Foreword:
Thanks for selecting ROX 12.0 SPORT as your new Bike Computer.
This is the full manual, to give you a detailed overview of the functions.
ROX 12.0 SPORT

S. 5 1. Button Functions
S. 6 2. First Wake Up
S. 7 3. Screen Overview
S. 7 3.1 Status Bar
S. 7 3.2 Battery status information Home Screen
S. 8 3.3 Swiping Gestures (Sub-menu)
S. 8 4. Home Screen
S. 8 4.1 Home Screen Overview
S. 9 4.1.1 Open Training Menu
S. 9 4.1.2 Sport Profile Selection
S. 9 4.1.3 Navigation
S. 10 4.1.4 Track
S. 10 4.1.5 Data Sync.
S. 11 4.2 Overview 3rd Party Integration
S. 11 4.2.1 Strava
S. 12 4.2.2 TrainingPeaks
S. 12 4.2.3 komoot
S. 14 4.2.4 Dropbox
S. 15 4.3 Overview: Settings, Workout, Memory
S. 15 4.3.1 Settings
A. Device
B. Map
C. Sport Profile
D. Connect Sensor
E. WiFi
F. User
G. Firmware Update
H. Reset to Default Settings
S. 21 4.3.2 Workout
S. 22 4.3.3 Memory (Training History)
S. 22 4.3.4 SIGMA CLOUD
S. 23 5. Navigation
S. 23 5.1 Single Point Navigation
S. 25 5.2 Multiple Point Navigation
S. 26 5.3 Draw my Route
S. 26 5.4 Start a Route
S. 27 6. Track
S. 28 6.1 How to transfer a track to the ROX 12.0 SPORT
S. 28 6.2 Where can I find my tracks?
CONTENT

CONTENT
S. 29 7. Training
S. 30 7.1 Before you start your training
S. 31 7.2 During the training
S. 33 7.3 After the training
S. 34 8. Specifications
S. 35 9. Legal disclaimer
Updates
More information
Guarantee, Warranty, Legal Disclaimer

The ROX 12.0 SPORT has a touch display, which you can use for almost any function or setting.
Functions like power on/off to start or stop the training and returning to the home screen
can be operated by the buttons, only.
An overview of the button functions is listed below:
1. BUTTON FUNCTIONS
TOGGLE - STOP/FINISH START/LAPS TOGGLE +
ON /OFF
HOME

To switch on the ROX 12.0 SPORT you must push the power button for about 3 seconds.
The display will light up and you can see the boot screen.
2. FIRST WAKE UP
NOTE:
In case the ROX 12.0 SPORT does not start, please charge it first!
The ROX 12.0 SPORT will start with a step by step first wake up sequence.
Follow the steps to set up the most important settings.
It is highly recommended to add your home WiFi. If connected, the ROX 12.0 SPORT can automatically upload
your training or check if there is a new update available.
Once you have finished the first wake up settings, you will get a short instruction on how to use the
ROX 12.0 SPORT. Please pay attention, to learn basics functions.
All settings are done,
and you will see the
home screen now.

You can see the following elements in the status bar:
3. SCREEN OVERVIEW
3.1 STATUS BAR
3.2 HOME SCREEN
GPS quality
(3 bars)
Battery status information
Clock
WiFi
(enabled when needed, only)
Status of the training
(started, paused, stopped)
The upper part is showing the active sport profile.
To enter the training, please push the play button
on the display.
In the lower part you will find the main menu with
different menu items. You can enter each one with
a single touch

Beside the main menu, the ROX 12.0 SPORT supports
short cut menus, where you can find all important
settings.
Please swipe from top to bottom, to open this menu.
If you swipe bottom-up, the navigation short cut menu
will appear.
3.3 SWIPING GESTURES (SUB-MENU)
4. HOME SCREEN
If you are a smartphone user, you know the home screen already. The ROX 12.0 is working in the same way.
You can adjust your settings and once you are done, simply push the home button to return to the home screen.
No need to push push the back button multiple times.
4.1 HOME SCREEN OVERVIEW
On the home screen you will find the following
menu items

4.1.1 OPEN TRAINING MENU
4.1.2 SPORT PROFILE SELECTION
4.1.3 NAVIGATION
To open the training menu you simply have
to push the play button in the colored area of
the home screen. Here you can customize the
training views to fit them to your needs.
Please check page 17 sport profiles for
detailed information).
Here you can see the training
time, if there is an ongoing
training.
Here you can select
different options to
create a route.
If you would like to change the
sport profile, please select the
“sport profile” button on the
display.
To learn more about sport profiles, please
check chapter 4.3.1. If you would like to
modify your sport profile, please go to
“settings ► sport profiles”.
Simply enter a destination or create a route
with multiple stops. To get more insides,
please check chapter 5.

4.1.4 TRACK
4.1.5 DATA SYNC.
All tracks which have been
imported from the DATA
CENTER, will be found here.
If you enter this menu item,
the ROX 12.0 SPORT will
automatically enable WiFi,
to be able to sync the data.
Further details about how to create and
transfer tracks can be found in chapter 6.
This is an overview page, to see the current
sync status.
