Schuchmann todd User manual

Instructions for use.
todd. the upright trainer.
todd.

Many thanks.
Dear Customer
At this point we would like to thank you for placing your trust in our company and
for purchasing our product. We ask you to read through the Instructions for
use carefully prior to initial commissioning of the product, and to observe them.
Please note that guidelines and representations in these Instructions for use may deviate
from your product due to diering equipment. We reserve the right to make technical
modifications.
Important information!
Ensure that these Instructions for use remain with the product.
Your schuchmann Team

03 Contents.
1. Preparation. ................................................................................ 05
1.1 Delivery............................................................................................................................05
1.2 Safety measures prior to use ..............................................................................05
1.3 Safe disposal...............................................................................................................05
1.3.1 Packaging...........................................................................................................05
1.3.2 Product................................................................................................................05
1.4 Where to store the Instructions for use..........................................................05
2. Product description. .................................................................... 06
2.1 Material information ................................................................................................06
2.2 Handling and transport ........................................................................................06
2.3 Application areas, use according to the intended purpose .............06
2.3.1 Indications .........................................................................................................06
2.3.2 Contraindications .........................................................................................07
2.4 Use not in accordance with the intended purpose / warning gui-
delines............................................................................................................................08
2.5 Equipment for basic model.................................................................................08
2.5.1 Equipment acc. HMV (Medical Aids Register) ..................................08
2.6 List of accessories....................................................................................................09
2.7 Product overview......................................................................................................09
2.8 General settings ........................................................................................................10
2.9 Getting in and out..................................................................................................... 11
3. Settings. ..................................................................................... 11
3.1 Angular adjustment of the central column................................................... 12
3.2 Height adjustment on the central column................................................... 12
3.3 Rear wheels / drum brake.................................................................................... 13
3.4 Wheel camber............................................................................................................14
3.5 Support rollers............................................................................................................. 15
3.6 Foot support................................................................................................................ 16
3.7 Individually adjustable footrests........................................................................ 16
3.8 Heel edges with footstraps.................................................................................. 17
3.9 Knee pelotte pads.................................................................................................... 17
3.10 Pelvis positioning.....................................................................................................18
3.10.1 Pelvic positioner / pelvic positioner with lateral guide.............. 18
3.10.2 Combined spine and pelvis pelotte pad......................................... 19
3.11 Buttocks pelotte pad / pelvic guidance pelotte pad with lateral
guide..............................................................................................................................20
3.11.1 Buttocks pelotte pad mount ...................................................................20
3.12 Chest pelotte pad / chest pelotte pad with lateral guide............... 22
3.13 Backstrap ................................................................................................................... 23
3.14 Back pelotte pad................................................................................................... 24
3.15 Headrest ..................................................................................................................... 24
3.16 Table ............................................................................................................................. 25
3.16.1 Therapy table made from Plexiglas with edge............................. 25

3.16.2 Working table made from wood with edge................................... 26
3.17 Storage basket ........................................................................................................ 26
4. Cleaning and maintaining. .......................................................... 27
4.1 Cleaning and disinfecting.....................................................................................27
4.1.1 Cleaning...............................................................................................................27
4.1.2 Disinfection.........................................................................................................27
4.2 Servicing........................................................................................................................27
4.3 Maintenance ...............................................................................................................27
4.3.1 Maintenance specifications .................................................................... 28
4.3.2 Maintenance plan ........................................................................................ 28
4.4 Spare parts................................................................................................................. 29
4.5 Duration of use and re-use ................................................................................ 29
5. Technical data. ............................................................................ 30
6. Guarantee. .................................................................................. 31
7. Identication. ............................................................................. 32
7.1 EU Declaration of Conformity.............................................................................. 32
7.2 Serial number / date of manufacture............................................................ 33
7.3 Product version .......................................................................................................... 33
7.4 Issue of the document ........................................................................................... 33
7.5 Name and address of the manufacturer, specialist dealer supplying
the product.................................................................................................................. 33
04 Contents.

05 1. Preparation.
1.1 Delivery
On receiving the product, please check it for completeness, lack of faults
and any transport damage. Inspect the goods in the presence of your
forwarder. Should transport damage have occurred, please arrange for
an inventory (determination of the faults) to be made in the presence of
the forwarder. Please send a complaint in writing to the specialist dealer
responsible.
1.2 Safety measures prior to use
The correct use of the product requires a detailed and careful instruction
of the user or the accompanying person. We ask you to read through the
Instructions for use carefully prior to initial commissioning of the product,
and to observe them. It is possible that product parts that get in contact
with the skin may heat up in the sun. Cover these areas or protect the
device from direct sunlight.
1.3 Safe disposal
In order to preserve and protect the environment, to prevent environmental
pollution and to improve the recycling of raw materials, please note the
disposal instructions in points 1.3.1 and 1.3.2.
1.3.1 Packaging
The packaging of the product should be kept for any future transport that
might be required. Should you have to return the product for repairs or in
case of a guarantee claim, please if possible use the original box so that
the product is optimally packaged. Otherwise, separate the packaging
materials for recycling according to their classification.
Do not leave packaging materials unattended, as they are a possible source of
danger.
1.3.2 Product
Attheendoftheproductlifecycle,recycletherawmaterialsusedintheproduct
according to their nature (see material information under point 2.1).
1.4 Where to store the Instructions for use
Please store these Instructions for use carefully and ensure that these
instructions for use remain with the product in case of re-use. Should you
lose the instructions, you can always download an updated version at
www.schuchmann.de .

06 2. Product description.
2.1 Material information
The base frame and the individual elements are made of steel or alumi-
nium which are non-corroding and powder-coated. All body supports
(except for the knee pelotte pads) are padded and covered. The covers
are made of 100% polyester or polyamide textile substrate, and are flame
resistant (according to DIN EN 1021-1+2).
2.2 Handling and transport
The upright trainer is not intended to be carried since it is equipped with
support rollers. Should you have to carry the equipment due to obstacles,
ensure that all moving parts are tightened. Then two people should positi-
on themselves next to the upright trainer, grip it on the left and right of the
frame and carry it to the required location. To transport the upright trainer,
reduce all adjustments to their most compact size (set lowest height etc.).
2.3 Application areas, use according to the intended purpose
The todd. upright trainer is a medical product of risk class 1 for indoors and
is used for upright training with severely impaired or non-existent ability to
stand.
2.3.1 Indications
The todd. upright trainer is designed for users with significantly pronounced
impairment of standing and walking, especially due to:
• Paraplegia
• Advanced multiple sclerosis
• Cerebral paresis
• Muscular dystrophy
The assumption of a standing position with the upright trainer is used to
prepare for walking training and/or to achieve positive eects of an up-
right body position (e.g. with regard to cardiovascular regulation/bone
metabolism/peristalsis/urinary diversion and/or to prevent decubitus,
thrombosis or joint contractures, promotion of head control and arm func-
tion and improvement of spatial awareness).
If the individual therapy requires a change in location of the upright frame
and the spatial conditions permit a change in location, this is possible with
the todd. upright trainer.

07 2. Product description.
2.3.2 Contraindications
In general, the indications for standing should be approved by a doctor or
orthopedist. It should therefore be clarified prior to procurement whether
contraindications exist for the patient. In general, any type of pain repre-
sents a contraindication. No upright trainer care should be conducted wi-
thout establishing prior to use whether the patient has an abnormal foot
position which requires medical attention.
Depending on the disease symptoms and therapy, please clarify how long
the user may stand in the upright trainer. The following symptoms may
occur in some cases:
• Circulation problems
• Pain in the leg and back areas
• Spastic seizures
It must also be clarified whether the user can be brought into full standing
position. For many users, only standing in a bent position is possible at first.
Never correct posture using force or strong pressure!

08 2. Product description.
2.4 Use not in accordance with the intended purpose / warning guide-
lines
• Ensure that the upright trainer is used by
only one user.
• The upright trainer may only be used indoors on solid, even ground.
• Never leave the user without supervision in the upright trainer.
• Correct usage of the upright trainer requires precise and careful training
of the accompanying person.
• The max. load (see Point 5) may not be exceeded.
• Do not use the upright trainer if it has defective, worn or missing parts.
• For reasons of fire safety, the upright trainer may not be placed close to
an open fire or any other strong source of heat such as electric or gas
heaters.
• Only use accessories and spare parts made by Schuchmann, otherwise
you will endanger the user.
• Only use the upright trainer if all components have been correctly
mounted and adjusted.
• When adjusting the upright trainer there is the risk of trapping or
crushing limbs.
• Users who have diculty reading must have someone read these
Instructions for use aloud so that they understand how to use the
standing exercise trainer.
2.5 Equipment for basic model
• Base frame (standard) with height and depth-adjustable foot support
and four height-adjustable support rollers (75 mm), suspended with
locks at the back
• Base frame (abducting) with individually adjustable footrests, with two
height-adjustable support rollers (75 mm) at the front and one support
roller (30 mm) at the back
• Incl. chest harness, buttocks pelotte pad and three-dimensionally
adjustable knee pelotte pads with patella recess
• Angular adjustment of the central column mechanical from 0° - 15
• incl. drum brakes, easy to operate via locking lever
• Adjustable wheel camber
2.5.1 Equipment acc. HMV (Medical Aids Register)
Acc. the HMV (Medical Aids Register), the upright trainer todd. requires the
provision of heel edges and footstraps.

09 2. Product description.
2.6 List of accessories
• Chest structure
• Chest pelotte pad with lateral
guide
• Backstrap
• Knee pelotte pads
• Back pelotte pad
• Pelvic guidance pelotte pad with
lateral guide
• Buttocks pelotte pad
• Pelvic positioner
• Combined spine and pelvic
pelotte pads
• Headrest
• Therapy table with edge
• Work table (for size 3+4)
• Storage basket (for size 1+2)
• Rear wheels
• Rear wheels with closed hand rims
• Spoke guard
• Foot support
• Individually-adjustable footrests
• Heel edges
• Footstraps
2.7 Product overview
The Fig. below is intended to show you the designation of the most
important components as well as the terms which you will find in these
Instructions for use.
Chest pelotte pad with
lateral guide
Pelvic positioner
Knee pelotte pads
with adjustable
positioner
brackets
Therapy table from
Plexiglas with edge
Central column can
be inclined from 0° - 15°
Support wheels
Buttocks pelotte pad
with lateral guide
suspended
support wheels
with parking
Divided foot plate
Rear wheels with
hand rims
Manual crank
to adjust the
pelvic position
Storage net

10 2. Product description.
2.8 General settings
todd. is delivered completely assembled and in the smallest possible
setting. Before the user is placed into the upright trainer, the necessary
presettings must be carried out.
User dimensions
Presettings
E
A
B
F
D
G
C
Taking the user's
dimensions Carrying out adjustments to the upright trainer see
ABody size Foot plate to headrest 3.2 + 3.16
BPelvic height Foot plate until the top edge of the buttocks pelotte
pad adapter, then adjust about 5 cm downwards 3.6 + 3.12
CPelvic depth Depth of the buttocks pelotte pad 3.12
DPelvic width Width of the combined spine and pelvic pelotte pad 3.11
ESternum height Height of the chest pelotte pad with lateral guide 3.13
FChest width Width of the chest pelotte pad with lateral guide 3.13
GKnee height Height of knee pelotte pads 3.10

11 2. Product description.
2.9 Getting in and out
After all pre-settings have been made, plea-
se first lock the two support rollers (A- see
point 3.5) or the drum brake (B- see point 3.3)
getting in and out. Now bring the central co-
lumnintotheuprightposition(C- seepoint3.1)
and remove the buttocks pelotte pad (D).
To remove the buttocks pelotte pad (D), undo
the wing nut (E), pull out the buttocks pelotte
pad (D) upwards and fold down the mount (F)
(if folding buttocks pelotte pad mount is in-
stalled). Pull the release cable (G) for folding
down and keep it slightly tense.
Now you can approach todd. from the rear
with the user in the wheelchair / buggy etc.
and secure against unintentional rolling away.
Subsequently lift the user out of the wheel-
chair/buggy and place him/her in the stan-
ding unit, insert the buttocks pelotte pad (D)
into the mount (F). Then lift the mount (F)
together with the buttocks pelotte pad (D)
upwards until the mount (F) engages. Hold
again the release cable (G) lightly tensioned.
Now you can undertake the fine adjustments
on the individual components. Please obser-
ve here the guidelines on the adjustment of
the respective components (see Point 3).
Only have the user get in and out of the product
on stable and at ground.
A
3. Settings.
Settings and adjustments to the product or accessories may only be made
by people who have been given the necessary instructions by a medical
product advisor. Please ensure that none of the user's extremities are in
the respective area when making adjustments of any kind to minimise the
risk of injury.
B
D
C
D
E
FG

12 3. Settings.
3.1 Angular adjustment of the central column
The central column can be mechanically ad-
justed from 0° - 15° using a clamping lever.
Please secure the upright trainer against
unintentional rolling away and lock the two
support rollers (A) or the drum brake (B).
In order to adjust the angle, loosen the clam-
ping lever (C), bring the central column into
the required position and turn the clamping
lever to tighten again.
For the abductable variant, also the clam-
ping lever of the third support roller (D) must
be loosened before positioning the central
column and then fastened again.
If the clamping lever is not located in a
position from which it is easy to operate,
its position can be changed when idling by
gently pulling the lever away from the screw.
3.2 Height adjustment on the central co-
lumn
In the upper area of the central column (E)
there is a black inner profile (F) that can
be extended and is therefore adjustable
in height. In order to adjust the inner profi-
le (F), loosen the hexagon socket screws (G)
for sized 1+2, bring the profile into the desi-
red position and tighten the hexagon socket
screws (G) again. For sizes 3+4 please undo
the wing screws (H) for this procedure.
For each height adjustment hold the inner
prole rmly as it could otherwise slip into the
central column due to its own weight.
Only undertake height adjustment if there is
no-one in the upright trainer!
After each adjustment, please retighten all screw connections!
C
D
F
G
E
B
A
H

13 3. Settings.
3.3 Rear wheels / drum brake
The drive wheels are puncture-free and
removable. Please press the button in the
middle of the wheel hub (A) and the drive
wheel can be easily removed and replaced.
When inserting the quick release axles, you
should be able to hear it engage with an
audible "click".
The upright trainer is equipped with drum
brakes (B) at the drive wheels for a safe stand
and against unintentional rolling away.
Please apply the parking brake (C) to acti-
vate the drum brake.
Check the tight axial t of the quick release axle
each time the rear wheel is mounted!
A
C
B

14 3. Settings.
3.4 Wheel camber
The wheel camber can be adjusted individually.
Like this the distance at the top between the
hand rims (A) can be changed and an optimal
gripping distance for the user can be achie-
ved. Like this, todd. can also be adjusted
individually to the pelvis width of the user.
To do this, please remove the hexagon socket
screw (B) at each wheel mount (C), bring it
into the desired angle and insert the hexagon
socket screw (B) into the hole corresponding
to the desired angle (1-4).
The drive wheels (see point 3.3) can also be
removed beforehand for easier handling.
Please ensure that the position of the support rollers also changes by
adjusting the wheel camber and their height must be adapted
subsequently (see point 3.5).
Change the wheel camber only when the upright trainer is not in use!
After each adjustment, please retighten all screw connections!
The wheel camber must always be adjusted the same on both sides!
For Size 1 For Size 2 For Size 3+4
115° 12° 9°
212° 9° 6°
39° 6° 3°
4-3° 0°
1
2
3
4
A
BC

15
3.5 Support rollers
The standard version of todd. has height-ad-
justable support rollers in the front (A) and
rear (B). The abductable version of todd. has
a support roller (C) at the back.
The front support rollers (A) are firmly moun-
ted on the base frame. At the rear support
rollers (B) elastomers (D) integrated in the
base frame ensure that they are suspended
(to absorb any possible impact e.g. when ro-
cking). In addition, the rear support rollers (B)
are each equipped with a parking brake (E).
To lock these, press them down with the tip
of your foot.
When adjusting the wheel camber (see
point 3.4) the positions of the support rol-
lers are changed. Subsequently loosen the
torx screws (F) on the front support rollers (B)
and the torx screws (G) on the rear support
rollers (B). Subsequently position all support
rollers in such a way that they are in cont-
act again with the floor and tighten again
all screws (F+G).
For the abducted version of todd. the rear
support roller (F) is automatically adjusted if
the angle of the central column is adjusted.
To do this however, a clamping lever (see
point 3.1) must be loosened before any ang-
le adjustment.
After each adjustment, please retighten all screw connections!
C
G
F
AB
C
D
E
3. Settings.

1616 3. Settings.
3.6 Foot support
The foot support can be adjusted in height
at the central column. To do this, undo the
four screws (A) and bring the foot support
into the desired position.
Additionally, the foot support can also be
adjusted in depth. To do this, undo the two
wing screws (B) that can be found below the
foot support. Now bring the foot support into
the desired depth adjustment.
After each adjustment, please retighten all
screw connections!
3.7 Individually adjustable footrests
The individually adjustable footrests can be
adjusted in height, width and angle.
In order to adjust the individual footrests in
height, undo the screws (D+E) and bring the
respective footrest to the desired height.
In order to adjust the width of the footrests,
unto the nuts of the screws (F+G) on the un-
derside of the respective footrest and bring
it into the desired position.
In order to adjust the angle of the footrest for
an abduction of the legs, loosen the screw (H)
and turn the grub screw (I). Further angle ad-
justment, e.g. for pointed foot position, can
be undertaken via the Allen screw (J). Using a
ratchet joint, the entire divided footrest can
be adjusted at an angle.
After each adjustment, please retighten all
screw connections!
F
G
I
J
H
DD
E
E
A A
B
B

17 3. Settings.
3.8 Heel edges with footstraps
The heel edges with footstraps (A) are moun-
ted on the foot support or the individually
adjustable footrests. They can be adjusted
in width, depth and angle.
In order to adjust the width or the angle, loo-
sen the wing screws (B) below the respective
footrest and bring the heel edges (A) into the
required position.
The footstraps (C) are each equipped with a
magnetic closure (D). In order to undo them,
you simply have to pull on the red straps (E).
In order to close the strap, simply guide the
closure again into the seams of the strap. It
will close automatically.
3.9 Knee pelotte pads
The knee pelotte pads with patella recess (F)
and the knee pelotte pads with support bra-
ckets (G) can be adjusted in height, angle
and depth. The distance between the knee
pelotte pads can also be adjusted.
In order to adjust the height, please hold the
respective knee pelotte pad, undo the wing
screw (G) and bring the knee pelotte pad
mount into the desired position.
In order to adjust the depth, the angle and the
width, please loosen the clamping lever (H)
and bring the knee pelotte pad into the re-
quired position.
If the height adjustment range is too small
for size 1, the pelotte pad mount (I) can also
be screwed on the mounting bracket (J) from
below to achieve the desired position. To do
this, loosen the clamping lever (H), unscrew
it completely and fix the pelotte pad mount
together with the pelotte pad from below
with the clamping lever on the mounting
bracket.
After each adjustment, please retighten all screw connections!
A
C
D
E
GG
B
B
FF
H
J
I
G
H
I
J

1818 3. Settings.
3.10 Pelvis positioning
The pelvic positioner, pelvic positioner with
lateral guide (see point 3.10.1) and the com-
bined spine and pelvis pelotte pad (see
point 3.10.2) can be adjusted in height and
in depth via the mount (A) on the central co-
lumn.
The height can be set by loosening the wing
screws (B), bringing the mount (A) together
with the respective pelotte pad on the cen-
tral column into the desired position and
tightening again the wing screws (B).
If the height adjustment is not sucient, you
can also turn the mount(A) by 180° upwards.
To do this, you have to completely remove
the screws (C).
In addition, the height of the respective pelotte pad can also be adjusted
directly at the mount (A). To do this, undo the screws (D), bring the pelotte
pad into the desired position and tighten the screws (D) again.
In order to adjust the depth, undo the screws (C) and bring the
respective pelotte pad into the desired depth setting.
After each adjustment, please retighten all screw connections!
3.10.1 Pelvic positioner / pelvic positioner
with lateral guide
The pelvic positioner (E) and the pelvic po-
sitioner pelotte pad with lateral guide (F)
can be adjusted in height and depth
(see point 3.10).
The pelvic positioner with lateral guide (F)
can also be adjusted in width.
Initially, fold up the two covers (G) on the rear
of the pelotte pad and undo the screws (H).
Now bring the two lateral guides (I) into the
desired position and retighten the screws (H).
After each adjustment, please retighten all
screw connections!
A
B
C
F
D
E
A
H
H
G
I
G
I

19
3.10.2 Combined spine and pelvis pelotte pad
The combined spine and pelvis pelotte
pad (A) can be adjusted in width and depth.
The height can be adjusted individually on
both sides. To do this, undo the screw (B) and
bring the respective pelotte pad into the
desired position.
Additionally, the combined spine and pelvis
pelotte (A) can also be adjusted in height via
the mount (C) (see point 3.10).
In order to adjust the width, undo the screw (D)
on both sides and bring the pelotte pads
into the desired positions.
In order to adjust the depth, remove the
cover from the respective pelotte pad and
undo the screws (E). Now bring the pelotte
pad into the desired position.
After each adjustment, please retighten all
screw connections!
E
D
B
3. Settings.
A A
C

20 3. Settings.
3.11 Buttocks pelotte pad / pelvic guidance
pelotte pad with lateral guide
The buttocks pelotte pad (A) and the pelvic
guidance pelotte pad with lateral guide (B)
can be adjusted in height and depth using
the buttocks pelotte pad mount (see point
3.11.1). In addition, both can be removed for
transfer (see point 2.9).
For the removal, undo the wing screw (C) and
pull out the respective pelotte pad upwards.
Immediately after the transfer, plug the pe-
lotte pad again into the mount and tighten
the wing screw (C) again.
If the height adjustment using the buttocks
pelotte pad mount is not sucient (see point
3.11.1), you can undo the two screws (D) at
the back of the respective pelotte pad and
also adjust the height of the pelotte pad.
After each adjustment, please retighten all
screw connections!
3.11.1 Buttocks pelotte pad mount
The buttocks pelotte pad mount (standard
- E) and the buttocks pelotte pad mount
(foldable - F) can both be adjusted in height
and depth.
In order to adjust the height, undo the wing
screws (G) on both buttocks pelotte pads,
bring the buttocks pelotte pads together
with the respective pelotte (see point 3.11) on
the central column into the desired position
and tighten the wing screws (G) again.
In order to set the depth, loosen the hexa-
gon socket screw (H), bring the buttocks pe-
lotte pads mount with the pelotte pad into
the desired position and tighten the hexa-
gon socket screw (H) again.
A
B
C
D
E
F
G
H
