Ruijie RG-S6930-2C Installation and operating manual

Ruijie RG-S6930-2C Switch
Hardware Installation and Reference Guide
Document Version: V2.0
Date: September 12, 2023
Copyright © 2023 Ruijie Networks

Copyright
All rights are reserved in this document and this statement.
Without the prior written consent of Ruijie Networks, no organization or individual is permitted to reproduce,
extract, back up, modify, or distribute the content of this document in any manner or form. It is also prohibited to
translate the document into other languages or use any or all parts of it for commercial purposes.
and trademarks are owned by Ruijie Networks.
All other trademarks or registered trademarks mentioned in this document are owned by their respective owners.
Disclaimer
The products, services, or features that you purchase are subject to commercial contracts and terms. It is
possible that some or all of the products, services, or features described in this document may not be available
for purchase or use. Unless agreed upon otherwise in the contract, Ruijie Networks does not provide any explicit
or implicit statements or warranties regarding the content of this document.
The content of this document is subject to constant change due to product version upgrades or other reasons.
Thus, Ruijie Networks reserves the right to modify the content of the document without prior notice or prompt.
This manual serves solely as a user guide. While Ruijie Networks endeavors to ensure the accuracy and
reliability of the content when compiling this manual, it does not guarantee that the content of the manual is free
of errors or omissions. All information contained in this manual does not constitute any explicit or implicit
warranties.

I
Preface
Intended Audience
This document is intended for:
Network engineers
Technical support and servicing engineers
Network administrators
Technical Support
Ruijie Networks website: https://www.ruijienetworks.com/
Online support center: https://ruijienetworks.com/support
Case portal: https://caseportal.ruijienetworks.com
Community: https://community.ruijienetworks.com
Email support: [email protected]
Live chat: https://www.ruijienetworks.com/rita
Conventions
1. Signs
The signs used in this document are described as follows:
Danger
An alert that contains important safety instructions. Before you work on any equipment, be aware of the
hazards involved and be familiar with standard practices for preventing accidents.
Warning
An alert that calls attention to important rules and information that if not understood or followed can result in
data loss or equipment damage.
Caution
An alert that calls attention to essential information that if not understood or followed can result in function
failure or performance degradation.
Note
An alert that contains additional or supplementary information that if not understood or followed will not lead to
serious consequences.
Specification
An alert that contains a description of product or version support.

II
2. Notes
The manual provides configuration information, including models, port types, and command line interfaces, for
reference purposes only. In the event of any discrepancy or inconsistency between the manual and the actual
version, the actual version shall take precedence.

I
Contents
Preface.................................................................................................................................................. I
1 Overview ........................................................................................................................................... 1
1.1 About the RG-S6930-2C............................................................................................................1
1.2 Component Modules..................................................................................................................1
1.3 Chassis ......................................................................................................................................2
1.3.1 Appearance....................................................................................................................2
1.3.2 LEDs ..............................................................................................................................5
1.3.3 Ports...............................................................................................................................6
1.3.4 Cooling...........................................................................................................................7
1.3.5 Technical Specifications.................................................................................................7
1.3.6 Asset Tag......................................................................................................................10
1.4 Expansion Modules .................................................................................................................11
1.4.1 M6900-36CQ18DC-CES .............................................................................................11
1.4.2 M6900-72CQ-CES.......................................................................................................14
1.5 Power Module..........................................................................................................................16
1.5.1 RG-PA1600II-F.............................................................................................................17
1.6 Fan Module..............................................................................................................................19
1.6.1 M2EFAN II-F ................................................................................................................19
1.7 Cables......................................................................................................................................20
1.7.1 Console Cable .............................................................................................................20
1.7.2 Ethernet Cable.............................................................................................................21
1.7.3 Power Cord..................................................................................................................22
1.7.4 Grounding Wire............................................................................................................23

II
1.8 Pluggable Modules..................................................................................................................24
2 Preparing for Installation................................................................................................................. 25
2.1 Safety Guidelines.....................................................................................................................25
2.1.1 General Precautions....................................................................................................25
2.1.2 Chassis-Lifting Guidelines...........................................................................................25
2.1.3 Electricity Safety ..........................................................................................................25
2.1.4 Preventing ESD Damage.............................................................................................26
2.1.5 Laser Safety.................................................................................................................26
2.1.6 Storage Guidelines ......................................................................................................26
2.2 Site Requirements...................................................................................................................27
2.2.1 Floor Loading...............................................................................................................27
2.2.2 Airflow...........................................................................................................................27
2.2.3 Space...........................................................................................................................27
2.2.4 Temperature.................................................................................................................27
2.2.5 Humidity.......................................................................................................................27
2.2.6 Cleanliness...................................................................................................................28
2.2.7 System Grounding.......................................................................................................29
2.2.8 Preventing Electromagnetic Interference ....................................................................30
2.2.9 Surge Protection..........................................................................................................30
2.3 Rack-Mounting Guidelines.......................................................................................................30
2.4 Tools ........................................................................................................................................31
2.5 Unpacking the Switch..............................................................................................................32
2.5.1 Verifying the Shipped Content.....................................................................................32
2.5.2 Unpacking the Container.............................................................................................32

III
3 Installing the Switch ........................................................................................................................ 34
3.1 Installation Procedure..............................................................................................................35
3.2 Installing the Rack....................................................................................................................36
3.2.1 Installation Guidelines..................................................................................................36
3.2.2 Procedure.....................................................................................................................36
3.3 Installing the Chassis...............................................................................................................37
3.3.1 Installation Guidelines..................................................................................................37
3.3.2 Mounting the Brackets.................................................................................................37
3.3.3 Mounting the Chassis on the Rack..............................................................................37
3.4 Installing the Protective Grounding Wire.................................................................................38
3.4.1 Installation Guidelines..................................................................................................38
3.4.2 Procedure.....................................................................................................................38
3.5 Installing and Removing the Fan Module................................................................................39
3.5.1 Installing the Fan Module.............................................................................................39
3.5.2 Removing the Fan Module...........................................................................................40
3.6 Installing and Removing the Expansion Module .....................................................................40
3.6.1 Installing the Expansion Module..................................................................................40
3.6.2 Removing the Expansion Module................................................................................41
3.7 Installing and Removing the Power Module............................................................................42
3.7.1 Installing the Power Module.........................................................................................42
3.7.2 Removing the Power Module.......................................................................................44
3.8 Installing and Removing the Pluggable Module......................................................................45
3.9 Verifying Installation.................................................................................................................45
3.10 Connecting the Power Cord ..................................................................................................46

IV
4 Commissioning................................................................................................................................ 46
4.1 Setting Up the Configuration Environment..............................................................................46
4.2 Powering on the Device...........................................................................................................48
4.2.1 Checklist Before Power-on..........................................................................................48
4.2.2 Power-on......................................................................................................................49
4.2.3 ChecklistAfter Power-on .............................................................................................49
5 Monitoring and Maintenance........................................................................................................... 50
5.1 Monitoring................................................................................................................................50
5.1.1 Monitoring the LEDs....................................................................................................50
5.1.2 Running the CLI Commands.......................................................................................50
5.2 Maintenance ............................................................................................................................50
5.2.1 Replacing the Power Module.......................................................................................50
5.2.2 Replacing the Fan Module...........................................................................................51
5.2.3 Replacing the Lithium Battery......................................................................................51
5.2.4 Replacing the Fuse......................................................................................................51
6Troubleshooting ............................................................................................................................ 52
6.1 Flowchart..................................................................................................................................52
6.2 Common Issues.......................................................................................................................53
6.2.1 Forgetting Login Password..........................................................................................53
6.2.2 AC Power Module Failure............................................................................................53
6.2.3 Fan Module Not Rotating.............................................................................................53
6.2.4 No Output on the Console...........................................................................................53
6.2.5 Garbled Output on the Console...................................................................................53
6.2.6 Optical Port Linkdown..................................................................................................54

V
7Appendix......................................................................................................................................... 54
7.1 Labeling Process.....................................................................................................................54
7.1.1 Hand Writing on Labels................................................................................................54
7.1.2 Pasting Labels .............................................................................................................54
7.1.3 Label Contents.............................................................................................................55
7.2 Connectors and Media.............................................................................................................56
7.2.1 100BASE-TX/10BASE-T Port......................................................................................56
7.2.2 1000BASE-T Port ........................................................................................................56
7.3 Surge Protection......................................................................................................................58
7.3.1 Installing an AC PowerArrester...................................................................................58
7.3.2 Installing an Ethernet Port Arrester..............................................................................59
7.4 Site Selection...........................................................................................................................61
7.5 Recommended Cabling...........................................................................................................61

Hardware Installation and Reference Guide Overview
1
1 Overview
1.1 About the RG-S6930-2C
The RG-S6930-2C switch is a core switch featuring high-performance, high-density, and large-buffer launched
by Ruijie Networks for data centers and high-end campuses. The RG-S6930-2C switch adopts a flexible
modular design with 100GE/200GE expansion modules and diverse data center features, which can be
deployed as the data center gateway for MAN and DCI scenarios. It can be used with Ruijie’s RG-N18000-X
and RG-S6500 switches for a high-performance and high-reliability data center network.
Table 1-1 RG-S6930-2C Overview
Chassis
100GE
QSFP28
Ports
200GE
QSFP56
Ports
Expansion
Module
Slots
Power
Redundancy
Fan
Redundancy
RG-S6930-2C
N/A
N/A
2
2+2
7+1
M6900-36CQ18DC-
CES
32
18
N/A
N/A
N/A
M6900-72CQ-CES
72
N/A
N/A
N/A
N/A
Note
The product images involved in this manual are for indicative purpose only. The appearance is subject to the
actual equipment.
1.2 Component Modules
The RG-S6930-2C adopts the modular design. Compliant with industry standards, the design differentiates
modules and integrates module interfaces to ensure an integrated system with independent function modules.
Table 1-2 Component Modules
Chassis
Expansion Module
Power Module
Fan Module
RG-S6930-2C
M6900-36CQ18DC-
CES
RG-PA1600II-F
M2EFAN II-F
M6900-72CQ-CES

Hardware Installation and Reference Guide Overview
2
Caution
Different power modules are interchangeable. That is, the switch allows concurrent AC and High-voltage
DC (HVDC) input. For example, input 1 uses mains electricity (AC power) and input 2 use Uninterrupted
Power Supply (UPS) HVDC power.
Different expansion modules are not interchangeable.
1.3 Chassis
The RG-S6930-2C hardware system consists of a chassis, a power supply system, and a cooling system.
Power supply system: provides four power module slots and supports 2+2 power redundancy.
Cooling system: provides eight fan module slots and supports 7+1 fan redundancy.
Expansion module: provides two expansion module slots and supports two models.
1.3.1 Appearance
1. Appearance
Figure 1-1 Front View of the RG-S6930-2C

Hardware Installation and Reference Guide Overview
3
Figure 1-2 Rear View of the RG-S6930-2C
2. Structure
Figure 1-3 Front Panel Structure
Table 1-3 Front Panel Components
No.
Component
1
Mounting bracket (optional cable management bracket)
2
FAN status LED
3
System status LED
4
Power status LED

Hardware Installation and Reference Guide Overview
4
5
ID LED
6
Management port LINK LED
7
Management port
8
Management port ACT LED
9
Console port
10
USB port
11
FUNC button
12
Switching port status LED
13
100GE QSFP28 port
14
200GE QSFP56 port
15
Asset tag
16
Ground for ESD-preventive wrist strap
Figure 1-4 Rear Panel Structure
Table 1-4 Rear Panel Components
No.
Component
1
Ground for ESD-preventive wrist strap
2
Power module slot
3
Fan status LED
4
Fan module slot
5
Grounding stud

Hardware Installation and Reference Guide Overview
5
1.3.2 LEDs
Table 1-5 LEDs
Silkscreen
Label
LED
Description
SYS
System status
LED
Solid green: The system is operating normally.
Blinking green: The system is starting up.
Solid red:
○The system (including all modules) is not functioning properly.
○At least two fan modules are not installed.
○Three power modules are not installed or not connected with
the AC power cord.
○The temperature exceeds the limit and the switching service
resets.
Solid yellow:
○The temperature reaches the threshold.
○A fan module is not installed.
○One or two power modules are not installed or not connected
with the AC power cord.
Off: The system is not receiving power or not operating even after
receiving power.
PSU
Power status
LED
Solid green: The power module is operating normally.
Blinking green: The power module is starting up.
Solid red: Three power modules are not installed or not connected
with the AC power cord.
Solid yellow: One or two power modules are not installed or not
connected with the AC power cord.
Off: The system is not receiving power or not operating even after
receiving power.
FAN
Fan status LED
Solid green: The fan module is operating normally.
Blinking green: The fan module is starting up.
Solid red:
○The system (including all modules) is not functioning properly.
○At least two fan modules are not installed.
○The temperature exceeds the limit and the switching service
resets.
Solid yellow:
○The temperature reaches the threshold.
○A fan module is not installed.
Off: The system is not receiving power or not operating even after
receiving power.

Hardware Installation and Reference Guide Overview
6
Silkscreen
Label
LED
Description
ID
Locating LED
Locating is enabled.
Locating is disabled (default).
LINK/ACT
Management
port LED
LINK solid yellow: The port has made a successful 10/100 Mbps link.
LINK solid green: The port has made a successful 1,000 Mbps link.
LINK off: No link is detected for the port.
ACT blinking yellow: The port is sending and receiving traffic at
10/100 Mbps.
ACT blinking green: The port is sending and receiving traffic at 1,000
Mbps.
ACT off: The port is not sending or receiving traffic.
1.3.3 Ports
Table 1-6 Ports
Port
Connector Type
Description
Accessory
Management port
RJ45
The management port is used to
set up the onsite or remote
configuration environment.
Standards compliance:
IEEE802.3ab
Working mode: 10/100/1000
Mbps with auto-negotiation
and full-duplex
CAT5 or higher cable
USB port
USB
The USB port is connected with a
USB flash drive for configuration
backup and firmware upgrade.
USB 2.0
FAT32 file format
USB 2.0 flash drive
Console port
RJ45
The console port is connected to a
console for onsite configuration.
Standards compliance: RS-
232
Working mode: Duplex
Universal Asynchronous
Receiver/Transmitter (UART)
Baud rate:
○Range: 9,600 bit/s to
115,200 bit/s
○Default value: 115,200
bit/s
Console cable

Hardware Installation and Reference Guide Overview
7
1.3.4 Cooling
The S6930-2C adopts the front-to-rear airflow. Air flows in through the ports and out through the power module,
as shown in Figure 1-5.
Caution
Maintain a minimum clearance of 200 mm (7.87 in.) around the equipment for air circulation.
At least seven fan modules are required. If any slot is unoccupied, install a filler panel to enable proper
airflow and to keep dust out of the chassis.
Dust the equipment every three months to avoid blocking the ventilation openings on the housing.
Figure 1-5 Front-to-Rear Airflow
1.3.5 Technical Specifications
Table 1-7 Technical Specifications
Class
Item
Specification
Technical
indicators
CPU
2.9 GHz quad-core
Memory
16 GB, DDR4 (compatible with 32 GB)
Flash memory
NOR flash: 16 MB (for BootROM)
SSD
240 GB
Physical
characteristics
Dimensions
(W x D x H)
Without packing materials: 442 mm x 760 mm x 175 mm
(17.40 in. x 29.92 in. x 6.89 in., 4 RU)
With packing materials: 600 mm x 980 mm x 407 mm (23.62
in. x 38.58 in. x 16.02 in.)
Weight
Chassis and modules (eight fan modules and four power
modules) without packing materials: 33.55 kg (73.97 lbs.)
Chassis and modules (eight fan modules and four power
modules) with packing materials: 43.15 kg (95.13 lbs.)

Hardware Installation and Reference Guide Overview
8
Class
Item
Specification
Structure
Flexible module design
Two expansion module slots
Four power module slots
Eight fan module slots
Ports
Service port
144 x 100GE ports (two M6900-72CQ-CES modules)
36 x 200GE ports + 72 x 100GE ports (two M6900-
36CQ18DC-CES modules)
Console port
1 x RJ45 port
USB port
1 x UBS 2.0 port
Management port
1 x Gigabit RJ45 port supporting backward compatibility
Environment
Altitude
Operating altitude: 0–5,000 m (16,404.20 ft.)
Storage altitude: 0–5,000 m (16,404.20 ft.)
Temperature
Operating temperature: 0°C to 40°C (32°F to 104°F) at an
altitude in the range of 0–1,800 m (0–5,905.51 ft.)
Note
At an altitude in the range of 1,800–5,000 m (5,905.51–
16,404.20 ft.), every time the altitude increases by 200 m
(656.17 ft.), the maximum temperature decreases by 1°C
(1.8°F).
Storage temperature: –40°C to +70°C (–40°F to +158°F)
Humidity
Operating humidly: 10% RH to 90% RH (non-condensing)
Storage humidity: 5% RH to 95% RH (non-condensing)
Noise
Sound pressure level at 27°C(80.6°F): < 78 dB
Surge protection
AC power protection
Common mode: 2 kV
Differential mode: 1 kV
Power supply
Power supply
mode
AC
HVDC
Power connector
C14 three-pin connector
Power
consumption
Max: 2,934 W
Typical: 1,338 W
Static: 600 W
Voltage
AC: 100 V AC to 240 V AC, 50 Hz to 60 Hz
HVDC: 180 V DC to 300 V DC

Hardware Installation and Reference Guide Overview
9
Class
Item
Specification
AC input
RG-PA1600II-F:
○Rated voltage: 110 V AC/220 V AC
○Frequency range: 50 Hz to 60 Hz
○Max. voltage range: 90 V AC to 264 V AC (47 Hz to 63
Hz)
○Rated voltage range: 100 V AC to 127 V AC; rated input
current: 12 A
○Rated voltage range: 200 V AC to 240 V AC; rated input
current: 9.5 A
DC input
RG-PA1600II-F:
○HVDC range: 180 V DC to 300 V DC
○Rated voltage: 240 V DC
○Rated input current: 8.5 A
Max. output
power
consumption
RG-PA1600II-F:
○Rated voltage range: 100 V AC to 127 V AC; power:
1,000 W
○Rated voltage range: 200 V AC to 240 V AC; power:
1,600 W
○Rated voltage range: 180 V DC to 300 V DC; power:
1,600 W
Airflow direction
RG-PA1600II-F: Front-to-rear airflow (air exhaust on power
module panel)
Cooling
Cooling mode
Fan cooling
Fan type
Swappable fan
Reliability
Mean Time
Between Failure
(MTBF)
33.3 years
Mean Time to
Recovery (MTTR)
0.5 hours
Availability
0.9999983
Power
redundancy
2+2
Fan redundancy
7+1
Hot swapping
Hot swappable power and fan modules

Hardware Installation and Reference Guide Overview
10
Class
Item
Specification
Certification
EMC
GB/T 9254.1
Safety standard
GB 4943.1
Environment
protection
Environment protection regulation
Warning
Operation of this equipment in a residential environment could cause radio interference.
This equipment is not suitable for use in locations where children are likely to be present.
This equipment should be installed in the equipment room. Only a skilled person should be allowed to
install, replace, or service this equipment. Do not open the enclosure when the equipment is running. Cut
off the power supply before opening the enclosure in case of an electric shock.
1.3.6 Asset Tag
The asset tag is in the upper right corner of the rear panel. The tag can be pulled out of the panel. You can add
your own asset tracking label without interfering with the intended air flow.
Figure 1-6 Asset Tag

Hardware Installation and Reference Guide Overview
11
1.4 Expansion Modules
1.4.1 M6900-36CQ18DC-CES
1. Appearance
Figure 1-7 Front Panel Appearance
Figure 1-8 Front Panel Structure
Table 1-8 Front Panel Components
No.
Component
1
Expansion module status LED
2
Port LED
3
100GE QSFP28 port
4
200GE QSFP56 port
Note
The M6900-36CQ18DC-CES has three rows of ports. The top row includes ports 1F, 4F, 7F…52F, the
middle row includes ports 2F, 5F, 8F…53F, and the bottom row includes ports 3F, 6F, 9F…54F.
The port LEDs are numbered from left to right corresponding to ports 1F to 54F.
