Scope of Supply/Bill of Material & Mounting Drawings
Part Number: T-XRX-07-01-SL / T-XRX-07-02
Part Description: GPS BAR –TRIUMPH TIGER800 XRX
Applicable to Finished colour versions of Black and Silver
Installation / Parts List / Bill of Material for Mounting
No. Description Quantity Torque * (N-m) Remarks **
1 RH Bracket 1
2 End Adaptor 2
3 GPS Bar 1
4 LH Bracket 1
5 Washer M8 2
6 Screw M8 x 16 2 9 - 10 Use Liquid Thread Locker
SRC Design uses Metric System of Measurement and all dimensions are in Millimeters
* Recommended to use the Torque specified in the table
** Denotes Usage of Liquid Thread Locker in specified locations

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
The Wind shield on the front has to be
removed. Unscrew them from its position and
keep it aside.
This will facilitate access to the Mounting
holes for fitment of GPS Bracketry.
Step 2:
Unscrew the 2 off Button Head screws, as
shown, and keep them aside.
SRC’s GPS Bracketry will be mounted/fitted
using the above screws.
Step 3:
Under the Speedo console, unscrew the 2
off Button head screws, as shown.
Again, the same hardware will be used for
mounting/fitting the GPS Bracketry.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step 4:
Orient and align the LH Bracket (4), as
shown, with its mounting hole in-line with
the hole under the Speedo console, on the
LH side, as shown above.
Slip-in 1 off Button head screw (which was
removed in the previous step) and secure
the threads.
Step 5:
Orient and align the RH Bracket (1), as
shown, with its mounting hole in-line with
the hole under the Speedo console on the
RH side, as shown above.
Slip-in 1 off Button head screw and secure
the threads.
The LH and RH GPS Brackets in
“As is mounted condition” is as
shown in the drawing to the
right.

Copyright By SRC
Design and Specification are subjected to change
Page 5
Step 7:
Follow the step 6, for mounting the RH
Bracket and secure the threads
The LH and RH Brackets, are as shown in
the drawing on the left, in “As is
mounted condition”.
Step 6:
Orient and align the LH Bracket (4) to the front
side mounting hole, as shown, and slip-in 1 off
Button Head screw (which was removed in
Step 2) and secure the threads.

Copyright By SRC
Design and Specification are subjected to change
Page 6
Step 8:
The GPS Bar (3), has the End Adaptors,
welded together and Orient and align it
in-line to the Mounting hole on top of
the LH and RH bracket, as shown.
Step 9:
Slide-in Washer M8 (5) and Screw M8 x
16 (6) –1 off from each side of the
bracket and fully tighten the GPS bar,
as shown.
The GPS Bar in final mounted condition
is as shown.

Copyright By SRC
Design and Specification are subjected to change
Page 7
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
