SRC H-ADV150-01-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-ADV150-01-01-SL / H-ADV150-01-02
Part Description: Head Light Guard –HONDA ADV150
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
The Mounting Screws, which will be used for mounting
the Brackets of the Head Light Guard, can be found on
the Front Left hand side and Right hand side. The same
can be unscrewed out, 2 off on each side.
Orient and align the SideLightGuard LH(4) &
SideLightGuard RH (6), as shown.
Slip-in the Spacer –Delrin M5 14x10(5) –2 off
from either side.
Slide-in the Washer M5 (7) and Screw M5 x 30 (10)
–2off, into the top side of the mounting hole, from
either sides.
Mounting of the Bottom Plate LH (2).& the
Bottom Plate RH (6) This takes the mounting hole
available in the Motorbike (as shown in the
drawing).
Orient and align the Bottom Plate, and slide in the
Cilp M6 (13) –2 off, Bush Delrin M6 14x7 (12) –2
off, Washer M6 (8) -2 off, Screw M6x25 (11) –2
off, from the Bottom side.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Orient and Align the Head Light Guard (1), as
shown, in-line with the 4off Mounting holes in the
SideLightGuard LH&RH (4)(6) and Bottom Plat
LH&RH (2)(3) and Slide in the Washer M5 (7) –4 off
on each side and Screw M5x6 (9) –8off on each
side.
Ensure Mounting symmetry and tighten the screws
to torque as per specifications in the BOM table.
Final Mounted condition of the Head Light Guard, is
as shown in the drawing above.

Copyright By SRC
Design and Specification are subjected to change
Page 5
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not affect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modifications are to be done, prior to the fitment of the accessories, it will be explicitly
specified in the instruction sheets
