Skov DA 1700 LPC -3 Manual

DA 1700 LPC -3
Dual Actuator Wall Fan
Technical User Guide
604493 • 2022-03-01
English For other language variants of this document we refer to:
Español Para otras variantes del idioma de este documento, visite:
Français Pour les versions dans d'autres langues de ce document veuillez consulter:
http://docs.skov.com/1195

DA 1700 LPC -3
2 Technical User Guide
Product and Documentation Changes
SKOV A/S reserves the right to change this document and the product herein described without further notice.
In case of doubt, please contact SKOV A/S.
The date of change appears from the front and back pages.
IMPORTANT!
Notes concerning alarm systems
Breakdowns, malfunctions or faulty settings may cause substantial damage and financial losses when regulat-
ing and controlling the climate in a livestock house. It is therefore essential to install a separate, independent
alarm system that monitors the house climate concurrently with the climate and production controller. According
to EU-directive No. 98/58/EU, an alarm system must be installed in all mechanically ventilated houses.
We would like to draw your attention to the fact that the product liability clause of general terms and conditions
of sale and delivery specifies that an alarm system must be installed.
Note
• All rights belong to SKOV A/S. No part of this manual may be reproduced in any manner whatsoever without
the expressed written permission of SKOV A/S in each case.
• All reasonable efforts have been made to ensure the accuracy of the information contained in this manual.
Should any mistakes or imprecise information occur in spite of this, SKOV A/S would appreciate being noti-
fied thereof.
• Irrespective of the above, SKOV A/S shall not accept any liability with regard to loss or damage caused or
alleged to be caused by reliance on any information contained herein.
• Copyright by SKOV A/S.

DA 1700 LPC -3
1 Product description........................................................................................................................................5
2 Product survey ...............................................................................................................................................6
2.1 DA 1700 wall fan ........................................................................................................................ 6
2.2 Accessories................................................................................................................................ 7
3 Mounting guide.............................................................................................................................................10
3.1 Recommended tools................................................................................................................ 10
3.2 Placement of wall fan .............................................................................................................. 12
3.3 Preparing hole in wall.............................................................................................................. 12
3.3.1 Necessary space for wall fan with LPC motor controller............................................................ 12
3.3.2 Measurements for round hole in sandwich wall ......................................................................... 13
3.3.3 Measurements for square hole in concrete and brick wall......................................................... 14
3.3.4 Measurements for square hole in wooden wall.......................................................................... 15
3.4 Measure and saw out the holes.............................................................................................. 16
3.5 Press the front panel together................................................................................................ 17
3.6 Click and point the ventilation ducts together...................................................................... 17
3.7 Mounting ventilation duct on front panel .............................................................................. 18
3.8 Mounting center pillar ............................................................................................................. 19
3.9 Mounting actuator.................................................................................................................... 21
3.10 Mounting the center pillar on the ventilation duct................................................................ 23
3.11 Mounting in wall....................................................................................................................... 24
3.12 Mounting impeller .................................................................................................................... 25
3.13 Mounting bottom motor suspension .....................................................................................25
3.14 Mounting lifting kit................................................................................................................... 26
3.15 Mounting the motor in the fan housing ................................................................................. 27
3.16 Mounting top motor suspension ............................................................................................ 27
3.17 Cabling from motor and actuator ........................................................................................... 28
3.18 Foaming and pointing of the outside..................................................................................... 29
3.19 Pointing of the inside .............................................................................................................. 30
3.20 Mounting of wall cover outside .............................................................................................. 31
3.21 Mounting the cone ................................................................................................................... 32
3.22 Mounting of inside safety net ................................................................................................. 33
3.23 Mounting of accessories......................................................................................................... 34
3.23.1 Mounting of outside safety net ................................................................................................... 34
3.23.2 Mounting storm protection on outside safety net ....................................................................... 35
3.23.3 Mounting the storm protection wire for cone.............................................................................. 35
3.23.4 Mounting outside suspension .................................................................................................... 36
3.23.5 Mounting support kit................................................................................................................... 37
3.23.6 Mounting insulation plate ........................................................................................................... 38
4 Installation guide ..........................................................................................................................................39
4.1 Electrical connection............................................................................................................... 39
4.1.1 Disclaimer at retrofitting fans ..................................................................................................... 39
4.1.2 Mains supply dimensioning regarding harmonic distortion ........................................................ 39
4.1.3 Overvoltage protection............................................................................................................... 39
4.1.4 Position of motor controller/frequency converter ....................................................................... 40
4.1.5 Mounting distances for the motor controller/frequency converter .............................................. 40
4.1.6 Cabling into the motor controller/frequency converter ............................................................... 40
4.1.7 Cabling to connection box and LPC motor controller................................................................. 41
4.2 Connection in the LPC motor controller/frequency converter ............................................ 42
4.2.1 Terminals for three-phase supply .............................................................................................. 43
Technical User Guide

DA 1700 LPC -3
Technical User Guide
4.2.2 Terminals for power supply of fan.............................................................................................. 43
4.2.3 Signal terminals ......................................................................................................................... 43
4.3 LED indication on display ....................................................................................................... 44
4.4 Operation .................................................................................................................................. 44
4.4.1 Change 10-0 V analog input into 0-10 V.................................................................................... 46
4.5 Emergency opening for shutter motor .................................................................................. 48
4.5.1 Fan active at power failure......................................................................................................... 48
4.5.2 Fan not active at power failure................................................................................................... 49
4.6 Connection to actuator............................................................................................................ 50
4.7 Connection of extra 24 V power supply................................................................................. 51
4.8 Jumper setting ......................................................................................................................... 52
4.9 General information about circuit diagrams ......................................................................... 53
4.9.1 Color code.................................................................................................................................. 53
4.9.2 Power supply isolator................................................................................................................. 53
4.9.3 Letter code ................................................................................................................................. 53
4.10 Cable plans and circuit diagrams........................................................................................... 54
4.10.1 Circuit diagram for OFF/AUTO/ON switch ................................................................................. 54
4.10.1.1 DA 1700 with LPC ..................................................................................................................... 54
4.10.2 DA 1700 LPC -3 with alarm relay .............................................................................................. 55
4.10.2.1 Cable plan.................................................................................................................................. 55
4.10.2.2 Circuit diagram........................................................................................................................... 55
4.10.3 DA 1700 LPC -3 3x400 V .......................................................................................................... 56
4.10.3.1 Cable plan.................................................................................................................................. 56
4.10.3.2 Terminals in LPC 3 x 400 V fan ................................................................................................. 56
4.10.3.3 Dual actuator control box LPC ................................................................................................... 57
4.10.3.4 Circuit diagram........................................................................................................................... 57
5 Maintenance instructions ............................................................................................................................58
5.1 Cleaning.................................................................................................................................... 58
5.1.1 Fan............................................................................................................................................. 58
5.1.2 Motor controller/frequency converter ......................................................................................... 58
5.2 Recycling/Disposal .................................................................................................................. 58
6 Trouble shooting instructions.....................................................................................................................59
6.1 Resetting errors ....................................................................................................................... 61
7 Technical data...............................................................................................................................................62
7.1 DA 1700-6 LPC -3 ACT 3x400 V ............................................................................................. 62
7.1.1 ErP/Ecodesign DA 1700-6 LPC -3 ACT 400V3 50/60 Hz ......................................................... 64
7.2 Actuator .................................................................................................................................... 65
8 Dimensioned sketch.....................................................................................................................................66
8.1 Wall fan with LPC motor controller ........................................................................................ 66
8.2 LPC motor controller ............................................................................................................... 66
8.3 Light trap .................................................................................................................................. 67

DA 1700 LPC -3
Technical User Guide 5
1 Product description
DA 1700 dual actuator wall fan is a flange-mounted corrosion-free fan with cone and motor-controlled shutter.
The fan is supplied in one version focused on low energy consumption and one version focused on maximizing
air output.
DA 1700 dual actuator is characterized by having a particularly tightly closed shutter, which prevents unwanted
air movement when the fan is not in operation, and a direct-driven motor to reduce motor maintenance.
DA 1700 dual actuator is specially designed for harsh livestock house environments. This applies to both cli-
matic and electrical influences.

DA 1700 LPC -3
6 Technical User Guide
2 Product survey
2.1 DA 1700 wall fan
For every 100 pcs. DA 1700 wall fans, 1 pcs. DA 1700 lifting kit and mounting parts are supplied. For
every 101-200 pcs., 2 pcs. DA 1700 lifting kit and mounting parts, etc. are supplied.
The lifting kit and mounting parts consist of:
DA 1700 lifting kit
safety straps
extra DA 1700 mounting parts.
3 pcs. technical user guides for the DA 1700 wall fan in English.

DA 1700 LPC -3
Technical User Guide 7
435346 DA 1700-6 LPC -3 ACT 400V3 50/60 Hz
Fan control method - stepless.
The dual actuator is only recommended for areas with particularly strong
wind conditions, to ensure an optimal climate for the animals.
Note that the dual actuator solution has a higher current consumption com-
pared to the standard shutter motor.
Safety net outside must be mounted to comply with CE marking, in coun-
tries where this is required.
LPC motor controller
PM motor 1,5 kW.
0,7 m motor cable.
Supplied with mounting parts for assembly of DA 1700.
ErP 2015 approved.
435346 should not be used for negative pressure higher than 100 Pa.
2.2 Accessories
435327 DA 1700 safety net outside
DA 1700 outside safety net used if extra safety is required.
1 per wall fan.
Supplied with mounting parts.
Storm protection for mounting on outside net is included DA 1700.
If a DA 1700 outside safety net is deselected:
• A safety guard must be established.
• The 435337 DA 1700 storm protection wire for cone must be bought
separately.
• The requirements of the International Standard for Safety of machinery
ISO 13857 must be complied with.
435337 DA 1700 storm protection wire for cone
The DA 1700 storm protection wire for cone is used, if the DA 1700 outside
safety net is deselected.
1 per wall fan.
435375 DA 1700 outside suspension
Used if required if DA 1700 is sagging and has not maintained its round-
ness.
Delivered without screws for fastening.
1 per wall fan.

DA 1700 LPC -3
8 Technical User Guide
435368 DA 1700 support kit
Used if required if DA 1700 is sagging and has not maintained its round-
ness.
Delivered with mounting parts.
1 per wall fan.
560356 DA 1700 lifting kit and mounting parts ACT
DA 1700 lifting kit is used for mounting the fan motor.
Includes:
• 1 x DA 1700 lifting kit
• 1 x safety strap
• 1 x DA 1700 mounting parts
• 3 x technical user guides for the DA 1700 wall fan in English.
Order only if additional DA 1700 lifting kit and mounting parts are required.
435319 DA 1700 screw kit
DA 1700 screw kit can be used for mounting DA 1700 in wall.
1 per wall fan +
1 per wall cover
Includes:
• 21 x tapping screw 4.8x70 pan TX25 A2 ISO14585C
• 21 x washers ø6.4/ø18x1.6 A2 DIN9021
435317 DA 1700 insulation plate
The plate is used to minimize draughts and heat loss during cold periods,
when DA 1700 is not in use.
The plate should always be used if the dimensioned outside temperature is
less than 0°C.
Supplied with mounting parts.
1 per wall fan.
435328 DA 1700 bracket for insulation plates
DA 1700 bracket for insulation plates is used for storage of insulation plates
when they are not in use, i.e. typically during the summer.
1 per 5 DA 1700 insulation plates.

DA 1700 LPC -3
Technical User Guide 9
435325 DA 1700 light trap black out
The light trap is mounted and removed manually.
Supplied as an unassembled unit incl. brackets.
Used for DA 1700 wall fan if a large amount of dimming is required in the
livestock house.
Light reduction factor 11.000.000:1.
The light trap reduces the air output of the fan by approx. 28%.
For mounting light trap see Mounting guide for DA 1700 light trap black out.
435326 DA 1700 light trap brown out
The light trap is mounted and removed manually.
Supplied as an unassembled unit incl. brackets.
Used for DA 1700 wall fan if dimming is required in the livestock house.
Light reduction factor 17.000:1.
The light trap reduces the air output of the fan by approx. 15 %.
For mounting light trap see Mounting guide for DA 1700 light trap brown
out.

DA 1700 LPC -3
10 Technical User Guide
3 Mounting guide
Check that the parts ordered are present and undamaged before starting work. Please read through the entire
guide before starting assembly and fitting.
If the wall fan is installed in areas with risk of ice/snow slide, precautions must be made
to avoid damage to the wall fan.
3.1 Recommended tools
A list of the recommended tools for mounting purposes can be seen below.
Item Description
Cordless drill
Screwdriver bits
Drill kit
Atomizer
Sealant gun
Hammer
Utility knife
Wedge
Marker pen
Torque wrench
Tape measure
Combination spanner kit
Screwdriver
