Singer Supreme Dry SDHM-12L User manual

SDHM-12L & SDHM-16L
Dehumidifier
Αφυγραντήρας
GB INSTRUCTION MANUAL
GR ΒΙΒΛΙΟ ΟΔΗΓΙΩΝ
R290

GB ENGLISH....................................... 3
GR EΛΛΗΝΙΚΑ .................................. 29

3
ENGLISH
This product is using the Environment
friendly refrigerant R290. R290 has no
damaging influence on the ozone layer
(ODP), a negligible greenhouse effect
(GWP) and is available worldwide. This
refrigerant is tasteless and combustible,
moreover, it can burn and explode under
certain condition. Special precautions must
be taken into consideration before using
and maintenance of this appliance due to
the coolant's high flammability: so please
read this user manual carefully before using
and maintenance.
SYMBOLS FROM THE UNIT AND USER MANUAL
This unit uses a flammable refrigerant gas.
If refrigerant gas leaks and comes in contact
to fire or heating part, it will be created harmful
gas and there is risk of fire.
Read the USER MANUAL carefully before op-
eration and maintenance.
Further information is available in the USER
MANUAL and the SERVICE MANUAL.
Service personnel are required to carefully
read the USER and SERVICE MANUAL before
operation and maintenance.
Additional warning for appliance with R290 refrigerant gas
(refer to the rating plate for the type of refrigerant gas used).
R290 refrigerant gas complies with European environmental
directives.

4
ENGLISH
WARNINGS (FOR USING R290 REFRIGERANT ONLY)
Appliance shall be installed, operated and
stored in a room with a floor area larger than
4 m2.
This product needs to be in a room without
continuously operating ignition sources (for
example: open flames, an operating gas appli-
ance, an operating electric heater or stove with
open fire, etc.)
• Be aware that the refrigerants may not contain an odor.
• Do not pierce or burn.
• Do not use means to accelerate the defrosting process or to
clean, other than those recommended by the manufacturer.
• Compliance with national gas regulations shall be observed.
• Keep ventilation openings clear of obstruction.
• The appliance shall be stored so as to prevent mechanical
damage from occurring.
• A warning that the appliance shall be stored in a well-ventilat-
ed area where the room size corresponds to the room area as
specified for operation.
• Any person who is involved with working on or breaking into a
CAUTION: RISK OF FIRE
FLAMMABLE MATERIAL
READ THE MAΝUAL CAREFULLY
BEFORE USING THE APPLIANCE.
MAKE SURE TO SAVE THIS MANUAL
FOR FUTURE REFERENCE.

5
ENGLISH
refrigerant circuit should hold a current valid certificate from an
industry-accredited assessment authority, which authorizes
their competence to handle refrigerants safely in accordance
with an industry recognized assessment specification.
• Servicing shall only be performed as recommended by the
equipment manufacturer. Maintenance and repair requiring
the assistance of other skilled personnel shall be carried out
under the supervision of the person competent in the use of
flammable refrigerants.
IMPORTANT SAFETY INFORMATION
• Avoid installation behind a door.
• Use only with the supply voltage specified on the rating plate
of the Dehumidifier.
• Before installing, cleaning and servicing turn off the power and
unplug the unit.
• Do not place appliance close to a radiant heat source.
• Do not use the appliance near flammable gas of combustibles,
such as gasoline, bezene, thinner, etc.
• Do not immerse in liquid or allow liquid to run into the interior of
the appliance, as this could create an electrical shock hazard.
• Do not use this appliance on a wet surface, or where it can fall
or be pushed into water.
• Do not reach for an appliance that has fallen into water. Switch
off at supply and unplug immediately.
• Do not operate any appliance with a damaged cord, plug or
after the appliance malfunctions or has been dropped or dam-
aged in any manner. Refer appliance to a qualified electrical

6
ENGLISH
person for examination, electrical or mechanical adjustment,
service or repair before further use.
• Do not operate appliance with wet hands.
• This appliance is intended for indoor household use only and
not for commercial or industrial use.
• Use this appliance only as described in this manual. Any other
use is not recommended by the manufacturer and may cause
fire, electric shock or injury.
• Do not use this appliance in a window as rain may cause elec-
tric shock.
• Do not use abrasive cleaning products on this appliance. Wipe
with a soft cloth to clean the exterior. Always remove plug from
the mains supply before cleaning.
• Switch off the appliance before changing its position.
• Do not remove the power plug from the socket by pulling the
cord – grip the plug instead.
• Always unplug appliance when not in use.
• Do not run cord under carpeting, throw rugs or runners etc.
Arrange cord away from areas where it is likely to be tripped
over.
• Do not modify power cord length or share the outlet with other
appliances.
• Disconnect the power if strange sounds, smell or smoke
comes from it.
• Do not place heavy object on the power cord and take care so
that the cord is not compressed.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabili-
ties, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.

7
ENGLISH
• Young children should be supervised to ensure they do not
play with the appliance.
• If the supply cord is damaged, it must be replaced by a quali-
fied electrical person in order to avoid a hazard.
• Do not spray pesticides or flammable gas near the unit.
• Do not scrape the unit using sharp objects.
• Do not splash any oil or water into the unit.
• Install the unit on a flat, horizontal surface to avoid vibration
and noise.
• Do not put heavy objects on the appliance.
• Do not cover the intake or exhaust opening with cloths or tow-
els.
• Do not drink or use the water drained from the unit.
• Do not take the water tank out during operation.
• Empty the water tank before moving the unit to avoid water
spilling.
• Do not tilt the unit to prevent water from spilling and damaging
the machine.
• Do not insert or allow slim rods or other foreign objects to enter
any opening, as this may cause an electric shock, fire or dam-
age to the appliance.
• Never insert your finger or other foreign objects into grills or
openings. Take special care to warn children of these dangers.
• If any abnormal situations occur, immediately turn off the pow-
er supply.

8
ENGLISH
SERVICE & REPAIR
1. For service or repair under warranty, please contact the au-
thorized service company that is mentioned on the guarantee
card that accompanies the product.
2. Do not operate any product with a damaged cord or plug. If
the supply cord is damaged, return the appliance to a SINGER
service center for examination repair or adjustment. Do not at-
tempt to dismantle any part of the appliance. This should only
be done at an authorized SINGER service centre.
3. The partial or total non-respect of the safety instructions in the
present instruction manual will automatically release Singer of
any type of responsibility in case of malfunction of the machine
or injuries to persons or animals.
4. In case of manipulation, repairing or any modification of the
machine made by unqualified persons or in case of improper
use, the guarantee will be automatically cancelled.
PRODUCT DESCRIPTION
The dehumidifier is used to remove excessive moisture from the
air. The resulting reduction in relative humidity protects buildings
and their contents from the adverse effects of excess humidity.
Before Initiation
• To avoid any damage, place the unit in an upright position for
at least 24 hours before initiation.
• Make sure that the air outlet and air inlet are never blocked.
• Only operate the unit on a horizontal surface to ensure no wa-
ter leaks out.
• After removing the packaging, make sure that the appliance is
in good condition.
• Do not allow children to play with the packaging materials as
there is risk of suffocation.

9
ENGLISH
OVERVIEW
Front
FILTERS
ACTIVE CARBON FILTER (BLACK): is the filter most used
to remove gases. The result is purifying the air from contami-
nants and particulates.
SILVER ION FILTER succeeds disinfection and sterilization
HEPA (AVAILABLE ONLY IN SDHM-16L SUPREME DRY)
Helps to remove dust and microbes, drastically reducing the
chances of allergies and diseases
Air Outlet
Power switch
Air inlet Handle
Water tank
3-color humidity
indicator
Back

10
ENGLISH
SPECIFICATIONS
MODEL No. SDHM-12L SUPREME
DRY
SDHM-16L SUPREME
DRY
Dehumidify Capacity 12L/day (30ºC 80%RH) 16L/day (30ºC 80%RH)
Rated voltage/Frequency AC220-240V/50Hz AC220-240V/50Hz
Rated power input 210W (27°C 60% RH) 240W (27°C 60% RH)
Max. Input Power 250W (32°C 90% RH) 290W (32°C 90% RH)
Rated Input Current 1.26A (27°C 60% RH) 1.22A (27°C 60% RH)
Max. Input Current 1.45A (32°C 90% RH) 1.40A (32°C 90% RH)
Water Tank Capacity 2.5L 3.5L
Air volume 120m³/h 190m³/h
Noise Level ≤42dB(A) ≤48dB(A)
Refrigerant Charge R290/45(g) R290/55(g)
Product Dimensions
(LxWxH)
250x250x460mm 260x260x618mm
Net Weight 10kg 13kg
Suction Side Pressure 1.2MPa 1.2MPa
Discharge Side Pressure 2.5MPa 2.5MPa
BEFORE FIRST USE
Install the unit in a convenient position as per the diagram shown below.
minimum 20cm
minimum 20cm
minimum 20cm
minimum 20cm
minimum 20cm

11
ENGLISH
No
te
s
:
•
Be
f
ore movin
g
the unit, remove any water
f
rom the water tank
.
•
To save ener
g
y, keep win
d
ows an
d
d
oor close
d
w
h
en unit is runnin
g
.
•
Plea
s
e in
s
tall the unit on a
fl
at horizontal
s
ur
f
ace
.
O
PERATI
O
NS
High fan speed
Humidity digital slide setting
Timer
Dry clothes
Humidity Auto Defrost
Water tank
full
Power
Low fan speed
ModeTimerSleep Ventilation
Ordinary Dehumidification
Continuous Dehumidification

12
ENGLISH
Indication
3-color Ambient humidity indicator on the front part of the appliance
BLUE color shows Ambient humidity <50%
GREEN color shows Ambient humidity between 50% and 70%
RED color shows Ambient humidity >70%
POWER:
Press the POWER button to turn the unit on or off.
HUMIDITY DIGITAL SLIDE SETTING:
Slide the humidity digital slide setting to set the desired dehumidification de-
gree (30%-80%). Pressing the negative mark humidity shows 30% and then
by sliding you can be set in 5% increments from 30, 35, 40, 45,…, 80.(positive
mark).
MODE:
Press the MODE button to select the mode of operation. Four different modes
are possible:
1. ORDINARY DEHUMIDIFYING mode: Ordinary mode is the default mode
when the power is on and appliance operate under default humidity 55%
RH. Button lights up and the fan speed is low. Both fan speed and hu-
midity can be adjusted under ordinary mode according to the environmental
humidity.
2. CONTINUOUS (LOW) DEHUMIDIFYING mode : Press the MODE button
to select this mode . Here, the unit always works with low fan speed for
any room humidity and the humidity cannot be changed.
3. VENTILATION Mode: Press the MODE button once to select this mode .
Here, the unit works only the fan. Only fan speed can be adjusted to high or
low speed but the humidity cannot be changed. The environmental humidity
can be shown on the panel.
4. CLOTHES DRYING mode: Press this button to switch to continuous
clothes drying mode.
There will be high fan speed under this mode and the humidity cannot be
changed. The environmental humidity can be shown on the panel.

13
ENGLISH
FAN :
Press the FAN button to select this mode. You can switch to low or high fan
speed by pressing the FAN button again.
TIMER:
Press the button to determine off or on time (0-24h)
Setting of timed shutdown
Under the operation status of the machine, press the [Timer] key to adjust the
time from 1 hour to 24 hours. Each press will increase the set time by one hour
and after 24 hours, the figure will return to 1 for another circulation. User could
also long press the [Timer] key and the time increases in rotation. When the
set time is due, the machine will be shut down automatically. After the setting,
if there’s no action on the [Timer] key within 5 seconds, it means the timing
has been confirmed. Under the timed shutdown status, the key light above the
[Timer] is on.
Setting of the timed startup
Under the standby status of the machine, the way to adjust the time is the
same as that of the timed shutdown. After the setting, if there is no action on
the [Timer] key within 5 seconds, it means the timing has been confirmed.
Under the timed startup status, the key light above the [Timer] is on and the
control screen displays the set time.
SLEEP MODE:
Press this button, the button lights up and the Sleep mode turns on. All indica-
tions become dark. Touch any button to activate the display. Touch the Sleep
button again to exit this mode.
WATER TANK FULL
When the water tank is full for 5 seconds, the indicator light shows red, the
buzzer will warn for 20 times and the compressor will stop automatically. At this
time, empty the water tank and put it back to correct position.
AUTO DEFROST-LOW TEMPERATURE WORK
Dehumidifier may defrost automatically if it is operated in room temperature
less than ≤23℃.

14
ENGLISH
Defrosting function may start up and operate for some time (about 5 minutes)
automatically every 25 minutes or even longer according to room temperature:
• 18℃< temperature ≤23℃; the machine will automatically defrost every 120
minutes. The power indicator will flash continuously, and the fan will keep
working at high speed.
• 12℃< temperature ≤18℃the machine will automatically defrost every 25
minutes. The power indicator will flash continuously, and the fan will keep
working at high speed.
• 5℃< temperature ≤12℃the machine will automatically defrost every 20
minutes. The power indicator will flash continuously, and the fan will keep
working at high speed.
• During the defrosting operation, the dehumidification function may in-
termit.
• Please do not turn off the switch or pull out the power plug during the
defrosting operation.
Clothes drying: Place the unit in a room with closed doors
along with the clothes rack and switch on the appliance by
pressing the Continuous (clothes drying) mode button.
LED DISPLAY

15
ENGLISH
ORDINARY DEHUMIDIFYING mode
CONTINUOUS (LOW) DEHUMIDIFYING mode
VENTILATION Mode
CLOTHES DRYING mode
ROOM HUMIDITY
TIMER mode
WATER DRAINAGE
Empty the tank
●Grab the notch at the side of the tank and pull it out with both hands.
Take it slowly and steadily in case of spilled water.
●Hold the tank by the handle and carry it gently. Empty the water.
●Put the water tank back in position. The dehumidifier automatically starts
working again.
Handle

16
ENGLISH
CAUTIONS
1. Do not remove the float in the water tank, otherwise, the machine cannot
start work or power on.
2. If the water tank is dirty, clean by cool water or warm water, cannot use
cleaner, steel wool, chemical rag duster, gas oil, benzene, thinner or other
solvent to clean it, otherwise, it would damage the water tank and lead to
leakage.
3. When you place the water tank back into place, please use two hands to
push the water tank into the machine and force to the right position. If you
do not place the water tank in the right position, the machine would not
power on or start.
Continuous Drainage
This dehumidifier has a continuous drainage hole which used to be connected
by a plastic tube, then the dehumidification water can be continuous drainage.
• Turn off the unit and unplug, take out the water tank and then insert the pipe
• Use a water hose to connect the water outlet.
• For continuous drainage, the end of the hose should not be submerged in
water to prevent it from being blocked or damaged.
Remove the
water tank
Inserting pipe

17
ENGLISH
MAINTENANCE
NOTE:TURNOFFTHEUNITANDUNPLUGITBEFOREANYMAINTENANCE
OR REPAIR TO AVOID ELECTRIC SHOCKS.
Cleaning
Unplug the unit before cleaning. Clean the housing with a soft moist cloth.
Do not use chemical solvents (such as benzene, alcohol, gasoline).
The surface may be damaged or even the whole case may be deformed.
Do not spray water directly on the unit.
Filters
The unit is equipped with:
• air filter common (washable)
• active carbon filter (non-washable).
• silver ion filter (non-washable).
• HEPA filter* (non-washable)
*available only in model SDHM-16L Supreme Dry.
If the filter is blocked with dust, the efficiency of it will reduce.
Clean the washable filter every 2 weeks and replace the other filters after using
for 6~8 months.
HOW TO CLEAN THE FILTER
• Take out the filter
Filter
frame
Air filter
common
Carbon active
filter
Silver ion
filter
HEPA
filter

18
ENGLISH
• Clean the filter
1) Wash the common air filter by immersing it gently into warm water (about
40°) with a neutral detergent, rinse it and dry it thoroughly in a shaded place.
2) The other 3 filters CANNOT be cleaned. When the filter gets very dirty, re-
place it with a new filter.
NOTE: Order placed the filters (starting from outside to inside):
Air filter common >>> silver ion filter>>>carbon active filter>>>
HEPA filter>>>
Dehumidifier storage
If the dehumidifier will not be used for an extended period of time:
1. Drain the water tank completely and make sure there is no more water
stocked inside.
2. Unplug the unit and fold up the power supply cord.
3. Remove and clean the air filter, allow it to dry completely and reinstall it.
4. Stand the unit upright, and store the dehumidifier in a cool, dry location,
away from direct sunlight, extreme temperature and excessive dust.

19
ENGLISH
TROUBLESHOOTING
Before contacting the service, review this list which includes common incidents
that are not result of a defect in the device.
Problem Possible Cause Solution
Not working
No power supply Connect to a function-
ing outlet and switch on
Water Full Indication
Flashes
Drain water tank and
reset it, or re-position
the water tank to right
place
Small dehumidifying
capacity
Is the air filter clogged? Clean the air filter as
instructed
Is the intake duct or
discharge duct ob-
structed?
Remove the obstruction
from the discharge duct
or intake duct.
Loud noise when run-
ning
Is the machine put in
the plat place?
Put the machine on the
plat ground
Is the filter clogged? Wash the filter
Stop operation dur-
ing the dehumidifying
process
Whether the room
temperature is too high
or too low.
The dehumidifier may
start automatically
when the room tem-
perature be normal
The clothing cannot be
dry fast
Whether the room tem-
perature is very low
The wet clothing may
dry more slowly in low
temperature
PRODUCT REPAIR FOR APLLIANCES CONTAINING R290
Warnings
• Do not exceed impedance greeter than 0.236ohm in supply the appli-
ance is connected to. Failure to comply may lead the supply authority
to impose restrictions to connection. Please consult your energy supply
authority if the use of equipment exceeds 0.236 ohm.
• All operators or refrigeration circuit maintenance personnel should obtain
a valid certificate issued by an industry-approved assessment agency to

20
ENGLISH
determine their qualification for safe disposal of refrigerants as required
by the industry-approved assessment specification.
• Remember the environment when disposing of packaging around the ap-
pliance and when the appliance has reached its by date.
• A warning that the appliance shall be stored in a well-ventilated area
where the size corresponds to the room area as specified for operation.
• The appliance shall be stored to prevent mechanical damage from occur-
ring.
• Information for spaces where refrigerant pipes are allowed, including
statements
• that the installation of pipework shall be kept to a minimum.
• that pipework shall be protected from physical damage and, in the case
of flammable refrigerants, shall not be installed in an unventilated space.
• that compliance with national gas regulations shall be observed.
• that mechanical connections shall be accessible for maintenance pur-
poses.
• that, for appliances containing flammable refrigerants, the minimum floor
area of the room shall be mentioned in the form of a table or a single
figure without reference to a formula.
• A warning to keep any required ventilation openings clear of obstruction.
• A notice that servicing shall be performed only as recommended by the
manufacturer.
• A warning that ducts connected to an appliance shall not contain a poten-
tial ignition source.
• When the portable air conditioner or dehumidifier is turned on, the fan can
work continuously stable under normal conditions to provide the minimum
air volume of 100m3/h even when the compressor is closed due to the
temperature controller.
• Do not pierce or burn.
• Use only implements recommended by the manufacturer for defrosting or
cleaning.
• Do not perforate any of the components in the refrigerant circuit. Refriger-
ant gas may be odorless.
• Use care when storing the appliance to prevent mechanical faults.
• Only persons authorized by an accredited agency certifying their compe-
tence to handle refrigerants in compliance with sector legislation should
