SOMFY MONOGRAM Motorised Roller/Roman User manual

if OK ➞ step 5 Press until... motor jogs Up and Down
2 sec.
if NOT OK ➞ step 4
or
When using a multi
channel handset please
ensure you select the
appropriate channel
before continuing to
program your blind.
You can then program
the blind you are
installing. Once
complete you can then
take all other blinds out
of sleep mode.
Reset and program your motor
Putting your blind into programming mode...
Putting additional blinds into SLEEP MODE (Only required if you have multiple blinds to program or already have blinds on site)
If you need to change the motor direction...
Set the DOWN position...
Set the UP position...
Place the blind in the desired UP position...
Check the motor direction...
Press until...
...desired position up position
Short simultaneously
push both buttons
2 x short simultaneous press
Blind goes down, must press stop
before the blinds reaches the bottom
The motor moves upwards and
stops at the UP position
Stop near desired down position Adjust to desired down position
Only connect the motor that should be programmed to power. When programming a multi channel control, choose channel first.
If you are programming multiple blinds or already have blinds installed you will need to place all other blinds into SLEEP MODE
except the blind you wish to program. To do this follow the steps below.
Press simultaneously until...
...motor jogs Up and Down
Press and hold button on the motor.
Motor jogs 3 times... first after 2 sec,
after 7 sec and after 12 sec. ➞ OK
Press and hold the motor head
program button or in the case of
the Luxury motor use a paper clip
to push the smaller button until
the blind jogs once
Press and hold UP, DOWN and
MY button together until the blind
jogs once. The blind is now in
sleep mode.
To take the blind out os SLEEP MODE
quickly press and release the
program button, the blind will jog
once to confim
Press the circle button until
the light indicator is lit for your
chosen channel
Monogram Motorised Roller/Roman
Complete Programming
3x
2.
1.
4.
6.
7.
5.
3.
if OK ➞ step 5 Press until... motor jogs Up and Down
2 sec.
if NOT OK ➞ step 4
or
When using a multi
channel handset please
ensure you select the
appropriate channel
before continuing to
program your blind.
You can then program
the blind you are
installing. Once
complete you can then
take all other blinds out
of sleep mode.
Reset and program your motor
Putting your blind into programming mode...
Putting additional blinds into SLEEP MODE (Only required if you have multiple blinds to program or already have blinds on site)
If you need to change the motor direction...
Set the DOWN position...
Set the UP position...
Place the blind in the desired UP position...
Check the motor direction...
Press until...
...desired position up position
Short simultaneously
push both buttons
2 x short simultaneous press
Blind goes down, must press stop
before the blinds reaches the bottom
The motor moves upwards and
stops at the UP position
Stop near desired down position Adjust to desired down position
Only connect the motor that should be programmed to power. When programming a multi channel control, choose channel first.
If you are programming multiple blinds or already have blinds installed you will need to place all other blinds into SLEEP MODE
except the blind you wish to program. To do this follow the steps below.
Press simultaneously until...
...motor jogs Up and Down
Press and hold button on the motor.
Motor jogs 3 times... first after 2 sec,
after 7 sec and after 12 sec. ➞ OK
Press and hold the motor head
program button or in the case of
the Luxury motor use a paper clip
to push the smaller button until
the blind jogs once
Press and hold UP, DOWN and
MY button together until the blind
jogs once. The blind is now in
sleep mode.
To take the blind out os SLEEP MODE
quickly press and release the
program button, the blind will jog
once to confim
Press the circle button until
the light indicator is lit for your
chosen channel
Monogram Motorised Roller/Roman
Complete Programming
3x
2.
1.
4.
6.
7.
5.
3.
See our instructional
video here on how to
program your motor.
if OK ➞ step 5 Press until... motor jogs Up and Down
2 sec.
if NOT OK ➞ step 4
or
When using a multi
channel handset please
ensure you select the
appropriate channel
before continuing to
program your blind.
You can then program
the blind you are
installing. Once
complete you can then
take all other blinds out
of sleep mode.
Signature Motorised Roller Blind
Reset and program your motor
Putting your blind into programming mode...
Putting additional blinds into SLEEP MODE (Only required if you have multiple blinds to program or already have blinds on site)
If you need to change the motor direction...
Set the DOWN position...
Set the UP position...
Place the blind in the desired UP position...
Check the motor direction...
Press until...
...desired position up position
Short simultaneously
push both buttons
2 x short simultaneous press
Blind goes down, must press stop
before the blinds reaches the bottom
The motor moves upwards and
stops at the UP position
Stop near desired down position Adjust to desired down position
Only connect the motor that should be programmed to power. When programming a multi channel control, choose channel first.
If you are programming multiple blinds or already have blinds installed you will need to place all other blinds into SLEEP MODE
except the blind you wish to program. To do this follow the steps below.
Press simultaneously until...
...motor jogs Up and Down
Press and hold button on the motor.
Motor jogs 3 times... first after 2 sec,
after 7 sec and after 12 sec. ➞ OK
Press and hold the motor head
program button or in the case of
the Luxury motor use a paper clip
to push the smaller button until
the blind jogs once
Press and hold UP, DOWN and
MY button together until the blind
jogs once. The blind is now in
sleep mode.
To take the blind out os SLEEP MODE
quickly press and release the
program button, the blind will jog
once to confim
Press the circle button until
the light indicator is lit for your
chosen channel
Complete Programming
3x
2.
1.
4.
6.
7.
5.
3.
When using a multi
channel handset please
ensure you select the
appropriate channel
before continuing to
program your blind. This
step is not applicable to
single channel remotes.
Press the circle button until
the light indicator is lit for your
chosen channel
Monogram Motorised Roller/Roman
Complete Programming
You can then program
the blind you are
installing. Once
complete you can then
take all other blinds out
of sleep mode.
Reset & Program your motor
Putting your blind into programming mode...
Putting additional blinds into SLEEP MODE (Only required if you have mutliple blinds to program or already have blinds on site)
If you need to change the motor direction...
Set the DOWN position...
Set the UP position...
Place the blind in the desired UP position...
Check the motor direction...
if OK, follow step 4
Press and hold UP until the blind
is at the desired top position
Press then release MY and
DOWN together
Press then release MY and UP
together
Blind goes down, must press stop
before the blinds reaches the bottom
The motor moves upwards and
stops at the UP position
Stop near desired down position Adjust to desired down position
Only connect the motor that should be programmed to power. When programming a multi channel control, choose channel first.
if you programming mutliple blinds or already have blinds installed you will need to place all other blinds into SLEEP MODE
except the blind you wish to program. To do this, follow the steps below.
Press and hold UP and DOWN
until the motor jogs
Press and hold button on the motor.
Motor jogs 3 times... first after 2 sec,
after 7 sec and after 12 sec. ➞ OK
Press and hold the motor head
program button or in the case of
the Luxury motor use a paper clip
to push the smaller button until the
blind jogs once
To take the blind out of SLEEP MODE
quickly press and release the
program button, the blind will jog
once to confirm
Press and hold UP, DOWN and MY
button together until the blind jogs
once. The blind is now in sleep
mode.
Press and hold MY until the motor jogs
2 sec.
if NOT OK , follow step 3
or
EN Sonesse 28 WireFree RTS / Sonesse 30 WireFree RTS
4Copyright© 2017 - 2018 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved.
2.3. COMMISSIONING
Orange LED blinks continously in setting mode.
Green LED blinks once when any order from paired remote is received.
2.3.1. Wake up the drive
For initial unpackaging of drive, wake up the drive by briefly
pressing the motor head programming button or plugging on
the charger.
The driven product briefly moves Up and Down 3 times and LED
lights orange.
2.3.2. Preprogramming the control point
Press the UP and DOWN buttons simultaneously on the control point:
the driven product moves Up and Down and the control point is temporarily programmed to driven
product.
2.3.3. Checking the rotation direction
Press the control point UP button:
a) If the driven product raises (a), the rotation direction is
correct: proceed to section «Setting the end limits».
b) If the driven product is lowers (b), the rotation direction is
incorrect: move to the next step.
• b1) Press the control point MY button until the driven
product moves Up and Down: the rotation direction
has been modified and green LED blinks 5 times.
• b2) Press the control point UP button to confirm the
rotation direction.
2.3.4. Setting the end limits
The end limits can be set in any order.
1) Press and hold the UP button to move the driven product to
the desired Up position. If necessary, adjust the Up position
using the UP or DOWN buttons and green LED blinks 5
times.
2) To memorize the UP limit: Press the MY and DOWN
buttons simultaneously and release once the driven product
begins to move. The Up limit is now memorized.
3) Press the MY button when the driven product reaches
the desired Down position. If necessary, adjust the down
position using the UP or DOWN buttons.
4) To memorize the Down limit: Press the MY and UP buttons
simultaneously and release when the driven product begins
to move. The Down limit is now memorized. The driven
product moves up and will stop at its upper limit and green
LED blinks 5 times.
5) To confirm and complete limit programming: Press and hold the MY button until the driven
product briefly moves Up and Down. The end limits are now recorded.
3x
a
b
=
=
b2b1
1 2
3 4
5
5133455B005_Sonesse 28_30 Wirefree RTS_ENESFRRUAR.indb 4 29/05/2018 10:43
2.
1.
4.
6.
7.
5.
3.

adjust the Top and Bottom limit
set ‘My’ position
remove programmed ‘My’ position
Press then release UP and
DOWN until the motor jogs
Press and hold UP and DOWN
until motor jogs
To confirm new MY position
press MY until motor jogs
Place the blind in the
DOWN position
Place the blind in the
UP position
Place the blind in the
desired position
Choose a new down position
Choose a new up position
Place the blind in the MY position Hold MY for 5 seconds until motor jogs
Press MY to stop blind at new down
position, then press and hold MY
until motor jogs
Press MY to stop blind at new down
position, then press and hold MY
until motor jogs
adjust ‘My’ position
Repeat procedure to a new desired position
1. 2.
or or
5 sec.
5 sec.
5 sec.
2 sec.
2 sec.
1.
3.
1.
2.
4.
Confirm end limit setting... Record an RTS transmitter...
2 sec.
Press and hold MY until the
motor jogs
Press and release the programming button on the back of the remote...
motor jogs to confirm limits are locked and setup is complete
*Do not press and hold.
8.7.
