Sauder 418735 User manual

sauder.com
Bookcase with Doors
Model 418735
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-17
Español pg 18-20
Lot # 530075 05/24/19
Purchased: __________________
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Share your journey!
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-523-3987.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Here's one for
the books.

Table of Contents Assembly Tools Required
3
4
5-17
18-20
21-22
23
Part Identification
Hardware Identification
Assembly Steps
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
418735 www.sauder.com/servicePage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A UPPER RIGHT END (1)
B UPPER LEFT END (1)
C RIGHT END (1)
D BOTTOM (1)
E LEFT END (1)
F ADJUSTABLE SHELF (2)
G TOP (1)
H SHELF (1)
I BACK (1)
J SMALL BACK (1)
K DOOR (2)
L LOWER ADJUSTABLE SHELF (1)
M UPPER END MOLDING (2)
M33 TOP MOLDING (1)
M34 BASE MOLDING (1)
M76 SHELF MOLDING (2)
Now you know
our ABCs.
418735www.sauder.com/service Page 3
A
B
C
D
E
F
G
F
I
J
K
L
M
M
K
H
M76
M33
M34
M76

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
418735 www.sauder.com/servicePage 4
SAFETY BRACKET - 1
1G
BLACK 9/16" LARGE HEAD SCREW - 13
1S BLACK 1-7/8" FLAT HEAD SCREW - 5 2S
METAL PIN - 12
1R
SILVER 5/8" FLAT HEAD SCREW - 8
23S
22H
HINGE
SPACER - 4
12E TACK GLIDE - 4
BROWN 1-5/8" FLAT HEAD SCREW - 3
55S
DOOR
STOP - 2
4I
NAIL - 57
1N
HIDDEN CAM - 12
1F CAM DOWEL - 12
2F
SILVER 1-1/2" MACHINE SCREW - 2
95S
KNOB - 2
69K
BACKPLATE - 2
92K RUBBER SLEEVE - 12
2R
13H HINGE - 4
METAL
BRACKET - 6
4G

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/service/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push twelve HIDDEN CAMS (1F) into the ENDS (A, B, C,
and E) and BOTTOM (D). Then, insert the metal end of a
CAM DOWEL (2F) into each HIDDEN CAM.
418735www.sauder.com/service Page 5
(12 used)
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A
B
C
D
E

Step 2
å Fasten the UPPER ENDS (A and B) to the TOP (G).
Tighten four HIDDEN CAMS.
å Fasten the TOP MOLDING (M33) to the TOP (G). Use
three BROWN 1-5/8" FLAT HEAD SCREWS (55S).
å NOTE: Do not overtighten the SCREWS into the TOP.
418735 www.sauder.com/servicePage 6
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface with
HIDDEN CAMS
Surface without
HIDDEN CAMS
Notched edge
Notched edge
G
A
B
BROWN 1-5/8" FLAT HEAD SCREW
(3 used for the TOP MOLDING)
55S
Rounded edge
Curved edge
M33
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution

å Slide the UPPER END MOLDINGS* (M) onto the notched
edges of the UPPER ENDS (A and B).
å *U.S. Patent No. 5,499,886
Step 3
418735www.sauder.com/service Page 7
Notched edge
Slide the UPPER END
MOLDING (M) onto
the notched edge.
A
B
M
M
Slide the UPPER END
MOLDING (M) onto
the notched edge.
The large
groove is closer
to this edge.
The large
groove is closer
to this edge.
Just think. The sooner
you do this, the sooner
you do something else.

Step 4
å Fasten the SHELF (H) to the UPPER ENDS (A and B). Use
four BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å Push two DOOR STOPS (4I) into the holes in the SHELF (H).
418735 www.sauder.com/servicePage 8
H
A
B
4I
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
These holes are
closer to this edge.

å Fasten the LEFT END (E) to the SHELF (H). Tighten two
HIDDEN CAMS.
å Fasten the BOTTOM (D) to the LEFT END (E). Tighten two
HIDDEN CAMS.
Step 5
418735www.sauder.com/service Page 9
Arrow
Minimum
190 degrees
Maximum
210 degrees
E
H
D
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
These holes
must be here.

Step 6
å Fasten the RIGHT END (C) to the BOTTOM (D) and SHELF (H).
Tighten four HIDDEN CAMS.
å Fasten six METAL BRACKETS (4G) to the ENDS (C and E) and
BOTTOM (D). Use six BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the edges of the METAL BRACKETS are even with
the edges of the ENDS and BOTTOM.
å Fasten the BASE MOLDING (M34) to the ENDS (C and E) and
BOTTOM (D). Use six BLACK 9/16" LARGE HEAD SCREWS (1S)
through the METAL BRACKETS on the ENDS and BOTTOM and
into the BASE MOLDING.
418735 www.sauder.com/servicePage 10
BLACK 9/16" LARGE HEAD SCREW
(12 used for the METAL BRACKETS)
1S
Arrow
Minimum
190 degrees
Maximum
210 degrees
D
C
E
H
Curved edge
4G
4G
M34
4G
