Sauder 409944 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-19
Français p 20-22
Español p 23-25
Lot # 387426 12/29/15
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Utility Stand
Shoal Creek Collection | Model 409944
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
For things 'n such.

Table of Contents Assembly Tools Required
2-3
4-5
6-19
20-22
23-25
26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
409944 www.sauder.com/servicesPae 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A2 RIGHT END (1)
B2 LEFT END (1)
C TOP (1)
D BACK (1)
D14 RIGHT DRAWER SIDE (1)
D15 LEFT DRAWER SIDE (1)
D61 DRAWER BACK (1)
D985 DRAWER BOTTOM (1)
E SHELF (1)
F BOTTOM (2)
G RIGHT FRONT LEG (1)
H LEFT FRONT LEG (1)
I REAR LEG (2)
J2 DRAWER FRONT (1)
M67 DRAWER BRACE (1)
O END MOLDING (2)

Part Identification Now you know
our ABCs.
409944www.sauder.com/services Pae 3
A2
B2
C
D
E
FG
H
I
J2
O
O
I
F
M67
D61
D14
D15
D985

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
409944 www.sauder.com/servicesPae 4
FILE GLIDE - 2
4B
FILE BRACKET - 1
57G
HIDDEN CAM - 17
1F
CAM COVER - 1
BB
METAL PIN - 4
WPULL - 2 Z
CAM SCREW - 4
8F
SLIDE CAM - 2
X
CAM DOWEL - 13
2F
FILE ROD - 2
CC
FILE BRACKET - 1
12B
40CA CABINET RIGHT - 1 40CB CABINET LEFT - 1 40CC DRAWER RIGHT - 1 40CD DRAWER LEFT - 1

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
409944www.sauder.com/services Pae 5
SILVER 3/4" MACHINE SCREW - 4
FF
BROWN 7/16" LARGE HEAD SCREW - 4
HH
BLACK 2-1/4" FLAT HEAD SCREW - 4
EE
GOLD 5/16" FLAT HEAD SCREW - 8
II NAIL - 20 JJ
BLACK 9/16" FLAT HEAD SCREW - 4
GG
30S BLACK 1-9/16" FLAT HEAD SCREW - 5

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push seventeen HIDDEN CAMS (1F) into the ENDS (A2
and B2), LEGS (G, H, and I), SHELF (E), BOTTOMS (F),
and DRAWER BRACE (M67). Then, insert the metal end
of a CAM DOWEL (2F) into each HIDDEN CAM, except in
the ENDS (A2 and B2).
409944 www.sauder.com/servicesPae 6
(17 used)
(12 used)
Arrow
1F
2F
Do not tihten the HIDDEN CAMS in this step.
Do not insert
CAM DOWELS
into these parts.
A2
B2
E
F
G
H
I
I
F
M67
Arrow
Arrow
1F
The arrow in the HIDDEN
CAM must point toward the
hole in the ede of the board.
Hole
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow

å Fasten the CABINET RIGHT (40CA) and CABINET LEFT (40CB)
to the ENDS (A2 and B2). Use four GOLD 5/16" FLAT HEAD
SCREWS (II) throuh holes #1 and #3.
å Fasten the REAR LEGS (I) to the ENDS (A2 and B2). Use four
BLACK 2-1/4" FLAT HEAD SCREWS (EE).
Step 2
409944www.sauder.com/services Pae 7
1
2
34
A2
B2
I
I
BLACK 2-1/4" FLAT HEAD SCREW
(4 used for the LEGS)
EE
Anled ede
These holes
must be here.
Roller end
Roller end
Surface without
HIDDEN CAMS
These holes
must be here.
1
2
3
4
Remember:
Rihty tihty.
Lefty loosey.
GOLD 5/16" FLAT HEAD SCREW
(4 used for the RAILS)
II

Step 3
å With the REAR LEG (I) on the floor, fasten the LEFT
END (B2) to the SHELF (E). Tihten two HIDDEN CAMS.
409944 www.sauder.com/servicesPae 8
B2
E
I
Finished ede
Start Tighten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
Surface with HIDDEN CAMS

å Insert a METAL PIN (W) into the holes of each short ede
of the BOTTOMS (F).
å Fasten the BOTTOMS (F) to the LEFT END (B2). Tihten
two HIDDEN CAMS.
å NOTE: Be sure the PINS in the BOTTOMS (F) insert into
the holes in the LEFT END (B2).
Step 4
409944www.sauder.com/services Pae 9
Surface with HIDDEN CAMS
B2
W
F
W
Finished ede
Finished ede
Surface with HIDDEN CAMS
F
Arrow
Minimum
190 derees
Maximum
210 derees

Step 5
å With the REAR LEG (I) on the floor, fasten the RIGHT
END (A2) to the SHELF (E) and BOTTOMS (F). Tihten
four HIDDEN CAMS.
å NOTE: Be sure the PINS in the BOTTOMS (F) insert into
the holes in the RIGHT END (A2).
409944 www.sauder.com/servicesPae 10
A2
E
F
F
I
Arrow
Minimum
190 derees
Maximum
210 derees

å Turn four BLACK 9/16" FLAT HEAD SCREWS (GG) into the
ENDS (A2 and B2) until the shoulders of the SCREWS rest
on the surfaces of the ENDS.
å Slide the END MOLDINGS (O) onto the ENDS (A2 and B2).
Line up the rooves in the MOLDINGS over the heads of
the SCREWS in the ENDS.
Step 6
409944www.sauder.com/services Pae 11
Apply pressure with your hands
as you uide the MOLDINGS over
the SCREWS and onto the ENDS.
O
A2
B2
GG
GG
O
Shoulder
Shoulder
BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
GG

Step 7
å Turn four CAM SCREWS (8F) into the FRONT LEGS (G
and H) as shown in the upper diaram below.
å Fasten the LEGS (G and H) to the ENDS (A2 and B2) as
shown in the lower diaram below. Tihten four
HIDDEN CAMS.
409944 www.sauder.com/servicesPae 12
8F
G
H
A2
B2
G
H
Anled ede
1
2

å Fasten the TOP (C) to the LEGS (G, H, and I). Tihten
three HIDDEN CAMS.
Step 8
409944www.sauder.com/services Pae 13
C
G
H
I
The HIDDEN CAM in this LEG
will be tihtened in the next step.
Finished ede
Arrow
Minimum
190 derees
Maximum
210 derees
Surface with holes

Step 9
å Carefully turn your unit over onto its front edes. Lay the
BACK (D) over your unit.
å Make equal marins alon the two lon and two short
edes of the BACK (D). Push on opposite corners of your
unit if needed to make it "square".
å Fasten the BACK (D) to your unit usin the NAILS (JJ).
å Fasten the LEFT REAR LEG (I) to the TOP (C). Tihten the
HIDDEN CAM.
409944 www.sauder.com/servicesPae 14
Tihten this HIDDEN CAM.
C
D
I
Arrow
Minimum
190 derees
Maximum
210 derees
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
NAIL
(20 used in this step)
JJ

Step 10
409944www.sauder.com/services Pae 15
å Insert the DRAWER SIDES (D14 and D15) at an angle
into the slot at each end of the DRAWER FRONT (J2). å Slide the DRAWER BOTTOM (D985) into the grooves in the DRAWER SIDES (D14 and D15) and
DRAWER FRONT (J2).
å Fasten the DRAWER BRACE (M67) to the DRAWER
FRONT (J2). Tighten one HIDDEN CAM. å Fasten the DRAWER BACK (D61) to the DRAWER SIDES (D14 and D15) and DRAWER BRACE (M67). Use
five BLACK 1-9/16" FLAT HEAD SCREWS (30S).
Surface with
HIDDEN CAM
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(5 used in this step)
J2
J2
M67
J2
M67
VIEW THE T-LOCK BOX VIDEO
D15
D14
D15
D985
D14
D14
D15
D61
Unfinished
surface
30S
Be sure the
DRAWER
BOTTOM
inserts into
the DRAWER
BACK roove.
The tabs should insert freely
into the slots. Gently tilt the
DRAWER SIDES side to side
until the tabs slip into the slots.
With the palm of your hand,
tap the DRAWER BOTTOM
down into the roove.

Step 11
å Insert a SLIDE CAM (X) into the DRAWER SIDES (D14 and D15).
å Fasten the DRAWER RIGHT (40CC) and DRAWER LEFT (40CD)
to the DRAWER SIDES (D14 and D15). Use four GOLD 5/16"
FLAT HEAD SCREWS (II) throuh holes #2 and #4.
å NOTE: The screw head in the CAM must be visible throuh the
slotted hole in the SLIDE.
409944 www.sauder.com/servicesPae 16
X
X
D14
D15
Roller end
Roller end
1
2
3
4
1
2
3
4
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
II
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES

å Fasten a FILE BRACKET (57G) to the DRAWER FRONT (J2) as shown in the upper diaram below. Use two
BROWN 7/16" LARGE HEAD SCREWS (HH).
å Fasten a FILE BRACKET (12B) to the DRAWER BACK (D61). Use two BROWN 7/16" LARGE HEAD SCREWS (HH).
å Fasten two PULLS (Z) to the DRAWER FRONT (J2). Use four SILVER 3/4" MACHINE SCREWS (FF).
å Press one of the FILE GLIDES (4B) over the RIGHT DRAWER SIDE (D14) as shown in the lower diaram below. The
FILE GLIDES are necessary to han files.
å Slide the FILE RODS (CC) throuh the holes in the FILE BRACKETS (57G and 12B) and into the FILE GLIDE (4B) on
the RIGHT DRAWER SIDE (D14).
å Slide another FILE GLIDE (4B) onto the other end of the FILE RODS (CC), then press this FILE GLIDE over the
LEFT DRAWER SIDE (D15).
Step 12
409944www.sauder.com/services Pae 17
J2
Z
12B
12B
CC
4B
4B
D61
D15
57G
57G
SILVER 3/4" MACHINE SCREW
(4 used for the PULLS)
FF
BROWN 7/16" LARGE HEAD SCREW
(4 used for the FILE BRACKETS)
HH
CC
D14
Want options? Customize
your item with add-on
hardware kits available
on sauder.com.

Step 13
å Carefully stand your unit upriht.
å To insert the drawer into your unit, tip the front of the
drawer down and drop the rollers on the drawer behind
the rollers on the unit. Lift the front of the drawer up and
slide it into the unit.
å Push a CAM COVER (BB) onto the HIDDEN CAM on the
RIGHT REAR LEG (I).
409944 www.sauder.com/servicesPae 18
IBB
50 lbs.
25 lbs.
35 lbs.
Pro Tip: Lift with your
les. And, you know,
your arms.

å To make adjustments to the drawers, loosen SCREW #4 in the SLIDES a 1/4 turn, then turn the CAM clockwise or
counter-clockwise. Notice how the drawer raises or lowers as you turn the CAM. The hiher the screw in the oblon hole,
the hiher your drawer front will be. The lower the screw, the lower the drawer front. By adjustin the drawers this way, it
will help the DRAWER FRONTS line up better when closed. Tihten the SCREW when finished with adjustments.
å NOTE: Please read the back paes of the instruction booklet for important safety information.
å This completes assembly. Clean with your favorite furniture polish or a damp cloth. Wipe dry.
Step 14
409944www.sauder.com/services Pae 19
And to celebrate, why not share your success story?
The hiher the screw in the oblon hole,
the hiher your drawer front will be. The
lower the screw, the lower the drawer front.
Loosen screw #4 a 1/4 turn, turn the cam a 1/4 turn
maximum in both the clockwise and counter-clockwise
directions to make adjustments, and then tihten screw #4.
Cam
43

A l’usae exclusif du
Canada Noter la date
d’achat de cet élément
et conserver le livret
pour future référence.
Pour contacter Sauder
en ce qui concerne cet
élément, faire référence
au numéro de lot et
numéro de modèle en
appelant notre numéro
sans frais.
Lot nº : ____________
Date de
l’achat: ____________
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
NOUS SOMMES LA POUR VOUS AIDER!
Nous faisons de notre mieux pour nous assurer que votre meuble
arrive dans d’excellentes conditions. Nos représentants du service
Clientèle sont aimables et prêts à vous aider au cas où une pièce
aurait été endommaée ou manquerait (ou si vous aviez besoin
d’aide pour l’assemblae). NE RAMENEZ PAS LE MEUBLE AU
MAGASIN. Au Canada, composez ce numéro d’appel ratuit:
1-800-523-3987
Du lundi au vendredi, de 9 heures du matin à
5:30 heures du soir (horaire Côte Est)
(sauf jours fériés)
Si une pièce a besoin d’être remplacée, la pièce de remplacement
sera envoyée dans les 48 heures. (Sauf week-ends et jours fériés)
Utilisez les instructions d’assemblae en français avec les
schémas étape par étape du manuel d’instruction en anlais.
Chaque étape en français correspond à la même étape
en anlais. La pièce devant être attachée à l’élément est
représentée en ris sur les schémas de chaque étape pour plus
de précision. Comparer la “Liste de pièces” ci-dessous avec
la “PART IDENTIFICATION” du manuel en anlais pour vous
familiariser avec les pièces avant l’assemblae.
REMARQUE : CE MANUEL D’INSTRUCTIONS CONTIENT
D’IMPORTANTES INFORMATIONS RELATIVES À LA SÉCURITÉ.
À LIRE ET CONSERVER POUR TOUTE RÉFÉRENCE FUTURE.
Meuble d'appointModèle 409944
40CA ÉLÉMENT DROITE.......................................................1
40CB ÉLÉMENT GAUCHE...................................................1
40CC TIROIR DROIT.................................................................1
40CD TIROIR GAUCHE...........................................................1
4B ARMATURE POUR DOSSIERS.........................2
12B CONSOLE POUR DOSSIERS.............................1
1F EXCENTRIQUE ESCAMOTABLE...................17
2F CHEVILLE D'EXCENTRIQUE ........................... 13
8F VIS D'EXCENTRIQUE ...............................................4
57G CONSOLE POUR DOSSIERS.............................1
W GOUPILLE EN MÉTAL.............................................4
X EXCENTRIQUE DE COULISSE.........................2
Z POIGNÉE............................................................................2
BB COUVERCLE D'EXCENTRIQUE........................1
CC TIGE DE DOSSIER......................................................2
EE VIS TÊTE PLATE 57 mm NOIRE.....................4
FF VIS À MÉTAUX 19 mm ARGENTÉE..............4
GG VIS TÊTE PLATE 14 mm NOIRE......................4
HH VIS TÊTE LARGE 11 mm MARRON..............4
II VIS TÊTE PLATE 8 mm DORÉE ......................8
JJ CLOU ................................................................................20
30S VIS TÊTE PLATE 40 mm NOIRE ....................5
A2 EXTRÉMITÉ DROITE..................................................1
B2 EXTRÉMITÉ GAUCHE...............................................1
C DESSUS...............................................................................1
D ARRIÈRE ..............................................................................1
D14 CÔTÉ DROIT DE TIROIR........................................1
D15 CÔTÉ GAUCHE DE TIROIR..................................1
D61 ARRIÈRE DE TIROIR...................................................1
D985 FOND DE TIROIR..........................................................1
E TABLETTE..........................................................................1
F DESSOUS..........................................................................2
G PIED AVANT DROIT....................................................1
H PIED AVANT GAUCHE.............................................1
I PIED ARRIÈRE................................................................2
J2 DEVANT DE TIROIR....................................................1
M67 ENTRETOISE DE TIROIR........................................1
O MOULURE D’EXTRÉMITÉ .....................................2
409944 www.sauder.com/servicesPae 20
