Sauder 410627 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 357576 11/19/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Corner TV Stand
August Hill Collection | Model 410627
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Your center of
attention.

Table of Contents Assembly Tools Required
3
4
5-18
19-21
22-24
25-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Use of a TV that is too heavy or large is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or
death. A TV that is too large for the available space might be accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly!
• This Sauder unit is designed for use with televisions weighing less than 95 pounds. Never use with a TV that weighs more.
• The size of the television, front-to-back and side-to-side, must fit within the space defined in the diagram.
• Never place the front edge of the TV past the front edge of the TV support shelf (or stop molding – if equipped)
• Never allow the sides of the TV to extend past the side edges of the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend past the rear of the support shelf.
• Be sure to apply the warning label as instructed in the last assembly step. The label provides important safety related information.
WARNING
!
95 lbs.
95 lbs.
17-1/2"
17-1/2"
39-1/4"
39-1/4"
410627 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A END (2)
B UPRIGHT (1)
C LOWER UPRIGHT (1)
D TOP (1)
E BOTTOM (1)
F SHELF (1)
G BACK (1)
H DOOR (2)
I RIGHT FRONT/LEFT REAR LEG (2)
J LEFT FRONT/RIGHT REAR LEG (2)
K EXTENSION BLOCK (2)
L STOP MOLDING (1)
M TOP MOLDING (1)
N BASE (1)
O TOP RAIL (2)
P BOTTOM RAIL (2)
A
B
C
D
E
F
G
H
I
J
K
L
M
N
O
P
A
O
P
H
K
J
I
410627www.sauder.com/services Page 3

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
HIDDEN CAM - 30
Q2 CAM DOWEL - 22 R2 CAM SCREW - 8 S2
VHINGE - 4 WASHER - 2 WPULL - 2 X
YBUMPER CARD - 2
(Refer to the last step for proper
location and application)
WARNING LABEL - 1
BB
WARNING
Never use this furniture with a TV that is too
large or too heavy. Severe injury or death
can occur.The TV and furniture will be
unstable and may tip.
-The TV must less than 95 lbs.
-The base of the TV must be able to sit
completely on this shelf.
-Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not try
to remove. Surface will be damaged.
02/ 02 269227
FOOT BASE - 1
U
FOOT - 1
T
HOLE PLUG - 2
AA
BLACK 1-7/8" FLAT HEAD SCREW - 4
DD
BROWN 1-1/2" FLAT HEAD SCREW - 3
EE BLACK 9/16" FLAT HEAD SCREW - 8 FF
BLACK 9/16" PAN HEAD SCREW - 4
GG BLACK 1/2" FLAT HEAD SCREW - 8 HH
BROWN 7/16" LARGE HEAD SCREW - 8
II
NAIL - 33
KK
BLACK 2-1/2" LARGE HEAD SCREW - 4
CC
SILVER 1/4" MACHINE SCREW - 2
JJ
410627 www.sauder.com/servicesPage 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Push thirty HIDDEN CAMS (Q2) into the ENDS (A),
UPRIGHTS (B and C), TOP (D), BOTTOM (E), SHELF (F),
and one set of LEGS (I and J). Then, insert twenty-two
CAM DOWELS (R2) into the HIDDEN CAMS.
410627www.sauder.com/services Page 5
A
B
C
D
E
F
I
J
A
Arrow
Q2
R2
Q2
Arrow
Do not tighten the HIDDEN CAMS in this step.
(22 used)
(30 used)
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
Do not insert CAM DOWELS into
the long edges of the ENDS (A).
Q2
Insert a HIDDEN CAM
and CAM DOWEL into
one LEG (I and J).
Scan this QR code or go to this address:
http://qr.sauder.com/?ID=1551
to watch a video on how to assemble your unit.

Step 2
å Turn eight CAM SCREWS (S2) into the LEGS (I and J).
å Fasten the LEGS (I and J) to the ENDS (A). Tighten four
HIDDEN CAMS.
410627 www.sauder.com/servicesPage 6
S2
A
I
J
A
I
J
I
J
12
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
Angled edge
LEG with HIDDEN CAM
LEG with HIDDEN CAM
Angled edge

å Carefully turn the ENDS (A) over.
å Turn eight BLACK 9/16” FLAT HEAD SCREWS (FF) into the
ENDS (A) until the shoulder of the SCREWS rest on the surface
of the ENDS.
å Slide the RAILS (O and P) onto the ENDS (A). Line up the
groove in the RAILS over the head of the SCREWS in the ENDS.
Step 3
410627www.sauder.com/services Page 7
A
A
Shoulder
Apply pressure with your hands
as you guide the MOLDINGS over
the SCREWS and onto the ENDS.
BLACK 9/16" FLAT HEAD SCREW
(8 used in this step)
FF
O
O
P
P
Shoulder

Step 4
å Carefully turn the ENDS (A) over.
å Fasten the other LEGS (I and J) to the ENDS (A). Tighten four
HIDDEN CAMS.
å Insert two HOLE PLUGS (AA) into the holes in the LEGS (I and J).
410627 www.sauder.com/servicesPage 8
12
A
I
J
A
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
AA
Angled edge
This END will now be
called the LEFT END.
This END will now be
called the RIGHT END.
Angled edge

å Fasten the STOP MOLDING (L) to the TOP (D). Tighten
four HIDDEN CAMS.
Step 5
410627www.sauder.com/services Page 9
L
D
Unfinished surface
Rounded edge
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
Surface with
HIDDEN CAMS

Step 6
å Fasten the LEFT END (A), UPRIGHT (B), and LEFT
FRONT/RIGHT REAR LEG (J) to the TOP (D) and STOP
MOLDING (L). Tighten five HIDDEN CAMS.
410627 www.sauder.com/servicesPage 10
A
J
B
DL
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface
with
HIDDEN
CAMS
Surface without
HIDDEN CAMS
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Finished edge
