SMC Networks ProtoCessor FPC-ED2 User guide

Document Revision: 2.A
Web Configurator
Template Revision: 69
ProtoCessor FPC-ED2
Start-up Guide
For Interfacing Leonard Valve Products: Valve
To Building Automation Systems:
BACnet MS/TP, BACnet/IP, Modbus TCP/IP, Modbus RTU,
Metasys N2 and EtherNet/IP
APPLICABILITY & EFFECTIVITY
Explains ProtoCessor hardware and how to install it.
The instructions are effective for the above as of November 2017.
BULLETIN NUC-PSUG-1

Leonard Valve ProtoCessor Start-up Guide
Page 2 of 32
Technical Support
Thank you for purchasing the ProtoCessor for Leonard Valve.
Please call Leonard Valve for Technical support of the ProtoCessor product.
Sierra Monitor Corporation does not provide direct support. If Leonard Valve needs to escalate the
concern, they will contact Sierra Monitor Corporation for assistance.
Support Contact Information:
Leonard Valve
1360 Elmwood Avenue
Cranston, RI 02910
Customer Service:
[phone]
[phone]
Website: leonardvalve.com
Email: [e-mail]

Leonard Valve ProtoCessor Start-up Guide
Page 3 of 32
Quick Start Guide
1. Record the information about the unit. (Section 3.1)
2. Set the COM settings for the device connected to ProtoCessor. (Section 3.3)
3. Connect ProtoCessor FPC-ED2’s 3 pin RS-485 port to the Field Protocol cabling. (Section 4.2)
4. Use a browser to access the ProtoCessor’s embedded tool, which is referred to in this manual as
the Web Configurator, to select the device that will be attached to ProtoCessor. Once the device
is selected, the ProtoCessor Automatically builds and loads the Configuration. (Section 5)
5. BACnet/IP, Modbus TCP/IP or EtherNet/IP: Use a browser to access the ProtoCessor Web
Configurator to change the IP Address. No changes to the configuration are necessary. (Section
5.5)

Leonard Valve ProtoCessor Start-up Guide
Page 4 of 32
TABLE OF CONTENTS
1Certifications........................................................................................................................................6
1.1 BTL Mark –BACnet®Testing Laboratory.......................................................................................6
2Introduction..........................................................................................................................................7
2.1 ProtoCessor Gateway.....................................................................................................................7
3Setup for ProtoCessor ........................................................................................................................8
3.1 Record Identification Data ..............................................................................................................8
3.2 Point Count Capacity and Registers per Device ............................................................................8
3.3 Configuring Device Communications .............................................................................................8
3.3.1 Input COM Settings on the Device Connected to the ProtoCessor..........................................8
4Interfacing ProtoCessor to Devices...................................................................................................9
4.1 ProtoCessor FPC-ED2 Showing Connection Ports............................................................9
4.2 BACnet MS/TP, Modbus RTU, Metasys N2: Wiring Field Port to RS-485 Network.10
5Use ProtoCessor Web Configurator to Setup the Gateway ..........................................................11
5.1 Connect the PC to ProtoCessor via the Ethernet Port .................................................................11
5.2 Connecting to ProtoCessor Web Configurator.............................................................................12
5.3 Select Field Protocol.....................................................................................................................14
5.4 Devices Connected to ProtoCessor .............................................................................................15
5.5 Ethernet Network: Setting IP Address for Field Network..............................................................17
6How to Start the Installation Over: Clearing Profiles.....................................................................19
7BACnet Explorer NG..........................................................................................................................20
Appendix A. Troubleshooting..................................................................................................................21
Lost or Incorrect IP Address ............................................................................................21
Viewing Diagnostic Information .......................................................................................22
Check Wiring and Settings...............................................................................................23
LED Diagnostics for Communications Between ProtoCessor and Device......................24
Take Diagnostic Capture with the FieldServer Toolbox ..................................................25
Update Firmware .............................................................................................................28
BACnet: Setting Network_Number for more than one ProtoCessor on Subnet..............28
Securing ProtoCessor with Passwords............................................................................29
Appendix B. Vendor Information –Leonard Valve................................................................................30
Valve Modbus RTU Mappings to BACnet, Metasys N2 and EtherNet/IP........................30
Appendix C. Reference.............................................................................................................................31
Specifications...................................................................................................................31
Appendix C.1.1. Compliance with UL Regulations...........................................................................31
Appendix D. Limited 2 Year Warranty.....................................................................................................32

Leonard Valve ProtoCessor Start-up Guide
Page 5 of 32
LIST OF FIGURES
Figure 1: ProtoCessor Part Numbers............................................................................................................8
Figure 2: Supported Point Count Capacity ...................................................................................................8
Figure 3: Registers per Device .....................................................................................................................8
Figure 4: COM Settings.................................................................................................................................8
Figure 5: ProtoCessor FPC-ED2 ..................................................................................................................9
Figure 6: Connection from ProtoCessor to RS-485 Field Network.............................................................10
Figure 7: RS-485 BMS Network EOL Switch..............................................................................................10
Figure 8: Web App Splash Page.................................................................................................................12
Figure 9: Login Window ..............................................................................................................................12
Figure 10: Web App Landing Page.............................................................................................................13
Figure 11: Configuration Tab ......................................................................................................................13
Figure 12: Web Configurator Showing Protocol Selector Parameter .........................................................14
Figure 13: Web Configurator Showing no Active Profiles...........................................................................15
Figure 14: Web Configurator Showing Active Profile Additions..................................................................16
Figure 15: Web Configurator Screen ..........................................................................................................17
Figure 16: Changing IP Address via FS-GUI..............................................................................................18
Figure 17: BACnet Explorer NG on a BACnet Network..............................................................................20
Figure 18: Ethernet Port Location...............................................................................................................21
Figure 19: Error Messages Screen.............................................................................................................22
Figure 20: Diagnostic LEDs ........................................................................................................................24
Figure 21: Ethernet Port Location...............................................................................................................25
Figure 22: Web Configurator –Network Number Field...............................................................................28
Figure 23: FS-GUI Passwords Page...........................................................................................................29
Figure 24: Password Recovery Page .........................................................................................................29
Figure 25: Specifications.............................................................................................................................31

Leonard Valve ProtoCessor Start-up Guide
Page 6 of 32
1 CERTIFICATIONS
1.1 BTL Mark –BACnet®
1
Testing Laboratory
1
BACnet is a registered trademark of ASHRAE.
The BTL Mark on ProtoCessor is a symbol that indicates that a product has
passed a series of rigorous tests conducted by an independent laboratory
which verifies that the product correctly implements the BACnet features
claimed in the listing. The mark is a symbol of a high-quality BACnet product.
Go to www.BACnetInternational.net for more information about the BACnet
Testing Laboratory. Click here for the BACnet PIC Statement.

Leonard Valve ProtoCessor Start-up Guide
Page 7 of 32
2 INTRODUCTION
2.1 ProtoCessor Gateway
The ProtoCessor is an embedded module that is designed into Leonard Valve’s product (hereafter called
“device”) and is preconfigured to support BACnet MS/TP, BACnet/IP, Metasys®
2
N2 by JCI, Modbus
TCP/IP, Modbus RTU or EtherNet/IP.
It is not necessary to download any configuration files to support the required applications. The
ProtoCessor is pre-loaded with all the tested Profiles/Configurations for the device to support the desired
protocols.
2
Metasys is a registered trademark of Johnson Controls Inc.

Leonard Valve ProtoCessor Start-up Guide
Page 8 of 32
3 SETUP FOR PROTOCESSOR
3.1 Record Identification Data
Each ProtoCessor has a unique part number located on the side or the back of the unit. This
number should be recorded, as it may be required for technical support. The numbers are as
follows:
Model
Part Number
ProtoCessor FPC-ED2
FPC-ED2-1145
Figure 1: ProtoCessor Part Numbers
•FPC-ED2 units have the following 2 ports: RS-485 + Ethernet
3.2 Point Count Capacity and Registers per Device
The total number of Registers presented by the device attached to the ProtoCessor cannot
exceed:
Part number
Total Registers
FPC-ED2-1145
1,500
Figure 2: Supported Point Count Capacity
Devices
Registers Per Device
Valve
41
Figure 3: Registers per Device
3.3 Configuring Device Communications
3.3.1 Input COM Settings on the Device Connected to the ProtoCessor
•The connected serial device MUST have the same Baud Rate, Data Bits, Stop Bits, and
Parity settings as the ProtoCessor.
•Figure 4 specifies the device serial port settings required to communicate with the ProtoCessor.
Port Setting
Device
Protocol
PSP
Baud Rate
9600
Parity
None
Data Bits
8
Stop Bits
1
Figure 4: COM Settings

Leonard Valve ProtoCessor Start-up Guide
Page 9 of 32
4 INTERFACING PROTOCESSOR TO DEVICES
4.1 ProtoCessor FPC-ED2 Showing Connection Ports
Figure 5: ProtoCessor FPC-ED2

Leonard Valve ProtoCessor Start-up Guide
Page 10 of 32
4.2 BACnet MS/TP, Modbus RTU, Metasys N2: Wiring Field Port to RS-485
Network
•Connect the BACnet MS/TP, Modbus RTU or Metasys N2 RS-485 network wires to the 3-pin RS-
485 connector on ProtoCessor ED2 as shown below in Figure 6.
oUse standard grounding principles for RS-485 GND
•See Section 5.5 for information on connecting to BACnet/IP and Modbus TCP/IP
network.
•If the ProtoCessor is the last device on the BACnet MS/TP, Modbus RTU or Metasys N2
trunk, then the End-Of-Line Termination Switch needs to be enabled (Figure 7).
oThe default setting from the factory is OFF (switch position = right side)
oTo enable the EOL Termination, turn the EOL switch ON (switch position = left
side)
BMS RS-
485 Wiring
ProtoCessor
Pin #
Pin
Assignment
RS-485 +
Pin 1
RS-485 +
RS-485 -
Pin 2
RS-485 -
-
Pin 3
RS-485 GND
Figure 7: RS-485 BMS Network EOL Switch
Figure 6: Connection from ProtoCessor to RS-485 Field Network
G
-
+
End-of-Line Switch

Leonard Valve ProtoCessor Start-up Guide
Page 11 of 32
5 USE PROTOCESSOR WEB CONFIGURATOR TO SETUP THE GATEWAY
5.1 Connect the PC to ProtoCessor via the Ethernet Port
•Connect a CAT5 Ethernet cable (Straight through or Cross-Over) between the local PC and
ProtoCessor.
•The Default IP Address of ProtoCessor is 192.168.1.24, Subnet Mask is 255.255.255.0. If the PC
and ProtoCessor are on different IP Networks, assign a static IP Address to the PC on the
192.168.1.xxx network.
For Windows 10:
Right click on > >
> >
Right-click on Local Area Connection > Properties
Highlight >
Use the following IP Address:
Click twice.

Leonard Valve ProtoCessor Start-up Guide
Page 12 of 32
5.2 Connecting to ProtoCessor Web Configurator
After setting a local PC on the same subnet as the ProtoCessor (Section 5.1), open a web browser on
the PC and enter the IP Address of the ProtoCessor; the default address is 192.168.1.24.
NOTE: If the IP Address of the ProtoCessor has been changed by previous configuration, the assigned
IP Address can be discovered using the FS Toolbox utility. See Appendix A.1 for instructions.
•Once at the Web App splash page, click the Login button.
•Enter the previously set up or default username and password.
NOTE: The default username is “admin”. The default password is “admin”.
Figure 9: Login Window
Figure 8: Web App Splash Page

Leonard Valve ProtoCessor Start-up Guide
Page 13 of 32
•From the Web App landing page (Figure 10), click the Configure tab.
•Then click the Profiles Configuration button to go to the Web Configurator page.
NOTE: The FieldPoP™ tab (see Figure 11) allows users to connect to the SMC
Cloud, Sierra Monitor’s device cloud solution for IIoT. The SMC Cloud enables secure
remote connection to field devices through a FieldServer and its local applications for
configuration, management, maintenance. For more information about the SMC Cloud,
refer to the SMC Cloud Start-up Guide.
NOTE: For Web App instructions to the System View, Historian and Event Logger functions, see
the SMC Cloud Start-up Guide.
Figure 10: Web App Landing Page
Figure 11: Configuration Tab

Leonard Valve ProtoCessor Start-up Guide
Page 14 of 32
5.3 Select Field Protocol
•On the Web Configurator page, the first configuration parameter is the Protocol Selector.
•Select the field protocol desired, using the number key under the Parameter Description header,
and click the Submit button.
oA message will appear at the top of the screen stating that the update was completed and to
restart the system.
•Click the System Restart button on the bottom of the screen and wait for the system to reset.
Figure 12: Web Configurator Showing Protocol Selector Parameter

Leonard Valve ProtoCessor Start-up Guide
Page 15 of 32
5.4 Devices Connected to ProtoCessor
NOTE: If Modbus TCP/IP was selected for the Field/BMS protocol, skip this section. Device
profiles are NOT used for Modbus TCP/IP.
•In the Web Configurator, the Active Profiles section is shown on the lower left side of the screen.
•The Active Profiles section lists the currently active device profiles, including previous Web
Configurator additions. This list is empty for new installations, or after clearing all configurations.
(Figure 13)
•To add an active profile to support a device, click the ADD button under Active Profiles. This will
present a drop-down box underneath the Current Profile column that lists all the available profiles.
NOTE: Leave the BACnet Virtual Server Nodes field on the default “No” setting.
Figure 13: Web Configurator Showing no Active Profiles

Leonard Valve ProtoCessor Start-up Guide
Page 16 of 32
•For every device that is added, assign a unique Modbus Node-ID. This specification must match
the device’s network settings.
•Once the Profile for the device has been selected from the drop-down list, enter the value of the
device’s Node-ID.
•Then press the “Submit” button to add the Profile to the list of devices to be configured.
•Repeat this process until all the devices have been added.
•Completed additions are listed under “Active Profiles”as shown in Figure 14.
Figure 14: Web Configurator Showing Active Profile Additions

Leonard Valve ProtoCessor Start-up Guide
Page 17 of 32
5.5 Ethernet Network: Setting IP Address for Field Network
•After setting a local PC to the same subnet as the ProtoCessor (Section 5.1), open a web
browser on the PC and enter the IP Address of the ProtoCessor; the default address is
192.168.1.24.
•The Web Configurator is displayed as the landing page. (Figure 15)
•To access the FS-GUI, click on the “Diagnostics & Debugging” button in the bottom right
side of the page.
Figure 15: Web Configurator Screen

Leonard Valve ProtoCessor Start-up Guide
Page 18 of 32
•From the FS-GUI landing page, click on “Setup” to expand the navigation tree and then select
“Network Settings” to access the IP Settings menu. (Figure 16)
•Modify the IP Address (N1 IP Address field) of the ProtoCessor Ethernet port.
•If necessary, change the Netmask (N1 Netmask field).
•If necessary, change the IP Gateway (Default Gateway field).
NOTE: If the ProtoCessor is connected to a managed switch/router, the IP Gateway of the
ProtoCessor should be set to the IP Address of that managed switch/router.
•Click the “System Restart” button at the bottom of the page to apply changes and restart the
ProtoCessor.
•Unplug Ethernet cable from PC and connect it to the network switch or router.
•Record the IP Address assigned to the ProtoCessor for future reference.
Figure 16: Changing IP Address via FS-GUI

Leonard Valve ProtoCessor Start-up Guide
Page 19 of 32
6 HOW TO START THE INSTALLATION OVER: CLEARING PROFILES
•After setting a local PC to the same subnet as the ProtoCessor (Section 5.1), open a web
browser on the PC and enter the IP Address of the ProtoCessor; the default address is
192.168.1.24.
•If the IP Address of the ProtoCessor has been changed by previous configuration, the assigned
IP Address must be gathered from the network administrator.
•Login to the Web App.
•Click to the Configuration tab and then click the Profiles Configuration button to open the Web
Configurator page.
•At the bottom-left of the page, click the “Clear Profiles and Restart” button.
•Once restart is complete, all past profiles discovered and/or added via Web Configurator are
deleted. The unit can now be reinstalled.

Leonard Valve ProtoCessor Start-up Guide
Page 20 of 32
7 BACNET EXPLORER NG
A typical working example of a BACnet Explorer NG on a BACnet Network:
For additional details related to the BACnet Explorer NG, go to the Sierra Monitor website’s Resource
Center and download the BACnet Explorer NG Start-up Guide.
For purchasing information, look up the BACnet Explorer NG page on the Sierra Monitor website and
click on the “BUY NOW” tab.
Multi-Port Switch
BACnet MS/TP
BACnet/IP
PC Connected to
BACnet
Explorer’s Web
Browser
BACnet/IP
BACnet Explorer NG
BACnet Router
Figure 17: BACnet Explorer NG on a BACnet Network
