1 Safety information
1.1 General safety notes
1.1.1 Safety notes
■Read the operating instructions before commissioning.
■Connection, mounting, and configuration may only be performed by trained spe‐
cialists.
■Not a safety component in accordance with the EU Machinery Directive.
■UL: Only for use in applications in accordance with NFPA 79. These devices must
be fused with a 1 A fuse that is suitable for 30 VDC. UL-listed adapters with con‐
necting cables are available.
■When commissioning, protect the device from moisture and contamination.
■These operating instructions contain information required during the life cycle of
the sensor.
EN/IEC 60825-1:2014
IEC60825-1:2007
Laser
1
Maximum pulse power < 64 mW
Puls length: 7 ns
Wavelength: 650 nm
Complies with 21 CFR 1040.10
and 1040.11 except for deviations
pursuant to Laser Notice No. 50,
dated June 24, 2007
LASER CLASS 1
ATTENTION
WARNING: Interruption, manipulation or incorrect use can lead to hazardous exposure
due to laser radiation.
1.2 Notes on UL approval
The device must be supplied by a Class 2 source of supply.
UL Environmental Rating: Enclosure type 1
2 Product description
2.1 Intended use
The PowerProx Small Teach-in - WTT190LC-B2233A00 is an opto-electronic photoelec‐
tric proximity sensor (referred to as “sensor” in the following) for the optical, non-con‐
tact detection of objects. If the product is used for any other purpose or modified in any
way, any warranty claim against SICK AG shall become void.
Photoelectric proximity sensor with background suppression and analog distance value
output.
1 SAFETY INFORMATION
48024108 | SICK
Subject to change without notice

7.6
(0.30)
9.7
(0.38)
18.3
(0.72)
21 (0.83)
11.4
(0.45)
31.5 (1.24)
28.5 (1.12)
25.4 (1.00)
0.5 (0.02)
0.5 (0.02)
9.7
(0.38)
3(0.12)
L D
12
(0.47)
Figure: A
7.6
(0.30)
9.7
(0.38)
18.3
(0.72)
21 (0.83)
11.4
(0.45)
31.5 (1.24)
28.5 (1.12)
25.4 (1.00)
0.5 (0.02)
0.5 (0.02)
9.7
(0.38)
3(0.12)
L D
12
(0.47)
Figure: A -2
PRODUCT DESCRIPTION 2
8024108 | SICK
Subject to change without notice 5

2.2 Dimensional drawing
2
1
4 5
ß 9
6
7
8
3
4.8
(0.19)
28.3 (1.11)
17
(0.67) 32.8 (1.29)
9
(0.35)
16
(0.63)
44.4 (1.75)
39.2 (1.54)
2.6
(0.1)
3.7 (0.12)
1.2
(0.05)
1.9
(0.07)
Ø 3.1
(0.12)
7
(0.28)
6(0.24)
2.8 (0.11)
17.4 (0.69)
1Receiver
2Sender
3Connection
4RUN button
5(+/Q2) button
6Output display Q1 (orange)
7IO-Link communication (green)
8Output display Q2 (orange)
9(-/Q1) button
ßDisplay
à(SET) button
3 Commissioning
3.1 Check the application conditions:
Check the application conditions: Adjust the sensing range and distance to the object
or background and the remission capability of the object according to the correspond‐
ing diagram [see H1, H2] (x = sensing range, y = minimum distance between the object
and background in mm (object remission / background remission)). Remission: 6% =
black, 90% = white (referring to standard white as per DIN 5033).
The minimum distance (= y) for background suppression can be read from diagram the
diagram [see H15] as follows:
Example: x = 1,000 mm, y = 20 mm. That is, the background is suppressed at a dis‐
tance of > 20 mm from the object.
2 PRODUCT DESCRIPTION
68024108 | SICK
Subject to change without notice

200
(7.87)
180
(7.09)
160
(6.03)
120
(4.72)
80
(3.15)
40
(1.57)
140
(5.51)
100
(3.94)
60
(2.36)
20
(0.79)
0
Min. distance from object to background in mm (inch)
01,000
(39.37)
2,000
(78.74)
3,000
(118.11)
Distance in mm (inch)
1
2
3
4
5
6
7
8
9
ß
Figure: H-1 - Small teach and analog 6% / 90%
200
(7.87)
180
(7.09)
160
(6.03)
120
(4.72)
80
(3.15)
40
(1.57)
140
(5.51)
100
(3.94)
60
(2.36)
20
(0.79)
0
Min. distance from object to background in mm (inch)
01,000
(39.37)
2,000
(78.74)
3,000
(118.11)
Distance in mm (inch)
1
2
3
4
5
6
7
8
9
ß
Figure: H-2 - Small teach and analog 90% / 90%
3.2 Mounting
Mount the sensor using a suitable mounting bracket (see the SICK range of acces‐
sories).
Note the sensor's maximum permissible tightening torque of 0.8 Nm.
Note the preferred direction of the object relative to the sensor [F].
3.3 Electronics
The sensors must be connected in a voltage-free state (UV = 0 V). The information in
the graphics must be observed, depending on the connection type:
– Male connector connection: pin assignment
– Cable: Wire color
WTT190L
1 (brn) +12 - 24 VDC
1
2
4
3
2 (wht) Multi function input/output
3 (blu) GND
4 (blk) Switching output, IO-Link communication
Only apply voltage/switch on the voltage supply (UV > 0 V) once all electrical connec‐
tions have been established. The green LED lights up on the sensor.
Explanations on connection diagram:
L+ = Supply voltage
MF = Programmable input or output
M = Ground
C/Q = Communication and switching output
3.4 Functioning of the programmable input
Function Minimum duration
Laser shutdown 4 ms
External teach-in Q1 1 s
COMMISSIONING 3
8024108 | SICK
Subject to change without notice 7

Function Minimum duration
External teach-in Q2
3.5 Alignment
Align the sensor with the object. Select the position so that the red emitted light beam
hits the center of the object. You must ensure that the optical opening (front screen) of
the sensor is completely clear [F]. We recommend making the adjustments using an
object with a low remission.
Figure: E
4 Configuration
Perform configuration:
4.1 Setting the switching output via the teach-in quick access button (-/Q1) (+/Q2)
The sensing range is adjusted by pressing the teach-in quick access button for > 1 s.
Do not operate the teach-in buttons using sharp objects. We recommend placing the
sensing range in the object, e.g., see Graphic F. Once the sensing range has been
adjusted, the object is removed from the path of the beam. This causes the background
to be suppressed and the switching output to change.
Sensing range settings via IO-Link. See IO-Link description (8024109).
The sensor is adjusted and ready for operation. Use the following graphic to check the
function. If the switching output fails to behave in accordance with the graphic, check
the application conditions. See section Fault diagnosis chapter 5.
Figure: F
3 COMMISSIONING
88024108 | SICK
Subject to change without notice

4.2 Additional functions
Table 1: Process data structure
Byte
offset Byte 0 Byte 1 Byte 2 Byte 3
Bit
offset 9 8 7 6 5 4 3 2 1 0
Distance
to object
Distance
to object Spare Value Qint.8 Qint.7 Qint.6 Qint.5 Qint.4 Qint.3 Qint.2 Qint.1 QL2 QL1
Integer
16
Integer
16
Unsigned
Integer 6 Boolean
Information on the IO-Link functions can be found in the IO-Link photoelectric sensors
operating instructions (available for download from www.sick.com under the device part
number).
4.3 Setting the switching outputs and other sensor configurations via the menu
As an alternative, the switching outputs can also be set via the menu. Further sensor
configurations can also be performed via the menu. The menu is accessed by briefly
pressing the Set button for < 1 s. Graphic K describes how to navigate within the menu.
NOTE
Entries qn1 and qn2 are only available when the accompanying teaching mode (qc1,
qc2) has been set to 2-point or window mode.
CONFIGURATION 4
8024108 | SICK
Subject to change without notice 9
