Sauder Kitchen Cart 419324 User manual

sauder.com
Kitchen Cart
Model 419324
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-18
Español pg 19-21
Lot # 531744 07/19/19
Purchased: __________________
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Share your journey!
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Now you're cookin'
with class.

Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Table of Contents Assembly Tools Required
3
4
5-15
16-18
19-21
22
23
Skip the power trip.
This time.
Page 2 www.sauder.com/service 419324
Wood/Laminate: Use your favorite type of furniture polish. Do not spray polish directly onto the furniture. Spray onto a soft cloth then
wipe onto the furniture. Always test polish in a discrete location first, such as the inside of a door, to ensure that there is no adverse
reaction. Clean spills immediately with a soft, damp cloth. Dust frequently with a soft cloth. Protect surfaces by using felt, leather or
cork under the accessories. Use a protective pad when using your furniture as a writing surface (especially when using a ballpoint pen).
Never slide objects across surfaces. Lift objects from the top surface rather than dragging them across the finish when moving them.
Do not expose furniture to direct sunlight, drying heat sources or dampness.
CARE and CLEANING
When properly used and maintained, the granite surface should maintain its beauty and provide you with many years of use. Please
read and follow these instructions:
1. Blot up spills immediately. Acidic substances like wine, tomato sauce, and sodas can stain the surface.
2. Clean the surface with a sponge or soft cloth. Use formulated stone cleaners or plain water.
a. Avoid using soaps since soaps will form a build-up on the surface.
b. Avoid using bathroom, tub, and tile or grout cleaners. These contain abrasives that can scratch and dull the surface.
c. Avoid using vinegar, ammonia, lemon, or "orange" cleaners. These can damage the surface.
3. Use coasters under bottles, glasses, and cans. Use trivets or hot pads under pots and pans. This is good practice for all
surfaces and helps prevent inadvertent scratches and chipping.
4. Always use cutting boards for food preparation activities:
a. Especially after preparations involving raw meats, the cutting board must be sanitized.
b. If used as a cutting surface, granite will dull cutlery. Knives will also scratch the granite surface.
Care of the Granite Top
Granite is a totally natural material and as such can have color and crystal variances, slight surface pits, spar lines and imperfections
which will naturally occur within a sheet. The Granite top included may have such variations.
Natural Stone Disclaimer

åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Part Identification Now you know
our ABCs.
A GRANITE TOP (1)
B RIGHT END (1)
C BOTTOM (1)
D LEFT END (1)
E UPRIGHT (1)
F ADJUSTABLE SHELF (1)
G BACK PANEL (1)
H REAR BRACE (1)
I FRONT BRACE (1)
J DRAWER GLIDE (1)
K SMALL PANEL (1)
L DRAWER FRONT (2)
M SHELF (1)
N DOOR (1)
O BAR SUPPORT (2)
P BAR (1)
Q LEFT DRAWER SIDE (2)
R DRAWER BACK (2)
S RIGHT DRAWER SIDE (2)
T DRAWER BOTTOM (2)
Page 3
www.sauder.com/service419324
A
B
C
D
E
F
G
H
I
K
L
M
N
P
Q
RS
TL
Q
RS
T
J
O

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
PHILLIPS BOLT - 1
X
12mm PHILLIPS SCREW - 6
AA 14mm PHILLIPS SCREW - 2 BB
HINGE - 2
CC KNOB - 1 DD DOOR MAGNET - 1 EE MAGNET PLATE - 1 FF
METAL PIN - 8
GG DRAWER STOP - 2
HH PULL - 2
II LOCKING CASTER - 2 JJ
CASTER - 2
KK HOLE COVER - 16 LL ALLEN WRENCH - 1 NN
ALLEN SCREW - 24
W50mm PHILLIPS SCREW - 2 Y
25mm PHILLIPS SCREW - 16
Z
BLACK 12mm PHILLIPS SCREW - 1
MM
Page 4 www.sauder.com/service 419324

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Fasten the UPRIGHT (E) to the BOTTOM (C). Use two ALLEN
SCREWS (W). Tighten with the ALLEN WRENCH (NN).
C
E
W
NN
Page 5
www.sauder.com/service419324

å Fasten the BRACES (H and I) to the UPRIGHT (E). Use
two ALLEN SCREWS (W).
å NOTE: Be sure that the grooves in the BOTTOM (C),
UPRIGHT (E), and REAR BRACE (H) all line up.
Step 2
E
I
H
W
W
NN
Page 6 www.sauder.com/service 419324

å Fasten the LEFT END (D) to the BOTTOM (C) and
BRACES (H and I). Use six ALLEN SCREWS (W) and
tighten using the ALLEN WRENCH (NN).
Step 3
E
I
HC
D
NN
W
Page 7
www.sauder.com/service419324

å Slide the BACK PANEL (G) into the grooves on the
BOTTOM (C), UPRIGHT (E), and REAR BRACE (H).
å Fasten the DOOR MAGNET (EE) to the UPRIGHT (E). Use
two 14mm PHILLIPS SCREWS (BB).
Step 4
E
H
C
G
EE
BB
Page 8 www.sauder.com/service 419324

å Fasten the KNOB (DD) to the DOOR (N). Use one
PHILLIPS BOLT (X).
å Fasten the MAGNET PLATE (FF) to the door. Use one
BLACK 12mm PHILLIPS SCREW (MM).
Step 5
N
DD
X
FF
MM
Page 9
www.sauder.com/service419324

å Insert the HINGES (CC) into the DOOR (N) as shown.
å Fasten the DOOR (N) to the BOTTOM (C) and the
FRONT BRACE (I).
å NOTE: You should loosen the SCREW connecting the
FRONT BRACE (I) to the UPRIGHT (E) in order to allow
you to pull it apart slightly to insert the HINGES (CC) into
the BOTTOM and the FRONT BRACE. Once the DOOR is
in place, tighten the SCREW back down using the
ALLEN WRENCH (NN).
Step 6
N
E
I
CC
Page 10 www.sauder.com/service 419324
