Spectrum Industries InVision User manual

with optional
Pedestal Riser
InVision Active Learning
POD System
Owner’s Manual
0114246R1 Page 1 of 12
CAUTION:
Before using this product, read this manual and follow
all safety and operating instructions.
Before you begin, please make sure all parts and
proper quantities are included. Any parts damaged
during shipment must be reported within 15 days of
receipt. To report information regarding damages or if
you have any questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
Chippewa Falls, WI 54729, USA
37109 Table
37110 Center Pedestal
37111 Pedestal Riser
37112 Modesty Panel
InVision Active Learning POD System™

(1) 025069
caster/glide wrench
Safety
Hardware Package Contents
0114246R1 Page 2 of 12
• Read this owner’s manual before assembling or using this table.
• Do not sit or allow students to sit on top of table.
• Do not allow children to move table.
• Move tables slowly and carefully when mobile.
(1) 0113973
worksurface
(4) 0113974
leg
(2) 0113978
leg bracket
(4) 026038
5/16-18 x 5/8” bell glide
(26) 026064
1/4-20 x 5/8” PHMS
(3) Table Parts Bag
(1) 037749
Unit-to-unit bracket
(4) 0105662
stem caster
Modesty Panel Parts Bag37112 - Modesty Panel
(1) 0114258
modesty panel
(2) 026064
1/4-20 x 5/8” PHMS
(2) 0101382
#14 x 7/8” PHSM
37109 - Table
• Keep ngers and hands away from the table edges when moving
to prevent pinching.
• For indoor use only. Do not install or store the unit where it will be
exposed to weather. Keep unit dry.
Note: The items shown here represent all the structural components available for the InVision Active Learning POD System. Some of the items shown
may not be included with your particular unit-some assembly steps may not apply. Before beginning assembly, please review these instructions.

Pedestal Riser Parts Bag
(12) 026064
1/4-20 x 5/8” PHMS
(3) 059984
2.5” Snap-in grommet
(6) 041289
1/4-20 x 1-3/4” PHMS
(6) 0102063
1/4-20 x 35mm JC bolt
37111 - Pedestal Riser
(1) 025039
4mm hex wrench
(1) 025069
caster/glide wrench
0114246R1 Page 3 of 12
(3) 0114243
corner columns
(3) 0114244
instrument
panel
(1) 0114245
open panel
Parts Bag
(3) 037779
5/16-18 x 1” glide
(20) 026064
1/4-20 x 5/8” PHMS
(3) 039622
2” grommet
(15) 0100167
8-32 x 1/2” PH thread
cutting screw
(3) 0113961
oor mount bracket
(3) 041943
1/4-20 locknut
(3) 0113960
corner column
(1) 0113967
door assembly
(1) 0113964
door stop bracket
(2) 0113962
side panel
(1) 0113959
top panel
(2) 0113963
shelf
37110 - Center Pedestal

Phillips
Screwdriver
Glide
wrench
(included)
Tools Required
1. Table assembly - 37109
0114246R1 Page 4 of 12
A. Assemble legs
1. To make a leg assembly, attach a leg bracket (notches facing leg plates Figure 1B)
to two legs with (4) 1/4-20 x 5/8” PHM screws. Figure 1A. Leave these screws
loose until the legs are attached to the worksurface. This will help align the mount-
ing holes. Each table requires a left and right leg assembly.
2. Attach the front bell glides and casters as shown.
3. Repeat this procedure for each set of legs.
Figure 1A
left
leg assembly
front bell
glides
rear
caster
rear
caster
right
leg assembly
leg
bracket
leg
bracket
Figure 1C
B. Attach legs to worksurface
1. Place the worksurface face-down onto a non-abrasive surface.
2. Attach each leg assembly to the worksurface with (8) 1/4-20 x 5/8”
PHM screws. Figure 1C. Note: Bell glides should be on the curved-
side of the worksurface.
3. Tighten all screws securely.
4. Flip table upright.
5. Repeat this assembly procedure on all three tables.
worksurface
1/4-20 x 5/8” PHMS
(8) per leg assembly
left
leg assembly
right
leg assembly
bell
glide
bell
glide
1/4-20 x 5/8” PHMS
(4) per leg assembly
1/4-20 x 5/8” PHMS
(4) per leg assembly
caster
caster
notches facing
leg plates
Figure 1B
leg leg
leg
plate
leg leg
leg
plate
Note: Each table comes with
(4) casters and (4) glides. The
table can be assembled with all
4 casters for frequent mobility,
4 glides for xed locating, or
2 casters / 2 glides for oc-
casional mobility. Figure 1A
below shows the 2 casters / 2
glide assembly option.

Tools Required
0114246R1 Page 5 of 12
2. Center pedestal assembly - 37110
Option #1:
If you are assembling a standard (ush worksurface) table, install
the solid top panel on the center pedestal. Figure 2A.
Figure 2A
Option #2:
If you will be using the optional pedestal riser, install the open
panel (included with the riser) on the center pedestal. Figure 2B.
Pedestal riser assembly will continue on p.8.
Figure 2B
A. Choose pedestal top panel
solid top
panel
open panel
under riser
pedestal riser with
solid top panel
center
pedestal
center
pedestal
pedestal riser
Phillips
Screwdriver
Glide wrench
(included)
7/16” or adjustable
wrench

0114246R1 Page 6 of 12
1. Place the top panel face-down onto a non-abrasive surface. Figure 2C.
2. Align and attach the corner columns to the top panel using 1/4-20 x 5/8” PHM screws. Do not tighten completely yet.
Figure 2C
side panelside panel
door stop bracket
(attach w/ two 8-32 x 1/2” PH
thread-cutting screws)
(door will be hinged on the
opposite side as the bracket)
8-32 x 1/2” PH
thread-cutting
screws (2 per side)
corner
column
corner
column
glides
(3 req’d)
oor bracket
(optional)
top panel
(solid shown)
for solid top
panel install:
(3) 1/4-20 x 5/8”
PHMS
B. Assemble pedestal
corner
column
for open top
panel install:
(1) 1/4-20 x 5/8”
PHMS here only
Note: If you will be attaching the pedestal riser later with the open top panel, install (1) 1/4-20 x 5/8”
PHM screw in the center mounting hole of each corner column. Longer screws will also be used during
the riser assembly on p.8 to secure the riser to the corner columns.
3. Attach the (2) side panels to the corner columns as shown with 8-32 x 1/2” PH thread-cutting screws. (4) screws per panel will be used.
Tighten securely, but do not overtighten these screws.
4. After the side panels and corner columns are installed, tighten all screws.
5. Install a glide into each corner column.
6. Determine which side you’d like the door to be hinged (from left or right). The door is symmetrical and can be hinged from the left or right side.
Attach the door stop bracket to the corner column opposite the determined hinge side with (2) 8-32 x 1/2” PH thread-cutting screws. Tighten screws
securely, but do not overtighten these screws.
7. Optional: If the unit is to be anchored to the oor, attach a oor bracket to each corner column with a 1/4-20 x 5/8” PHM screw and 1/4-20 locknut.
8. Flip the unit over.

0114246R1 Page 7 of 12
9. Install the two adjustable shelves at the desired height and attach to the side panels with (4) 1/4-20 x 5/8” PHM
screws and tighten securely. Figure 2D. Use the lowest set of mounting holes when installing the lower shelf.
10. Attach the door to the corner column (opposite the door bracket) with (5) 8-32 x 1/2” PH thread-cutting screws.
Be careful not to overtighten these screws.
11. Install (3) 2” grommets in the top panel.
Figure 2D
1/4-20 x 5/8” PHMS
(4 per shelf)
door
8-32 x 1/2” PH
thread-cutting screws
(5 req’d)
Note: At this point, if you are using the optional oor brackets, place the pedestal into its nal location,
adjust the brackets to contact the oor and tighten securely. Mark the bracket hole locations onto the oor.
These hole locations will be used with anchor fasteners compatible with your specic oor. (Not included.)
2” grommet
(3 req’d in solid
top panel only)
door
bracket
corner
column
top panel
(solid shown)
Note: If you will be attaching the pedestal riser, install the door, but not the shelves, then proceed with the
pedestal riser assembly instructions on p.8.
Note: Spectrum recommends using the low-
est set of mounting holes when installing the
lower shelf to maximize pedestal stability.

Tools Required
Phillips
Screwdriver
4mm hex wrench
(included)
0114246R1 Page 8 of 12
3. Pedestal Riser Assembly - 37111
1. Attach each corner column to the installed open panel top as shown with (2) 1/4-20
x 1-3/4” PHM screws. (installed from under the open top panel). Figure 3A. Do not
tighten these screws completely yet.
2. Install a 2” snap-in grommet into each corner column.
Figure 3A
corner
column
corner
column
corner
column
1/4-20 x 1-3/4”
PHMS
(2 per column)
2” snap-in
grommet
2” snap-in
grommet
open top
panel
Note: If you are installing the pedestal riser onto an existing pedestal with a solid top panel:
• The solid top panel must be removed and replaced with the open top panel prior to the riser assembly.
(See step B1-B2 on p.6 for the open top panel assembly procedure.)
• The shelves should also be removed to provide easier access to the screws underneath.
A. Install corner columns

0114246R1 Page 9 of 12
1. Set the solid top panel onto the corner columns while aligning the mounting holes. Figure 3B. Secure each
corner column to the solid top with (2) 1/4-20 x 5/8” PHM screws and tighten securely.
2. Attach each instrument panel to the corner columns with (2) 1/4-20 x 35mm JC bolts. Tighten securely.
3. Tighten all screws securely.
4. Reinstall shelves.
Figure 3B
solid top panel
1/4-20 x 35mm JC bolt
(2 per panel)
instrument
panel
1/4-20 x 5/8” PHMS
(2 per corner column)
B. Install solid top panel and instrument panels

Phillips
Screwdriver
Tools Required
0114246R1 Page 10 of 12
4. Modesty panel assembly - 37112
1. Carefully ip the table over onto a non-abrasive surface. Figure 4.
2. Remove the upper 1/4-20 x 5/8” PHM screw from each leg assembly.
3. Orient the modesty panel as shown while aligning the worksurface mounting holes.
4. Install (2) #14 x 7/8” PHSM screws into the worksurface to secure. Do not tighten completely yet.
5. Re-install the previously removed 1/4-20 x 5/8” PHM screws to secure the modesty panel to the leg assemblies.
6. Tighten all screws securely.
7. Repeat this procedure for the remaining tables.
Figure 4
1/4-20 x 5/8” PHMS
(remove from leg
assembly before attach-
ing modesty panel)
A. Install modesty panel
#14 x 7/8” PHSM
(2 req’d)
1/4-20 x 5/8” PHMS
(remove from leg
assembly before attach-
ing modesty panel)

Phillips
Screwdriver
Tools Required
0114246R1 Page 11 of 12
5. Connecting tables together (optional)
1. To connect the tables together, place all three tables around the module.
2. Place the unit-to-unit bracket across the table seam and align with the worksurface mounting holes.
3. Attach with (2) 1/4-20 x 5/8” PHM screws. Figure 5.
4. Keep screws loose until all three tables are aligned and connected, then tighten securely.
Figure 5
unit-to-unit
bracket
1/4-20 x 5/8” PHMS
(2 per bracket)
A. Install brackets

Warranty
0114246R1 Page 12 of 12
WE WILL MAKE IT RIGHT FOR YOU!
Spectrum is committed to provide complete customer satisfaction. Each of our products are manufactured from the best materials available and each
product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations).
Our Customer Service Help Line 1-800-235-1262 is ready to provide immediate attention to any questions, comments or concerns. We are available
to answer your calls Monday through Friday from 7 am to 5 pm CST, excluding observed holidays. In addition your product comments or concerns are
welcome via e-mail at: [email protected].
Warranty Statement
We guarantee all Spectrum products to be free of all defects in materials and workmanship, for the original owner, for a period of ten years. Any item
deemed defective by Spectrum or the original manufacturer, under normal use conditions, will be repaired or replaced at Spectrum’s discretion. This
warranty applies to all products manufactured and distributed by Spectrum except the products
listed below.
Items that have a varying warranty include, but are not limited to, the following:
• Adjustable Crank/Electric Desk Legs (1 yr)
• Flat Panel Desk Gas Cylinders (1 yr)
• Upholstered Soft-Goods (5 yrs)
• Adjustable Height & Stacking Chair Parts – including frames, gas cylinders, wood and plastic parts, and control handles (7 yrs)
• Adjustable Height & Stacking Chair Casters (2 yrs)
• Chair Upholstery & Textiles (2 yrs of normal use of Soft Goods, Adjustable Height, Stacking, Wood and Metal Chairs)
• Chair Upholstery - Graded-In Fabrics and C.O.M (no warranty)
• Height Adjustable Columns and Lifts (1 yr)
• General Use Casters (1 yr)
• Electrical – Electri-Pak, Power Communication Modules, and special order ECA electrical items (1 yr)
• Electrical - Power Strips & Electrical Timers (1 yr)
• Electrical Surge Suppressors (lifetime)
• Electrical - Retractable Power Cords (1 yr)
• Keyboard/Mouse Trays (1 yr)
• Flat Panel Monitor Arm – General Parts (5 yrs)
• Flat Panel Monitor Arm – Gas Cylinders (2 yrs)
• CRT Monitor Arm (1 yr)
Warranty is void if product is not used for its intended purpose or subjected to an unusual application, multiple-shift use, alteration, accident, abuse or
abnormal wear and tear. Representations of colors on-line and in printed materials are meant to be a close reference to the actual colors but not an
exact match. Slight variations in color and texture of wood stains, powder coating, laminates, fabrics and other materials are normal in different manu-
facturing lots; as such these variations are not considered defects.
DESIGNED FOR INDOOR USE ONLY – Unless specifically stated in the product specifications, Spectrum’s products have been designed and con-
structed for indoor use only. Moving or using outdoors, or on excessively rough surfaces, may cause damage to the products and will void the warranty.
If an outdoor application is desired please contact us to discuss potential custom design solutions.
The warranty, as stated above, supersedes any previous warranties and is effective as of 9/1/2010
925 First Avenue, PO Box 400, Chippewa Falls, WI 54729 Ph:800-235-1262, 715-723-6750 Fax: [phone]
E-mail: [email protected] web: www.spectrumfurniture.com
