and fix the chassis.
Anti-static tool Prevent static electricity.
Special Tools Wire stripper, and crimping pliers Create network cables and grounding
cables.
Multimeter Test power supply and DC resistance.
Meter 500V megohmmeter Test the insulation resistance and grounding
resistance.
The tools are customer supplied.
Installation Requirements
Place the router on the right place.
If you plan to install RG-RSR77 series router in a cabinet, verify that the cabinet meets the following conditions:
Install the router in an open cabinet as much as possible. If you install the router inside a closed cabinet, please make sure that
the cabinet has a good ventilation and heat dissipation system.
Make sure that the cabinet is firm enough to bear the weight of RG-RSR77 series router and its installation accessories.
Make sure that the dimensions of the cabinet spare certain space for the installation of the front, rear, left and right panels of
RG-RSR77 series router for the sake of heat dissipation.
The cabinet should be properly grounded.
Ventilation Requirements: Figure-3 shows the ventilation of RG-RSR77 series router. You must ensure that sufficient spacing is
reserved at the ventilation openings to ensure the normal working of ventilation. After various cables have been connected, they
should be arranged into bundles or placed on the cabling rack, to avoid blocking the air inlets.
For RG-RSR77 series router ventilation, see the Figure-3:

·
Figure-3 Ventilation of RG-RSR77 Series
Checking Before Installation
Before powering on RG-RSR77 series router, make sure that:
The fan meets the requirements of current device. For details, see Fan.
The power system is suitable. For details, see Power.
The power system is fastened with screws properly.
Do not power on the system or do maintenance by one person when the system is powered on.
There is no potential risk in the operating area. For example, the power is not grounded; the power is not grounded reliably; or the
ground is wet.
Keep the router away from wet or liquid.
Be aware of the emergent power switch in the room. Once an accident occurs, shut down the power switch.
All the power systems are powered off when necessary.
Power cords are closely connected to the power module.
Power cords are long enough.
The rated current of power outlet is not larger than 16A and the power outlet is grounded well.
Each power module is supplied by a power socket.
Fan
RG-RSR77 series routers use standard fans for heat dissipation.
Power Supply
Specification
RG-RSR77 series routers can use the following power supplies:
RG-PA300I AC power supply

·
Model RG-PA300I
Rated Input Value 100 VAC to 240 VAC; 50/60Hz; 6 A
Rated Out Value 12 V/30 A; 12 VFAN/6 A
Maximum Power 400 W
RG-PD650I DC power supply
Model RG-PD650I
Rated Input Value -36 VDC to 72 VDC : 25 A Max
Rated Out Value +12 VDC : 0-48.2 A; 12 VFAN :0-6A
Maximum Power 650 W
Precaution:
Use 110 VAC or 220 VAC as the AC input power voltage; use -48 VDC as the DC input power voltage.
The AC and DC power modules are hot swappable.
Once the AC power is powered on, the IN and OUT LEDs on the panel turn solid green.
To prevent damage caused by rapid power cycle to parts, do not power on RG-RSR77 series router within 30 seconds after
power off.
Use the corresponding cables to connect power modules.
It is recommended to clear the dust filter once per three months.
Users should select power module according to the total consumption power of purchased modules, and 20 percent of maximum
power consumption should be reserved before you select the appropriate number of power modules.
Modules of RG-RSR77 Series Router Maximum Power Consumption (W)
RSR7704-SRCMI 45
RSR7704-FAN 40
RSR7708-SRCMI 45
RSR7708-FAN 60
RSR7716-SRCMI 45
RSR7716-FAN 80
RSR77-SIP1 25
RSR77-SIP2 25
FNM-4GE-1 25
FNM-2CPOS-STM1 30
FNM-4POS-STM1 30
NME-1POS-STM1 12
DNME-8E1/CE1 15
NME-6FE 12
NME-1ATM-STM1 12
NME-4HS 12
DNME-SEC 6
DFNM-8GE 80
DFNM-2XFP 80
FNM-8GE 45
FNM-2XS 45
FNM-1CPOS-STM16/4CPOS-STM4 50

·
DFNM-32GT/16SFP 100
DFNM-48SFP 110
For higher reliability, it is recommended to use the 1+1 dual power system redundant mode in the RSR7704 and the N+1 power
system redundant mode in the RSR7708 and RSR7716 when using the AC power supply module and use 1+1 dual power
system redundant mode in the RSR7704 and RSR7708 and the N+1 or N+N redundant mode in the RSR7716 when using the
DC power supply module.
Please pay attention to the following when the DC power supply module is used:
1) Do not touch the DC power module when it is working.
2) Input power supply must be provided with the insulation-reinforced power supplies or batteries.
3) Power supply input polarities cannot be reversed.
System Grounding
Grounding Requirements
An outstanding grounding system is the basis of stable and reliable operation of RG-RSR77 series router and the essential
condition for prevention of lightning and interference.
For the safety of humans and routers, good grounding is necessary for the router. The electric resistance between the router
chassis and the ground must be less than 0.1 ohm.
Grounding description
There are two kinds of ground in a machine room: safe ground and lightning prevention ground.
Safe ground guarantees the safety of humans and routers. A typical example is the AC protection ground of 3-core socket of
power supply bank.
Figure-4 3-core Socket of Power Supply Bank
Lightning prevention ground prevents lightning shock. The lightning prevention system of general equipment is a separate
system composed of lightning rod, down-conductor and grounding system.
Some machine room has only safe ground without lightning prevention ground or a safe ground sharing lightning prevention
ground.
Chassis grounding pole
There is a grounding pole on the rear of RG-RSR77 series router, as shown in the Figure-5.

·
Figure-5 Grounding Pole on the Rear of RG-RSR77 series router
Grounding Method
Connect the grounding pole on the chassis back of RG-RSR77 series router to the grounding pole or grounding bar of the
machine room through grounding cables.
Connect power modules to the socket through 3-core AC cables. The AC protection ground of the socket is also connected to the
grounding pole or grounding bar of the machine room. This method is specific for RG-RSR7704/RSR7708/RSR7716 chassis
using AC power modules.
If the DC power module is used, you need to connect the protection ground of this power supply to the grounding pole or
grounding bar of the machine room through grounding cables.
Router Grounding Steps
Release the nut on the grounding pole of the rear chassis and DC power supply module.
Lock the terminal of the grounding cable to the grounding pole.
Tighten the nut.
Connect the other end of the grounding cable to the grounding pole or grounding bar of the machine room.
Static Electricity Prevention
To avoid the damages of static electricity to the internal parts of routers, note that:
Static electricity prevention measures are taken in the sites where routers are installed.
Wear anti-static wrist strap to install various router parts, especially when you may touch circuit boards with hands.
Grasp the edge of modules. Do not touch the parts or printed circuits directly.
The anti-static wrist strap is shipped with RG-RSR77 series router, which is used as follows:
Stretch out the hand into the anti-static wrist strap.
Lock the wrist strap and make sure that the metal part of the anti-static wrist strap is in good touch with skin.
Insert the anti-static wrist strap in the anti-static wrist strap jack of the router chassis or clip on the grounding pole of the chassis.
The anti-static wrist strap jack is located on the front panel of the chassis marked with yellow ESD.
The anti-static wrist strap is grounded well and the DC electric resistance between the body and the ground is in the range of 1 to
10 mega ohm.
Common Troubleshooting Procedures
Fault 1: The AC power module does not work.
Fault Description
The RDY LED of each line card is OFF, the Power LED of the fan tray is OFF, and the fan does not work.
The LED on the panel of the power module is OFF. The fan does not work.

·
Troubleshooting
1. Place the switches of all the power modules to OFF. Check if the wire connection of the cabinet is correct.
2. Check if the cables of the cabinet have been correctly connected. Check whether the power cables are tightly connected to the
cabinet power sockets and power modules.
3. Check whether the power modules are installed correctly. If necessary, check whether the connectors on the backboard of the
power system are tightened.
Fault 2: An exception occurs to the LEDs when line cards are powered on.
Fault Description
The RDY LED of the line card is OFF, flashing, or RED.
Troubleshooting
1. Check if the line card is firmly inserted. If not, install the line card again and ensure that it is inserted into slot before you tighten the
fastening screws.
2. If the line card still does not work, check if the connector of the slot on the backplane is loose. If yes, insert the board to another slot
for a try.
3. If the slot and connection are not the cause, return the line card for repair.
Fault 3: The LED is abnormal after a line card works for some time.
Fault Description
The RDY LED of the line card is OFF or RED. The fault remains after restart.
Troubleshooting
1. Check if the card gets loose. If so, install the line card again and ensure that it is inserted into slot before you tighten the fastening
screws.
2. If the line card still does not work, check if the connector of the slot on the backplane is loose and check if the guide rail of the slot is
deformed. If so, insert the board to another slot for a try.
3. If the slot and connection are not the cause, return the line card for repair.
Fault 4: The LED of the main control board is abnormal.
Fault Description
The LED of the main control board becomes abnormal after the board is powered on or works for some time. For example, the System
LED is flashing or OFF.
Troubleshooting
1. Check if the main control board gets loose. If so, install the main control board again and ensure that it is inserted into slot, before
you tighten the fastening screws.
2. If the line card still does not work, check if the connector of the slot on the backplane is loose and check if the guide rail of the slot is
deformed. If yes, insert the board to another slot for a try.
3. If the slot and connection are not the cause, return the main control board for repair.
Fault 5: The fan tray does not work or an exception occurs to the LED.
Fault Description
After the system starts, the fans in the fan tray do not work or the Power LED is OFF, and the FAN LED on the main control board is
red or OFF.
Troubleshooting

·
1. Check if the connection between the fan tray and the backplane is secure and if the connector gets loose.
2. If the connection is secure, replace the fan tray.
Fault 6: The serial port console has no output.
Fault Description
After the system starts, the serial port console does not display any information.
Troubleshooting
1. Check whether the serial port cables are connected correctly and whether the connected serial port is identical with that configured
on the super terminal.
2. Check whether the configuration of the serial port on the super terminal is the same as that on the router. If not, modify the serial
port configuration parameters.
3. If there is still no serial port printed information, please contact Ruijie Customer Service Department for technical support.
Fault 7: The serial port console outputs illegible characters.
Fault Description
The serial port console outputs illegible characters.
Troubleshooting
1. Check whether the serial port cables are connected correctly and whether the baud rate settings of the connected serial port match
those of the super terminal.
2. Check whether the serial port cable is standard.
If above mentioned methods still do not solve your problems, please contact Ruijie Networks for technical assistance.
