Skov DA 1700 Manual

DA 1700 dual actuator
Wall Fan
Technical User Guide
604420 • 2021-08-17
English For other language variants of this document we refer to:
Español Para otras variantes del idioma de este documento, visite:
Français Pour les versions dans d'autres langues de ce document veuillez consulter:
http://docs.skov.com/1195

DA 1700 dual actuator
2 Technical User Guide
Product and Documentation Changes
SKOV A/S reserves the right to change this document and the product herein described without further notice.
In case of doubt, please contact SKOV A/S.
The date of change appears from the front and back pages.
Note
• All rights belong to SKOV A/S. No part of this manual may be reproduced in any manner whatsoever without
the expressed written permission of SKOV A/S in each case.
• All reasonable efforts have been made to ensure the accuracy of the information contained in this manual.
Should any mistakes or imprecise information occur in spite of this, SKOV A/S would appreciate being noti-
fied thereof.
• Irrespective of the above, SKOV A/S shall not accept any liability with regard to loss or damage caused or
alleged to be caused by reliance on any information contained herein.
• Copyright by SKOV A/S.

DA 1700 dual actuator
1 Product description........................................................................................................................................5
2 Product survey ...............................................................................................................................................6
2.1 DA 1700 wall fan ........................................................................................................................ 6
2.2 Accessories................................................................................................................................ 7
3 Mounting guide.............................................................................................................................................10
3.1 Recommended tools................................................................................................................ 10
3.2 Placement of wall fan .............................................................................................................. 12
3.3 Preparing hole in wall.............................................................................................................. 12
3.3.1 Necessary space for wall fan without LPC motor controller....................................................... 12
3.3.2 Necessary space for wall fan with LPC motor controller............................................................ 12
3.3.3 Measurements for round hole in sandwich wall ......................................................................... 13
3.3.4 Measurements for square hole in concrete and brick wall......................................................... 14
3.3.5 Measurements for square hole in wooden wall.......................................................................... 15
3.4 Measure and saw out the holes.............................................................................................. 16
3.5 Press the front panel together................................................................................................ 17
3.6 Click and point the ventilation ducts together...................................................................... 17
3.7 Mounting ventilation duct on front panel .............................................................................. 18
3.8 Mounting center pillar ............................................................................................................. 19
3.9 Mounting actuator.................................................................................................................... 21
3.10 Mounting in wall....................................................................................................................... 23
3.11 Mounting impeller .................................................................................................................... 24
3.12 Mounting bottom motor suspension .....................................................................................24
3.13 Mounting lifting kit................................................................................................................... 25
3.14 Mounting the motor in the fan housing ................................................................................. 26
3.15 Mounting top motor suspension ............................................................................................ 26
3.16 Cabling from motor and actuator ........................................................................................... 27
3.17 Foaming and pointing of the outside..................................................................................... 28
3.18 Pointing of the inside .............................................................................................................. 29
3.19 Mounting of wall cover outside .............................................................................................. 30
3.20 Mounting the cone ................................................................................................................... 31
3.21 Mounting of inside safety net ................................................................................................. 32
3.22 Mounting of accessories......................................................................................................... 33
3.22.1 Mounting of outside safety net ................................................................................................... 33
3.22.2 Mounting storm protection on outside safety net ....................................................................... 34
3.22.3 Mounting the storm protection wire for cone.............................................................................. 34
3.22.4 Mounting outside suspension .................................................................................................... 35
3.22.5 Mounting support kit................................................................................................................... 36
3.22.6 Mounting insulation plate ........................................................................................................... 37
4 Installation guide ..........................................................................................................................................38
4.1 Electrical connection............................................................................................................... 38
4.1.1 Disclaimer at retrofitting fans ..................................................................................................... 38
4.1.2 Mains supply dimensioning regarding harmonic distortion ........................................................ 38
4.1.3 Cabling to connection box and LPC motor controller................................................................. 38
4.1.4 Cabeling and placement of LPC motor controller ...................................................................... 39
4.2 Connection in the LPC motor controller................................................................................ 40
4.2.1 Terminals for power supply........................................................................................................ 41
4.2.2 Terminals for power supply of fan.............................................................................................. 42
4.2.3 Signal terminals ......................................................................................................................... 42
4.2.4 Terminals on relay module (accessories) .................................................................................. 42
Technical User Guide

DA 1700 dual actuator
Technical User Guide
4.3 LED indication on the motor controller ................................................................................. 43
4.4 Alarms....................................................................................................................................... 43
4.5 Emergency opening for shutter motor .................................................................................. 44
4.5.1 Fan active at power failure......................................................................................................... 44
4.5.2 Fan not active at power failure................................................................................................... 45
4.6 Connection to actuator............................................................................................................ 46
4.7 Connection of extra 24 V power supply................................................................................. 47
4.8 Jumper setting ......................................................................................................................... 48
4.9 General information about circuit diagrams ......................................................................... 49
4.9.1 Color code.................................................................................................................................. 49
4.9.2 Power supply isolator................................................................................................................. 49
4.9.3 Letter Code ................................................................................................................................ 49
4.10 Cable Plans and Circuit Diagrams ......................................................................................... 50
4.10.1 Circuit diagram for OFF/AUTO/ON switch ................................................................................. 50
4.10.1.1 DA 1700 with LPC ..................................................................................................................... 50
4.10.1.2 DA 1700 ON/OFF ..................................................................................................................... 51
4.10.2 DA 1700 LPC with alarm relay .................................................................................................. 52
4.10.2.1 Cable plan.................................................................................................................................. 52
4.10.2.2 Circuit diagram........................................................................................................................... 52
4.10.3 DA 1700 LPC 3x400 V .............................................................................................................. 53
4.10.3.1 Cable plan.................................................................................................................................. 53
4.10.3.2 Terminals in LPC 3 x 400 V fan ................................................................................................. 53
4.10.3.3 Dual actuator control box LPC ................................................................................................... 54
4.10.3.4 Circuit diagram........................................................................................................................... 54
4.10.4 DA 1700 ON/OFF 3x400 V ....................................................................................................... 55
4.10.4.1 Cable plan.................................................................................................................................. 55
4.10.4.2 Terminals in ON/OFF 3 x 400 V fan........................................................................................... 55
4.10.4.3 Dual actuator control box ON/ OFF ........................................................................................... 56
4.10.4.4 Circuit diagram........................................................................................................................... 56
5 Maintenance instructions ............................................................................................................................57
5.1 Cleaning.................................................................................................................................... 57
5.1.1 Fan............................................................................................................................................. 57
5.1.2 Motor controller .......................................................................................................................... 57
5.2 Recycling/Disposal .................................................................................................................. 57
6 Troubleshooting instructions......................................................................................................................58
7 Technical data...............................................................................................................................................60
7.1 DA 1700-6 LPC ACT 3x400 V .................................................................................................. 60
7.1.1 ErP/Ecodesign DA 1700-6 LPC ACT 3x400 V .......................................................................... 62
7.2 DA 1700-7 ACT 3x400 V........................................................................................................... 63
7.2.1 ErP/Ecodesign DA 1700-7 ACT 3x400 V .................................................................................. 64
7.3 Actuator .................................................................................................................................... 65
8 Dimensioned sketch.....................................................................................................................................66
8.1 Wall fan with LPC motor controller ........................................................................................ 66
8.2 Wall fan ..................................................................................................................................... 66
8.3 LPC motor controller ............................................................................................................... 67
8.4 Light trap .................................................................................................................................. 67

DA 1700 dual actuator
Technical User Guide 5
1 Product description
DA 1700 dual actuator wall fan is a flange-mounted corrosion-free fan with cone and motor-controlled shutter.
The fan is supplied in one version focused on low energy consumption and one version focused on maximizing
air output.
DA 1700 dual actuator is characterized by having a particularly tightly closed shutter, which prevents unwanted
air movement when the fan is not in operation, and a direct-driven motor to reduce motor maintenance.
DA 1700 dual actuator is specially designed for harsh livestock house environments. This applies to both cli-
matic and electrical influences.

DA 1700 dual actuator
6 Technical User Guide
2 Product survey
2.1 DA 1700 wall fan
For every 100 pcs. DA 1700 wall fans, 1 pcs. DA 1700 lifting kit and mounting parts are supplied. For
every 101-200 pcs., 2 pcs. DA 1700 lifting kit and mounting parts, etc. are supplied.
The lifting kit and mounting parts consist of:
DA 1700 lifting kit
safety straps
extra DA 1700 mounting parts.
3 pcs. technical user guides for the DA 1700 wall fan in English.

DA 1700 dual actuator
Technical User Guide 7
435369 DA 1700-6 LPC ACT 3x400 V 50/60 Hz w/wall cover
Fan control method - stepless.
The dual actuator is only recommended for areas with particularly strong
wind conditions, to ensure an optimal climate for the animals.
Note that the dual actuator solution has a higher current consumption com-
pared to the standard shutter motor.
Safety net outside must be mounted to comply with CE marking, in coun-
tries where this is required.
LPC motor controller
PM motor 1,5 kW.
0,7 m motor cable.
Supplied with mounting parts for assembly of DA 1700.
ErP 2015 approved.
435369 should not be used for negative pressure higher than 100 Pa.
435370 DA 1700-7 ACT 3x400 V 50 HZ w/wall cover
Fan control method - ON/OFF
The dual actuator is only recommended for areas with particularly strong
wind conditions, to ensure an optimal climate for the animals.
Note that the dual actuator solution has a higher current consumption com-
pared to the standard shutter motor.
Safety net outside or motor controlled shutter must be mounted to comply
with CE marking, in countries where this is required.
AC motor 3x400 V 1,2 kW.
0,7 m motor cable.
Supplied with mounting parts for assembly of DA 1700.
ErP 2015 approved.
435370 should not be used for negative pressure higher than 100 Pa.
2.2 Accessories
435327 DA 1700 safety net outside
DA 1700 outside safety net used if extra safety is required.
1 per wall fan.
Supplied with mounting parts.
Storm protection for mounting on outside net is included DA 1700.
If a DA 1700 outside safety net is deselected:
• A safety guard must be established.
• The 435337 DA 1700 storm protection wire for cone must be bought
separately.
• The requirements of the International Standard for Safety of machinery
ISO 13857 must be complied with.

DA 1700 dual actuator
8 Technical User Guide
435337 DA 1700 storm protection wire for cone
The DA 1700 storm protection wire for cone is used, if the DA 1700 outside
safety net is deselected.
1 per wall fan.
435375 DA 1700 outside suspension
Used if required if DA 1700 is sagging and has not maintained its round-
ness.
Delivered without screws for fastening.
1 per wall fan.
435368 DA 1700 support kit
Used if required if DA 1700 is sagging and has not maintained its round-
ness.
Delivered with mounting parts.
1 per wall fan.
560356 DA 1700 lifting kit and mounting parts ACT
DA 1700 lifting kit is used for mounting the fan motor.
Includes:
• 1 x DA 1700 lifting kit
• 1 x safety strap
• 1 x DA 1700 mounting parts
• 3 x technical user guides for the DA 1700 wall fan in English.
Order only if additional DA 1700 lifting kit and mounting parts are required.
435319 DA 1700 screw kit
DA 1700 screw kit can be used for mounting DA 1700 in wall.
1 per wall fan +
1 per wall cover
Includes:
• 21 x tapping screw 4.8x70 pan TX25 A2 ISO14585C
• 21 x washers ø6.4/ø18x1.6 A2 DIN9021

DA 1700 dual actuator
Technical User Guide 9
435317 DA 1700 insulation plate
The plate is used to minimize draughts and heat loss during cold periods,
when DA 1700 is not in use.
The plate should always be used if the dimensioned outside temperature is
less than 0°C.
Supplied with mounting parts.
1 per wall fan.
435328 DA 1700 bracket for insulation plates
DA 1700 bracket for insulation plates is used for storage of insulation plates
when they are not in use, i.e. typically during the summer.
1 per 5 DA 1700 insulation plates.
435325 DA 1700 light trap black out
The light trap is mounted and removed manually.
Supplied as an unassembled unit incl. brackets.
Used for DA 1700 wall fan if a large amount of dimming is required in the
livestock house.
Light reduction factor 11.000.000:1.
The light trap reduces the air output of the fan by approx. 28%.
For mounting light trap see Mounting guide for DA 1700 light trap black out.
435326 DA 1700 light trap brown out
The light trap is mounted and removed manually.
Supplied as an unassembled unit incl. brackets.
Used for DA 1700 wall fan if dimming is required in the livestock house.
Light reduction factor 17.000:1.
The light trap reduces the air output of the fan by approx. 15 %.
For mounting light trap see Mounting guide for DA 1700 light trap brown
out.
445076 LPC-2 relay module
Used for mounting motor controller, if an alarm output is required.
1 x potential free output relay 1 A, 30 V DC/24 V AC.

DA 1700 dual actuator
10 Technical User Guide
3 Mounting guide
Check that the parts ordered are present and undamaged before starting work. Please read through the entire
guide before starting assembly and fitting.
If the DA 1700 is installed in areas with risk of ice/snow slide, precautions must be made
to avoid damage to the wall fan.
3.1 Recommended tools
A list of the recommended tools for mounting purposes can be seen below.
Item Description
Cordless drill
Screwdriver bits
Drill kit
Atomizer
Sealant gun
Hammer
Utility knife
Wedge
Marker pen
Torque wrench
Tape measure
Combination spanner kit
Screwdriver

DA 1700 dual actuator
Technical User Guide 11
Item Description
Foam gun
Ladder
Jigsaw
Socket wrench set
Water pump (multi-grip) pliers
Spirit level
Try square
2 men

DA 1700 dual actuator
12 Technical User Guide
3.2 Placement of wall fan
The wall fan must be placed in the livestock house according to the drawing supplied. Contact SKOV A/S in
case of significant deviation.
Check that all wall fans can be placed freely in relation to other housing equipment upon agreement with the
client.
Place the insulation of the brickwork all the way in against the wall fan and all the way round (as in other build-
ing constructions). This way you prevent a cold bridge along the side of the wall fan from being formed.
3.3 Preparing hole in wall
3.3.1 Necessary space for wall fan without LPC motor controller
(B)
(C)
(D)
(E)
(A)
There must be a minimum of (A) space inside the live-
stock house for the wall fan.
There must be minimum of (B) of space including the
wall thickness outside the livestock house for the wall
fan.
Wall thickness (C).
The recommended space in front of the cone is (D).
Recommended installation height from floor is mini-
mum (E) in order to ensure space for dung removal.
3.3.2 Necessary space for wall fan with LPC motor controller
(B)
(C)
(D)
(E)
(A)
There must be a minimum of (A) space inside the live-
stock house for the wall fan.
There must be minimum of (B) of space including the
wall thickness outside the livestock house for the wall
fan.
Wall thickness (C).
The recommended space in front of the cone is (D).
Recommended installation height from floor is mini-
mum (E) in order to ensure space for dung removal.

DA 1700 dual actuator
Technical User Guide 13
3.3.3 Measurements for round hole in sandwich wall
The dimensions below are given in mm .
Recommended measurements for individual mounting of wall fan.
(A) Minimum distance is 550 mm, when mounting the LPC motor controller above wall fan. Without LPC motor
controller, the distance can be reduced to a minimum of 275 mm.
Minimum distance between wall fans.
(A)
Minimum distance from wall fan to wall, floor and ceiling.

DA 1700 dual actuator
14 Technical User Guide
3.3.4 Measurements for square hole in concrete and brick wall
The dimensions below are given in mm .
Recommended measurements for individual mounting of wall fan.
(A) Minimum distance is 550 mm, when mounting the LPC motor controller above wall fan. Without LPC motor
controller, the distance can be reduced to a minimum of 275 mm.
Minimum distance between wall fans.
(A)
Minimum distance from wall fan to wall, floor and ceiling.

DA 1700 dual actuator
Technical User Guide 15
3.3.5 Measurements for square hole in wooden wall
The dimensions below are given in mm .
Recommended measurements for individual mounting of wall fan.
(A) Minimum distance is 550 mm, when mounting the LPC motor controller above wall fan. Without LPC motor
controller, the distance can be reduced to a minimum of 275 mm.
Minimum distance between wall fans.
(A)
Minimum distance from wall fan to wall, floor and ceiling.

DA 1700 dual actuator
16 Technical User Guide
3.4 Measure and saw out the holes
Remember always to use a spirit level.
Drill 10 mm holes all the way through the wall.
Cut the holes.

DA 1700 dual actuator
Technical User Guide 17
3.5 Press the front panel together
Lay the 4 front panels on the floor.
Press the front panels together in all 4 corners.
3.6 Click and point the ventilation ducts together
Silicone
Point the side of the ventilation duct.
(A) (B)
(A)
(B)
Click the 4 ventilation ducts together alternately.
(A) Ventilation duct without motor suspension.
(B) Ventilation duct with motor suspension.

DA 1700 dual actuator
18 Technical User Guide
3.7 Mounting ventilation duct on front panel
Position the ventilation duct on the front panel.
Assemble the front panel and the ventilation duct using:
• 16 x M6x25 screws
• 32 x ø6 washers
• 16 x bushings ø6/ø10x11.6
• 16 x M6 self-locking nuts
Assemble the front panel and the ventilation duct using:
• 12 x M6x25 screws
• 24 x ø6 washers
• 12 x bushings ø6/ø10x11.6
• 12 x M6 self-locking nuts

DA 1700 dual actuator
Technical User Guide 19
3.8 Mounting center pillar
Mount the two shutters, one at a time, in the center pillar.
Mount top and bottom brackets on the center pillar using:
• 2 x M6x50 screw
• 4 x ø6.4/ø18x1.2 washers
• 2 x bushings ø6/ø10x39.6
• 2 x M6 self-locking nut
Make sure that the 2 holes in the center pillar are at
the bottom.

DA 1700 dual actuator
20 Technical User Guide
Mount the shutter lock through the shutter and down
around the center pillar.
Make sure that the shutter lock snaps into the center
pillar.
