Sauder Palladia Lateral File User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-28
Français p 29-32
Español p 33-36
Lot # 530604 06/20/19
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Lateral File
Palladia Collection | Model 412015
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Get all organized
and stu.

Table of Contents Assembly Tools Required
2-3
4-5
6-28
29-32
33-36
37-38
39
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
412015 www.sauder.com/servicesPae 2
Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A OUTER RIGHT END (1)
B OUTER LEFT END (1)
C3 INNER RIGHT END (1)
D3 INNER LEFT END (1)
D32 LEFT DRAWER SIDE (2)
D33 RIGHT DRAWER SIDE (2)
D61 DRAWER BACK (2)
D729 DRAWER BOTTOM (2)
E2 TOP (1)
F2 BOTTOM (1)
G BACK (1)
H BRACE (1)
I DRAWER FRONT (2)
M26 VERTICAL MOLDING (2)
M63
DRAWER BRACE (2)
(Hidden part usin recycled
material. Color may vary.)
N SKIRT (1)
O FRONT MOLDING (1)
P BOTTOM MOLDING (1)
R RIGHT MOLDING (1)
S LEFT MOLDING (1)
T PLINTH (4)
U HALF DISK (4)

Part Identification Now you know
our ABCs.
412015www.sauder.com/services Pae 3
A
B
C3
D3
E2
F2
G
H
N
O
P
R
S
T
T
T
T
I
D729
D32
D33
D61
U
U
M63
M26
M26
U
U

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412015 www.sauder.com/servicesPae 4
7F TWIST-LOCK®FASTENER - 12 MOLDING
CONNECTOR - 2
17F
ANGLE BRACKET - 10
27G
FILE GLIDE - 4
5B
29G SAFETY STOP - 2 20G DRAWER STOP - 2
KNOB - 4
33K
FILE BAR - 4
1B
DRAWER FRONT
BRACKET - 4
10G
FILE ROD - 4
9B
INTERLOCK TRACK - 1
22G
FILE BRACKET - 4
12B
NAIL - 36
1N
METAL BRACKET - 6
4G
METAL PIN - 4
1R
HIDDEN CAM - 2
1F CAM DOWEL - 2 2F
(EXTENSION SET SHOWN SEPARATED)
EXTENSION SLIDE - 4
40MC
EXTENSION RAIL - 4
40MA

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
412015www.sauder.com/services Pae 5
SILVER 1/2" MACHINE SCREW - 4
38S
BLACK 9/16" LARGE HEAD SCREW - 44
1S
SILVER 1-1/8" FLAT HEAD SCREW - 12
10S
BLACK 1-1/4" FLAT HEAD SCREW - 4
7S
BROWN 7/16" LARGE HEAD SCREW - 4
6S
BROWN 1" FLAT HEAD SCREW - 6
12S
GOLD 5/16" FLAT HEAD SCREW - 16
3S
30S BLACK 1-9/16" FLAT HEAD SCREW - 10
BLACK 1-15/16" FLAT HEAD SCREW - 4
113S

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the
empty carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the lare holes in the
OUTER ENDS (A and B).
å Repeat this step for the INNER ENDS (C3 and D3)
and BOTTOM (F2).
412015 www.sauder.com/servicesPae 6
A
B
7F
(12 used)
Do not tihten the TWIST-LOCK® FASTENERS in this step.
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=2586
to watch a video on how to assemble your unit.

å Fasten four HALF DISKS (U) to four PLINTHS (T). Use four SILVER
1-1/8" FLAT HEAD SCREWS (10S).
å Fasten ten ANGLE BRACKETS (27G) to the OUTER ENDS (A and B).
Use ten BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edes of the ANGLE BRACKETS are even with
the edes of the ENDS.
å Fasten the PLINTHS (T) and VERTICAL MOLDINGS (M26) to the
OUTER ENDS (A and B). Use ten BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 2
412015www.sauder.com/services Pae 7
The larer
hole should
be facin up.
T
T
T
T
T
T
U
U
U
U
A
B
Surface with
TWIST-LOCK
®
FASTENERS
Surface with
TWIST-LOCK
®
FASTENERS
Use the holes below the roove in
the VERTICAL MOLDING (M26).
Use the holes
below the roove
in the VERTICAL
MOLDING (M26).
27G
27G
The VERTICAL
MOLDINGS should
be centered over
the HALF DISKS.
The VERTICAL MOLDINGS should
be centered over the HALF DISKS.
(10 used)
SILVER 1-1/8" FLAT HEAD SCREW
(4 used for the HALF DISKS)
10S
BLACK 9/16" LARGE HEAD SCREW
(20 used for the ANGLE BRACKETS)
1S
M26
M26
Use the lower two
holes in the PLINTH.

Step 3
å The next three steps involve an important safety feature
desined to prevent more than one drawer from openin
at the same time.
å Insert the two SAFETY STOPS (29G) into the holes
shown in the INNER RIGHT END (C3).
412015 www.sauder.com/servicesPae 8
C3
This pin must insert into the location
holes in the INNER RIGHT END (C3).
29G
29G
29G

å Diaram 1. Measure 1-1/2" from one end of the INTERLOCK TRACK (22G). Position the
INTERLOCK TRACK as shown.
å SAFETY STOP / TRACK ATTACHMENT:
å Diaram 2. Tilt the first ede of the INTERLOCK TRACK (22G) into the SAFETY STOP (29G).
å Diaram 3. Rotate the INTERLOCK TRACK and apply force to snap the second ede into the
SAFETY STOP.
å Diaram 4. Repeat the SAFETY STOP/ TRACK ATTACHMENT for the next SAFETY STOPS
while holdin the previously completed SAFETY STOP in its location hole. Visually check
that all INTERLOCK TRACK edes have been snapped into the SAFETY STOPS as shown in
diaram 3.
å Diaram 5. Remove the INTERLOCK TRACK assembly from Diaram 4 and flip it over
before insertin the INTERLOCK TRACK (22G) with SAFETY STOPS (29G) into the roove
in the INSIDE RIGHT END (C3).
Step 4
412015www.sauder.com/services Pae 9
C3
C3
Cut out this rectanle
to use as a "spacer"
1-1/2"
4.
5.
1.
1-1/2"
29G
2. 3.
29G
22G
22G
22G
22G
STOP
Be sure the
interlock track
snaps into each
safety stop.
F
L
I
P
O
V
E
R

Step 5
412015 www.sauder.com/servicesPae 10
å Separate the EXTENSION SLIDES (40MC) from the EXTENSION RAILS (40MA) as shown in the upper diaram
below. Be prepared, the parts are reasy.
å Fasten four EXTENSION RAILS (40MA) to the INNER ENDS (C3 and D3). Use eiht GOLD 5/16" FLAT HEAD
SCREWS (3S) throuh holes #1 and #4.
å NOTE: For each EXTENSION RAIL, turn a SCREW into the hole shown in the enlared diaram. Then, slide the
inner cartride of the EXTENSION RAIL in to find the other hole that lines up with the hole in the END. Turn a
SCREW into this hole.
After fastenin the EXTENSION RAIL to the INNER
END (C3), the SAFETY STOP should touch the top
ede of the RAILS. If the ap is larer than 1/16"
the drawers could lock up and not open. If this
happens, open two drawers at the same time to
override the interlock system. Remove the drawers
to re-adjust the INTERLOCK TRACK assembly.
C3
D3
Open end
Open end
Open end
GOLD 5/16" FLAT HEAD SCREW
(8 used in this step)
3S
Push the black lever in and pull the SLIDE from the RAIL.
40MA40MC
1
2
34
1
2
3
4
1
2
34
1
2
3
4

å Tap two MOLDING CONNECTORS (17F) into the notches
in the MOLDINGS (O, R, and S).
å Fasten the MOLDINGS (O, R, and S) to the TOP (E2). Use
eiht SILVER 1-1/8" FLAT HEAD SCREWS (10S).
å NOTE: Do not overtihten the SCREWS into the TOP.
Step 6
412015www.sauder.com/services Pae 11
17F
17F
O
R
S
O
R
S
E2
Flat end
Flat end
Use your hammer to tap the
MOLDING CONNECTORS (17F)
into the notches in the MOLDINGS.
Finished surface
Rounded ede
SILVER 1-1/8" FLAT HEAD SCREW
(8 used in this step)
10S
Surface
with holes

Step 7
å Fasten the OUTER LEFT END (B) to the LEFT MOLDING (S).
Tihten two TWIST-LOCK® FASTENERS.
412015 www.sauder.com/servicesPae 12
B
S
Surface with
TWIST-LOCK
®
FASTENERS
Dowel end
O
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution
How to use the SAUDER TWIST-LOCK® FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoinin part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoinin
part while lockin the FASTENER.
2. Tihten the FASTENER with a Phillips
screwdriver as tiht as possible.

å Insert two METAL PINS (1R) into the INNER LEFT END (D3).
å Fasten the INNER LEFT END (D3) to the TOP (E2).
Tihten two TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the INNER LEFT END
insert into the holes in the TOP.
Step 8
412015www.sauder.com/services Pae 13
D3 E2
Surface with
TWIST-LOCK
®
FASTENERS
1R

Step 9
å Fasten the OUTER RIGHT END (A) to the RIGHT MOLDING (R).
Tihten two TWIST-LOCK® FASTENERS.
å Insert two METAL PINS (1R) into the INNER RIGHT END (C3).
å Fasten the INNER RIGHT END (C3) to the TOP (E2). Tihten two
TWIST-LOCK® FASTENERS.
å NOTE: Be sure the METAL PINS in the INNER RIGHT END insert
into the holes in the TOP.
412015 www.sauder.com/servicesPae 14
The surfaces with theTWIST-LOCK®
FASTENERS should be facing inside. A
C3
R
E2
1R

å Fasten the BOTTOM (F2) to the OUTER ENDS (A and B).
Tihten four TWIST-LOCK® FASTENERS.
å Fasten the BOTTOM (F2) to the INNER ENDS (C3 and D3).
Use four BLACK 1-15/16" FLAT HEAD SCREWS (113S).
Step 10
412015www.sauder.com/services Pae 15
A
B
F2
D3
C3
Finished ede
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)
113S

Step 11
å Fasten the BRACE (H) to the BOTTOM MOLDING (P) and
SKIRT (N). Use six BROWN 1" FLAT HEAD SCREWS (12S).
å Fasten the BRACE (H) to the PLINTHS (T). Use four
BLACK 1-1/4" FLAT HEAD SCREWS (7S).
412015 www.sauder.com/servicesPae 16
Surface with more holes
H
N
T
T
P
HALF DISK (U)
HALF DISK (U)
The unfinished ede of the
BOTTOM MOLDING should
be aainst the SKIRT.
These edes
should be even.
BLACK 1-1/4" FLAT HEAD SCREW
(4 used for the PLINTHS)
7S
BROWN 1" FLAT HEAD SCREW
(6 used in this step)
12S
These edes
should be even.

å Fasten six METAL BRACKETS (4G) to the BRACE (H). Use
six BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the edes of
the BRACE.
Step 12
412015www.sauder.com/services Pae 17
H
4G
4G
4G
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
(6 used)

Step 13
å Carefully turn your unit onto its front edes.
å Fasten the BRACE (H) to the BOTTOM (F2) and
OUTER ENDS (A and B). Use six BLACK 9/16" LARGE
HEAD SCREWS (1S).
412015 www.sauder.com/servicesPae 18
H
A
B
F2
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S

å Unfold the BACK (G) and lay it over your unit.
å Make equal marins alon all four edes of the BACK (G).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (G) to your unit usin the NAILS (1N).
Step 14
412015www.sauder.com/services Pae 19
G
Finished surface
NAIL
(36 used in this step)
1N
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step 15
å Push two HIDDEN CAMS (1F) into the DRAWER BRACES (M63).
Then, insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM.
412015 www.sauder.com/servicesPae 20
Arrow
1F
Do not tihten the HIDDEN CAMS in this step.
M63
M63
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
