Satel CA-6 KLED User manual

®
KEYPAD
CA-6 KLED
ca6kled_e 03/06
The CA-6 KLED keypad is designed for operating and programming the CA-6 alarm
control panel. Information on the security system status is provided by 15 LED
indicators and acoustic signals. The keypad has 12 keys intended for entering data
and launching selected functions. The keys can be illuminated, and operations with
them can be audibly acknowledged.
Fig. 1. View of the keypad.
LED indicators show the current status of 2 partitions and 8 zones of the control panel:
POWER (green color) – the LED indicates the control panel power status:
−ON – mains supply and battery OK,
−blinking – low battery,
−OFF – AC loss.
PHONE (red color) – LED ON indicates that the telephone line is occupied by
the control panel.
TROUBLE (yellow color) – blinking LED indicates there is a failure in the alarm
system.
ALARM - 2 LEDs (red color), designated "A" and "B", assigned to partitions –
alarm is signaled by the LED blinking. The LED goes out after alarm reset.
ARMED - 2 LEDs (green color), designated "A" and "B", assigned to partitions –
armed status is signaled by the LED ON. The blinking LED indicates that the
partition exit delay countdown is in process.
1…8- (red color) LEDs indicating the status of system zones:
−ON – zone violated,
−blinking fast – alarm memory (the zone triggered alarm, but is not
violated any more),

SATEL CA-6 KLED2
−ON with a short extinguishment every 2 seconds – detector tamper
(2EOL zone type),
−flashing 2 every 2 seconds – tamper memory (detector was tampered
with - 2EOL zone type),
−blinking slowly – zone bypassed (indicated only with the partition
disarmed).
Some of the control panel states are additionally indicated by the following LED
combinations:
•[POWER] and [PHONE] LEDs are blinking alternately - the control panel is in
the service mode;
•[POWER], [PHONE] and [TROUBLE] LEDs are blinking simultaneously - the
control panel signals entering into the user functions menu;
•[POWER], [PHONE], [TROUBLE] and [ALARM] (both) LEDs are ON - the
control panel performs the alarm memory display function;
•[TROUBLE] LED is blinking, [POWER] and [PHONE] LEDs are ON - the
control panel performs the trouble memory display function.
For further information regarding the installation and operation of the keypad please
refer to the INSTALLER MANUAL and USER MANUAL of the CA-6 alarm control panel.
Technical data
Nominal supply voltage (±15%).......................................................................... 12V DC
Average current consumption.................................................................................15mA
Operating temperature range ................................................................... -10°C…+55°C
Housing dimensions (width x height x thickness).................................... 144x80x27mm
The latest EC declaration of conformity and product approval certificates
are available for downloading on the www.satel.pl website
