Sauder Soft Modern 415138 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-22
Français pg 23-26
Español pg 27-30
Lot # 357958 12/03/13
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Queen Platform Bed
Soft Modern Collection | 415138
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
You are getting sleepy.
Very sleepy.

Table of Contents Assembly Tools Required
2-3
4
5-22
23-26
27-30
31
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A2 HEADBOARD RIGHT END (1)
B2 HEADBOARD LEFT END (1)
C2 HEADBOARD TOP (1)
D2 HEADBOARD RAIL (1)
E2 HEADBOARD SLAT (4)
F2 HEADBOARD TOP SUPPORT (1)
G2 HEADBOARD SLAT SUPPORT (4)
H RIGHT LEG (1)
I LEFT LEG (1)
J2 RIGHT RAIL (1)
K2 LEFT RAIL (1)
L2 FOOT RAIL (1)
M2 RIGHT PLATFORM (1)
N2 LEFT PLATFORM (1)
O2 FOOT PLATFORM (1)
P2 PLATFORM DECK (4)
Q CENTER SUPPORT (1)
R SHORT SUPPORT (2)
S OUTER SUPPORT (2)
T SUPPORT BRACE (4)
U2 SHORT CLEAT (4)
V LONG CLEAT (2)
W HEADBOARD BRACE (1)
Part Identification
415138 www.sauder.com/servicesPage 2

Part Identification
A2
B2
C2
D2
E2
F2
G2
H
I
J2
K2
L2
M2
N2
O2
P2
Q
R
S
T
U2
V
W
S
T
R
T
T
V
P2
P2
P2
U2
U2
U2
G2
G2
G2
E2
E2
E2
415138www.sauder.com/services Page 3

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
HIDDEN CAM - 50
1F CAM SCREW - 13 8F
BLACK 1-1/4" FLAT HEAD SCREW - 24
7S
BLACK 1-15/16" FLAT HEAD SCREW - 32
4S
PROPEL NUT - 8
14M
BLACK 2-3/8" FLAT HEAD BOLT - 8
103S
METAL BRACKET - 10
4G
BLACK 9/16" LARGE HEAD SCREW - 20
1S
36P CAM COVER - 11
12S BROWN 1" FLAT HEAD SCREW - 4
SCREW COVER - 8
16P
METAL PIN - 16
1R
CAM DOWEL - 37
2F
SILVER 1" LARGE HEAD SCREW - 19
102S
415138 www.sauder.com/servicesPage 4

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
å NOTE: You will need someone’s help to build this unit. Due to the size and weight of this unit, you should build it close to its
final location.
å NOTE: You may find it useful to glance at Steps 16 and 18 to help you choose where to build your unit that allows for
ample room.
å Push fifty HIDDEN CAMS (1F) into the HEADBOARD TOP (C2), HEADBOARD TOP SUPPORT (F2), HEADBOARD SLAT
SUPPORTS (G2), RAILS (J2, K2, and L2), PLATFORMS (M2 and N2), and HEADBOARD BRACE (W). Then, insert the
metal end of a CAM DOWEL (2F) into each HIDDEN CAM except the RAIL (L2) and PLATFORMS (M2 and N2).
415138www.sauder.com/services Page 5
C2
F2
G2
J2
K2
L2
M2
N2
W
G2
G2
G2
Arrow
1F
2F
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
(50 used)
(37 used)
Arrow
The arrow in the HIDDEN CAM
must point toward the hole in
the edge of the board.
Hole
Do not insert
CAM DOWELS
into these parts.
Do not insert
CAM DOWELS
into this part.

Step 2
å Turn thirteen CAM SCREWS (8F) into the
RAILS (J2 and K2) and FOOT PLATFORM (O2).
415138 www.sauder.com/servicesPage 6
8F
O2
8F
K2
J2

BLACK 9/16" LARGE HEAD SCREW
(10 used in this step)
1S
å Using your hammer, gently tap eight PROPEL NUTS (14M) into the
holes in the RAILS (J2 and K2) as shown in the upper diagram.
å Fasten ten METAL BRACKETS (4G) to the HEADBOARD SLAT
SUPPORTS (G2) and FOOT RAIL (L2) as shown in the lower
diagram. Use ten BLACK 9/16" LARGE HEAD SCREWS (1S).
Step 3
415138www.sauder.com/services Page 7
G2
J2
K2
G2
G2
G2
(8 used)
14M
4G
4G
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
L2
Surface with HIDDEN CAMS

Step
å Fasten the PLATFORMS (M2 and N2) to the FOOT
PLATFORM (O2). Tighten four HIDDEN CAMS.
Step 4
415138 www.sauder.com/servicesPage 8
12
Rounded edge
Rounded edge
Rounded edge
Unfinished surface
Surface with HIDDEN CAMS
N2
M2
O2
Surface with HIDDEN CAMS

Step
415138www.sauder.com/services Page 9
Step 5
å Fasten the RAILS (J2 and K2) to the FOOT RAIL (L2).
Tighten four HIDDEN CAMS and use two BLACK
9/16" LARGE HEAD SCREWS (1S) through the METAL
BRACKETS on the FOOT RAIL and into the RAILS.
K2
J2
L2
Surface with HIDDEN CAMS
Surface without HIDDEN CAMS
These holes
must be here.
Surface with HIDDEN CAMS
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
These holes
must be here.
Edge without HIDDEN CAMS
Edge without HIDDEN CAMS
Edge without HIDDEN CAMS
BLACK 9/16" LARGE HEAD SCREW
(2 used for the METAL BRACKETS)
1S

Step
å Fasten the RAILS (J2, K2, and L2) to the
PLATFORMS (M2, N2, and O2). Tighten
seventeen HIDDEN CAMS.
Step 6
415138 www.sauder.com/servicesPage 10
K2
J2
L2
N2
M2
O2
Arrow
Minimum
190 degrees
Maximum
210 degrees

Step
415138www.sauder.com/services Page 11
Step 7
å Fasten the PLATFORM DECKS (P2) to the
PLATFORMS (M2, N2, and O2). Use nineteen
SILVER 1" LARGE HEAD SCREWS (102S).
P2
P2
P2
P2
M2
O2
N2
102S
SILVER 1" LARGE HEAD SCREW
(19 used in this step) 102S

Step
å Fasten the HEADBOARD RAIL (D2) to the RAILS (J2 and K2).
Use four BLACK 1-15/16" FLAT HEAD SCREWS (4S).
å Fasten the LEGS (H and I) to the RAILS (J2 and K2). Use four
BLACK 1-1/4" FLAT HEAD SCREWS (7S) and four BLACK
2-3/8" FLAT HEAD BOLTS (103S).
Step 8
415138 www.sauder.com/servicesPage 12
K2
J2
H
IBLACK 1-1/4" FLAT HEAD SCREW
(4 used in this step)
7S
103S
BLACK 2-3/8" FLAT HEAD BOLT
(4 used in this step)
D2
Surface with
two holes
Surface with
four holes
Unfinished edge
This hole
must be here.
4S
BLACK 1-15/16" FLAT HEAD SCREW
(4 used in this step)

Step
415138www.sauder.com/services Page 13
Step 9
å Fasten the SHORT CLEATS (U2) to the RAILS (J2 and K2).
Use twelve BLACK 1-1/4" FLAT HEAD SCREWS (7S).
å Fasten the LONG CLEATS (V) to the RAILS (D2 and L2). Use
eight BLACK 1-1/4" FLAT HEAD SCREWS (7S).
K2
J2
D2
L2
U2
U2
U2
V
V
U2
BLACK 1-1/4" FLAT HEAD SCREW
(20 used in this step)
7S

Step
å Fasten the HEADBOARD TOP (C2) to the HEADBOARD
TOP SUPPORT (F2). Tighten three HIDDEN CAMS.
Step 10
Arrow
Minimum
190 degrees
Maximum
210 degrees
C2
F2
Flat edge
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
415138 www.sauder.com/servicesPage 14
Finished edge

å Fasten the HEADBOARD SLATS (E2) to the HEADBOARD
SLAT SUPPORTS (G2). Tighten twelve HIDDEN CAMS.
Step 11
E2
G2
G2
G2
G2
E2
E2
E2
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Surface with HIDDEN CAMS
Arrow
Minimum
190 degrees
Maximum
210 degrees
415138www.sauder.com/services Page 15
Surface with holes
Surface with holes
Surface with holes
Surface with holes

Step 12
å Fasten the HEADBOARD TOP (C2) and HEADBOARD
TOP SUPPORT (F2) to the HEADBOARD RIGHT END (A2).
Tighten three HIDDEN CAMS.
C2
F2
A2
Surface with more holes
Flat edge
Surface with HIDDEN CAMS
Angled edge
415138 www.sauder.com/servicesPage 16

å Insert eight METAL PINS (1R) into the holes in the
HEADBOARD RIGHT END (A2).
å Fasten the HEADBOARD SLAT SUPPORTS (G2) to the
HEADBOARD RIGHT END (A2). Use four BLACK 9/16"
LARGE HEAD SCREWS (1S) through the METAL BRACKETS
and into the HEADBOARD RIGHT END.
å NOTE: Be sure the METAL PINS in the HEADBOARD RIGHT
END insert into the holes in the HEADBOARD SLATS (E2).
Step 13
415138www.sauder.com/services Page 17
A2
E2
G2
G2
G2
G2
E2
E2
E2
1R
(8 used) BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S

Step 14
å Fasten the HEADBOARD BRACE (W) to the HEADBOARD RIGHT END (A2). Tighten two
HIDDEN CAMS.
å Insert eight METAL PINS (1R) into the holes in the HEADBOARD LEFT END (B2).
å Fasten the HEADBOARD SLAT SUPPORTS (G2) to the HEADBOARD LEFT END (B2). Use
four BLACK 9/16" LARGE HEAD SCREWS (1S) through the METAL BRACKETS and into
the HEADBOARD LEFT END.
å NOTE: Be sure the METAL PINS in the HEADBOARD LEFT END insert into the holes in the
HEADBOARD SLATS (E2).
å Fasten the HEADBOARD TOP (C2), HEADBOARD TOP SUPPORT (F2), and HEADBOARD
BRACE (W) to the HEADBOARD LEFT END (B2). Tighten five HIDDEN CAMS.
C2
F2
B2
E2
G2
G2
G2
G2
E2
E2
E2
W
Surface with less holes
Angled edge
A2
Arrow
Minimum
190 degrees
Maximum
210 degrees 1R
(8 used)
415138 www.sauder.com/servicesPage 18
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
Surface with HIDDEN CAMS
Unfinished edge

Step
103S
BLACK 2-3/8" FLAT HEAD BOLT
(4 used in this step)
Step 15
å With someone’s help, carefully flip the bedframe over.
å Fasten the HEADBOARD ENDS (A2 and B2) to the
RAILS (J2 and K2). Use four BLACK 2-3/8" FLAT
HEAD BOLTS (103S).
å Fasten the HEADBOARD BRACE (W) to the
HEADBOARD RAIL (D2). Use four BROWN 1" FLAT
HEAD SCREWS (12S).
BROWN 1" FLAT HEAD SCREW
(4 used in this step)
12S
103S
415138www.sauder.com/services Page 19
B2
A2
WK2
D2
J2

Step
å Place your bed in its final location
with the bottom of the headboard end
approximately 15 inches from the wall.
å NOTE: Be sure to place your bed the
recommended distance from any walls,
windows, or objects in the room so that
you don't damage anything when flipping
your unit.
å With someone's help, carefully lean your
unit up on edge to create space to build the
platform/support in the next step.
å NOTE: You will need someone to hold the
unit to stabilize it while you continue in the
next step.
å The next step involves building the support
for underneath your bed so this requires
the support to be built near the bed's final
location for less movement or relocation.
Step 16
415138 www.sauder.com/servicesPage 20
64 1/2" minimum
15 inches
Wall, window, or
object
Wall, window, or
object
The platform in Step 17 should
be built in this location. See
Step 18 for helpful information.
flip bed
on edge
