Spectrum Industries 37137 User manual

Tools Required
Phillips
Screwdriver
7/16”
Wrench
Assembly Instructions
0190576R1 Page 1 of 2
Assembly Instructions
Important
Before you begin, read and comply with all safety and operating instructions,
and ensure all parts and correct quantities are included.
Any parts damaged during shipment must be reported within 5 days of receipt.
To report information regarding missing parts or damage, to purchase parts
or accessories, or if you have any questions, please contact us.
www.spectrumfurniture.com
800-235-1262, 715-723-6750
Thank you for purchasing Spectrum products!
Flip-up Shelf for 3D2GO™Printer Cart
37137
1. Installation
1. Determine the side of the unit the shelf will go on. (Left or right).
2. Align each channel bracket with the leg mounting holes. Figure 1.
(The two sets of 3 smaller holes will face outward.)
3. Install (1) 1/4-20 x 5/8” PHM screw at the top of each bracket.
4. Install (1) 1/4-20 x 2-1/2” PHM screw and Keps nut on the bottom
of each bracket.
Figure 1
(2) 026064
1/4-20 x 5/8”
PHMS
(2) 0106543
1/4-20 Keps nut
(1) 039622
2” Grommet
(2) 0190564
1/4-20 x 2-1/2”
PHMS
(4) 0100167
8-32 x 1/2” PH
Thread-cutting
screw
Note: Only one ip-up shelf, or one
handle will attach to each side-not
both at the same time.
(1) 0119425
Worksurface
(2) 056886
Shelf bracket
(2) 0135022
Channel bracket
(2) 0109646
Shelf shim
(8) #8 x 1”
PHSM screw
Flip-up Shelf Assembly
Channel Bracket
1/4-20 Keps nut
1/4-20 x 2-1/2” PHMS
1/4-20 Keps nut
1/4-20 x 2-1/2” PHMS
1/4-20 x 5/8” PHMS
1/4-20 x 5/8” PHMS
Leg
Leg
Channel Bracket

0190576R1 Page 2 of 2
925 FIRST AVENUE, CHIPPEWA FALLS, WI 54729 / 800-235-1262 / 715-723-6750 / WWW.SPECTRUMFURNITURE.COM
© 2018 Spectrum Industries Inc., All rights reserved.
2. Attach Flip-up shelf assembly
1. Extend both shelf brackets fully.
2. Align the brackets with both sets of “tri-holes” as shown.
3. Attach the shelf with (4) 8-32 x 1/2” PH thread-cutting screws using
the holes shown. Figure 2.1 and Figure 2.2.
4. Tighten screws securely.
5. Install 2” grommet.
Figure 3
3. Operation
The shelf will automatically lock into place when lifted into the horizontal
position with the levers released. Figure 3. To lower or ip-up the shelf,
press and hold the levers under each folding shelf bracket at the same
time while slowly lowering or raising the shelf. Do not exceed a maximum
of 25 lb of weight on the shelf. Do not move the unit while the shelf is in
the horizontal position.
Note: Wiring for document cameras or laptop computers placed on the
ip-up shelf should be routed on top of the audience-side of the shelf.
Use of the shelf grommet hole for wiring will result in pinching of the
cords when the shelf is folded.
CAUTION
Keep clear of pinch points during shelf movement.
Do not exceed 25 lb [11.35 kg] of weight on shelf.
Release lever
(press here)
Figure 2.2
Upper right hole
Upper hole
2” Grommet
Flip-up shelf assembly
(4) 8-32 x 1/2” PH
Thread-cutting screws
Left Bracket Right Bracket
Figure 2.1
