Sauder Bandit 425667 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Share your journey!
Sauder.com
sauder.com
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Enlish p 1-24
Français p 25-28
Español p 29-32
You'll love what we have in
storage.
Lot # 541403 2/10/20
Purchased: __________________
Bandit Pet
Storae Cabinet
Pet Furniture Collection | Model 425667

Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4-5
6-24
25-28
29-32
33-34
35
Pae 2 www.sauder.com/service 425667
Electric drill with
1/8" or 3/8" bit
(ONLY in indicated step)

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
A TOP (1)
B BOTTOM (1)
C LEFT END (1)
D RIGHT END (1)
E SHELF (1)
F DOOR (1)
G UPPER BACK (1)
H LEFT LEG (1)
J BRACE (1)
K LOWER BACK (1)
L PANEL (1)
M BOWL PLATE (1)
N BOWL PLATE BRACE (1)
Q RIGHT LEG (1)
A
B
C
D
E
F
G
H
J
K
L
M
N
O
Pae 3www.sauder.com/service425667

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
CAM SCREW - 16
1HIDDEN CAM - 16 2WOOD DOWEL - 9 3
HINGE - 2
46ROD HANGER - 2
BOWL - 2
7MAGNETIC CATCH - 1 8 9 COAT HANGER - 2
L-WRENCH - 1
12
APPLIQUE CARD - 1
13
ROD - 1
10 KNOB - 1 11
Pae 4 www.sauder.com/service 425667
TIE PLATE - 1
5
FURNITURE TIPPING
RESTRAINT KIT - 1
96

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
2-3/8" HEX HEAD SCREW - 4
14
SILVER 1/2" FLAT HEAD SCREW - 12
18 1/2" PAN HEAD SCREW - 4
19
BLACK 1/2" FLAT HEAD SCREW - 10
20
16 1316" MACHINE SCREW  1 BLACK 5/8" FLAT HEAD SCREW - 2
17
Pae 5www.sauder.com/service425667
1-9/16" HEX HEAD SCREW - 10
15

Hardware Usage Guide
HOW TO USE A HIDDEN CAM & CAM SCREW OR CAM DOWEL
NOTE: Various CAM SCREWS or a CAM DOWEL may be used.
Cam Screws Cam Dowel
Turn the CAM SCREW or
gently tap the CAM DOWEL
until the shoulder is against
the surface of the part.
1.
Hidden CamHidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2.
3.
1
2
Insert the CAM SCREW or CAM DOWEL into the
HIDDEN CAM. Tighten the HIDDEN CAM.
Pae 6 www.sauder.com/service 425667

Step 1 Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å Push eiht HIDDEN CAMS (2) all the way into the holes in
the BOTTOM (B) and PANEL (L).
å Turn two CAM SCREWS (1) into the PANEL (L)
Pae 7 www.sauder.com/service 425667
1
L
B
Arrow
2
2
Arrow
2
Arrow
Just think. The sooner
you do this, the sooner
you do somethin else.
1

StepStep 2
å Insert one WOOD DOWEL (3) into the PANEL (L).
å Fasten the PANEL (L) to the BOTTOM (B). Tihten two
HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWEL in the PANEL inserts
into the hole in the BOTTOM.
Pae 8www.sauder.com/service425667
L
B
Surface without HIDDEN CAMS
Surface with HIDDEN CAMS
3
1
Groove

Step 3
å Fasten a ROD HANGER (6) to the LEFT END (C). Use two
BLACK 1/2" FLAT HEAD SCREWS (20).
å Turn five CAM SCREWS (1) into the LEFT END (C).
å NOTE: Use the exact holes shown.
å Push six HIDDEN CAMS (2) all the way into the holes in
the LEFT END (C) and SHELF (E).
Pae 9 www.sauder.com/service 425667
C
E
6
Arrow
2
2
Arrow
Arrow
2
BLACK 1/2" FLAT HEAD SCREW
(2 used in this step)
20
1
(5 used)
1
Groove

å Insert three WOOD DOWELS (3) into the LEFT END (C).
å Fasten the BOTTOM (B), PANEL (L), and SHELF (E). to the
LEFT END (C) Tihten five HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the LEFT END
insert into the holes in the BOTTOM, PANEL, and SHELF.
Step 4
Pae 10www.sauder.com/service425667
L
B
C
E
Surface with HIDDEN CAMS
3
Unfinished ede
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
1
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

Step 5
å Fasten a ROD HANGER (6) to the RIGHT END (D). Use
two BLACK 1/2" FLAT HEAD SCREWS (20).
å Turn five CAM SCREWS (1) into the RIGHT END (D).
å Push two HIDDEN CAMS (2) all the way into the holes in
the RIGHT END (D).
Pae 11 www.sauder.com/service 425667
D
Groove
6
Arrow
2
1
(5 used)
BLACK 1/2" FLAT HEAD SCREW
(2 used in this step)
20
1

Step 6
å Insert three WOOD DOWELS (3) into the RIGHT END (D).
å Fasten the RIGHT END (D) to the BOTTOM (B), PANEL (L),
and SHELF (E). Tihten five HIDDEN CAMS.
å NOTE: Be sure the WOOD DOWELS in the LEFT END
insert into the holes in the BOTTOM, PANEL, and SHELF.
Pae 12www.sauder.com/service425667
Surface without HIDDEN CAMS
Surface with HIDDEN CAMS
L
B
E
D
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS
These holes must be here.
1
3

Step 7
å Push the UPPER BACK (G) into the rooves in the
ENDS (C and D) and the BOTTOM (B).
å NOTE: Carefully stand your unit upriht to insert the
BACK into the roove in the BOTTOM.
Pae 13 www.sauder.com/service 425667
B
D
G
Unfinished
surface
C
Groove
Do not stand the unit upriht without the
BACK fastened. The unit may collapse.
Caution

å Turn four CAM SCREWS (1) into the TOP (A).
å Fasten the MAGNETIC CATCH to the TOP (A). Use two
BLACK 5/8" FLAT HEAD SCREWS (17).
Step 8
Pae 14www.sauder.com/service425667
A
BLACK 5/8" FLAT HEAD SCREW
(2 used in this step)
17
8
1
(4 used)
Groove
1

å Insert two WOOD DOWELS (3) into the TOP (A).
å Fasten the TOP (A) to the ENDS (C and D). Tihten four HIDDEN CAMS.
å Be sure the UPPER BACK (G) fits into the roove in the TOP.
å Open the FURNITURE TIPPING RESTRAINT KIT (96) and fasten the SAFETY STRAP to the TOP (A). Use the provided
short screw.
å Use the FURNITURE TIPPING RESTRAINT KIT (96) for added stability. Fasten the strap to the top surface of the
TOP (A) usin the short screw as shown.
Step 9
Pae 15 www.sauder.com/service 425667
A
C
D
G
1
Safety strap
Groove
3
96

Step 10
å Fasten the LEGS (H and O) to the LOWER BACK. Use four
1/2" PAN HEAD SCREWS (19).
å NOTE: Do not completely tihten the SCREWS in this step
Pae 16www.sauder.com/service425667
K
H
O
1/2" PAN HEAD SCREW
(4 used in this step)
19
Side Step: Make
nachos. (Optional, but
recommended.)

Step 11
å Place the BOWL PLATE (M) on top of the BOWL PLATE
BRACE (N) as shown.
å Fasten the BOWL PLATE BRACE (N) to the
LEGS (H and O). Turn eiht 1-9/16" HEX HEAD
SCREWS (15) a few turns usin the L-WRENCH (12).
å NOTE: Do not completely tihten the SCREWS in this step
Pae 17 www.sauder.com/service 425667
K
M
M
H
O
N
N
Middle Bar closer
to this side.
15
15
12
1-9/16" HEX HEAD SCREW
(8 used in this step)
15

Step 12
å Fasten the BRACE (J) to the LEGS (H and O). Turn
two 1-9/16" HEX HEAD SCREWS (15) a few turns
usin the L-Wrench (12).
å Completely tihten the SCREWS at this time.
Pae 18www.sauder.com/service425667
H
JO
12
15
1-9/16" HEX HEAD SCREW
(2 used in this step)
15

å Carefully lay your unit on its back ede.
å Fasten the LEGS (H and O) to the ENDS (C and D).
Tihten four 2-3/8" HEX HEAD SCREWS (14) usin the
L-WRENCH (12).
å NOTE: You should start each SCREW a few turns before
completely tihtenin any of them.
Step 13
B
C
12
Pae 19www.sauder.com/service425667
H
O
D
2-3/8" HEX HEAD SCREW
(4 used in this step)
14

Step
å Fasten the TIE PLATE (S) to the DOOR (F). Use two
BLACK 1/2" FLAT HEAD SCREWS (20).
å Fasten two HINGES (4) to the door. Use four SILVER 1/2"
FLAT HEAD SCREWS (18).
Step 14
Pae 20 www.sauder.com/service 425667
F
SILVER 1/2" FLAT HEAD SCREW
(4 used for the HINGES)
18
BLACK 1/2" FLAT HEAD SCREW
(2 used for the TIE PLATE)
20
5
4
