Soundoff Signal P Series User manual

9X7 P SERIES WARNING 0722 REV A
1.800.338.7337 / www.soundo󰀨signal.com
P SERIES WARNING LIGHT
EPSSE0TF(X)-(X) -- 9X7 Screw Mount, & Stud Mount
• HIGH CURRENT interconnects must be properly terminated. Poor crimp
quality can cause heat build-up and fire. Follow the crimp connector
manufacturer instructions.
• DO NOT install this product or route any wires in the Air Bag Deployment
Zone. Refer to vehicle Owner’s Manual for deployment zones.
• Do NOT use system to disconnect headlights, brake lights or other safety
equipment.
• Unit may become hot to touch during normal operation.
• Failure to properly install connectors, fuses or wiring may cause vehicle
failure or fire.
• Installation must only be performed by trained technician. Installer must
determine vehicle wiring configuration and proper integration of system.
• Use proper wire gauge. All power wires connecting to positive (+) or
negative (-) battery terminal or local chassis ground (-) must be sized to
supply at least 125% of max. current and properly fused at power source.
• Install protective grommets when routing wire through firewall or metal.
• Petroleum/silicone based lubricants will cause the silicone lens to discolor.
WARNING
!
ROUTE WIRES ONLY IN LOCATIONS THAT ARE NOT SUBJECTED TO
POTENTIAL WEAR. MAKE SURE TO AVOID ROUTING WIRES IN THE
DEPLOYMENT AREA OF YOUR AIR BAG. REFER TO YOUR VEHICLE'S
OWNER'S MANUAL FOR AIRBAG DEPLOYMENT ZONES.
WARNING
Protected by U.S. Patent 10,703,260 and Patents Pending
https://soundoffsignal.com/legal/patent-notification/
DIMENSIONS . . . . . . . . . . . . . . . . . . 2
WARNING LIGHT OPTIONS . . . . . . . 2
TECHNICAL SPECIFICATIONS . . . . . . 3
WIRING INFORMATION . . . . . . . . 4-6
STUD MOUNT INSTALLATION . . . . . 7
SCREW MOUNT INSTALLATION . . . . 8-9
RETENTION CLIP INSTRUCTIONS . . . 10
NOTICE:
Installers and users must comply with all applicable federal, state and local laws regarding use and installation of warning
devices. Improper use or installation may void warranty coverage.To review our Limited Warranty Statement & Return Policy
for this or any SoundO Signal product, visit our website at www.soundosignal.com/tech-services/returns/. If you have
questions regarding this product, contact Technical Services, Monday - Friday, 8 a.m. to 5 p.m. ET at 1.800.338.7337 (press
#4). Questions or comments that do not require immediate attention may be emailed to techservices@soundosignal.com.
ENHANCING SAFETY THROUGH INNOVATION

1.800.338.7337 / www.soundo󰀨signal.com
29X7 P SERIES WARNING 0722 REV A
9.06”
7.25”
1.23”
0.74” 0.46”
DIMENSIONS & BEZEL INFORMATION:
9x7 DIMENSIONS WITHOUT BEZEL
0.74”
9.62”
7.79”
1.32”
0.44”
9x7 DIMENSIONS WITH BEZEL
FIG. 1
FIG. 2
WARNING LIGHT OPTIONS:
9x7 LED OPTIONS
• Single Color
9x7 LED COLOR OPTIONS
• Red • White
• Amber • Green
• Blue
9x7 LENS COLOR OPTIONS
• Red • Clear
• Amber • Green
• Blue
9x7 CERTIFICATIONS
• SAEJ595 • NFPA 1901-2009
• California Title 13 • KKK-A-1822 (July 2021)
9x7 MOUNTING OPTIONS
• Stud Mount
• Screw Mount
9x7 AVAILABLE FLASH PATTERNS
• Double* • Quint*
• Double 2* • Random 1
• Inter-cycle • Random 2
• Power Pulse* • Road Runner*
• Q-switch • Steady-Burn Driver Title 13 Quad
• Quad* • Steady-Burn/Road Runner
• Quad 2* • Warp
• Quad Pulse-pop*
*Certified Flash Patterns
PART NUMBERS (UNCONFIGURED)
• 9x7 - EPSSC0J XX-X**
**See SoundOff Signal configurator or sales representative
for specific color, lens, and mounting options.

1.800.338.7337 / www.soundo󰀨signal.com
39X7 P SERIES WARNING 0722 REV A
TECHNICAL SPECIFICATIONS:
9x7 P SERIES WARNING LIGHT
TECHNICAL SPECIFICATIONS
Input Voltage: 9-32Vdc
WARNING LIGHT CURRENT
CONSUMPTION (Amps)
12.8Vdc 25.6Vdc
Peak Average Peak Average
Red 1.90 0.95 0.95 0.48
Amber, Blue,
Green, or White 2.20 1.10 1.10 0.55
AFTER POWER IS ON, touching the WHITE wire to the ground
will allow you to change various settings on the module.
(Refer to page 4)

1.800.338.7337 / www.soundo󰀨signal.com
49X7 P SERIES WARNING 0722 REV A
WIRING AND TABLE INFORMATION:
OVER-VOLTAGE PROTECTION
When an over-voltage condition is detected, the module will flash an overvolt-
age warning pattern of 50mS ON/950mS OFF to alert of the overvoltage condi-
tion and protect the electronics from damage due to heat/voltage.
THERMAL COMPENSATION PROTECTION
The LED module is designed to provide maximum power output while provid-
ing protection to the electronic components by reducing the output power at
extreme temperatures.
SYNC 2
Synchronizing the flashing of multiple light modules is accomplished by con-
necting the Green wires of different light modules together. Up to 24 light
modules can be connected for synchronized flashing. All light module flash
patterns must be set to the same flash pattern # to ensure proper operation.
Refer to the Sequence Type section in Set-Up Table (page 8) to setup light
modules to flash in alternate or simultaneous flash pattern. NOTE: Will NOT
work with non-Sync 2 products such as Ghost, LED3, and 4 wire Intersector.
WILL WORK with Sync 2 products nFORCE Secondary Lights, nFORCE FIT and 5
wire Intersector Lights.
REMOTE MODE: For use with bluePRINT® system only
Connecting the Green wire to ground before applying power to the Red or
Orange wires will place the LED module into remote mode and the light output
color will be directly controlled by the input wires as shown below. For Cruise
mode or Low Power control of the LED module, the signal to the control wires
must be 100 +/- 2Hz using the duty cycle inputs listed below to produce the
light output.
WIRE HOOK-UP TABLE
WIRE COLOR: FUNCTION:
RED Power (Primary)
BLACK Ground
GREEN** Sync2 *
WHITE to GROUND Setup Wire (See pg. 6*)
WHITE to POWER Function Wire
ORANGE Power (Secondary)
** To sync multiple mPower lights, connect the Green
wire from each light together.
* Will NOT work w/ other sync products such as Ghost,
LED3, & 4 wire Intersector w/external flasher
* Will Work with Sync 2 products nFORCE Secondary
Lights, nFORCE FIT and 5 wire Intersector Lights.
BLACK
RED
WHITE
GREEN
Sync
Set-up/Function
ORANGE
+Vd c
A FUSE
5
+Vd c
+Vd c
A FUSE
5
CERTIFICATION APPLICABLE
COLORS
SAEJ595 Red, Amber, Blue,
White, Green
CALIFORNIA TITLE 13 Red, Amber, Blue
NFPA 1901-2009 Red, Amber, Blue,
White
KKK-A-1822F (JULY 2021) Red, Amber, Blue,
White, Green
Lights are chassis-grounded. If you need to
ground-switch the light, you must isolate the lights
metal backing, heatsink, studs and/or screws from
the body of the vehicle or use a relay.
*CA13 AMBER is met in Low Power Only
FIG. 3
FLASH PATTERNS CERTIFICATIONS
PATTERN
#SINGLE COLOR FLASHES PER MINUTE
HIGH
POWER
LOW
POWER
1 QUINT 70 SAE, KKK SAE, KKK
2 WARP 360 NA NA
3 INTER-CYCLE - NA NA
4 DOUBLE 70 SAE, KKK SAE, KKK
5 QUAD 80 SAE, NFPA,
KKK
SAE, NFPA,
KKK
6 POWER PULSE 180 SAE, NFPA,
KKK
SAE, NFPA,
KKK
7 ROAD RUNNER 118 SAE, CA13*,
NFPA, KKK
SAE, CA13*,
NFPA, KKK
8 Q-SWITCH - NA NA
9
STEADY-BURN / ROADRUNNER
(SEQUENCE TYPE 1: STEADY
BURN, SEQUENCE TYPE 2:
ROADRUNNER)
- / 118 NA NA
10
STEADY-BURN DRIVER TITLE
13 QUAD (SEQUENCE TYPE
1: STEADY BURN, SEQUENCE
TYPE 2: TITLE 13 QUAD)
- / 65 NA NA
11 QUAD 2 67 SAE, KKK SAE, KKK
12 DOUBLE 2 95 SAE, NFPA,
KKK
SAE, NFPA,
KKK
13 RANDOM 1 - NA NA
14 RANDOM 2 - NA NA
15 QUAD PULSE-POP 75 SAE, CA13*,
NFPA, KKK
SAE, CA13*,
NFPA, KKK

1.800.338.7337 / www.soundo󰀨signal.com
59X7 P SERIES WARNING 0722 REV A
WIRING AND TABLE INFORMATION (CONT.):
FUNCTION TABLES
The functional operation of the LED module can be changed while
applying the +V to the Red wire with the Black wire connected
to ground. When the light is flashing, momentarily connect the
White wire to ground for >4S and <5S (light will go steady high,
steady low, off, steady high, steady low) then release. The function
table will now advance to the next table (table 1 to table 2, table
2 to table 3, table 3 to table 4, or table 4 to table 1. In the case
that the custom table is programmed, the order is 1 to 2, 2 to 3,
3 to 4, or 4 to 7 (custom), and 7 to 1.) Repeat above process until
required function table is active.
AFTER SELECTION
The light will "wink" to indicate which of the new tables is
selected. Custom table will "wink" 7 times.
EXAMPLE:
If the light is using Function Table 2 with the Orange
wire to power, which steady burns color 2, and you then apply the
White wire to ground, to change the Function Table to number 3,
this would cause the light to start flashing dual low power.
FUNCTION TABLE 1
WIRE LIGHT
RED ORANGE WHITE SINGLE
+9-32V - - FLASH
- +9-32V - CRUISE
+9-32V +9-32V - FLASH
- - +9-32V NO OP
+9-32V - +9-32V LOW PWR FLASH
- +9-32V +9-32V CRUISE
+9-32V +9-32V +9-32V LOW PWR FLASH
FUNCTION TABLE 2
WIRE LIGHT
RED ORANGE WHITE SINGLE
+9-32V - - FLASH
- +9-32V - STEADY COLOR 1
+9-32V +9-32V - STEADY COLOR 1
- - +9-32V NO OP
+9-32V - +9-32V CRUISE
- +9-32V +9-32V STEADY COLOR 1
+9-32V +9-32V +9-32V STEADY COLOR 1
FUNCTION TABLE 3
WIRE LIGHT
RED ORANGE WHITE SINGLE
+9-32V - - FLASH
- +9-32V - LOW PWR FLASH
+9-32V +9-32V - LOW PWR FLASH
- - +9-32V NO OP
+9-32V - +9-32V LOW PWR FLASH
- +9-32V +9-32V LOW PWR FLASH
+9-32V +9-32V +9-32V LOW PWR FLASH
FUNCTION TABLE 4
WIRE LIGHT
RED ORANGE WHITE SINGLE
+9-32V - -
- +9-32V -
+9-32V +9-32V -
- - +9-32V
+9-32V - +9-32V
- +9-32V +9-32V
+9-32V +9-32V +9-32V

1.800.338.7337 / www.soundo󰀨signal.com
69X7 P SERIES WARNING 0722 REV A
CRUISE MODE DUTY CYCLE
(@ 100HZ)
INPUT LIGHT OUTPUT
40% OFF
50% 5%
60% 10%
LOW POWER FLASH D.C.
(@ 100HZ)
INPUT LIGHT OUTPUT
70% 30%
80% 40%
90% 50%
WIRING AND TABLE INFORMATION (CONT.):
COLOR SWAP
This function is only valid for dual and tri-color warning light mod-
ules and can only be changed when the light module is in a flash-
ing mode (disabled for single color modules and when light mod-
ule is operating in cruise or steady ON functions). When the light
is flashing, momentarily connect the white wire to ground for >2S
and <3S (light will go steady high, steady low, off) then release.
The light module will switch between Color Swap OFF and Color
Swap ON. When Color Swap is OFF, the 1st color will flash 1st on
a dual/tri color pattern. When Color Swap is ON, the 2nd color will
flash 1st on a dual/tri color pattern.
SIMULTANEOUS/ALTERNATE
This function can only be changed when the LED module is in a
flashing mode (disabled in cruise or steady ON functions) and only
has an effect when at least 2 LED modules have the green sync
wire connected together. When the light is flashing, momentarily
connect the white wire to ground for >3S and <4S (light will go
steady high, steady low, off, steady high) then release. The light
module will switch between Simultaneous and Alternate each time
this sequence is done. To have light modules flash simultane-
ously, both light modules need to be set to the same sequence
type (Set-Up Table). To have light modules flash alternately, the
light modules need to be set to different sequence types (Set-Up
Table).
ADVANCE PATTERN
Flash pattern can only be changed when the LED module is in a
flashing mode (disabled in cruise or steady ON functions). When
the light is flashing, momentarily connect the white wire to ground
for >250mS and <1S (light will go steady high) then release. The
flash pattern will advance to the next pattern. If the light module
was at the last pattern, the pattern will reset to the 1st pattern.
BACKUP PATTERN
This function is only valid when the LED module is in a flashing
mode (disabled in cruise or steady ON functions). When the light
is flashing, momentarily connect the white wire to ground for >1S
and < 2S (light will go steady high, steady low) then release. The
flash pattern will backup to the previous pattern. If the light mod-
ule was at the first pattern, the pattern will change to the last pat-
tern on the list.
PATTERN RESET
This function is only valid when the LED module is in a flashing
mode (disabled in cruise or steady ON functions). When the light
is flashing, momentarily connect the white wire to ground for >5S
and <6S (light will go steady high, steady low, off, steady high,
steady low, off) then release. The flash pattern will reset to the 1st
pattern in the list.
FACTORY RESET
This function is only valid when the LED module is in a flashing
mode (disabled in cruise or steady ON functions). When the light
is flashing, momentarily connect the white wire to ground for >6S
and <7S (light will go steady high, steady low, off, steady high,
steady low, off, steady high) then release. The LED module will
reset to: pattern=1, Function Table=1, Color Swap=OFF, Simul-
taneous.
LOCKOUT CONFIGURATION WIRE
This function will disable the wire tap configuration mode that
is activated by holding the white wire to ground. The lock out is
activated by applying ground to the white wire for >7 seconds and
<8 seconds per the table below. The function can be disabled by
tapping the wire to ground and releasing 8 times within 5 seconds.
The light will flash 8 times when the feature is enabled or disabled
to notify the user of a setting change.
9X7 P SERIES LED LIGHT
REMOTE MODE FUNCTIONALITY
RED WIRE ORANGE
WIRE
SINGLE COLOR
COLOR
SWAP = OFF
COLOR
SWAP = ON
CRUISE - CRUISE COLOR 1 -
- CRUISE - -
CRUISE CRUISE - -
FLASH - FLASH COLOR 1 -
- FLASH - -
FLASH FLASH - -
STEADY ON - STEADY ON
COLOR 1 -
- STEADY ON - -
STEADY ON STEADY ON - -
CRUISE FLASH - -
CRUISE STEADY ON - -
Flash Steady ON - -
SETUP TABLE
SECONDS USER INTERFACE
FROM TO VISUAL FEEDBACK ACTION TAKEN
0 1 STEADY-HIGH (60%) FORWARD ONE PATTERN
1 2 STEADY-LOW (30%) BACKWARD ONE PATTERN
2 3 OFF COLOR SWAP (OFF OR ON )
3 4 STEADY - HIGH (60%) SEQUENCE TYPE: SIMULTANEOUS OR
ALTERNATE
4 5 STEADY - LOW (30%) SEE FUNCTION TABLE
5 6 OFF RESET TO PATTERN 1
6 7 STEADY-HIGH (60%)
FACTORY RESET (PATTERN 1, COLOR
SWAP: OFF, SIMULTANEOUS) SEPARATE
COLOR CONTROL: OFF
7 8 STEADY - LOW (30%) LOCK OUT WHITE CONFIGURATION WIRE
If held longer than 8 seconds, the light will go back to flashing
the current pattern and no action will be taken.

1.800.338.7337 / www.soundo󰀨signal.com
79X7 P SERIES WARNING 0722 REV A
4 “
1
|
2
2 “
1
|
4
Ø “
3
|
4
1
|
4
6X Ø “
DRILL FOR STUD MOUNT
DRILL FOR WIRE EXIT
3”
6”
STUD MOUNT INSTALLATION:
FIG. 4
9X7 STUD MOUNT LIGHT PICTURED (NO BEZEL)
FIG. 5
NOT TO SCALE, FOR REFERENCE ONLY
1. Drill (6) 1/4" holes to mount light and 3/4" wire hole (see Fig. 5).
2. Thread studs into the back of light.
3. Align the gasket to the mounting surface. Horizontal and vertical
orientations are indicated on gasket for proper seal.
4. Press light assembly against gasket, against mount surface.
5. Secure the light to mounting surface using (2) supplied nuts, on
the back side of vehicle mount surface.
NOTE: Tighten until gasket is compressed. DO NOT over tighten
and strip casting threads. DO NOT USE POWER TOOLS TO
TIGHTEN.
6. Plug the wire harness into the back of the light. Reference page
10 for retention clip installation.
9X7 STUD MOUNT LIGHT PICTURED (WITH BEZEL)
FIG. 6
STUD MOUNT (WITH BEZEL) INSTALLATION:
1. Drill (6) 1/4" holes to mount light and 3/4" wire hole (see Fig. 5).
2. Thread studs into the back of light.
3. Place (4) adapter castings into back of light.
4. Place bezel over front of light.
5. Insert (4) screws through bezel, light, and into adapter castings.
Tighten to secure bezel to light.
6. Align the gasket to the mounting surface. Horizontal and vertical
orientations are indicated on gasket for proper seal.
7. Press light/bezel assembly against gasket, against mount surface.
8. Secure the light to mounting surface using (2) supplied nuts, on
the back side of vehicle mount surface.
NOTE: Tighten until gasket is compressed. DO NOT over tighten
and strip casting threads. DO NOT USE POWER TOOLS TO
TIGHTEN.
9. Plug the wire harness into the back of the light. Reference page
10 for retention clip installation.

1.800.338.7337 / www.soundo󰀨signal.com
89X7 P SERIES WARNING 0722 REV A
SCREW MOUNT (SOUNDOFF STANDARD) INSTALLATION:
DRILL FOR WIRE EXIT
Ø “±0.02
3
|
4
4X DRILL
Ø “±0.010
5
|
16
8 “
3
|
8
4 “
3
|
16
3
“
9
|
32
6
“
9
|
16
FIG. 8
NOT TO SCALE, FOR REFERENCE ONLY
9X7 SCREW MOUNT TEMPLATE (SOUNDOFF STANDARD)
FIG. 7
9X7 SCREW MOUNT LIGHT PICTURED (SOUNDOFF STANDARD)
1. Drill for SoundOff Signal mount pattern. Reference Fig. 8 for
hole sizes.
2. Place Bezel over light.
3. Place Bezel and light onto gasket.
4. Insert supplied screws through the bezel, light, and gasket.
5. Place flat washers onto inserted screws.
6. Secure bezel and light together by attaching the well nuts to the
screws. Hold the screws in place and hand tighten the well nuts
against the flat washers to secure. Ensure the lip of the bezel is
properly seated in the gasket.
7. Pull the wire harness through the opening and plug into the back
of the light (see wiring diagram). Reference page 10 for retention
clip installation.
8. Secure the entire light assembly to the mounting surface. Insert
the well nuts into the drilled holes and tighten to 7 turns past full
contact.
NOTE: Tighten until gasket is compressed. DO NOT over tighten.
DO NOT USE POWER DRIVER. Horizontal and vertical orientations
indicated on gasket for proper drainage.

1.800.338.7337 / www.soundo󰀨signal.com
99X7 P SERIES WARNING 0722 REV A
4X DRILL
Ø “±0.010
5
|
16
DRILL FOR WIRE EXIT
Ø “
3
|
4
7 “
1
|
4
3 “
5
|
8
2
“
5
|
8
5
“
1
|
4
FIG. 10
NOT TO SCALE, FOR REFERENCE ONLY
9X7 SCREW MOUNT TEMPLATE (LEGACY STANDARD)
FIG. 9
9X7 SCREW MOUNT LIGHT PICTURED (LEGACY STANDARD)
SCREW MOUNT (LEGACY STANDARD) INSTALLATION:
1. Drill for Legacy Standard hole pattern. Reference Fig. 8 for hole
sizes.
2. Insert well nuts into drilled holes, fully seat to mount surface.
3. Align gasket to mount surface (note horizontal and vertical ori-
entations indicated on gasket for proper seal).
4. Place (4) adapter castings into gasket openings.
5. Insert (4) screws through (4) adapter castings into (4) wash-
ers and (4) well nuts and tighten to secure to vehicle surface.
Tighten to 7 turns past full contact (Press screw into well nut to
improve bite and prevent spinning. Hand tighten until well nut
is secure).
6. Pull the wire harness through the opening and plug into the back
of the light (see wiring diagram). Reference page 10 for retention
clip installation.
7. Place light into gasket, pressing light and gasket against mount
surface.
8. Place bezel over light.
9. Secure the bezel/light mount surface using (4) supplied screws.
Tighten to 1/8 turn past full contact.
NOTE: Tighten until gasket is compressed. DO NOT over tighten.
DO NOT USE POWER DRIVER. Horizontal and vertical orientations
indicated on gasket for proper drainage.

1.800.338.7337 / www.soundo󰀨signal.com
10 9X7 P SERIES WARNING 0722 REV A
WINDOW
TAB RETAINER
LOCKING ARM
FULLY SEATED RETENTION CLIP
FIG. 11
FIG. 13 FIG. 14
FIG. 12
NOTE: In the event the harness needs to be disengaged from the light, these instructions can be used to
reattach and apply the retention clip.
1. Plug harness into light housing, aligning tab to window, as shown in Fig 13.
2. Install the retainer clip over harness/light interface, inserting retainer into window, as shown in Fig. 14.
3. Press retainer clip's locking arm to snap closed.
RETENTION CLIP INSTRUCTIONS:
