SRC H-CRF300L-04-01-AL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
NO. Description Quantity Torque * (N-M) Remarks **
2
2
4
1
2
1
2
3
4
5
Top Rack
Bush 18 x 31
Bush 18 x 38
Taper Ring M8
Socket countersunk head sc rew M8 x 60
2
6Socket countersunk head sc rew M8 x 65
SRCDesign uses MetricSystem of Measurement and all dimensions in Millimeters
*Recommended to use the Torque specified in the table
**Denotes Usage of Liquid Thread Locker in specified Locations
22 - 24 Use LiquidThread Locker
22 - 24 Use LiquidThread Locker
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-CRF300L-04-01-AL
Part Description Top Rack–HONDA CRF 300 L / HONDA CRF 300 RALLY
Applicable to Finished colour versions of Black
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
Mounting Instructions
Step 1:
Before starting to mount the Top
Rack we can remove the original
screw in motorbike (as show)
Step 3:
Orient and Align the Top Rack (1), as
shown, Slip-in the Bush Spacer 18 x
31 mm (2) –1off between the
Mounting hole front side and Slip-in
Screw M8x 60 (5) –1off and Taper
Ring M8 (4) –1off
Slip-in the Bush Spacer 18 x 38 mm
(3) –1 off between the Mounting
End hole and Slip-in Screw M8 x 65
(6) –1 off and Taper Ring M8 (4) –1
off through the holes and secure the
threads.
Step 2:
Repeat the Step 1 for mounting
the Top Rack, as shown

Copyright By SRC
Design and Specification are subjected to change
Page 3
Step 4:
Repeat the above step for the other
side to secure the threads.
The Top Rack in “As is mounted condition” is as shown.

Copyright By SRC
Design and Specification are subjected to change
Page 4
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. We are showing here the Scope of Supply/ Installation/Parts list & BOM from SRC
8. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
9. If any additional modifications are to be done, prior to the fitment of the accessories, it will be
explicitly specified in the instruction sheets
