Night Stand
Beginnings Collection | Model 415544
Sweet stand.
Sweet dreams.

Table of Contents Assembly Tools Required
3
4
5-15
16-18
19-21
22
23
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
415544 www.sauder.com/servicesPage 2
Scissors

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
FF RIGHT END (1)
GG LEFT END (1)
HH TOP (1)
II BOTTOM (1)
JJ SKIRT (1)
KK BACK (1)
NN DRAWER FRONT (1)
D217 DRAWER SIDE (2)
D218 DRAWER BACK (1)
D613 DRAWER BOTTOM (1)
Now you know
our ABCs.
415544www.sauder.com/services Page 3
FF
GG
HH
II
JJ
KK
NN
D217
D217
D218
D613

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
415544 www.sauder.com/servicesPage 4
SLIDE SET - 1
16B HIDDEN CAM - 4
1F CAM DOWEL - 4 2F
ANGLE BRACKET - 3
5G DRAWER FRONT
BRACKET - 2
30G
PULL - 1
45K NAIL - 8 1N APPLIQUE CARD - 1 29P
BLACK 9/16" LARGE HEAD SCREW - 8
1S BLACK 1-7/8" FLAT HEAD SCREW - 4 2S
BLACK 1/2" FLAT HEAD SCREW - 4
43S BLACK 1-1/2" PAN HEAD SCREW - 4 49S
52S SILVER 3/4" PAN HEAD SCREW - 4 SILVER 3/4" MACHINE SCREW - 2 53S

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push four HIDDEN CAMS (1F) into the ENDS (FF and GG).
Then, insert the metal end of a CAM DOWEL (2F) into
each HIDDEN CAM.
415544www.sauder.com/services Page 5
GG
FF
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
1F
2F
(4 used)

Step 2
å NOTE: Before beginning this step, separate the SLIDES from the SLIDE SETS (16B) and the DRAWER PINS at the end of
the SLIDES using a SCISSORS. Save the DRAWER PINS. You will use them in Step 10.
å Fasten the SLIDES (16B) to the ENDS (FF and GG). Use four SILVER 3/4" PAN HEAD SCREWS (52S) through the first and
last holes in the SLIDES.
å NOTE: The SLIDES are marked "RIGHT" and "LEFT" for easy identification. The SLIDE marked "RIGHT" will fasten to the
RIGHT END (FF) and the SLIDE marked "LEFT" will fasten to the LEFT END (GG). There are also arrows on the SLIDES for
correct positioning on the ENDS.
415544 www.sauder.com/servicesPage 6
FF
GG
Finished edge
Angled edge
Straight edge
Notch
RIGHT SLIDE
DRAWER PIN
(Save for Step 10)
Using your Scissors, separate the
SLIDES and the DRAWER PINS
16B
16B
16B
SILVER 3/4" PAN HEAD SCREW
(4 used in this step)
52S
Finished edge
LEFT SLIDE
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS

å Fasten three ANGLE BRACKETS (5G) to the BOTTOM (II) and
SKIRT (JJ). Use three BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edges of the ANGLE BRACKETS are even
with the edges of the BOTTOM (II) and SKIRT (JJ).
Step 3
415544www.sauder.com/services Page 7
5G
5G
II
JJ
Surface with holes
BLACK 9/16" LARGE HEAD SCREW
(3 used in this step)
1S
Some assembly
(and snacks) required.

Step 4
å Fasten the TOP (HH) to the ENDS (FF and GG). Tighten
four HIDDEN CAMS.
415544 www.sauder.com/servicesPage 8
FF
GG
HH
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Finished edge
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Surface
with holes
Finished edge

å Fasten the BOTTOM (II) to the ENDS (FF and GG). Use four
BLACK 1-7/8"FLAT HEAD SCREWS (2S).
å Fasten the SKIRT (JJ) to the BOTTOM (II) and ENDS (FF and GG).
Use three BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 5
415544www.sauder.com/services Page 9
FF
GG II
JJ
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
BLACK 9/16" LARGE HEAD SCREW
(3 used for the ANGLE BRACKETS)
1S
ANGLE BRACKET
should be here.
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S

Step 6
å Carefully turn the Night Stand over onto its front edges. Lay
the BACK (KK) over the unit.
å Make equal margins along all three edges of the BACK (KK).
Push on opposite corners of your unit if needed to make
it "square".
å Fasten the BACK (KK) to the unit using the NAILS (1N).
415544 www.sauder.com/servicesPage 10
FF
GG
HH
KK
Edge without holes
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
NAIL
(8 used in this step)
1N
