Satel INT-SCR User manual

INT-SCR
Multifunctional keypad
with proximity card reader
Firmware version 2.01 int-scr_en 11/19
SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND
tel. [phone]
www.satel.eu

IMPORTANT
The device should be installed by qualified personnel.
Prior to installation, please read carefully this manual.
Changes, modifications or repairs not authorized by the manufacturer shall void your rights
under the warranty.
SATEL aims to continually improve the quality of its products, which may result in changes in
their technical specifications and software. Current information about the changes being
introduced is available on our website.
Please visit us at:
http://www.satel.eu
The declaration of conformity may be consulted at www.satel.eu/ce
The following symbols may be used in this manual:
- note,
- caution.

CONTENTS
1. Features ..............................................................................................................................2
2. Description...........................................................................................................................3
Operating modes...........................................................................................................3
LED indicators...............................................................................................................3
Bell key..........................................................................................................................3
Wires .............................................................................................................................4
3. Installation ...........................................................................................................................4
3.1 Address setting and operating mode selection.............................................................. 6
Address setting .............................................................................................................6
Operating mode selection ............................................................................................. 6
4. Configuring the keypad........................................................................................................ 7
4.1 Description of parameters and options.......................................................................... 7
Partition keypad with proximity card reader (INT-SCR)................................................. 7
Entry keypad (INT-ENT)..............................................................................................11
Partition keypad (INT-S/SK) ........................................................................................12
5. Using the keypad...............................................................................................................15
5.1 Partition keypad with proximity card reader (INT-SCR)............................................... 15
LED indicators.............................................................................................................15
Sound signaling........................................................................................................... 16
Available functions ......................................................................................................16
Impact of the EN 50131 standard on keypad use ....................................................... 18
5.2 Entry keypad (INT-ENT)..............................................................................................18
LED indicators.............................................................................................................18
Sound signaling........................................................................................................... 19
Available functions ......................................................................................................19
5.3 Partition keypad (INT-S/SK) ........................................................................................19
6. Specifications ....................................................................................................................19

2 INT-SCR SATEL
The INT-SCR multifunctional keypad with proximity card reader is compatible with the
INTEGRA and INTEGRA Plus alarm control panels. It can work as:
partition keypad with proximity card reader – identified in the alarm system as
INT-SCR. It allows the user to control one partition of the alarm system. The device
makes it possible to manage access to a single door. The user can use the access code
or the proximity card (i.e. a 125 kHz passive transponder in the form of a card, tag, etc.).
entry keypad – identified in the alarm system as INT-ENT. It allows the user to activate
delay for the “3. Interior delayed” type zones in the partition controlled with the keypad.
The user can use the access code or the proximity card (i.e. a 125 kHz passive
transponder in the form of a card, tag, etc.).
partition keypad – identified in the alarm system as INT-S/SK. It provides the same
features as the partition keypad with proximity card reader, but the user can only use the
access code.
The keypad is designed for both indoor and outdoor installation.
Fig. 1. INT-SCR multifunctional keypad.
1. Features
LED indicators.
12 keys used to operate the alarm system.
Bell key.
Backlit keys.
Built-in proximity card reader.
OC type output controlled directly from the keypad (BELL).
Relay output for control of electric strike, electromagnetic lock or another door actuator.

SATEL INT-SCR 3
Door status input.
Built-in sounder.
Tamper protection against enclosure opening and removal from the wall.
2. Description
Operating modes
You can select the keypad operating mode (see “Address setting and operating mode
selection”). The operating mode defines which features are available.
Partition keypad with proximity card reader (INT-SCR)
Ability to use cards, tags and other 125 kHz passive transponders to control the alarm
system.
Arming / disarming and alarm clearing in partition.
Capability of triggering alarm from the keypad.
Single door control.
Control of “24. MONO switch” and “25. BI switch” type outputs.
The ability to change access code by the user.
Entry keypad (INT-ENT)
Ability to use cards, tags and other 125 kHz passive transponders to control the alarm
system.
Activation of the delay for the “3. Interior delayed” type zones in the partition.
Control of “24. MONO switch” and “25. BI switch” type outputs.
Partition keypad (INT-S/SK)
Arming / disarming and alarm clearing in partition.
Capability of triggering alarm from the keypad.
Single door control.
Control of “24. MONO switch” and “25. BI switch” type outputs.
The ability to change access code by the user.
LED indicators
The keypad has 3 LEDs:
- red,
- green,
- yellow.
What information is presented by the LEDs depends on the operating mode (see “Using the
keypad”).
Bell key
The bell key controls directly the BELL output of the keypad. The BELL output is an OC type
low-current output. Pressing the key will short the output to the common ground.

4 INT-SCR SATEL
Wires
red +12V
blue COM
green DTA
black CLK
yellow NO
pink NC
grey C
brown IN
purple BELL
Fig. 2. Keypad wires.
Color Description
red +12V +12 VDC power input
blue COM common ground
green DTA data
black CLK clock
yellow NO relay output normally open contact
pink NC relay output normally closed contact
grey C relay output common contact
brown IN door status input (NC type)
purple BELL OC type output
3. Installation
Disconnect power before making any electrical connections.
If an additional cable must be used to make connections, use the unshielded non-twisted
cable. If you use the twisted-pair type of cable, remember that CLK (clock) and DTA (data)
signals must not be sent through one twisted pair. The wires must be run in one cable.
1. Open the keypad enclosure.
2. Place the enclosure base on the wall and mark the location of mounting holes.
3. Drill the holes for wall plugs (anchors).

SATEL INT-SCR 5
4. Using wall plugs (anchors) and screws, secure the enclosure base to the wall. Select wall
plugs specifically intended for the mounting surface (different for concrete or brick wall,
different for plaster wall, etc.).
5. Close the enclosure and secure it with the screw.
6. Connect the blue (COM), green (DTA) and black (CLK) wires to the appropriate terminals
of the control panel expander bus (see the control panel installer manual).
Fig. 3. Connecting the keypad to the control panel.
7. If the keypad is to control an electric strike, electromagnetic lock or another door actuator,
connect this device to the relay output as shown in Fig. 4. Depending on the device type,
use the following wires:
– NC – pink (NC contact of the relay) and gray (C contact of the relay),
– NO – yellow (NO contact of the relay) and gray (C contact of the relay).
It is not recommended that the door actuator be powered from the same source as the
keypad.
In the entry keypad mode, the relay output is disabled (you cannot control the
actuator).
Fig. 4. Connecting the actuator to the keypad.
8. If the keypad is to supervise the door status, connect the detector supervising the door
status to the brown wire (door status input) and the blue wire (COM). If the keypad is not

6 INT-SCR SATEL
to supervise the door status, connect the brown and blue wires together or, when
configuring the keypad, set value 0 for the “Max. door open time” parameter.
The door status input is not supported in the entry keypad mode.
9. Connect the power to the red (+12V) and blue (COM) wires. The keypad may be powered
directly from the control panel, from an expander with power supply or from a power
supply unit.
10.The purple wire (BELL output) you can connect e.g. to the one of the control panel zones.
11.Set the address and select the operating mode for the keypad (see “Address setting and
operating mode selection”).
12.Power on the keypad.
13.Start the identification function in the control panel (see the control panel installer
manual). How the keypad will be identified depends on selected operating mode.
3.1 Address setting and operating mode selection
The keypad with factory default settings has address 0 and its operating mode is “partition
keypad with proximity card reader”. If you wish to change its address or select another
operating mode, follow the procedure below.
1. Power off the keypad (if it is powered on).
2. Disconnect the green (DTA) and black (CLK) wires from the terminals of the control panel
expander bus.
3. Short the green and black wires.
4. Power on the keypad.
5. The and LEDs will start flashing alternately (then, you can disconnect the green
and black wires).
6. Set the address or select the operating mode.
Address setting
1. Press in turn and .
2. The LED will start flashing.
3. Use the numeric keys to enter a new address from the range of 0 to 31.
4. Press .
5. The and LEDs will start flashing alternately. You can proceed to select the
operating mode (press and in turn) or end the procedure (turn power off and
connect the green (DTA) and black (CLK) wires to the corresponding terminals of the
control panel expander bus).
Operating mode selection
1. Press in turn and .
2. The LED will start flashing.
3. Select the operating mode by pressing one of the keys:
- partition keypad with proximity card reader (INT-SCR),
- entry keypad (INT-ENT),
- partition keypad (INT-S/SK).
4. Press .

SATEL INT-SCR 7
5. The and LEDs will start flashing alternately. You can go on to set the address
(press and in turn) or end the procedure (turn power off and connect the green
(DTA) and black (CLK) wires to the corresponding terminals of the control panel expander
bus).
4. Configuring the keypad
The keypad settings you can configure using:
DLOADX program: “Structure” window “Hardware” tab “Expansion modules”
branch [keypad name],
LCD keypad: “Service mode” “Structure” “Hardware” “Expanders” “Settings”
[keypad name].
4.1 Description of parameters and options
Depending on the operating mode, a different set of parameters and options is available.
Presented in square brackets are the names of parameters and options displayed on the
keypad.
Partition keypad with proximity card reader (INT-SCR)
Name – individual name of the device (up to 16 characters).
Partition – partition operated by the keypad.
Lock [Lock feature] – if the option is enabled, the keypad can control access to a single door
(the following parameters are available: “Lock features”, “Relay ON time”, “Max. door open
time” etc.).
Lock features [Lock function] – mode of the relay operation (how it controls the door
actuator):
ON if partition armed [On if part.armed] – the relay will turn on after the partition is
armed. The relay will turn off after the partition is disarmed using the keypad. If the
partition is disarmed in another way, the relay will remain on (to turn the relay off, the
user must enter the code and press / present the card).
Fixed ON time [ON time] – the relay will turn on after access is granted. It will remain on
for the “Relay ON time” duration.
Fixed ON time – OFF if door open [ON, openoff] – the relay will turn on after access is
granted. It will remain on until the door is opened (the door status input is disconnected
from the common ground), however not longer than for the “Relay ON time” duration.
Fixed ON time – OFF if door closed [ON, closeoff] – the relay will turn on after access
is granted. It will remain on until the door is closed (the door status input is reconnected
to the common ground), however not longer than for the “Relay ON time” duration.
Relay ON time – the time period during which the relay can be ON after the access is
granted. You can enter from 1 to 255 seconds.
Authorization control [Unauth. event] – if this option is enabled, unauthorized opening of
the door will save the event to the control panel memory.
Alarm on unauth. access [Unauth. alarm] – if this option is enabled, unauthorized opening
of the door when the partition is armed will trigger an alarm. The option is available if the
“Authorization control” option is enabled.
Max. door open time [Max. door open] – the maximum period of time during which the door
can be open (the door status input can be disconnected from common ground). If the door
is open longer, audible alarm will be triggered in the keypad, and the event will be saved to

8 INT-SCR SATEL
the control panel memory. You can enter from the 0 to 255 seconds. If value 0 is
programmed, the door status will not be monitored.
Fig. 5. DLOADX program: settings of partition keypad with proximity card reader (INT-SCR).
Dependent on door (1) / Dependent on door (2) – you can select the door that must be
closed so that the user can get access (turn the relay on). It allows you to create an
airlock. You may select a door supervised by another expander or alarm system zone
programmed as type “57 Technical – door open”.
Confirmation – you can select whether and how the keypad is to communicate with the user
during operation:
No – the keypad will not inform the user in any way about execution of or refusal to
execute an operation.
Sound – the keypad will inform the user audibly about execution of or refusal to execute
an operation.
Backlight – the keypad will inform the user by flashing key backlight about execution of or
refusal to execute an operation.

SATEL INT-SCR 9
Code+* do not disarm [Code*not dis.] – if this option is enabled, entering the code and
pressing / presenting the card will not disarm the partition (to disarm the partition, the
user must enter the code and press / hold the card).
Access if armed [Code*in arm] – when the option is enabled, the user will get access (the
relay will turn on) even if the partition is armed. The option is available, if the “Code+* do
not disarm” option is enabled.
Code+# equal to code+* [Code#->Code*] – if the option is enabled, reaction to entering the
code and pressing / holding the card is the same as to entering the code and pressing
/ presenting the card. This means that the functions normally available on entering the
code and pressing / holding the card (e.g. arming the partition) are not available. The
option is available when the “Lock” option is enabled.
Users [Master users / Users] – the administrators and users which are permitted to use the
keypad.
FIRE alarm – if this option is enabled, pressing and holding for 3 seconds will trigger the
fire alarm.
AUX. alarm [Medical alarm] – if this option is enabled, pressing and holding for 3 seconds
will trigger the medical alarm.
PANIC alarm – if this option is enabled, pressing and holding for 3 seconds will trigger
the panic alarm.
silent [Silent panic] – if this option is enabled, the panic alarm triggered from the keypad will
be a silent one, i.e. the keypad will not indicate it, there will be no audible signal, but the
alarm will be reported to the monitoring station. The silent panic alarm is useful when the
control panel is sending events to the monitoring station, but unauthorized persons should
not be aware of the alarm being triggered. This option is available, if the “PANIC alarm”
option is enabled.
Alarm 3 incorrect codes [3 wrong codes] – if this option is enabled, using an incorrect code
/ card three times will trigger an alarm.
Quick arming [Quick arm] – if the option is enabled, the user needs no code / card to arm
the partition using the keypad.
Control “BI” output [BI outs ctrl.] – if this option is enabled, the ““Bi” output operating” type
of users can use the keypad to control outputs.
Control “MONO” output [MONO outs ctr.] – if this option is enabled, the ““Mono” output
operating” type of users can use the keypad to control outputs.
Partition blocking [Part.blocking] – if the option is enabled, using the code / card by a user
of the “Blocking partition” or “Guard” type will block the partition (violating a zone belonging
to the partition will trigger no alarm). The duration of blocking is to be defined for the
partition or the user (the user of “Blocking partition” type).
Guard round control [Guard control] – if this option is enabled, using the code / card by
a user of the “Guard” type will be registered as the guard round.
Changing access code [Changing code] – if this option is enabled, the user can change
own code from the keypad.
Exit delay clearing enable [Fin.exit time] – if the option is enabled, the user can terminate
the partition exit delay countdown by pressing successively and (if the “Exit delay
clearing” option is enabled for the partition).
Alarm signal [Alarm (time)] – if this option is enabled, the keypad will audibly signal alarms
throughout the “Global alarm time” (parameter programmed in the control panel).
Alarm signal (until canceled) [Alarm (latch)] – if this option is enabled, the keypad will
audibly signal alarms until they are cleared.

10 INT-SCR SATEL
Sign. entry delay [Entry time] – if this option is enabled, the keypad will audibly signal the
entry delay countdown.
Sign. exit delay [Exit time] – if this option is enabled, the keypad will audibly signal the exit
delay countdown.
Auto-Arm delay countdown [Auto-arm delay] – if this option is enabled, the keypad will
audibly signal the auto-arm delay countdown.
Acc. code sign. (hardware) [Code entered] – if this option is enabled, the keypad will
confirm with a single beep that the code is entered / card is presented (signaling
independent of the control panel). This signal is useful where a time lag occurs between
entering the code / presenting the card and generating the audible signal after verification
of the code / card by the control panel.
CHIME [Chime zones] – if this option is enabled, the keypad will audibly signal violation of
zones with “Chime in module” option enabled, belonging to the partition operated by
means of the keypad.
No auto-reset after 3 tamp. [No autorst.3t.] – if this option is enabled, the feature reducing
the number of tamper alarms from the module to three is disabled (the feature prevents
multiple logging of the same events and applies to successive uncleared alarms).
Backlight – the way how the keys backlight works:
No – always off.
Auto – on for about 40 seconds after pressing any key / reading a card. Additionally, it can
be turned on if a specific event occurs (see the “Auto-backlight” parameter).
Permanent – always on.
Auto-backlight – if the keys backlight goes on automatically, you can define whether and
what event will additionally turn on the backlight:
No – the keys backlight will not be additionally turned on.
Zone violation – the keys backlight will additionally go on if a selected zone is violated.
Entry delay, part. – the keys backlight will additionally go on if entry delay countdown
starts in the selected partition.
Unlock door if fire [Doors on fire] – you can define whether and when the fire alarm will
unlock the door controlled by the keypad (i.e. will activate the relay):
No [no open] – the door will not be unlocked in the event of fire alarm.
Part. fire alarm [on partit. fire] – the door will be unlocked in the event of fire alarm in the
partition to which the keypad is assigned.
Object fire alarm [on object fire] – the door will be unlocked in the event of fire alarm in
the object to which the keypad is assigned.
Fire alarm [on any fire] – the door will be unlocked in the event of fire alarm in the alarm
system.
Code+card – how functions are to be started by the users (e.g. arming / disarming, alarm
clearing, getting access, etc.).
Code OR card – using the code or the card.
Code AND card – using the code and the card.
Follow output – depending on the selected output state (output OFF – using the code or
the card; output ON – using the code and the card).

SATEL INT-SCR 11
Entry keypad (INT-ENT)
Fig. 6. DLOADX program: settings of entry keypad (INT-ENT).
Name – individual name of the device (up to 16 characters).
Partition – partition operated by the keypad.
Delay activation time [Delay act. time] – the time counted from using the code / card, during
which the “3. Interior delayed” type zones operate as delayed ones (in the partition
operated by keypad).
Users [Master users / Users] – the administrators and users which are permitted to use the
keypad.
Confirmation – you can select whether and how the keypad is to communicate with the user
during operation:
No – the keypad will not inform the user in any way about execution of or refusal to
execute an operation.
Sound – the keypad will inform the user audibly about execution of or refusal to execute
an operation.
Backlight – the keypad will inform the user by flashing key backlight about execution of or
refusal to execute an operation.
Alarm 3 incorrect codes [3 wrong codes] – if this option is enabled, using an incorrect code
/ card three times will trigger an alarm.
Control “BI” output [BI outs ctrl.] – if this option is enabled, the ““Bi” output operating” type
of users can use the keypad to control outputs.
Control “MONO” output [MONO outs ctr.] – if this option is enabled, the ““Mono” output
operating” type of users can use the keypad to control outputs.
Guard round control [Guard control] – if this option is enabled, using the code / card by
a user of the “Guard” type will be registered as the guard round.
Delay activation sign. [Delay act. time] – if this option is enabled, the keypad will audibly
signal the countdown of delay activation time.
Acc. code sign. (hardware) [Code entered] – if this option is enabled, the keypad will
confirm with a single beep that the code is entered / card is presented (signaling
independent of the control panel). This signal is useful where a time lag occurs between
entering the code / presenting the card and generating the audible signal after verification
of the code / card by the control panel.
No auto-reset after 3 tamp. [No autorst.3t.] – if this option is enabled, the feature reducing
the number of tamper alarms from the module to three is disabled (the feature prevents
multiple logging of the same events and applies to successive uncleared alarms).

12 INT-SCR SATEL
Backlight – the way how the keys backlight works:
No – always off.
Auto – on for about 40 seconds after pressing any key / reading a card.
Permanent – always on.
Partition keypad (INT-S/SK)
Fig. 7. DLOADX program: settings of partition keypad (INT-S/SK).
Name – individual name of the device (up to 16 characters).
Partition – partition operated by the keypad.
Lock [Lock feature] – if the option is enabled, the keypad can control access to a single door
(the following parameters are available: “Lock features”, “Relay ON time”, “Max. door open
time” etc.).
Lock features [Lock function] – mode of the relay operation (how it controls the door
actuator):
ON if partition armed [On if part.armed] – the relay will turn on after the partition is
armed. The relay will turn off after the partition is disarmed using the keypad. If the
partition is disarmed in another way, the relay will remain on (to turn the relay off, the
user must enter the code and press ).

SATEL INT-SCR 13
Fixed ON time [ON time] – the relay will turn on after access is granted. It will remain on
for the “Relay ON time” duration.
Fixed ON time – OFF if door open [ON, openoff] – the relay will turn on after access is
granted. It will remain on until the door is opened (the door status input is disconnected
from the common ground), however not longer than for the “Relay ON time” duration.
Fixed ON time – OFF if door closed [ON, closeoff] – the relay will turn on after access
is granted. It will remain on until the door is closed (the door status input is reconnected
to the common ground), however not longer than for the “Relay ON time” duration.
Relay ON time – the time period during which the relay can be ON after the access is
granted. You can enter from 1 to 255 seconds.
Relay [Relay type] – do not configure (the parameter is irrelevant to the behavior of the
multifunctional keypad relay).
Authorization control [Unauth. event] – if this option is enabled, unauthorized opening of
the door will save the event to the control panel memory.
Alarm on unauth. access [Unauth. alarm] – if this option is enabled, unauthorized opening
of the door when the partition is armed will trigger an alarm. The option is available if the
“Authorization control” option is enabled.
Max. door open time [Max. door open] – the maximum period of time during which the door
can be open (the door status input can be disconnected from common ground). If the door
is open longer, audible alarm will be triggered in the keypad, and the event will be saved to
the control panel memory. You can enter from the 0 to 255 seconds. If value 0 is
programmed, the door status will not be monitored.
Dependent on door (1) / Dependent on door (2) – you can select the door that must be
closed so that the user can get access (turn the relay on). It allows you to create an
airlock. You may select a door supervised by another expander or alarm system zone
programmed as type “57 Technical – door open”.
Confirmation – you can select whether and how the keypad is to communicate with the user
during operation:
No – the keypad will not inform the user in any way about execution of or refusal to
execute an operation.
Sound – the keypad will inform the user audibly about execution of or refusal to execute
an operation.
Backlight – the keypad will inform the user by flashing key backlight about execution of or
refusal to execute an operation.
Code+* do not disarm [Code*not dis.] – if this option is enabled, entering the code and
pressing will not disarm the partition (to disarm the partition, the user must enter the
code and press ).
Access if armed [Code*in arm] – when the option is enabled, the user will get access (the
relay will turn on) even if the partition is armed. The option is available, if the “Code+* do
not disarm” option is enabled.
Users [Master users / Users] – the administrators and users which are permitted to use the
keypad.
FIRE alarm – if this option is enabled, pressing and holding for 3 seconds will trigger the
fire alarm.
AUX. alarm [Medical alarm] – if this option is enabled, pressing and holding for 3 seconds
will trigger the medical alarm.
PANIC alarm – if this option is enabled, pressing and holding for 3 seconds will trigger
the panic alarm.

14 INT-SCR SATEL
silent [Silent panic] – if this option is enabled, the panic alarm triggered from the keypad will
be a silent one, i.e. the keypad will not indicate it, there will be no audible signal, but the
alarm will be reported to the monitoring station. The silent panic alarm is useful when the
control panel is sending events to the monitoring station, but unauthorized persons should
not be aware of the alarm being triggered. This option is available, if the “PANIC alarm”
option is enabled.
Alarm 3 incorrect codes [3 wrong codes] – if this option is enabled, using an incorrect code
three times will trigger an alarm.
Quick arming [Quick arm] – if the option is enabled, the user needs no code to arm the
partition using the keypad.
Control “BI” output [BI outs ctrl.] – if this option is enabled, the ““Bi” output operating” type
of users can use the keypad to control outputs.
Control “MONO” output [MONO outs ctr.] – if this option is enabled, the ““Mono” output
operating” type of users can use the keypad to control outputs.
Partition blocking [Part.blocking] – if the option is enabled, using the code by a user of the
“Blocking partition” or “Guard” type will block the partition (violating a zone belonging to the
partition will trigger no alarm). The duration of blocking is to be defined for the partition or
the user (the user of “Blocking partition” type).
Guard round control [Guard control] – if this option is enabled, using the code by a user of
the “Guard” type will be registered as the guard round.
Changing access code [Changing code] – if this option is enabled, the user can change
own code from the keypad.
Exit delay clearing enable [Fin.exit time] – if the option is enabled, the user can terminate
the partition exit delay countdown by pressing successively and (if the “Exit delay
clearing” option is enabled for the partition).
Alarm signal [Alarm (time)] – if this option is enabled, the keypad will audibly signal alarms
throughout the “Global alarm time” (parameter programmed in the control panel).
Alarm signal (until canceled) [Alarm (latch)] – if this option is enabled, the keypad will
audibly signal alarms until they are cleared.
Sign. entry delay [Entry time] – if this option is enabled, the keypad will audibly signal the
entry delay countdown.
Sign. exit delay [Exit time] – if this option is enabled, the keypad will audibly signal the exit
delay countdown.
Auto-Arm delay countdown [Auto-arm delay] – if this option is enabled, the keypad will
audibly signal the auto-arm delay countdown.
Acc. code sign. (hardware) [Code entered] – if this option is enabled, the keypad will
confirm with a single beep that the code is entered (signaling independent of the control
panel). This signal is useful where a time lag occurs between entering the code and
generating the audible signal after verification of the code by the control panel.
CHIME [Chime zones] – if this option is enabled, the keypad will audibly signal violation of
zones with “Chime in module” option enabled, belonging to the partition operated by
means of the keypad.
No auto-reset after 3 tamp. [No autorst.3t.] – if this option is enabled, the feature reducing
the number of tamper alarms from the module to three is disabled (the feature prevents
multiple logging of the same events and applies to successive uncleared alarms).
Backlight – the way how the keys backlight works:
No – always off.
Auto – on for about 40 seconds after pressing any key. Additionally, it can be turned on if
a specific event occurs (see the “Auto-backlight” parameter).

SATEL INT-SCR 15
Permanent – always on.
Auto-backlight – if the keys backlight goes on automatically, you can define whether and
what event will additionally turn on the backlight:
No – the keys backlight will not be additionally turned on.
Zone violation – the keys backlight will additionally go on if a selected zone is violated.
Entry delay, part. – the keys backlight will additionally go on if entry delay countdown
starts in the selected partition.
Unlock door if fire [Doors on fire] – you can define whether and when the fire alarm will
unlock the door controlled by the keypad (i.e. will activate the relay):
No [no open] – the door will not be unlocked in the event of fire alarm.
Part. fire alarm [on partit. fire] – the door will be unlocked in the event of fire alarm in the
partition to which the keypad is assigned.
Object fire alarm [on object fire] – the door will be unlocked in the event of fire alarm in
the object to which the keypad is assigned.
Fire alarm [on any fire] – the door will be unlocked in the event of fire alarm in the alarm
system.
5. Using the keypad
Most features are available on using the code or proximity card by the user.
By default, the following codes are preprogrammed in the control panel:
service code: 12345
object 1 master user (administrator) code: 1111
The factory default codes should be changed before you start using the alarm
system.
Do not make your code available to other people.
The keypad distinguishes between presenting and holding the card (in the latter case the
card must be held in front of the reader for about 3 seconds).
How the keypad behaves depends on the selected operating mode.
5.1 Partition keypad with proximity card reader (INT-SCR)
LED indicators
LED Color Description
red ON or flashing – alarm or alarm memory
green ON – partition is armed
flashing – exit delay countdown is running in the partition
yellow flashing – trouble or trouble memory (the LED goes out when
the partition is armed)
Information about the armed state can be extinguished after a preset time.
Flashing of the LEDs successively from left to right indicates no communication with
the control panel.

16 INT-SCR SATEL
Sound signaling
Beeps generated when operating
The installer can disable the sound signaling or replace it with flashing of the keypad
backlight (see “Configuring the keypad”).
1 short beep – any number key is pressed or the code / card is used.
2 short beeps – the first code / card is accepted during two code arming / disarming.
3 short beeps – confirmation of:
– starting the arming procedure (there is exit delay in the partition) or arming (there is no
exit delay in the partition),
– disarming and/or alarm clearing.
4 short and 1 long beeps – function is executed.
3 pairs of short beeps – code change is required.
1 long beep – refusal to arm (there are violated zones in the partition or there is a trouble).
2 long beeps – incorrect code / card.
3 long beeps – unavailable function.
Event signaling
The installer defines whether events are to be signaled audibly (see “Configuring the
keypad”).
5 short beeps – zone violation (CHIME).
Long beep every 3 seconds, followed by a series of short beeps for 10 seconds
and 1 long beep – countdown of exit delay (if the time is shorter than 10 seconds, only
the final sequence of short beeps will be generated).
A sequence of 7 beeps of diminishing duration, repeated every few seconds –
countdown of auto-arming delay.
2 short beeps every seconds – countdown of entry delay.
Continuous beep – alarm.
Long beep every 2 seconds – alarm memory.
Long beep every second – fire alarm.
Short beep every 2 seconds – fire alarm memory.
Very short beeps – door open too long.
Available functions
[Code] / presenting the card
Enter the code and press / present the card to:
get access (turn on the keypad relay),
disarm the partition,
clear alarm,
toggle the state of “25. BI switch” type outputs,
turn on the “24. MONO switch” type outputs,
confirm the guard round,
temporary block the partition.
You can start two or more functions at the same time (e.g. disarming, alarm clearing and
getting access).

SATEL INT-SCR 17
Availability of the functions depends on:
type and rights of the user,
keypad settings,
partition state.
If you use the code or card and the and LEDs start flashing alternately, this
will mean that the code and the card must be used to run the functions.
If you use the code/card to disarm the partition and the and LEDs start flashing
alternately, this will mean that the keypad is waiting for the code/card of the other user
(disarming using 2 codes).
[Code] / holding the card
Enter the code and press / hold the card to:
start the procedure of partition arming / arm the partition,
get access (turn on the keypad relay),
disarm the partition,
clear alarm,
toggle the state of “25. BI switch” type outputs,
turn on the “24. MONO switch” type outputs,
confirm the guard round,
temporary block the partition.
unblock access to cash machine.
You can start two or more functions at the same time (e.g. disarming, alarm clearing and
getting access).
Availability of the functions depends on:
type and rights of the user,
keypad settings,
partition state.
If you use the code or card and the and LEDs start flashing alternately, this
will mean that the code and the card must be used to run the functions.
If you use the code/card to arm / disarm the partition and the and LEDs start
flashing alternately, this will mean that the keypad is waiting for the code/card of the
other user (arming / disarming using 2 codes).
Quick arming
The installer may permit arming without using the code / card.
1. To select the arming mode, press one of the keys:
- full arming,
- full arming + bypasses,
- arming without interior,
- arming without interior and without entry delay.
2. Press . This will start the partition arming procedure (if the exit delay is 0, the partition
will be armed instantly).

18 INT-SCR SATEL
Triggering the alarm from keypad
The installer can permit triggering alarms from the keypad. To trigger an alarm, do the
following:
fire alarm – press and hold down for about 3 seconds,
medical (auxiliary) alarm – press and hold down for about 3 seconds,
panic alarm – press and hold down for about 3 seconds. The installer defines whether
the audible or silent panic alarm will be triggered.
Silencing the alarm sound at the keypad
To silence the alarm sound for about 40 seconds, press any key.
Code changing
You can change your code if the “Changing access code” option is enabled.
1. Press and hold the key for about 3 seconds.
2. When the and LEDs start flashing alternately, enter the old code and press .
3. When the and LEDs start flashing alternately, enter the new code and press .
Impact of the EN 50131 standard on keypad use
If the control panel is configured in accordance with the requirements of Standard EN 50131
for Grade 2 (INTEGRA) or Grade 3 (INTEGRA Plus):
the keypad does not signal alarms,
the LED indicates alarms only after entering the code / reading the card,
flashing of the LED indicates a trouble, bypassed zones or an alarm,
the LED goes out after 60 seconds (Grade 3),
quick arming features are not available,
arming procedure cannot be initiated, if there are violated zones in the partition or there is
a trouble in the system,
the partition will not be armed if, at the moment of completion of exit delay countdown:
– there is a violated zone in partition which was not violated when the arming procedure
was started,
– there is a trouble which did not exist when the arming procedure was started.
5.2 Entry keypad (INT-ENT)
LED indicators
LED Color Description
green flashing – delay activation time countdown is running
Flashing of the LEDs successively from left to right indicates no communication with
the control panel.
