Sharp PW-AT750 User manual

Insert the batteries using the procedure below before using the
PW-AT750 for the rst time.
To insert the batteries
1 Set the battery replacement switch on
the bottom of the unit to the “
解除( 交
換時 )
” position.
2 Remove the battery cover as shown
in the diagram.
3 Insert the batteries included with the
unit.
Make sure the battery polarity is correct.
• Insert the batteries over the ribbon
tab being sure not to cover the end
of the tab.
4 Replace the battery cover as shown in
the diagram.
5 Set the battery replacement switch to
the “
ロック( 使用時 )
” position.
6 Open the unit and press to turn
the power on.
The calibration screen
for the handwriting pad
appears.
Using the PW-AT750 for the first time • If the power cannot be turned on:
• Make sure the battery replacement switch is in the “
ロック

( 使用時 )
” position, then press again.
• If the power still cannot be switched on, try performing steps
1 through 6 in the above procedure again.
7 Pull out the stylus, extend it, and use it to accurately touch the
center of the “+” character displayed on the handwriting pad.
• Touch the center of the “+” character as it appears in four
different locations.
The LCD contrast adjustment screen appears.
8 Adjust the LCD contrast of the main display using ( )
and ( ).
9 The LCD contrast of the handwriting pad can be
adjusted by touching and displayed on
the pad.
Layout
Menu operation
The menu display consists of a list of classied menu items each with
a two digit alphanumeric character ( - ) to the left.
When you press to open the menu display, “
(Japanese dictionary)” is selected and the color of the number is
inverted (black and white reversed).
Press or to move the cursor (indicated by the color-inverted
number) and choose a different dictionary/function.
Individual menu items of each classied menu are displayed on the
right.
Selecting a dictionary/function in the
menu display
Press .
The menu display (dictionaries/functions selection display) appears.
The menu display (dictionaries/functions selection display)
Individual menu
Classied
menu
Selecting a menu item
● Select using the cursor keys and
1 Move the cursor (color-inverted) using or to the classied
menu you wish to choose and press or .
• To return the cursor to the classied menu, press .
2 Move the cursor using or to the dictionary/function you
wish to use and press .
The display of the dictionary/function you chose appears.
● Select using alphanumeric keys
1 Press the keys ( , , to ) that correspond to the
number shown to the left of the classied menu ( , , to
) you wish to choose.
The cursor will be displayed on the individual menu of the classied
menu you chose.
2 Press the alphanumeric key that corresponds to the characters
shown to the left of the dictionary/function you wish to use.
The display of the dictionary/function you chose appears.
• When the cursor is on an individual menu, return the cursor to
the classied menu by pressing or .
ELECTRONIC DICTIONARY
PW-AT750
QUICK REFERENCE
{
Global search key
(Searching through several
dictionaries is possible.)
Power on/off key
Function key
Utility keys for dictionaries
and functions
(S-jump, quick reference, example/note,
audio, switch, bookmark, preview, illustrations/
diagrams/notes, playing speed, word list)
Font size shift (zoom) keys
Menu (Menu customize) key
Card key
Back space (delete) key
Clear key
Card slot (side)
Page scroll keys
Volume control (side)
Earphone jack (side)
Speaker
Cursor keys
Dictionary/function selection keys
Display (Main display)
Escape key
Search/enter (store) key
Handwriting pad
Stylus holder (side)
10 When done, press .
The key sound (beep) on/off screen appears.
11 Select or to turn the key sound on/off.
Kana input screen appears.
12 Press to select alphabet character input or press to select
Japanese input.
Parts and functions
The handwriting pad is set to enter characters when the cursor is in
any part of the character entry area.
Entering characters using the pad
You can enter a character of an unknown Japanese word by tracing
it, then look it up in the dictionary.
Example: Look up an unknown Japanese word “ 持つ ”
in the Japanese-English dictionary.
1 Press .
The entry/selection screen of
ジーニアス英和
&
和英辞典
appears,
with the cursor placed over the spelling entry area.
The handwriting pad is set to the English character entry mode.
2 Press to move the cursor to the Japanese entry area.
The handwriting pad is now switched to enter kanji and kana.
Using the handwriting pad
3 Use the stylus to draw “
持
” on the handwriting pad.
The character shown in the candidate list display area is also
placed in the entry area so that the dictionary search can proceed.
4 If the character in the entry area is not the one you desired,
use the stylus to touch and select the desired character in the
list.
The character in the entry area changes.
• If you cannot nd the character in the list, touch or press
to erase it and reenter it on the pad.
5 Likewise, enter “
つ
” in the entry area.
When you start drawing, the previous entry is conrmed then
erased.
{
Indicator showing
types of characters
that are entered
button
button
button
button
Candidate list display area
Writing area
Main display Handwriting pad
PWAT750EN0928.indd 10/10/06,11:41AM1

• Press and the mark
becomes inverted ( ). Each
time you press , the audio
plays.
If several marks appear in
the display, press the or
keys to move the cursor to the
desired mark and press . The word is inverted and its
sound played using Text-to-Speech (TTS: synthesized voice).
◆ Press to stop the audio during play. Press and the
color of reverts to non-inverted.
◆ Be sure to adjust the playback volume control at the left side of
the unit to around the medium position before playing a sound
and then adjust to an appropriate level.
Adjusting the playback speed
1 Press .
The playback speed setting display
appears.
2 Press or to move the “ ” mark to select the playback
speed (the default is “
標準
”) and then press . The
playback speed is set and the main menu display appears.
Playback speed can also be adjusted by pressing ( )
when the audio mark or a word is inverted.
S-jump function
You can search through the contents for the denition or meaning of a
word on the detailed display.
Example: Use S-jump from the dictionary ジーニアス和英
辞典 display.
1 Press and input “
あ
いさつ
/aisatsu” and then press
.
The display of “
あいさつ
” in the
dictionary
ジーニアス和英辞典
appears.
2 Press .
■The cursor (color-inverted)
appears.
3 Move the cursor (color-inverted)
using , , , to the desired
word.
• English words or the word indicated by the jump mark ( ) are
selected in whole and their color inverted. You can also select
an English word or the word indicated by the jump mark using
and skip the Japanese.
• To select a Japanese word, you must rst mark the start and
end points.
To mark the word “ 言葉 ”
Move the cursor “ ■ ” to the starting point
“ 言 ” and press . Then press to
move the cursor “ ■ ” to the end point “ 葉 .”
(If you wish to mark a one letter word,
you do not have to mark the end point.)
4 Press .
A list of candidates appears in the
jump window.
• If the word is indicated with or
there is only one match, the
detailed display appears in the
jump window.
5 Press the number key that
corresponds to the desired word (in
this case ).
The detailed display appears in the
jump window.
6 Press to S-jump the display.
The detailed display of the selected word appears.
• To return to the previous display, press .
Storing frequently-used contents in My 辞書
Frequently-referred contents can be stored and recalled using
or by selecting from My 辞書 list.
While the main display is showing the menu, the handwriting pad
displays the rst ve items stored in My 辞書 . Touch the name of the
contents in the list to have it appear on the main display.
My
辞書
on the main display My
辞書
on the handwriting pad
Example: Register パーソナルカタカナ語辞典 in My 辞書 .
1 Press or .
The selection display of My
辞書
appears.
2 Press to show the My
辞書
setting
display.
Five contents are initially stored.
◆ While My
辞書
is displayed on the
handwriting pad, you can also
call the My
辞書
setting display by
touching the icon on the pad.
3 Use the number key to select the
number ( in this example) of
which you wish to store content.
( – can be selected in the
previous display.)
The contents selection display
appears.
4 Use the and keys to browse
the dictionary you wish to store,
and use the number keys ( in this
example) to select it.
The content is stored, and the screen
goes back to the My
辞書
setting
display.
• To continue storing contents, repeat steps 3 and 4 above in this
section. Up to 12 contents can be stored.
5 To end, press , , or .
◆ You can also call the My
辞書
setting display shown in step 2
from various setting displays. Press to have
various setting displays appear, then press to select “My
辞
書設定
”. When the My
辞書
setting display appears, you can
store contents.
Operation guide message
of S-jump function.
SHARP CORPORATION
PRINTED IN CHINA
0GS9701070////
TCADZ0213EHZZ
Using the mark on the display
Appearance of the marks , , , or similar on
the detailed display indicates more information related to the entry
is available, such as example sentences, explanations, notes,
illustrations or diagrams.
Press to select the rst mark and the color of the mark is
inverted.
Press , , , to move the highlight to the desired mark and
press to display the contents.
To exit, press twice.
When the mark appears, audio of the displayed information can
be played back.
Press to select the rst mark and the color of the mark is
inverted.
Press , , , to move the highlight to the desired mark and
press to play back the contents.
Example: Play back the audio using “ 旅行会話  英語 .”
1 Press and then
press to select the desired
item.
Global search function
You can search for a word in several target dictionaries.
Input the Japanese or English spelling and nd a denition from the
target dictionaries.
As you type, candidates for matching narrow (lter search). If there
are still many candidates after inputting the whole word, you can
switch to exact search to browse only the exact word you wish to
have dened.
Example: Global search for the word “advantage.”
1 Press .
The global search input display
appears.
2 Press .
Input “advantage” in “
スペル ?
”.
As you type, candidates for matching
narrow.
3 Press to search by exact
search.
The list of words corresponding to
your input appears.
If you wish to modify the entry, press
to return to the lter search
display and input again.
4 Select the desired word using the number keys.
The detailed display of the word appears along with its denitions.
• To return to the previous display, press .
Preview display function
If many candidates are listed for a word and it is difcult to decide
which word is the correct one, the preview display will help you by
providing a brief note about each word.
Each time you press ( ),
the preview display is turned on or off.
(The preview display is turned off in this
display example.)
PWAT750EN0928.indd 10/10/06,11:41AM2
