Samson 3730 Series Service manual

Series 3730
Type 3730-1 Electropneumatic Positioner
Mounting and
Operating Instructions
EB 8384-1 EN (1300-1610)
Firmware version 2.12
Edition December 2014
Fig. 1 · Type 3730-1

Contents Page
1 Important safety instructions . . . . . . . . . . . . . . . . . . . . . . 6
2 Article code . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3 Design and principle of operation. . . . . . . . . . . . . . . . . . . . 8
3.1 Technical data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
4 Attachment to the control valve – mounting parts and accessories . . . 12
4.1 Direct attachment . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1.1 Type 3277-5 Actuator . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1.2 Type 3277 Actuator . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Attachment according to IEC 60534-6 . . . . . . . . . . . . . . . . . 18
4.3 Attachment according to VDI/VDE 3847 . . . . . . . . . . . . . . . . 20
4.4 Attachment to Type 3510 Micro-flow Valve. . . . . . . . . . . . . . . 20
4.5 Attachment to rotary actuators . . . . . . . . . . . . . . . . . . . . . 22
4.5.1 Heavy-duty version . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.6 Reversing amplifier for double-acting actuators . . . . . . . . . . . . . 26
4.6.1 Reversing amplifier (1079-1118 or 1079-1119) . . . . . . . . . . . . 26
4.7 Attaching positioners with stainless steel housings. . . . . . . . . . . . 28
4.8 Air purging function for single-acting actuators . . . . . . . . . . . . . 28
4.9 Mounting parts and accessories . . . . . . . . . . . . . . . . . . . . 29
5 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1 Pneumatic connections . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.1.1 Signal pressure gauges . . . . . . . . . . . . . . . . . . . . . . . . 34
5.1.2 Supply pressure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.2 Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.2.1 Switching amplifier . . . . . . . . . . . . . . . . . . . . . . . . . . 37
6 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
6.1 Operator controls . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
7 Start-up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.1 Setting the volume restriction Q. . . . . . . . . . . . . . . . . . . . . . 40
7.2 Adapting the display. . . . . . . . . . . . . . . . . . . . . . . . . . 40
7.3 Entering the opening direction . . . . . . . . . . . . . . . . . . . . . 40
7.4 Setting other parameters . . . . . . . . . . . . . . . . . . . . . . . 41
7.5 Initialization . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
2EB 8384-1 EN
Contents

7.6 Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.7 Zero calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
7.8 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
7.9 Manual adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . 44
8 Code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
10 Servicing explosion-protected devices . . . . . . . . . . . . . . . . . 49
11 Dimensions in mm. . . . . . . . . . . . . . . . . . . . . . . . . . . 51
11.1 Fixing levels according to VDI/VDE 3845 (September 2010) . . . . . . 53
Test certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
EB 8384-1 EN 3
Contents

4EB 8384-1 EN

Revision in positioner firmware compared to the previous version
Previous version New
2.02 2.10
New reset function in Code P0, refer to section 7.8
New manual adjustment function in Code P14, refer to section 7.9
2.10 2.11
Internal modifications
2.11 2.12
Internal modifications
EB 8384-1 EN 5
Revision in positioner firmware

1 Important safety instructions
For your own safety, follow these instructions concerning the mounting, start-up and opera-
tion of the positioner:
4The positioner is to be mounted, started up or operated only by trained and
experienced personnel familiar with the product.
According to these Mounting and Operating Instructions, trained personnel refers to
individuals who are able to judge the work they are assigned to and recognize
possible dangers due to their specialized training, their knowledge and experience as
well as their knowledge of the applicable standards.
4Explosion-protected versions of this positioner may only be operated by personnel
who have undergone special training or instructions or who are authorized to work
on explosion-protected devices in hazardous areas. Refer to section 10.
4Any hazards that could be caused by the process medium, the operating pressure, the
signal pressure or by moving parts of the control valve are to be prevented by means
of the appropriate measures.
4If inadmissible motions or forces are produced in the actuator as a result of the supply
pressure, the supply pressure must be restricted by means of a suitable supply pres-
sure reducing station.
To avoid damage to any equipment, the following also applies:
4Do not operate the positioner with the back of the positioner/vent opening facing up-
wards. The vent opening must not be sealed when the positioner is installed on site.
4Proper shipping and appropriate storage are assumed.
4Do not ground electric welding equipment near to the positioner.
Note: The device with a CE marking fulfils the requirements of the Directives 94/9/EC and
2004/108/EC. The declaration of conformity is available on request.
6EB 8384-1 EN
Important safety instructions
Vent opening

2 Article code
EB 8384-1 EN 7
Article code
Article code Type 3730-1 xx0000000x00x000
With LCD, autotune
4 to 20 mA reference variable, two software limit switches
Explosion protection
Without 0
ATEX: II 2G Ex ia IIC T6 Gb, II 2D Ex tb IIIC T 80 °C Db IP 66 1
FM/CSA:
Class I, Zone 0 AEx ia IIC; Class I, II, III; Div.1, Groups A–G;
Class I, Div. 2, Groups A–D; Class II, Div. 2, Groups F, G/
Ex ia IIC T6; Class I, Zone 0; Class II, Groups E–G; Ex nA II T6; Class I, Zone 2;
Class I, Div. 2, Groups A–D; Class II, Div. 2, Groups E–G
3
ATEX: II 3G Ex nA II T6, II 3G Ex ic IIC T6, II 3D Ex tc IIIC T80°C IP66 8
Option: Inductive limit switch
Without 0
With SJ2-SN proximity switch (NC contact) 1
With SJ2-S1N proximity switch (NO contact) 2
Housing material
Standard aluminum 0
Stainless steel 1.4581 1
Special applications
Without 0
Compatible with paint 1
Exhaust air with ¼ NPT connection, back of positioner housing sealed 2
Special version
Without 0 0 0

3 Design and principle of
operation
The electropneumatic positioner is mounted
to pneumatic control valves and is used to
assign the valve position (controlled
variable x) to the control signal (reference
variable w). The DC control signal received
from a control unit is compared to the travel
or rotational angle of the control valve and
issues a signal pressure (output variable y).
The positioner is designed depending on the
corresponding accessories for direct attach-
ment to Type 3277 Actuators or for attach-
ment to actuators according to IEC 60534-6
(NAMUR).
Additionally, a coupling wheel included in
the accessories is required to transfer the ro-
tary motion for rotary actuators according to
VDI/VDE 3845.
Springless rotary actuators require an ac-
cessory reversing amplifier to permit the
powered operation in either direction.
The positioner basically consists of a travel
sensor system that functions proportional to
resistance, an analog i/p module with
downstream booster as well as the electronic
unit with a microcontroller. The positioner is
fitted with two adjustable software limit
switches as standard to indicate the valve's
end positions.
The position of the valve is transmitted as
linear travel motion or angle of rotation via
pick-up lever and travel sensor (2) to an an-
alog PD controller (3). Simultaneously, an
A/D converter (4) transmits the position of
the valve to the microcontroller (5). The PD
controller compares this actual position to
the 4 to 20 mA DC control signal (reference
variable) after it has been converted by the
A/D converter (4).
In case of a system deviation, the operation
of the i/p converter (6) is changed so that
the actuator (1) is filled or vented via the
downstream air capacity booster (7). This
causes the closure member of the control
valve to move to the position determined by
the reference variable.
The pneumatic air capacity booster (7) and
the pressure regulator (8) are provided with
supply air. An intermediate flow regulator
(9) with fixed settings is used to purge the
positioner and also guarantees trouble-free
operation of the pneumatic booster.
The output signal pressure supplied by the
booster can be limited to 2.4 bar by activat-
ing the parameter P9.
The volume restriction Q (10) is used to opti-
mize the positioner by adapting it to the ac-
tuator size.
Tight-closing function:
The pneumatic actuator is completely filled
with air or vented as soon as the reference
variable falls below 1 % or exceeds 99 %
(see end positions set over parameters P10
and P11).
8EB 8384-1 EN
Design and principle of operation

EB 8384-1 EN 9
Design and principle of operation
Fig. 2 · Functional diagram
%
S
mm
%
mm
w
x
Q
PD
A2
A1
45
3
11
12
6
7
8
10
1
w
9
x
y
2
7 Air capacity booster
8 Pressure regulator
9 Flow regulator
10 Volume restriction
11 Limit switches
12 Display
1 Control valve
2 Travel sensor
3 PD controller
4 A/D converter
5 Microcontroller
6 i/p converter

3.1 Technical data
10 EB 8384-1 EN
Design and principle of operation
Positioner (technical data in test certificates additionally apply for explosion-protected devices)
Travel, adjustable
Direct attachment to Type 3277: 3.6 to 30 mm
Attachment acc. to IEC 60534-6: 3.6 to 200 mm or 24° to 100° with rotary
actuators
Travel range Adjustable within the initialized travel/angle of rotation;
travel can be restricted to 15at the maximum
Reference variable w Signal range 4 to 20 mA · Two-wire device, reverse polarity protection,
split-range 4 to 11.9 mA and 12.1 to 20 mA, static destruction limit 100 mA.
Minimum current 3.7 mA
Load impedance ≤6 V (corresponding to 300 Ωat 20 mA)
Supply air
Air quality acc.
to ISO 8573-1
Supply pressure from 1.4 to 7 bar (20 to 105 psi),
Max. particle size and density: Class 4 · Oil content: Class 3, pressure dew
point: Class 3 or at least 10 K beneath the lowest ambient temperature to be
expected
Signal pressure (output) 0 bar up to supply pressure, limitable to approx. 2.4 bar via software
Characteristic Optionally 1 characteristic for globe valves, 8 characteristics for opening angle
Hysteresis ≤1 %
Sensitivity ≤0.1 %
Transit time < 0.5 s for initialization not permissible, adaptation over volume restriction Q
Direction of action w/x reversible
Air consumption, steady state Independent from supply pressure approx. 110 ln/h
Air output capacity
Actuator filled with air
Actuator vented
At ∆p = 6 bar: 8.5 mn3/h, at ∆p = 1.4 bar: 3.0 mn3/h · KVmax(20 °C) = 0.09
at ∆p = 6 bar: 14.0 mn3/h, at ∆p = 1.4 bar: 4.5 mn3/h · KVmax(20 °C) = 0.15
Permissible ambient
temperature
–20 to +80 °C in all versions
–45 to +80 °C with metal cable gland
–25 to +80 °C with inductive limit switches (SJ2-S1N) and metal cable gland
Limits in test certificate also apply for explosion-protected devices.
Influences Temperature: ≤0.15 %/10 K Supply air: None
Vibration: ≤0.25 % up to 2000 Hz and 4 g acc. to IEC 770
Electromagnetic
compatibility
Complying with requirements specified in EN 61000-6-2, EN 61000-6-3,
EN 61326-1 and NAMUR Recommendation NE 21
Electrical connections
One M20 x 1.5 cable gland for 6 to 12 mm clamping range · Additional sec-
ond M20 x 1.5 threaded hole · Screw terminals for 0.2 to 2.5 mm² wire
cross-section

EB 8384-1 EN 11
Design and principle of operation
Positioner (technical data in test certificates additionally apply for explosion-protected devices)
Explo-
sion
protec-
tion
ATEX Type 3730-11
Type 3730-18
II 2G Ex ia IIC T6 Gb, II 2D Ex tb IIIC T80°C Db IP66
II 3G Ex nA II T6, II 3G Ex ic IIC T6, II 3D Ex tc IIIC T80°C IP66
CSA Type 3730-13
Ex ia IIC T6; Class I, Zone 0; Class II, Groups E, F, G; Ex nA II T6; Class I,
Zone 2;
Class I, Div.2, Groups A, B, C, D; Class II, Div.2, Groups E, F, G
FM Type 3730-13 Class I, Zone 0 AEx ia IIC; Class I, II, III; Div.1, Groups A, B, C, D, E, F, G;
Class I, Div.2, Groups A, B, C, D; Class II, Div.2, Groups F, G
CCoE Type 3730-11 Ex ia IIC T6
GOST Type 3730-11
Type 3730-18
1Ex ia IIC T6 Gb, 1Ex tb IIIC T80°C Db IP66
2Ex nA IIC T6 Gc, 2Ex ic IIC T6 Gc, 2Ex tc IIIC T80°C Dc IP66
IECEx Ex ia IIC T6
NEPSI On request
INMETRO On request
Degree of protection IP 66/NEMA 4X
Use in safety-instrumented sys-
tems in compliance with
IEC 61508
Suitable for use in safety-relevant applications up to SIL 2 (single device) and
SIL 3 (with redundant configuration), safety shutdown at a reference variable
of 0 mA.
Weight Approx. 1 kg
Materials
Housing Die-cast aluminum EN AC-Al Si12(Fe) (EN AC-44300) acc. to DIN EN 1706,
chromated and plastic coated · Special version: Stainless steel 1.4581
External parts Stainless steel 1.4571 and 1.4301
Cable gland M20x1.5, black polyamide
Binary contacts
Two software limit switches with configurable limits (0.5 % steps), reverse polarity
protection, floating
Signal status
No response:
Response:
Without explosion protection
Conductive ( R = 348 Ω)
Non-conducting
Explosion-protected version
≥2.2 mA
≤1.0 mA
Operating voltage
- Binary input of the PLC acc. to
IEC 61131-2, Pmax = 400 mW
- NAMUR switching amplifier acc. to
EN 60947-5-6
Only for connection to NAMUR
signal converter acc. to EN
60947-5-6
Option:
Inductive limit switch
For connection to switching amplifier acc. to EN 60947-5-6.
Can be used in combination with a software limit switch.
SJ2-SN proximity switch NAMUR NC contact
SJ2-S1N proximity switch NAMUR NO contact

4 Attachment to the control
valve – mounting parts and
accessories
The positioner can be attached either di-
rectly to a SAMSON Type 3277 Actuator or
according to IEC 60534-6 (NAMUR) to con-
trol valves with cast yokes or rod-type yokes
as well as to rotary actuators according to
VDI/VDE 3845.
For attachment to the various actuators, cor-
responding mounting parts and accessories
are required. These are listed with their or-
der numbers in Tables 1 to 5.
On attaching the positioner, it is important
to observe the assignment between lever
and pin position according to the travels
listed in the travel tables.
The actual valve travel that can be achieved
is restricted by the pin position used and ad-
ditionally by the actuator spring compres-
sion required.
The travel range listed in the travel tables
opposite can only achieved if the nominal
range is set to MAX.
The positioner is standard equipped with the
lever M(pin position 35).
Note: If the standard mounted lever M (pin
position 35) is replaced, the newly mounted
lever must be moved once all the way as far
as it will go in both directions to adapt it to
the internal measuring lever.
12 EB 8384-1 EN
Attachment to the control valve – mounting parts and accessories
Fig. 3 · Lever M (set pin position 35)

EB 8384-1 EN 13
Attachment to the control valve – mounting parts and accessories
Travel tables
Note: The lever Mis included in the scope of delivery.
Levers S,L,XL for attachment according to IEC 60534-6 (NAMUR) are available as accesso-
ries (Table 3, page 31).
Direct attachment to Type 3277-5 and Type 3277 Actuators
Actuator size Rated travel Adjustment range at positioner Required
lever
Assigned
pin position
[cm²] [mm] Min. Travel Max.
120 7.5 5.0 to 25.0 M 25
120/175/240/350 15 7.0 to 35.0 M 35
355/700/750 30 10.0 to 50.0 M 50
Attachment according to IEC 60534-6 (NAMUR attachment)
SAMSON valves/Type 3271 Actuator Other valves/actuators
Required
lever
Assigned
pin position
Actuator size Rated travel
[cm²] [mm] Min. Travel Max.
60 and 120
with Type 3510 7.5 3.6 to 18.0 S 17
120 7.5 5.0 to 25.0 M 25
120/175/240/350 15 7.0 to 35.0 M 35
700/750 7.5
355/700/750 15 and 30 10.0 to 50.0 M 50
1000/1400/2800 30 14.0 to 70.0 L 70
1000/1400/2800 60 20.0 to 100.0 L 100
1400/2800 120 40.0 to 200.0 XL 200
Attachment to rotary actuators according to VDI/VDE 3845
Rotary actuators Required
lever
Assigned
pin position
Min. Opening angle Max.
24 to 100° M 90°

4.1 Direct attachment
4.1.1 Type 3277-5 Actuator
Refer to Table 1 on page 29 for the required
mounting parts as well as the accessories.
Note the travel table on page 13!
Actuator with 120 cm²
Depending on the type of positioner attach-
ment, the signal pressure is routed either left
or right of the yoke through a bore to the
actuator diaphragm. Depending on the
fail-safe action of the actuator "Actuator
stem extends" or "Actuator stem retracts"
(valve closes or opens if the supply air fails),
the switchover plate (9) must first be at-
tached to the actuator yoke. Align the
switchover plate with the corresponding
symbol for left or right attachment according
to the marking (view looking onto the
switchover plate).
1. Mount connecting plate (6) or pressure
gauge bracket (7) with pressure gauges
onto the positioner, making sure both
seal rings (6.1) are seated properly.
2. Remove screw plug (4) on the back of the
positioner and close the signal pressure
output (38) on the connecting plate (6) or
on the pressure gauge bracket (7) with the
stopper (5) included in the accessories.
3. Place follower clamp (3) on the actuator
stem, align and screw tight so that the
mounting screw is located in the groove
of the actuator stem.
4. Mount cover plate (10) with narrow side
of the cut-out opening (Fig. 4, on the left)
pointing towards the signal pressure
connection. Make sure that the bonded
gasket (14) points towards the actuator
yoke.
5. 15 mm travel: Keep the follower pin (2)
at lever M(1) on the back of the
positioner in the pin position 35 (deliv-
ered state).
7.5 mm travel: Remove the follower pin
(2) from the pin position 35, reposition it
in the bore for pin position 25 and
screw tight.
6. Insert formed seal (15) into the groove of
the positioner housing and the seal ring
(10.1) on the back of the housing.
7. Place positioner on the cover plate (10)
in such a manner that the follower pin
(2) rests on the top of the follower clamp
(3). Adjust the lever (1) correspondingly
and open the positioner cover to hold
the positioner shaft in position at the cap
or the switch (Fig. 14).
The lever (1) must rest on the follower
clamp with spring force. Mount the
positioner on the cover plate (10) using
the two fixing screws.
Note for all types of attachment except for
direct attachment to Type 3277-5: The sig-
nal pressure output at the back must be
sealed using the screw plug (4, order no.
0180-1254) and the associated O-ring (or-
der no. 0520-0412).
8. Mount cover (11) on the other side. Make
sure that the vent plug points downwards
when the control valve is installed to al-
low any condensed water that collects to
drain off.
14 EB 8384-1 EN
Attachment to the control valve – mounting parts and accessories

EB 8384-1 EN 15
Attachment to the control valve – mounting parts and accessories
9 11
Supply 9 Output 38
5
6
4
7
6
10
10.1
3
2
1
15
6.1
1.1
1.2
14
8
Fig. 4 · Direct attachment – Signal pressure connection for Type 3277-5 Actuator with 120 cm²
1 Lever
1.1 Nut
1.2 Disk spring
2 Follower pin
3 Follower clamp
4 Screw plug
5 Stopper
6 Connecting plate
6.1 Seal rings
7 Pressure gauge bracket
8 Press. gauge mounting kit
9 Switchover plate f. actuator
10 Cover plate
10.1 Seal ring
11 Cover
14 Gasket
15 Formed seal
Note:
Always use the connecting plate (6)
included in the accessories to connect
supply and output.
Never screw threaded parts directly
into the housing.
Symbols
Actuator stem
extends
Attachment left Attachment right
Actuator stem
retracts
Switchover plate (9)
Signal pressure
input for right
attachment
Marking
Cut-out of cover
plate
Signal pressure
input for left
attachment
Lever M

4.1.2 Type 3277 Actuator
Refer to Table 2 on page 31 for the required
mounting parts as well as the accessories
with their order numbers.
Note the travel table on page 13!
Actuators with 175 to 750 cm²
Mount the positioner on the yoke as shown
in Fig. 5. The signal pressure is routed to the
actuator over the connection block (12), for
actuators with fail-safe action "Actuator
stem extends" internally through a bore in
the valve yoke and for "Actuator stem re-
tracts" through external piping.
1. Place follower clamp (3) on the actuator
stem, align and screw tight so that the
mounting screw is located in the groove
of the actuator stem.
2. Mount cover plate (10) with narrow side
of the cut-out opening (Fig. 5, on the left)
pointing towards the signal pressure
connection. Make sure that the bonded
gasket (14) points towards the actuator
yoke.
3. For actuators with 355, 700 and
750 cm², remove the follower pin (2) at
lever M(1) on the back of the positioner
from pin position 35, reposition it in the
bore for pin position 50 and screw tight.
For actuators 175, 240 and 350 cm²
with 15 mm travel, the follower pin (2)
remains in pin position 35.
4. Insert formed seal (15) in the groove of
the positioner casing.
5. Place positioner on the cover plate in
such a manner that the follower pin (2)
rests on the top of the follower clamp
(3). Adjust the lever (1) correspondingly
and open the positioner cover to hold
the positioner shaft in position at the cap
or the switch (Fig. 14). The lever (1) must
rest on the follower clamp with spring
force. Mount the positioner on the cover
plate (10) using the two fixing screws.
6. Make sure that the tip of the gasket (16)
projecting from the side of the connec-
tion block (12) is positioned above the
actuator symbol that corresponds with
the actuator with fail-safe action
"Actuator stem extends" or "Actuator
stem retracts." If necessary, remove the
three fixing screws and the cover. Then
reposition the gasket (16) turned by
180°. The previous version of the con-
nection block (Fig. 5, bottom) requires
the switch plate (13) to be turned such
that the corresponding actuator symbol
points to the marking.
7. Place the connection block (12) with the
associated seal rings against the
positioner and the actuator yoke. Screw
it tight using the fixing screw (12.1). For
actuators with fail-safe action "Actuator
stem retracts", additionally remove the
stopper (12.2) and fit on the external
signal pressure piping.
8. Mount cover (11) on the other side.
Make sure that the vent plug points
downwards when the control valve is in-
stalled to allow any condensed water
that collects to drain off.
16 EB 8384-1 EN
Attachment to the control valve – mounting parts and accessories

EB 8384-1 EN 17
Attachment to the control valve – mounting parts and accessories
2
10 1415
1 2 3 11 11.1
SUPPLY
13
B
C
1.1
1.2
12
12.1
12
12.2
12.11216
16 16
12.2
SUPPLY
Ansicht A
Ansicht B
Ansicht C
SUPPLYG
G 3/8
A
Fig. 5 · Direct attachment – Signal pressure connection for Type 3277 Actuator with 175 to 750 cm2
Lever M
1 Lever
1.1 Nut
1.2 Disk spring
2 Follower pin
3 Follower clamp
10 Cover plate
11 Cover
11.1 Vent plug
12 Connection block
12.1 Screw
12.2 Stopper or connection for
external piping
13 Switch plate
14 Gasket
15 Formed seal
16 Gasket
View A
View C
View B
Cut-out of
cover plate (10)
Actuator stem
retracts extends
Actuator stem retracts
Actuator stem extends
Marking
Connection block (old)
with switch plate (13)

4.2 Attachment according to
IEC 60534-6
The positioner is attached to the control
valve with a NAMUR bracket (10).
Refer to Table 3 on page 31 for the required
mounting parts as well as the accessories
with their order numbers.
Note the travel table on page 13!
1. Screw the two bolts (14) to the bracket
(9.1) of the stem connector (9), place the
follower plate (3) on top and use the
screws (14.1) to tighten.
Actuator size 2800 cm² and 1400 cm² with
120 mm travel:
For a travel of 60 mm or smaller, screw the
longer follower plate (3.1) directly to the
stem connector (9). For a travel exceeding
60 mm, mount the bracket (16) first and
then the follower plate (3) to the bracket to-
gether with the bolts (14) and screws (14.1).
2. Mount NAMUR bracket (10) to the con-
trol valve as follows:
For attachment to the NAMUR rib, use
an M8 screw (11) and toothed lock
washer directly in the yoke bore.
For attachment to valves with rod-type
yokes, use two U-bolts (15) around the
yoke.
Align the NAMUR bracket (10) accord-
ing to the embossed scale so that the slot
of the follower plate (3) is centrally
aligned with the NAMUR bracket at mid
valve travel.
3. Mount connecting plate (6) or pressure
gauge bracket (7) with pressure gauges
(8) on the positioner, making sure both
seal rings (6.1) are seated properly.
4. Select required lever size (1) M,Lor XL
and pin position according to the actua-
tor size and valve travels listed in the ta-
ble below.
Should you require a pin position other
than position 35 with the standard in-
stalled lever M, or require a lever size L
or XL, proceed as follows:
5. Screw the follower pin (2) in the as-
signed lever bore (pin position) as listed
in the table. Only use the longer follower
pin (2) included in the mounting kit.
6. Place lever (1) on the positioner shaft
and screw tight using the disk spring
(1.2) and nut (1.1).
Note: If you have mounted a new lever (1),
you must move it once all the way as far as
it will go in both directions.
7. Place positioner on the NAMUR bracket
in such a manner that the follower pin
(2) rests in the slot of the follower plate
(3, 3.1). Adjust the lever (1) correspond-
ingly.
Screw the positioner to the NAMUR
bracket using both its fixing screws.
18 EB 8384-1 EN
Attachment to the control valve – mounting parts and accessories

EB 8384-1 EN 19
Attachment to the control valve – mounting parts and accessories
Fig. 6 · Attachment according to IEC 60534-6 (NAMUR)
10
11
1
114.1
3
3.1
16
15
14
1
1.2
1.1
2
9.1
9
6.1 6 7 8
1 Lever
1.1 Nut
1.2 Disk spring
2 Follower pin
3 Follower plate
3.1 Follower plate
6 Connecting plate
6.1 Seal rings
7 Pressure gauge bracket
8 Pressure gauge
mounting kit
9 Stem connector
9.1 Bracket
10 NAMUR bracket
11 Screw
14 Bolt
14.1 Screw
15 U-bolt
16 Bracket
Note: Always use the connecting plate (6) included in the accessories to
connect supply and output. Never screw threaded parts directly into the
housing.
Attachment to
NAMUR rib
Additional bracket for
actuators with 2800 cm2
and travel ≥60 mm
Attachment to rod-type yoke
Rods with 20 to 35 mm Ø
Lever XL and L

4.3 Attachment according to
VDI/VDE 3847
Only Type 3730-1xx0000000x0x006000
and Type 3730-1xx0000000x0x007000
Positioners can be attached according to
VDI/VDE 3847.
The attachment of positioners according to
VDI/VDE 3847 is described in detail in the
TV-SK 10021 document which is available
on request.
4.4 Attachment to Type 3510
Micro-flow Valve
The positioner is attached to the valve yoke
using a bracket.
Refer to Table 3 on page 31 for the required
mounting parts as well as the accessories
with their order numbers.
Note the travel table on page 13!
1. Screw bracket (9.1) to the stem connec-
tor (9).
2. Fasten the two pins (9.2) to the bracket
(9.1) on the stem connector. Mount the
follower plate (3) and fasten it using the
screws (9.3).
3. Mount the travel indication scale (acces-
sories) to the outer side of the yoke using
the hex screws (12.1), ensuring that the
scale is aligned with the stem connector.
4. Fasten the hex bar (11) onto the outer
side of yoke by screwing the M8 screws
(11.1) directly into the holes on the
yoke.
5. Fasten the bracket (10) to the hex bar
(11) using the hex screw (10.1), washer
and tooth lock washer.
6. Mount connecting plate (6) or pressure
gauge bracket (7) with pressure gauges
(8) on the positioner, making sure both
seal rings (6.1) are seated properly.
7. Unscrew the standard installed lever M
(1) including follower pin (2) from the
positioner shaft.
8. Take lever S(1) and screw follower pin
(2) in the bore for pin position 17.
9. Place lever Son the positioner shaft and
screw tight using the disk spring (1.2)
and nut (1.1).
Move lever once all the way as far as it
will go in both directions.
10. Place positioner on the bracket (10) in
such a manner that the follower pin
slides into the groove of the clamp (3).
Adjust the lever (1) correspondingly.
Screw the positioner to the bracket (10)
using both its screws.
20 EB 8384-1 EN
Attachment to the control valve – mounting parts and accessories
