Silhouette Titan Notion Guide

1
Titan Notion Adjustment Instructions

The following must be considered when glazing:
Lens shape must be taken from the lens pattern or from the OMA Files.
DO NOT calculate the lens shape by scanning the eye rim.
The screwless, flexible eyerim lock (Flex-Lens-Lock) enables easy mounting of the lens
because of the elasticity.
Milling of the Lens
Flex-Lens
Lock-System

Frame on lens front.
When mounting from
behind there is a
danger of cracking the
lens.
Insert top of lens
on upper edge of
frame.
Push frame edge over
lens edge along the
temple.
Push frame edge
over lens edge at
the bridge.


Glazing

Incline with Inclination Lever
Hold side part and frame eye rim firmly by hand.
* Fabric gloves or a piece of leather will help to hold in place.
Place inclination lever on side part and hinge and adjust requested inclination angle.

AC 400
from advanced
glazing box P0032


Inclination by Hand
Hold side part firmly at frame eye rim. Cover temple edge with hinge
closely. Adjust inclination at Titanium part.





Temple Disassembly
Hold Titanium side part firmly at the frame eye rim.
Bend temple slighty and pull out of the disc hinge in a straight motion.
Please Note: Force may only be applied backwards. Do not twist temple.



Hinge Greasing
Grease inside loop of hinge with high precision lubricant teflon. If neccessary clean
beforehand. Attach plastic plate and mount temple.
P0030

Fixing Hinge-BLS
Place hinge plates form-fit on both sides of hinge loop.
NOTE: The oval shape of the plastic BLS plug system will ensure correct positioning.
BLS 89

Place temple exactly at the slot of the BLS-hinge and click it in carefully until
it stops.
Temple Assembly

Temple Curving – Adjustment
Adjust curving of temple in large
movements.
Metal needle inside temple enables cold
adjustment of temple end. Do Not bend.
