7
®
SETUP TABLE
SECONDS USER INTERFACE
FROM TO VISUAL FEEDBACK ACTION TAKEN
0 1 STEADY-HIGH (60%) FORWARD ONE PATTERN
1 2 STEADY-LOW (30%) BACKWARD ONE PATTERN
2 3 OFF NO CHANGE
3 4 STEADY - HIGH (60%) SEQUENCE TYPE:
SIMULTANEOUS OR ALTERNATE
4 5 STEADY - LOW (30%) NO CHANGE
5 6 OFF RESET TO PATTERN 1
6 7 STEADY-HIGH (60%)
FACTORY RESET (PATTERN 1, COLOR SWAP:
OFF, SIMULTANEOUS)
SEPARATE COLOR CONTROL: OFF
If held longer than 7 seconds, the light will go back to ashing the current pattern
and no action will be taken.
with Clear Duty®Technology
WIRING AND TABLE INFORMATION (CONT.)
FOR THE 7X3 BACKUP LIGHT WITH WARNING ONLY
FLASH PATTERNS
PATTERN # SINGLE COLOR
1 QUINT
2 WARP
3INTER-CYCLE
4 DOUBLE
5 QUAD
6 POWER PULSE
7 ROAD RUNNER
8 Q-SWITCH
9
STEADY-BURN / ROADRUNNER
(SEQUENCE TYPE 1: STEADY BURN,
SEQUENCE TYPE 2: ROADRUNNER)
10
STEADY-BURN DRIVER TITLE 13
QUAD
(SEQUENCE TYPE 1: STEADY BURN,
SEQUENCE TYPE 2: TITLE 13 QUAD)
11 QUAD 2
12 DOUBLE 2
ADVANCE PATTERN
Flash pattern can only be changed when the LED module is in a ashing mode (disabled in cruise or steady ON functions). When the light is ashing, momentarily
connect the white wire to ground for >250mS and <1S (light will go steady high) then release. The ash pattern will advance to the next pattern. If the light module
was at the last pattern, the pattern will reset to the 1st pattern.
BACKUP PATTERN
This function is only valid when the LED module is in a ashing mode (disabled in cruise or steady ON functions). When the light is ashing, momentarily connect the
white wire to ground for >1S and < 2S (light will go steady high, steady low) then release. The ash pattern will backup to the previous pattern. If the light module
was at the rst pattern, the pattern will change to the last pattern on the list.
PATTERN RESET
This function is only valid when the LED module is in a ashing mode (disabled in cruise or steady ON functions). When the light is ashing, momentarily connect the
white wire to ground for >5S and <6S (light will go steady high, steady low, off, steady high, steady low, off) then release. The ash pattern will reset to the 1st
pattern in the list.
FACTORY RESET
This function is only valid when the LED module is in a ashing mode (disabled in cruise or steady ON functions). When the light is ashing, momentarily connect the
white wire to ground for >6S and <7S (light will go steady high, steady low, off, steady high, steady low, off, steady high) then release. The LED module will reset
to: pattern=1, Function Table=1, Color Swap=OFF, Simultaneous.
SIMULTANEOUS/ALTERNATE
This function can only be changed when the LED module is in a ashing mode (disabled in cruise or steady ON functions) and only has an effect when at least 2 LED modules have the green sync wire connected together. When the
light is ashing, momentarily connect the white wire to ground for >3S and <4S (light will go steady high, steady low, off, steady high) then release. The light module will switch between Simultaneous and Alternate each time
this sequence is done. To have light modules ash simultaneously, both light modules need to be set to the same sequence type (Set-Up Table). To have light modules ash alternately, the light modules need to be set to different
sequence types (Set-Up Table).
SYNC 2
Synchronizing the ashing of multiple light modules is accomplished by
connecting the Green wires of different light modules together. Up
to 24 light modules can be connected for synchronized ashing. All
light module ash patterns must be set to the same ash pattern # to
ensure proper operation. Refer to Sequence Type section in the Setup
Table to setup light modules to ash in alternate or simultaneous ash
pattern.
NOTE: Will NOT work with non-Sync 2 products,
such as Ghost, LED3, and 4 wire Intersector. WILL
WORK with Sync 2 products nFORCE Secondary
Lights, nFORCE FIT, and 5 wire Intersector Lights
Backup High/Low Power
To be compliant with government regulations, a
Backup Light System consisting of Dual Backup
Lights shall be operated in Low Power. A system
consisting of one Single Backup Light shall be
operated in High Power.
