Soundoff Signal SINGLE GHOST EGHST2 User manual

To review our Limited Warranty Statement & Return Policy for this or any SoundOff Signal product please visit our website at www.soundoffsignal.com and select the “Warranty & Returns”
link along the left column of our home page. If you have questions regarding this product please contact Technical Services, Monday - Friday, 8 am to 5 pm at 1.800.338.7337, press #4 to
skip the automated message. Questions or comments that do not require immediate attention may be emailed to [email protected].
1.800.338.7337. / www.soundoffsignal.com / Thank you for trusting us with your safety!
• Warning devices are strictly regulated and governed by Federal, State and Municipal ordinances.
These devices shall be used ONLY on approved vehicles. It is the sole responsibility of the user of these
devices to ensure compliance.
• DO NOT install this product or route any wires in the Air Bag Deployment Zone. Refer to your vehicle
Owner’s Manual for the location of any air bag deployment zones.
• DO NOT connect this device to a strobe power supply. This product is self-contained and does not
require an external power supply.
EGHST2(xx) 7.09
Important Information:
OPERATION:
WIRE CONNECTIONS
See setup procedure on second page.
The single GHOST™ comes equipped with
an internal flasher with 33 user selectable
patterns that can be synchronized either
alternating or simultaneous with up to three
other lights. It can also be put into slave
mode and driven through an external flasher.
1. Connect the GHOST™ BLACK wire to a
good, convenient ground.
2. Connect the GHOST™ RED wire to one
side of a user supplied on/off switch.
Connect the other side of the switch,
through a 5Amp fuse, to a source of
+10-30Vdc.
NOTE: The GHOST™ is a factory sealed
unit that CANNOT be serviced in the
field. Any attempt to gain access to the
GHOST™ unit will most likely cause per-
manent damage and void its warranty.
INSTALLATION:
Establish a position on the vehicle. Use
the gasket (provided) as a template
to drill ½” wire hole and pilot holes
for mounting screws. Note: pilot holes
are 4-7/8” on center. Caution: Do not
stretch gasket as this may change
the required hole spacing.
SINGLE GHOST™ LED SURFACE
MOUNT WARNING LIGHT
EGHST2(x) - Black
EGHST2(x)C - Chrome
EGHST2(x)W - White
WIRE HOOK-UP TABLE
WIRE COLOR: CONNECT TO:
RED +10-30Vdc
BLACK Ground (-)
WHITE Pattern Select
This product contains high
intensity LED devices. To prevent
eye damage, DO NOT stare into
light beam at close range.
WARNING
!
TECHNICAL
SPECIFICATIONS
Overall
Dimensions:
5.65”L x 1.06”H
x 1.8”D
Input Voltage
Range:
10-30Vdc
Current
Consumption:
<1 amp
# of LEDs: 6 Generation 3
LEDs
Operating
Temperature:
-40º to +65º C
# of Flash
Patterns
33

EGHST2(xx) 7.09
1 SINGLE LIGHT
Follow the ID selection steps and set the GHOST™ to the
following ID:
- Alternating (default): ID#1 or ID#3. (inludes cycle patterns
and steady burn patterns)
- Simultaneous: ID#2 or ID#4. (both lights will flash together
regardless of pattern)
2 SINGLE LIGHTS
Follow the ID selection steps and set the GHOST™ to the
following ID:
***IMPORTANT: Make sure both lights flash the same
pattern!***
- Both assemblies simultaneous with individual lights
alternating.
- Example: Driver/Passenger sim; Dr.(left alt right)
Pass.(left alt right)
- Set both GHOST™ Assemblies to ID#1
- Both assys. alternating with individual lights alternating.
- EX: Dr./Pass. alt; Dr.(left. alt. right.) Pass.(right alt. left)
- Set one GHOST™ to ID#1 and the other to ID#3
- Both assys. alternating with individual lights simultaneous
- EX: Dr./Pass. alt; Dr.(left sim left) Pass.(right sim right)
- Set one GHOST™ to ID#2 and the other to ID#4
- Both assys. simultaneous with individual lights simultaneous.
- EX: Dr./Dr. sim; Dr.(left sim left) Pass.(right sim right)
- Set both GHOST™ housings to ID#2
X-PATTERN - To obtain X-Patterns, follow the ID SELECTION steps
and set one of the four GHOST™ lights to ID#1, one to ID#2,
one to ID#3, and one to ID#4. Then proceed to the PATTERN
SELECTION steps.
NOTE: Be sure to mount each GHOST™ in the correct placement
based on ID#.
PATTERN SELECTION
1. Disconnect WHITE wire from any connections if applicable.
2. Turn GHOST™ ON.
3. Momentarily touching and removing the WHITE wire(s) to
ground will advance the GHOST™ to the next flash pattern.
Touching and removing the White wire for more than a few
seconds will allow you to change the GHOST™ to the previous
pattern. See flash pattern table. Continuing to touch and
remove the WHITE wire(s) to ground will allow you to scroll
through the pattern list. After pattern #33 is reached the list
will start over again at pattern #1.
X-PATTERN SEQUENCE X-PATTERN LIGHT HEAD PLACEMENT
ID#1>ID#4>ID#2>ID#3
NOTE: The GHOST™ is equipped with flash pattern memory. Once you
have selected a pattern the GHOST™ will always activate to that pat-
tern every time the unit is turned on. Tape up and secure WHITE wire
so that it will not accidentally change your selected pattern.
GHOST™ Sync Configuration Instructions
IMPORTANT! A MAXIMUM OF 2 DUAL LIGHTS
CAN BE SYNCED TOGETHER
1. Set ID#
a. Identify which pattern and sequence you want and look up
ID# settings at left.
b. Connections
i. RED: +10-30Vdc
ii. WHT: +10-30Vdc (Note: you will need to disconnect
after power is applied)
iii. BLK: Ground
c. Apply power to unit
d. Without disconnecting power from unit, disconnect WHT
wire
e. Momentarily connect WHT to Ground to change ID #
i. Identify ID# by number of sequential flashes
ii. Possible ID#s: 1 – 4
f. Disconnect power from unit to get out of ID mode.
2. Set Pattern
a. Reapply power to units.
b. Once all Light Head ID#s are configured, make sure all
lights
are flashing the same pattern.
c. Connect corresponding solored wires of all units together:
RED to RED, etc.
d. Change Pattern
i. Momentarily connect WHT wires to Ground
ii. Observe pattern change on all lights connected
e. Insulate all wires by taping with electrical tape
3. Connect Master Switch for Application
a. IMPORTANT! Ensure WHT Pattern/Sync Wires are tied
together
SLAVE MODE
The GHOST™ is capable of being activated through the use of a
user supplied flasher by putting it in slave mode.
1. Permanently connect the GHOST™ WHITE and BLACK wire to a
good, convenient ground.
2. Connect the GHOST™ RED wire, through a 5Amp fuse, to the
output of a +10-30Vdc switching flasher.
PATTERN RESET
1. Remove power
2. Place WHITE (sync) wire to ground
3. With sync wire grounded, re-power RED wire
4. Maintain for one second (light will dim)
5. Remove power and ground (pattern 1 set)
SINGLE GHOST™ LED SURFACE
MOUNT WARNING LIGHT
ID#4 ID#2
ID#3 ID#1
Flash Patterns
Pattern Name 1 Light Alternating 2 Lights
Silmultaneous
2 Lights
X-Pattern
4 Lights
F.P.M.
(Flashes /
Minute)
1. Quint
xx x 70
2. Warp x x x 350
3. Inter-Cycle Flash xx
4. Double Flash xx x 70
5. Quad Flash xx x 80
6. PowerPulse™ x x x 180
7. RoadRunner™ x x x 113
8. Q-Switch™ xx
9. RoadRunner™
Steady Burn
x x 113
10. Quad Steady
Burn
xx 80
11. E-Ideal Single
Flash
x x x 200
12. E-Ideal Double
Flash
x x x 146
13. Quad2 Flash xx x 67
14. Double2 Flash xx x 95
15. X-Warp x
16. X-Double x
17. PowerRunner xx x
18. LCR Quint xx x
19. Warp3 xx x
20. Ultra Warp x x x 545
21. Thunder &
Lightning
xx
22. Lite Speed xx x 85
23. SuperSonic x x 170
24. LCR Lite Speed xx x
25. SuperSonic
Ultra
xx x
26. Tempo Shift xx x
27. Tempo Shift
Warp
xx x
28. SBE2 xx x 67
29. C2 x x x 200
30. U2 x x x 176
31. Ultra Glow xx x
32. Cyclone xx x
33. Chameleon xx x
