Sauder Jaclyn Smith Gatsby 416403 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
Enlish p 1-22
Français p 23-25
Español p 26-28
Lot # 356986 11/14/13
Purchased: __________________
Be sure to ive us a rin before
makin any returns. 1-800-523-3987
Hihboy TV Stand
Jaclyn Smith Gatsby Collection | 416403
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
It stands. You sit.
A thin of beauty,
this one.

Table of Contents Assembly Tools Required
3
4
5-22
23-25
26-28
29-30
31
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Use of a TV that is too heavy or lare is hazardous. A TV that is too heavy will create a risk of a tip-over that can cause severe injury or
death. A TV that is too lare for the available space miht be accidentally pushed or bumped o the furniture, or subject to tip-over.
• Check the size and weiht of your TV. Compare it to the diaram below – before you bein assembly!
• This Sauder unit is desined for use with televisions weihin less than 50 pounds. Never use with a TV that weihs more.
• The size of the television, front-to-back and side-to-side, must fit within the space defined in the diaram.
• Never place the front ede of the TV past the front ede of the TV support shelf (or stop moldin – if equipped)
• Never allow the sides of the TV to extend past the side edes of the TV support surface.
• If the TV has a CRT picture tube, the picture tube cone may extend past the rear of the support shelf.
• Be sure to apply the warnin label as instructed in the last assembly step. The label provides important safety related information.
WARNING
!
50 lbs.
50 lbs.
416403 www.sauder.com/servicesPae 2
40-1/2"
40-1/2"
19-1/2"
19-1/2"

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the ede
to help distinuish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C HUTCH RIGHT END (1)
D HUTCH LEFT END (1)
E HUTCH UPRIGHT (1)
F2 TOP (1)
G HUTCH TOP (1)
H2 BOTTOM BRACE (2)
I2 BACK (2)
J DRAWER BRACE (3)
K FRONT SKIRT (1)
L DRAWER FRONT (3)
M DRAWER FRONT MOLDING (6)
N BOTTOM MOLDING (1)
D132 RIGHT DRAWER SIDE (3)
D138 LEFT DRAWER SIDE (3)
D197 DRAWER BACK (3)
D601 DRAWER BOTTOM (3)
416403www.sauder.com/services Pae 3
A
B
C
D
E
F2
G
H2
I2
J
K
LM
N
H2
M
D138
D601
D132
D197
I2

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
416403 www.sauder.com/servicesPae 4
3M ANTI-SKID PAD - 1
SAFETY BRACKET - 1
1G
BLACK 9/16" LARGE HEAD SCREW - 11
1S
ANGLE BRACKET - 5
5G
BLACK 1-1/4" FLAT HEAD SCREW - 12
7S
BLACK 1-7/8" FLAT HEAD SCREW - 5
2S
7F TWIST-LOCK®FASTENER - 4
3S GOLD 5/16" FLAT HEAD SCREW - 24
METAL PIN - 8
1R
10A SLIDE CAM - 6
30S BLACK 1-9/16" FLAT HEAD SCREW - 15
HIDDEN CAM - 22
1F CAM DOWEL - 22
2F
BLACK 7/8" MACHINE SCREW - 6
37S
PULL - 6
82K
WARNING
Never use this furniture with a TV that is
too large or too heavy. Severe injury or
death can occur.The TV and furniture
will be unstable and may tip.
-The TV must less than 50 lbs.
-The base of the TV must be able to sit
completely on this shelf.
Refer to instruction book for complete
safety information.
Note: This is a permanent label. Do not
try to remove. Surface will be damaged.
08/05 2 6 9 2 2 0 269220
WARNING LABEL - 1
1L
(Refer to step 16 for proper
location and application)
(EXTENSION SET SHOWN SEPARATED)
OEXTENSION RAIL - 6 PEXTENSION SLIDE - 6
5L WARNING LABEL - 1
(Refer to step 16 for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically desined to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or han on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push a SAUDER TWIST-LOCK®
FASTENER (7F) into the lare holes in the
HUTCH ENDS (C and D).
416403www.sauder.com/services Pae 5
Do not tihten the TWIST-LOCK® FASTENERS in this step.
7F
C
D

Step 2
å Push twenty-two HIDDEN CAMS (1F) into the ENDS (A and B),
BOTTOM BRACES (H), BACKS (I), and DRAWER BRACES (J).
Then, insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM, except on the lon ede of one of the
BOTTOM BRACES (H2).
416403 www.sauder.com/servicesPae 6
Arrow
1F
2F
Do not tihten the HIDDEN CAMS in this step.
(22 used)
Arrow
1F
2F
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Do not insert
HIDDEN CAMS
or CAM DOWELS
into this lon ede.
A
B
H2
J
H2
JJ
I2
I2

å Separate the EXTENSION SLIDES (P) from the
EXTENSION RAILS (O) as shown in the upper diaram.
Be prepared, the parts are reasy.
å Fasten the EXTENSION RAILS (O) to the ENDS (A and B).
Use twelve GOLD 5/16" FLAT HEAD SCREWS (3S).
å NOTE: For each EXTENSION RAIL, turn a SCREW into the
hole shown in the enlared diaram. Then, slide the inner
cartride of the EXTENSION RAIL in to find the other hole
that lines up with the hole in the END. Turn a SCREW into
this hole.
Step 3
416403www.sauder.com/services Pae 7
Push the release lever in and pull the SLIDE from the RAIL.
O
P
Finished ede
Open end
Finished ede
Open end
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
3S
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
A
B
O
O
O
O
O
O

Step 4
å Fasten the HUTCH LEFT END (D) to the TOP (F2). Use
two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
416403 www.sauder.com/servicesPae 8
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S
Surface with
TWIST-LOCK®
FASTENERS
Flat ede
Surface with fewer holes
D
F2

å Insert four METAL PINS (1R) into the HUTCH UPRIGHT (E).
å Insert the METAL PINS (1R) in one end of the HUTCH
UPRIGHT (E) into the holes in the HUTCH LEFT END (D).
å Fasten the HUTCH RIGHT END (C) to the TOP (F2). Use
two BLACK 1-7/8" FLAT HEAD SCREWS (2S).
å NOTE: Be sure the METAL PINS (1R) in the HUTCH
UPRIGHT (E) insert into the HUTCH RIGHT END (C).
Step 5
416403www.sauder.com/services Pae 9
C
E
D
F2
Finished surface
1R
Surface without
TWIST-LOCK®
FASTENERS
Flat ede
(4 used)
BLACK 1-7/8" FLAT HEAD SCREW
(2 used in this step)
2S

Step 6
å Fasten the HUTCH TOP (G) to the HUTCH ENDS (C and D).
Tihten four TWIST-LOCK® FASTENERS.
416403 www.sauder.com/servicesPae 10
G
Surface without holes
C
D
Flat ede
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoinin part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoinin part while lockin the
FASTENER.
2. Tihten the FASTENER with a Phillips screwdriver as tiht
as possible.
Dowel end

å Carefully lay the unit on its back edes.
å Fasten the LEFT END (B) to the TOP (F2). Tihten two
HIDDEN CAMS.
Step 7
416403www.sauder.com/services Pae 11
Surface with holes
Surface
with
HIDDEN
CAMS
Start Tihten
Arrow
Minimum
190 derees
Caution
Risk of damae or
injury. HIDDEN CAMS
must be completely
tihtened. HIDDEN
CAMS that are not
completely tihtened
may loosen, and parts
may separate. To
completely tihten:
Arrow
Maximum
210 derees
BF2
Flat ede
Finished ede

Step 8
å Fasten the BACKS (I2) to the TOP (F2). Tihten four
HIDDEN CAMS.
Maximum
210 degrees
Minimum
190 degrees
Arrow
F2
I2
I2
Surface with
HIDDEN CAMS Surface with
HIDDEN CAMS
416403 www.sauder.com/servicesPae 12

StepStep 9
å NOTE: You may need someone's help in this step.
å Insert two METAL PINS (1R) into the BOTTOM BRACES (H2).
å Fasten the BOTTOM BRACES (H2) to the LEFT END (B). Tihten
two HIDDEN CAMS.
å NOTE: Be sure the METAL PINS (1R) in the BOTTOM BRACES (H2)
insert into the holes in the LEFT END (B).
å Fasten the lower BOTTOM BRACE (H2) to the BACKS (I2). Tihten
four HIDDEN CAMS.
1R
Surface with more HIDDEN CAMS
Surface with fewer HIDDEN CAMS
B
H2
H2
Ede with CAM DOWELS
Ede without CAM DOWELS
Arrow
Minimum
190 derees
Maximum
210 derees
I2
I2
416403www.sauder.com/services Pae 13

Step
å Insert two METAL PINS (1R) into the BOTTOM BRACES (H2).
å Fasten the RIGHT END (A) to the TOP (F2) and BOTTOM
BRACES (H2). Tihten four HIDDEN CAMS.
å NOTE: Be sure the METAL PINS (1R) in the BOTTOM
BRACES (H2) insert into the holes in the RIGHT END (A).
Step 10
416403 www.sauder.com/servicesPae 14
1R
Arrow
Minimum
190 derees
Maximum
210 derees
A
H2
H2
F2
Finished ede
Surface without
HIDDEN CAMS

Step
416403www.sauder.com/services Pae 15
Step 11
å Fasten the BOTTOM MOLDING (N) to the BOTTOM
BRACE (H2). Tihten three HIDDEN CAMS.
Arrow
Minimum
190 derees
Maximum
210 derees
N
H2
Rounded ede
Unfinished surface

Step
å Fasten five ANGLE BRACKETS (5G) to the ENDS (A and B)
and the upper BOTTOM BRACE (H2). Use five BLACK 9/16"
LARGE HEAD SCREWS (1S).
å Fasten the FRONT SKIRT (K) to the ENDS (A and B) and the
upper BOTTOM BRACE (H2). Use five BLACK 9/16" LARGE
HEAD SCREWS (1S).
Step 12
A
B
K
H2
5G
5G
5G
BLACK 9/16" LARGE HEAD SCREW
(10 used in this step)
1S
Finished surface
Flat ede
416403 www.sauder.com/servicesPae 16

å Fasten two DRAWER FRONT MOLDINGS (M) to the
DRAWER FRONT (L). Use four BLACK 1-1/4" FLAT
HEAD SCREWS (7S).
å Repeat this step for the other DRAWER FRONTS (L) and
DRAWER FRONT MOLDINGS (M).
Step 13
416403www.sauder.com/services Pae 17
Surface with rooves
L
M
M
BLACK 1-1/4" FLAT HEAD SCREW
(12 used in this step)
7S

Step 14
416403 www.sauder.com/servicesPae 18
å Insert the DRAWER SIDES (D132 and D138)
at an angle into the slot at each end of the
DRAWER FRONT (L).
å Slide the DRAWER BOTTOM (D601) into the
grooves in the DRAWER SIDES (D132 and D138) and
DRAWER FRONT (L).
å Fasten the DRAWER BRACE (J) to the DRAWER
FRONT (L). Tighten one HIDDEN CAM. å Fasten the DRAWER BACK (D197) to the DRAWER
SIDES (D132 and D138) and DRAWER BRACE (J). Use five
BLACK 1-9/16" FLAT HEAD SCREWS. (30S). Repeat this
step for the other DRAWERS.
The tabs should insert freely into the
slots. Gently tilt the DRAWER SIDES side
to side until the tabs slip into the slots.
UNFINISHED
Surface with
HIDDEN CAM
12
34
Be sure the DRAWER
BOTTOM inserts into the
DRAWER FRONT roove.
With the palm of your hand, tap the
DRAWER BOTTOM down into the roove.
Groove
Arrow
Maximum
210 derees
Minimum
190 derees
Start each screw a few turns before
completely tihtenin any of them.
BLACK 1-9/16" FLAT HEAD SCREW
(15 used in this step)
30S
L
L
J
L
J
VIEW THE T-LOCK BOX VIDEO
D138
D132
D138
D601
D132
D132
D138
D197

å Insert a SLIDE CAM (10A) into the DRAWER SIDES (D132 and D138).
å Fasten the EXTENSION SLIDES (P) to the DRAWER SIDES (D132 and D138). Use four GOLD 5/16"
FLAT HEAD SCREWS (3S).
å NOTE: The screw head in the CAM must be visible throuh the slotted hole in the SLIDE.
å Fasten two PULLS (82K) to the DRAWER FRONT (L). Use two BLACK 7/8" MACHINE SCREWS (37S).
å Repeat this step for the other drawers.
Step 15
416403www.sauder.com/services Pae 19
P
D132
D138
P
Open end
Open end
Screw head - turn CAM to line up holes in
the SLIDES with holes in DRAWER SIDES
10A
10A
GOLD 5/16" FLAT HEAD SCREW
(12 used in this step)
3S
82K
L
BLACK 7/8" MACHINE SCREW
(6 used in this step)
37S
(6 used)

Step 16
å Carefully stand the unit upriht.
å To insert the drawers into your unit, line up the EXTENSION SLIDES on the drawer with the EXTENSION RAILS on the unit
and push the drawer into the unit until the drawer is fully inserted. The drawer will push in hard until it is all the way in, then
it will slide in and out easier.
å Apply the WARNING LABEL (1L) to the TOP (G). You should be able to read the label when the TV is removed from the
unit. When the TV is in place, it should hide the label. Peel o the backin and apply the label as shown in the diaram.
å Apply the WARNING LABEL (5L) to the upper DRAWER BOTTOM (D601). You should be able to read the label
when the drawer is open. When the drawer is closed, it will hide the label. Peel o the backin and apply the label as
shown in the diaram.
å NOTE: These are permanent labels intended to last for the life of the product. Once applied, do not try to remove them
å To help prevent the TV from slidin, place the ANTI-SKID PAD (3M) under the front support of the TV or divide amon the
front supports if more than one.
416403 www.sauder.com/servicesPae 20
3M
1L
WARNING
Never use this furniture with a TV
that is too lare or too heavy. Severe
injury or death can occur. The TV and
furniture will be unstable and may tip.
-The TV must weih less than 50 lbs.
-The base of the TV must be able to
sit completely on this shelf.
Refer to instruction book for
complete safety information.
Note: This is a permanent label. Do
not try to remove. Surface will be
damaged.
08/05 2 6 9 2 2 0 269220
1L
G
Serious or fatal crushin injuries can
occur from furniture tip-over. To help
prevent tip-over:
-Place heaviest items in the lowest drawers.
-Unless specifically desined to accommodate,
do not set TVs or other heavy objects on top of
this product.
-Never allow children to climb or han on
drawers, doors, or shelves.
-Never open more than one drawer at a time.
-If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce,
but not eliminate, the risk of tip-over.
WARNING
5L
D601
