STI UB-2PN User manual

UB-2PN Universal 2”
Pneumatic Button
We protect the things that protect you.®
ADA
Compliant
ADA
Compliant

NOTES
It is important to read, understand and follow all instructions provided with
this product. It is the installer’s responsibility to comply with NFPA 70 &
101, NEC, mounting specifications according to ADA and other applicable
electrical codes.This switch is rated Type NM (Non-Monitored) for non-
emergency signaling. Not to be used in place of panic hardware. To avoid
electrical shock, DO NOT attempt to install this product when power is
on. ADA mounting compliance requires the operable part of the initiating
device shall not be less than 3 1/2 ft. (1.1m ) or greater than 4 1/2 ft. (1.37m)
above finished floor surface. After installation and testing are complete,
provide a copy of this manual to all personnel responsible for testing and
maintenance of this product.
* For access control installations, power for the UB-2PN must be supplied
by a power source Listed to UL294. When used for access control, this
device shall be used as a part of an access controlled egress door system.
It is up to the local AHJ to allow use of this device in place of an automatic
sensor. For higher security installations, lower time limits should be used.
SWITCH RATING
Independent Form “Z” contacts
Rated at: 10A @ 240 VAC
Operating Temp: 15° to 120°F (-9° to 49°C)
1,000,000 Cycles
- 2 -
.91 in.
(23mm)
1.47 in.
(38mm)
2 in.
(51mm)
3.22 in.
(82mm)
4.83 in.
(123mm)
DIE CAST PLATE
SPRING
PUSH BUTTON ACTUATOR
ACTUATOR CAP
2 in. BUTTON
ALIGN TAB ON ACTUATOR
WITH SLOT BUTTON.
TURN CLOCKWISE TO LOCK.
INSERT ASSEMBLY WITH
SPRING INTO PLATE.
REAR VIEW
1
1
2

1. TO CHANGE BUTTON COLOR AND ROUND MESSAGE
1. Choose button message and color. If same as existing, proceed to 2.
2. To remove push button actuator assembly, squeeze actuator tabs in direction of #1 arrows.
3. Push actuator through plate in direction of #2 arrow.
4. Align actuator cap to push button actuator. Align button slots to tabs on push button actuator.
5. Snap button onto push button actuator and rotate right to lock.
6. Insert spring into push button actuator.
7. Squeeze legs of push button actuator and align into die cast plate.
1. Remove LED circuit board.
2. Remove current message by pushing in and
down on tabs 1 and 2 with a small screwdriver.
If necessary, also push in and down on tabs 3
and 4. Once message is loose, remove from
the front of the plate.
3. Select new message and snap into place.
Blank plates are included to create your own
custom message.
2. CHANGE TOP MESSAGE
- 3 -
.91 in.
(23mm)
1.47 in.
(38mm)
2 in.
(51mm)
3.22 in.
(82mm)
4.83 in.
(123mm)
DIE CAST PLATE
SPRING
PUSH BUTTON ACTUATOR
ACTUATOR CAP
2 in. BUTTON
ALIGN TAB ON ACTUATOR
WITH SLOT BUTTON.
TURN CLOCKWISE TO LOCK.
INSERT ASSEMBLY WITH
SPRING INTO PLATE.
REAR VIEW
1
1
2
.91 in.
(23mm)
1.47 in.
(38mm)
2 in.
(51mm)
3.22 in.
(82mm)
4.83 in.
(123mm)
DIE CAST PLATE
SPRING
PUSH BUTTON ACTUATOR
ACTUATOR CAP
2 in. BUTTON
ALIGN TAB ON ACTUATOR
WITH SLOT BUTTON.
TURN CLOCKWISE TO LOCK.
INSERT ASSEMBLY WITH
SPRING INTO PLATE.
REAR VIEW
1
1
2
Power In
12–30 VDC/VAC
Safety Tech. Int’l Inc.
P/N UB-11. Ver 1.0
wwyy
DIFFUSER
TO SUPERVISED STATION
OR AUXILLARY DEVICE
SW1
SW2
NC
COM
NO
NC
COM
NO
MAG LOCK
MESSAGE LENS PCB
12–24VDC
BUTTON LED
NORMAL POSITION BUTTON ACTIVATED
MAGNETIC LOCK
BUTTON LAMP
MESSAGE LAMP
ON
ON
OFF
OFF
OFF
ON
NO
NC
COM
LED –
LED +
SWITCH 1
SWITCH 2
12
34
SCREWDRIVER
4.830 in.
(123mm)
3.220 in.
(82mm)
1.328 in.
(34mm)
.867 in.
(22mm)
UB-1L LED PCB
NYLON WASHER
SELF TAPPING SCREW
#6 - 32 x 1” OVAL
HEAD MACHINE SCREW
(2) PROVIDED
#8-10 7/8 in. ANCHOR
(4) PROVIDED
DRILL POINT PROVIDED TOP & BOTTOM
FOR 1/2 in. CONDUIT. DRILL AS NEEDED.
#6 x 1 1/4 in.
PHILLIPS PAN HEAD SCREW
(4) PROVIDED
DRILL (4)
3/16 in.
DIAMETER HOLES
KIT-71100A-* BACKBOX
*ADD ONE OF THE FOLLOWING:
R=red, B=blue, G=green,
W=white, Y=yellow
#6-32 x 1 in. PHILLIPS
OVAL HEAD MACHINE SCREW
18-8 SS(2) PROVIDED
DRILL OUT THE (4) MOUNTING
HOLES, ONE IN EACH CORNER,
USING 5/32 in. DRILL BIT
BACKBOX MUST BE MOUNTED
WITH ARROWS POINTING UP
.867 in.
(22mm) 1.575 in.
(40mm)
UB-1L LED PCB
TOP TAB
ACTUATOR
Power In
12–30 VDC/VAC
Safety Tech. Int’l Inc.
P/N UB-11. Ver 1.0
wwyy
CAP
BUTTON
SPRING
NEW DRAWING

3. INSTALL OR REMOVE CONTACT BLOCK
- 4 -
4.83 in.
(123mm)
3.22 in.
(82mm) .91 in.
(23mm)
1.47 in.
(38mm)
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
SQUEEZE TABS AND PUSH
ASSEMBLY INTO PLATE
A
A
SQUEEZE TABS
AND PUSH
ASSEMBLY
INTO PLATE
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
NO
NC
COM
LED –
LED +
SWITCH 1
SWITCH 2
SQUEEZE TABS
AND PUSH
ASSEMBLY
INTO PLATE
POWER IN
12-30 VDC/VAC
NC
COM
NO
MAG LOCK
UB-1L LED PCB
UL Listed
NORMAL POSITION BUTTON ACTIVATED
MAGNETIC LOCK
MESSAGE LAMP
ON
OFF
OFF
ON
+
+
+
12-24 VDC Power Supply
NC
NO
NC
NO
(BLACK) NC
(RED) NO
NC (GREEN)
NO (WHITE)
OFF
ON
+
+
+
MAG LOCK
NC CONTACTS
NO CONTACTS
UB-1L LED PCB
UL Listed
12-24 VDC Power Supply
NORMAL POSITION BUTTON ACTIVATED
ON
OFF
MAGNETIC LOCK
MESSAGE LAMP
UB-1L LED PCB
NYLON WASHER
SCREW
COUNTERCLOCKWISE
CLOCKWISE
TIMER RANGE ADJUSTMENT SCREW
ADJUSTMENT RANGE - 2 TO 60 SECONDS
TIMER FACTORY SET TO MINIMUM TIME
SETTING. TO INCREASE TIME, TURN
SCREW CLOCKWISE IN 1/4 TURN
INCREMENTS. WHEN CLOSE TO DESIRED
TIME, TURN SCREW IN VERY FINE
INCREMENTS TO DESIRED SETTING.
CAUTION: OVER-TIGHTENING MAY
CAUSE DAMAGE TO TIMER.
CONNECTION AND LEAD WIRE
COLOR CODE
12
34
SCREWDRIVER
4.83 in.
(123mm)
3.22 in.
(82mm) .91 in.
(23mm)
1.47 in.
(38mm)
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
SQUEEZE TABS AND PUSH
ASSEMBLY INTO PLATE
A
A
SQUEEZE TABS
AND PUSH
ASSEMBLY
INTO PLATE
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
POWER IN
12-30 VDC/VAC
NO
NC
COM
LED –
LED +
SWITCH 1
SWITCH 2
SQUEEZE TABS
AND PUSH
ASSEMBLY
INTO PLATE
POWER IN
12-30 VDC/VAC
NC
COM
NO
MAG LOCK
UB-1L LED PCB
UL Listed
NORMAL POSITION BUTTON ACTIVATED
MAGNETIC LOCK
MESSAGE LAMP
ON
OFF
OFF
ON
+
+
+
12-24 VDC Power Supply
NC
NO
NC
NO
(BLACK) NC
(RED) NO
NC (GREEN)
NO (WHITE)
OFF
ON
+
+
+
MAG LOCK
NC CONTACTS
NO CONTACTS
UB-1L LED PCB
UL Listed
12-24 VDC Power Supply
NORMAL POSITION BUTTON ACTIVATED
ON
OFF
MAGNETIC LOCK
MESSAGE LAMP
UB-1L LED PCB
NYLON WASHER
SCREW
COUNTERCLOCKWISE
CLOCKWISE
TIMER RANGE ADJUSTMENT SCREW
ADJUSTMENT RANGE - 2 TO 60 SECONDS
TIMER FACTORY SET TO MINIMUM TIME
SETTING. TO INCREASE TIME, TURN
SCREW CLOCKWISE IN 1/4 TURN
INCREMENTS. WHEN CLOSE TO DESIRED
TIME, TURN SCREW IN VERY FINE
INCREMENTS TO DESIRED SETTING.
CAUTION: OVER-TIGHTENING MAY
CAUSE DAMAGE TO TIMER.
CONNECTION AND LEAD WIRE
COLOR CODE
12
34
SCREWDRIVER
INSTALL
To attach, align tabs (as shown)
and gently snap top, then bottom.
Be sure to hear BOTH tabs snap
into place. Contacts can be rotated
180° if desired.
REMOVE
To remove, use a small
flat blade screwdriver.
Position screwdriver
blade under tab
and gently rotate
screwdriver until tab
disengages. Repeat for
opposite tab.
CONTACT INFORMATION
CONTACT REMOVAL
DETAIL A

- 5 -
4. ATTACH POWER FOR MESSAGE LED (if desired - see drawing)
