Soundoff Signal BOLT2 User manual

BOLT2 LED LIGHT
E1XS2SME5(xx)
E1XS2SME5xx 0219
Pg. 1
1.800.338.7337 / www.soundoffsignal.com
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
Please see last page for Technical Specications
!
WARNING
This product contains high intensity LED devices. To
prevent eye damage, DO NOT stare into the light
beam at close range.
INSTALLATION
1. Establish a position on the vehicle on a level
surface. Orient the light output level on the
horizon.
2. Use the screw holes in the assembly as a
template to mark locations of wire and
mounting screws.
3. Use a 3/4” (19MM) diameter drill for the wire
holes.
4. Size pilot holes for mounting screws
appropriately.
5. Fasten light using mounting
screws. Do not torque mounting screws
beyond 10 in-lbs (1.13 N-m.)
WIRE HOOK-UP TABLE
WIRE COLOR: CONNECT TO:
RED +10-30 Vdc (Color 1)
YELLOW +10-30 Vdc (Color 2)
BLACK (-) Ground
WHITE
Pattern Select +Vdc/
Sync
GREEN (+) Dim/ Night Mode
•HIGH CURRENT interconnects must be properly terminated. Poor crimp quality can cause heat
build-up and fire. Follow crimp connector manufacturer instructions.
•DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to vehicle
Owner’s Manual for deployment zones.
•Unit may become hot to touch during normal operation.
•Failure to properly install connectors, fuses or wiring may cause vehicle failure or re.
•Installation must only be performed by trained technician. Installer must determine vehicle wiring
configuration and proper integration of system.
•Use proper wire gauge. All power wires connecting to positive (+) or negative (-) battery terminal
or local chassis ground (-) must be sized to supply at least 125% of max. current and properly fused at
power source.
•Install protective grommets when routing wire through rewall or metal.
WARNING

BOLT2 LED LIGHT
E1XS2SME5(xx)
E1XS2SME5xx 0219
Pg. 2
1.800.338.7337 / www.soundoffsignal.com
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning devices.
Improper use or installation may void warranty coverage.
To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product, visit our website at www.soundoffsignal.com/tech-services/returns/.
If you have questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. or after hours 5 p.m. to 8 p.m. ET at 1.800.338.7337 (press #4).
Questions or comments that do not require immediate attention may be emailed to [email protected].
SUPERIOR CUSTOMER RELATIONSHIPS. SMARTLY DESIGNED LIGHTING & ELECTRONIC SOLUTIONS.
Flash Patterns
Pattern Name ECE
Pattern SAE Pattern CA 13 Pattern
F.P.M.
(Flashes /
Second
1. Single
X X 2.08
2. Double X X 2.08
3. Quad 2 X 1.12
4. Quint X 1.18
5. Power Pulse X 3.03
6. Road Runner X X 1.89
7. Slow Runner X X 1.16
8. Steady ON N/A
TECHNICAL SPECIFICATIONS
Voltage Range 10-30Vdc
Current Draw @ 12.8Vdc 1.1 Amps
Number of LEDs Single Color: 9 LEDs
Dual Color: 18 LEDs (9x Color 1 & 9x Color 2)
Flash Patterns 8
Operating Temperature -40C to +65C
Dimensions (5.5” L x 1.6” H x 0.48” D)
140mm L x 41mm H x 12.2mm D
Mounts Surface Mount
Certications
ECE R65 Category X, Class 2 Amber, Blue, Red
SAE J595 Class 1, Red, Blue, Amber, White
CA Title 13 Table I, Class B, Red, Blue, Amber
ECE R10
Warranty 3 Year
OPERATING INSTRUCTIONS
Connect the Red / Yellow wire to switched (+) power, Black wire
to (-) Ground and all White wires from all lights together that
will be sync’d.
PATTERN RESET
Momentarily touch the White wire to (+) power for ≥5sec.
PATTERN SELECT
With light powered, touch White wire to Red Power wire for 1
second.
LOW POWER DIMMING OR NIGHT MODE
Connect the Red / Yellow wire to (+) power then connect Green
wire to (+) power to put light into Dim or Low Power mode.
SIMULTANEOUS / ALTERNATING MODE SELECT
(When synchronizing more than one light)
Connect Red wire to (+) power so light is ashing, then
Momentarily hold the White wire to (+) power for >2sec,
<4sec to toggle between Simultaneous and Alternating sync
modes.
Color 2 Flashing / Steady Mode Select
Connect Yellow wire to (+) power so light is ashing or steady
ON, then Momentarily hold the White wire to (+) power for
>2sec, <4sec to toggle between Flashing and Steady Modes
for Color 2.
