SALTO GEO Cylinder |the next generation of electronic cylinder lock
Fully integrated with the SALTO XS4 platform, GEO is a versatile, cost effective solution and its compact size and easy
installation makes it the ideal electronic locking system for almost any type of door.
European cylinder - GxEx
User Manual

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
2
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
INDEX
PRODUCT DESCRIPTION 3
WHATS ON THE BOX 3
ACCESSORIES 4
SALTO GEO RANGE 4
MODELS 4
DIMENSIONS 4
CERTIFICATIONS 5
Declaration of Conformity CE 5
Protection against access to hazardhous areas, resistance against ingress
of foreign particules and detrimental entry of water 5
Mechanical certications against vandalisme 5
Fireproof certications 5
TECHNICAL DATA 5
ACCES CONTROL FEATURES 6
OPENING MODES 6
OPERATION OF THE CYLINDER 6
INSTALLATION 7
PROGRAMMING 9
BATTERIES 9
Low battery status. 9
Battery failure. 9
Change the batteries 10
SALTO GEO SIGNALS 11
Access granted 11
Card rejection 11
Access time out 11
Low battery status 11
Battery changed (reset of the electronics) 12
Access granted + Toogle (ROM or RW systems) 12
End Toogle (ROM or RW systems) 13
Gear error 13
Security error 13

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
3
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
SP301585 SP3030577 SP301582-10 SALTOGEOGRIPA SALTOGEOGRIPH SP201587
PRODUCT DESCRIPTION
SALTO GEO cylinder is a battery operated electronic cylinder that brings all the advantages and
benets of an access control without wiring the door reducing installation costs and allowing you
to control and manage virtually anykind of door.
The SALTO GEO cylinder European prole is specially designed to t most Euro prole doors that
are equipped with a European prole cylinder mortise lock.
A wire free fully stand alone electronic access control solution, it is suitable for installation in
almost every type of wooden door including antique or listed wooden doors, metal and metal
framed doors and glass doors.
The key is always to be stored securely so that it is accessible only to the authorised
person.
If a key gets lost, the electronic cylinder is to be replaced immediately or, by changing
of the codication put to a new coding respectively to block/delete the coding of the lost
key.
WHATS ON THE BOX
When you purchase a SALTO GEO electronic Cylinder you get:
• SALTO GEO electronic cylinder
• 1 lithium battery CR2type
• Installation guide
• 1 M5 screw to x the cylindor onto the mortise lock
• 1 Knob blocking screew
For the mantainance of the cylinder in order to perform replacemnt of bat-
teries or the installation of double knob cylinders, electric swith cylinders
SALTO Recommends to purchase the SALTO Geo Installation tool
(SP220764) sold separately.
ACCESSORIES
• SALTO 2,5 mm Allen key for SALTO GEO to remove the thumbturn. (SP301585)
• SALTO 2 mm Allen key for SALTO GEO to remove the knob. (SP3030577)
• SALTO CR2 battery for SALTO GEO cylinders. (SP301582-10)
• SALTO Geo cylinder grip A. (SALTOGEOGRIPAx)
• SALTO Geo cylinder grip H. (SALTOGEOGRIPHx)
• SALTO euro cylinder measuring key for installers (PZ). (SP201587)
The product should not be modied in any way except in accordance with those
modications described in the instructions

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
4
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
SALTO GEO RANGE
Models
E1 = Half Euro profile cylinder.
GxE11xxxxx
E2 = Euro profile cylinder with thumbturn.
GxE21xxxxx
E3 = Euro profile double cylinder, double knob.
GxE31xxxxx
Dimensions
E1 = Half Euro profile cylinder.
GxE11xxxxx
E2 = Euro profile cylinder with thumbturn.
GxE21xxxxx
E2 = Euro profile cylinder with thumbturn
Antipanic function.
GxE21xxxxxA
E3 = Euro profile double cylinder, double
knob.
GxE31xxxxx
GxE3
GxE1 GxE2
le 10
38
Ø
43
38
Ø
43
le 10
L
le li
L
43
38
Ø
le li
L
38
Ø
43
le li
L
43
38
Ø
le li
L
38
Ø
43
le li
L
38
Ø
43
*leli
L
38
Ø
43
10
 17
33
Profile cylinder PZ
Panic Function
le 30/100
30/100
38
Ø
43
le li
L
38
Ø
43
12 h
20°
20°
60°
60°
12 h
120°
120°
Panic Function
cylinder
• The cylinder has a mechanism to
ensure that the cylinder cam re-
sets to a position where it doesn’t
interfere in the lock operation.
• The cam’s position is corrected
from 12 h +/- 120º to 12 h+/-120º.
• The panic function requires a
cylinder minimum interior length
(li) of 35mm.
• The panic function is not compati-
ble with double reader cylinder.

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
5
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
CERTIFICATIONS
Declaration of Conformity CE
Use of radio frequency spectrum
ETSI EN 302 291-1 V1.1.1 (2005-07)
ETSI EN 302 291-2 V1.1.1 (2005-07)
Electromagnetic Compatibility
ETSI EN 301 489-1 (2011-09)
ETSI EN 301 489-3 (2002-08)
Security requirements
EN 60950-1 (2007)
Following the provisions of the directive 2004/108/CE (Electromagnetic Compatibility)
and the directive 2006/95/CE (Low Voltaje).
Protection against access to hazardhous areas, resistance against ingress of
foreign particules and detrimental entry of water
IP protection: IP56
Mechanical certications against vandalisme
EN1303
SKG***
TECHNICAL DATA
Current required: 1 Lithium standard battery CR2
Environmental conditions: -20ºC / 60ºC
Number of openings: Up to 40,000 on 1 battery
Access control systems:
ROM System - Software required SALTO Pro Access ROM
RW System - Software required SALTO Pro Access RW or HAMS RW

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
6
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
ACCES CONTROL FEATURES
Opening modes
Standard: locked at all times. Need of a valid card to get access.
Automatic openings: 8 pairs of “hands free”(no card needed to access) timed
lock and unlocks per day subject to calendar and time periods (ROM and RW
systems only).
Toogle: present valid card to lock, present valid card to unlock
(ROM and RW systems).
Timmed Toogle: present valid card to lock, present valid card to unlock de
pending on schedules to switch between standard mode and Toogle mode
(ROM and RW systems).
Operation of the cylinder
Timezones
Each user can be assigned to a calendar and a time table consists of up to 8 different time
intervals with a resolution of 10 minutes assigned to each day of the week. You can also
distinguish between holidays, special days and working days.
Event Auditor
- Authorized access events auditor registration, denied access events auditor
registration, system maintenance events auditor registration (low battery, PPD
connection, ...) and automatic actions events auditor registration (automatic opening, ...)
- Each event is logged: Event type, user, date and time of the event.
- Permanent events restration. Non-volatile memory of the last X events (see table).
Maximum number of door per system
Maximum events on lock audit
Timezones
Timeperiods
Calendars in system
User groups
Maximum number of user per door 1000 4000000
16000 64000
680 1000
30 256
20 256
4 256
unlimited
unlimited
unlimited
Management software ProAccess
ROM
ProAccess
HAMS
(available SQL)
unlimitedZones in System
ROM
System
R&W
System
Present a valid card Turn the knob to
retrieve the latch
and deadbolt

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
7
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
INSTALLATION
1 - unpack
2 - Remove the knob to connect the battery
2 - Remove the battery protection
3 - Prepare the cylinder for the installation on the door
(for model GxE2)
SP220764
(not included)
2,5 mm allen key
(not included)
PH2 screw driver
(not included)
2 mm allen key
(not included)
Knob blocking screw
(included)
CR2 battery
(included)
CLICK !
PAIRED*
CLICK !
Important: the knob is uniquely paired to the cylinder,
and will not work if you switch in a different SALTO knob.
2.5 mm
M
a
x
.
L
e+
3
M
i
n
.
L
e
L
i
L
e

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
8
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
INSTALLATION
3 - Prepare the cylinder for the installation on the door (for model G9x3)
Remove one of the knobs in order to be able to fit the cylinder
For a correct installation
4 - x it to the door
5 - Screw it to the mortise lock
PAIRED*
360ºx3
2 mm allen key
(not included)
External Knob
For a correct installation the body
need to excel 3mm from the door
surface
At this point do not close the door
without having programmed the
cylinder rst
Model GxE2 Model GxE3
Door
lile
0 - 3mm max.

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
9
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
PROGRAMMING
To grant or deny access permissions are used the right SW license. Once you update the system
conguration:
- ROM System updates the access permissions on the cylinders using a PPD.
- RW System is not necessary to update the cylinders with the PPD. The system allows elec-
tronic cylinders to read, receive and write information via its operating smart cards or ‘intelligent’
keys. This data is captured from the cards at SVN on-line hot spots located at strategic points
around the building.The “online points” uploads and downloads user related information that is
then used to permit, control or deny access.
BATTERIES
Low battery status.
The low battery status can be recognised by 4 slow and low pitched warning tones. If these war-
nings are ignored then the batteries will fail.
Battery failure.
In the case of complete battery failure the product fails both safe and secure, i.e. the outside
handle fails “locked” to avoid intrusions, the inside handle fails “open” to permit emergency
openings. Note that once the cylinder is powered again with new batteries all the keys that were
programmed into the cylinder will still work as before, because the memory is retentive.
WARNING: The electronic cylinders needs to be updated with the PDD to recover the hour.
“The product should not be modied in any way except in accordance with those modications
described in the instructions”
BEEEEP BEEEEP BEEEEP BEEEEP

Manual_SALTO_GEO_VDS_ENG_08-13
www.saltosystems.com
SALTO Systems - SALTO Geo user manual
10
CONFIDENTIAL - This document contains condential and privileged information.
The reproduction of any part of the document is strictly prohibited without the prior written consent of Salto Systems S.L.
BATTERIES
Change the batteries
The new SALTO Geo Cylinder, permits to change the batteries without needing to open the door,
so in case of a battery failure you will be able to change the batteries using the SP220764 tool.
1 - Remove the knob
2 - Remove the battery
3 - Replace a new battery
4 - Mount the knob
ONLY
NEW BATTERY
CLICK !
