Soundoff Signal GHOST EGHST4 B-12 Series User manual

IMPORTANT INFORMATION:
Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances. These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these devices to ensure compliance.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/sales-support.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. at 1.800.338.7337 (press #4 to skip the automated message).
Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
• DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to your vehicle
Owner’s Manual for the location of any air bag deployment zones.
• DO NOT connect this device to a strobe power supply. This product is self-contained and does not
require an external power supply.
EGHST4(xx)-12 07.14
Important Information:
OPERATION:
WIRE CONNECTIONS
See setup procedure on second page.
The single GHOST comes equipped with
an internal flasher with 33 user select-
able patterns that can be synchronized
either alternating or simultaneous with up
to three other lights. It can also be put
into slave mode and driven through an
external flasher.
1. Connect the GHOST BLACK wire to a
good, convenient ground.
2. Connect the GHOST RED wire to one side
of a user supplied on/off switch. Connect
the other side of the switch, through a
5Amp fuse, to a source of +10-16Vdc.
NOTE: The GHOST is a factory sealed unit
that CANNOT be serviced in the field. Any
attempt to gain access to the GHOST™
unit will most likely cause permanent
damage and void its warranty.
1 SINGLE LIGHT
Follow the ID selection steps and set the
GHOST to the following ID:
- Alternating (default): ID#1 or ID#3.
(inludes cycle patterns
and steady burn patterns)
- Simultaneous: ID#2 or ID#4. (both
lights will flash together
regardless of pattern)
(Continued on opposite side)
This product contains high
intensity LED devices. To prevent
eye damage, DO NOT stare into
light beam at close range.
WARNING
!
TECHNICAL
SPECIFICATIONS
Overall
Dimensions:
4.0”L x 0.88”H x
1.75”D
Input Voltage
Range:
10-16Vdc
Current
Consumption:
0.75A / Module*
# of LEDs: 6 Generation 3 LEDs
Operating
Temperature:
-20º to +65º C
Light Sync
Technology:
Yes
*Pattern Dependent
INSTALLATION:
WARNING! This product contains high
intensity LED devices. To prevent eye
damage, DO NOT stare into light beam at
close range.
1. Screw Mount - Establish a position on
the vehicle. Use the mounting slots as
a template to mark hole locations. Drill
a hole using a #27 drill bit. The Torx
screws provided are self-tapping.
2. Loosen the two #10 TORX screws on the
back of each housing to adjust the angle
of the GHOST. After adjustment, tighten
the TORX screws.
Screw Mount
Hole with #27 drill
Supplied #10 thread
forming screw.
GHOST® SINGLE SURFACE
MOUNT LIGHT W/ PERMANENT
MOUNT BRACKET
EGHST4(x)B-12 - Black
1.800.338.7337 / www.soundoffsignal.com

EGHST4(xx)-12 07.14
NOTE: The GHOST is equipped with flash pattern memory. Once you
have selected a pattern the GHOST will always activate to that
pattern every time the unit is turned on. Tape up and secure WHITE
wire so that it will not accidentally change your selected pattern.
Ghost Sync Configuration Instructions
IMPORTANT! A MAXIMUM OF 4 SINGLE LIGHTS
CAN BE SYNCED TOGETHER
1. Set ID#
a. Identify which pattern and sequence you want and look up
ID# settings at left.
b. Connections
i. RED: +10-16Vdc
ii. WHT: +10-16Vdc (Note: you will need to disconnect after
power is applied)
iii. BLK: Ground
c. Apply power to unit
d. Without disconnecting power from unit, disconnect WHT wire
e. Momentarily connect WHT to Ground to change ID #
i. Identify ID# by number of sequential flashes
ii. Possible ID#s: 1 – 4
f. Disconnect power from unit to get out of ID mode.
2. Set Pattern
a. Reapply power to units.
b. Once all Light Head ID#s are configured, make sure all
lights are flashing the same pattern.
c. Connect corresponding colored wires of all units together:
RED to RED, etc.
d. Change Pattern
i. Momentarily connect WHT wires to Ground
ii. Observe pattern change on all lights connected
e. Insulate all wires by taping with electrical tape
3. Connect Master Switch for Application
a. IMPORTANT! Ensure WHT Pattern/Sync Wires are tied
together
PATTERN RESET
1. Remove power
2. Place WHITE (sync) wire to ground
3. With sync wire grounded, re-power RED wire
4. Maintain for one second (light will dim)
5. Remove power and ground (pattern 1 set)
SLAVE MODE
The GHOST is capable of being activated through the use of a user
supplied flasher by putting it in slave mode.
1. Permanently connect the GHOST WHITE and BLACK wire to a
good, convenient ground.
2. Connect the GHOST RED wire, through a 5Amp fuse, to the output
of a +10-16Vdc switching flasher.
2 SINGLE LIGHTS
Follow the ID selection steps and set the GHOST to the following
ID:
IMPORTANT: Make sure both lights flash the same pattern!
- Both assemblies simultaneous with individual lights alternating.
- Example: Driver/Passenger sim; Dr. (left alt right)
Pass. (left alt right)
- Set both GHOST Assemblies to ID#1
- Both assys. alternating with individual lights alternating.
- EX: Dr./Pass. alt; Dr. (left. alt. right.) Pass. (right alt. left)
- Set one GHOST to ID#1 and the other to ID#3
- Both assys. alternating with individual lights simultaneous
- EX: Dr./Pass. alt; Dr. (left sim left) Pass. (right sim right)
- Set one GHOST to ID#2 and the other to ID#4
- Both assys. simultaneous with individual lights simultaneous.
- EX: Dr./Dr. sim; Dr. (left sim left) Pass. (right sim right)
- Set both Ghost housings to ID#2
X-PATTERN - To obtain X-Patterns, follow the ID SELECTION
steps and set one of the four GHOST lights to ID#1, one to ID#2,
one to ID#3, and one to ID#4. Then proceed to the PATTERN
SELECTION steps.
NOTE: Be sure to mount each GHOST in the correct placement
based on ID#.
PATTERN SELECTION
1. Disconnect WHITE wire from any connections if applicable.
2. Turn GHOST ON.
3. Momentarily touching and removing the WHITE wire(s) to
ground will advance the GHOST to the next flash pattern.
Touching and removing the White wire for more than a few
seconds will allow you to change the GHOST to the previous
pattern. See flash pattern table. Continuing to touch and
remove the WHITE wire(s) to ground will allow you to scroll
through the pattern list. After pattern #33 is reached the list
will start over again at pattern #1.
X-Pattern Light Head Placement
ID#4 ID#2
ID#3 ID#1
X-Pattern Sequence
ID#1> ID#4> ID#2> ID#3
Flash Patterns
Pattern Name 1 Light
Alternating 2
Lights
Silmultaneous 2
Lights
X-Pattern
4 Lights
F.P.M.
(Flashes /
Minute)
1. Quint x x x 70
2. Warp x x x 350
3. Inter-Cycle Flash x x
4. Double Flash x x x 70
5. Quad Flash x x x 80
6. PowerPulse x x x 180
7. RoadRunner x x x 113
8. Q-Switch x x
9. RoadRunner Steady
Burn
x x 113
10. Quad Steady Burn x x 80
11. E-Ideal Single Flash x x x 200
12. E-Ideal Double
Flash
x x x 146
13. Quad2 Flash x x x 67
14. Double2 Flash x x x 95
15. X-Warp x
16. X-Double x
17. PowerRunner x x x
18. LCR Quint x x x
19. Warp
3
x x x
20. Ultra Warp x x x 545
21. Thunder &
Lightning
x x
22. Lite Speed x x x 85
23. SuperSonic x x 170
24. LCR Lite Speed x x x
25. SuperSonic Ultra x x x
26. Tempo Shift x x x
27. Tempo Shift Warp x x x
28. SBE2 x x x 67
29. C
2
x x x 200
30. U
2
x x x 176
31. Ultra Glow x x x
32. Cyclone x x x
33. Chameleon x x x
GHOST® SINGLE SURFACE
MOUNT LIGHT W/ PERMANENT
MOUNT BRACKET
EGHST4(x)B-12 - Black
