SRC B-TRK502-14-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
NO. Description Quantity Torque * (N-M) Remarks ** Check List
4
410 - 12
1
1
1
1
2
3
4
5
Lower Plate
Top Plate
Middle Plate
Use LiquidThread Locker
Nut M6
SRCDesign uses MetricSystem of Measurement and all dimensions in Millimeters
*Recommended to use the Torque specified in the table
**Denotes Usage of Liquid Thread Locker in specified Locations
Countersink Screw M6 X 20
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: B-TRK502-14-01-SL
Part Description: Large Side Stand –BENELLI TRK502 / TRK502 X
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Step 1:
During Mounting the Large Side Stand, let the
Motorbike firmly rest on the floor, using the Centre
Stand.
The side stand can be brought forward (position as
shown in the drawing) to have access to the
Mounting/ Assembly of the SRC Large Side Stand.
Step 2:
Orient and Slip-in the Middle Plate (4), as shown.
The peripheral Inner walls of the Middle plate,
will closely hug the outer walls of the Side stand.
Orient the Bottom Plate (1), in-line with the
Mounting Holes on the Middle Plate and slide-in
the M6 Screws (4) from the bottom side.
The Bottom plate has a rear side flap, which
closely hugs the Rear Periphery of the Middle
plate, to ensure orientation, as well as to ensure
No slackness
Step: 4
Slide-in the Top Plate (3), as shown
and orient the mounting holes in-line
with the 4 Projecting screws.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Secure the threads on the screw using M6
Nut (5), as shown.
As shown in the left, is the Final Mounted
condition of the Side Stand

Copyright By SRC
Design and Specification are subjected to change
Page 5
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and
follow the step-by-step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the
Accessory part to the Vehicle. We have prepared this based on our experience and
knowledge, related to the Vehicle, Part and its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s
accessory part. It is advised to the User, to inspect and ensure the original state of all other
Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour
and/or the stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will
help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all
functions of the Vehicle. It is always advised to check loosening of the fasteners after the first
50 kilo meters of ride and at regular intervals.
7. We are showing here the Scope of Supply/ Installation/Parts list & BOM from SRC
8. To the maximum extent possible, our design use the current Mounting/Fitment of the
Original Equipment, so that Installation of these accessories will not affect the Payload or
Function of the Vehicle or the Part on which it is mounted to protect it
9. If any additional modifications are to be done, prior to the fitment of the accessories, it
will be explicitly specified in the instruction sheets.
