Storage Canopy C4080S User manual

SHELTER
ASSEMBLY MANUAL
Model # W12xL24xH 4.5m
C4080S Container Shelter

1
SPECIFICATION
Width:12m Length:24m Height:4.5m
IMPORTANT-----READ MANUAL FIRST
Improper site preparation, Assembly and Maintenance may invalidate warranty and cause
unnecessary and costly mistake. If you have any questions contact your local dealer.
For User Friendly assembly we have identified each individual component with the part code as
indicated in the parts list. Please refer to the part code numbers and drawing to ensure problem
free assembly.
It’s necessary to tighten the roof fabric enough to avoid “hammocks” on the roof and also
re-tighten once or twice again after a few months of use. This is important when assembly in cold
weather (autumn and winter) because the fabric is stiff then and when we got the sun and warm
weather afterwards it will make the fabric “slack” again and need to be re-tighten before next
winter.
It’s the owners responsibility to take of snow immediately if not slide off by itself.
READ ALL INSTRUCTIONS BEFORE ASSEMBLY
1. Keep work area clean. Cluttered areas invite injuries. Do not set up near snow drifts, in
slippery places, in high winds, or wet location.
2. Keep children away. All children should be kept away from the work area.
3. Don’t over reach. Keep proper footing and balance at all times.
4. Do not assemble in under the influence of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If
there is any doubt, do not assemble.
5. Be aware of possible windy conditions; fasten the bases in concrete if these conditions are
likely to occur. Remove the cover during hurricane.
6. Be careful with power and heat sources. Do not keep heat sources near the tarpaulin. Do not
expose to open flame.
7. Be aware of personal safety during assembly and use. Be careful not to pinch fingers with
clips and tubes when assembling: when using makes sure there is adequate ventilation for
exhaust and other dangerous fumes.

2
Parts List
Part Code
Description
Qty
1
Top Bent Tube
11
2
Side Bent Tube
22
3
Lower Bent Tube
22
4
Purlin
70
5
Top Tension Device
16
6
Clips
32
7A
Left Base Plate
11
7B
Right Base Plate
11
8
Ratchet
22
9
Nylon band for ratchet
22
10
Tensioning Tube
2 Groups
11
Bolts M8x70
176
11A
Bolts M12x30
132
12
Bolts M10x80
77
13
Roof Cover
1
14
Knitting Rope for Cover
1
15
Plastic Plug
4
16
Angle iron
4
17
Angle iron for base plate
22

3
EQUIPEMNT AND TOOLS FOR INSTALIATION
1. Measuring tape
2. String for alignment
3. Step ladder
4. Welder
5. Sledge hammer
6. Wrench
7. Scissors
INSTALLATION PROCESS
A—BASE INSTALLATION
Please refer to the diagram (Figure 1) to place the base plates.
Figure 1
1. The measurement is from center to center of the tubes. Referring to the above diagram and
confirm the place of the base plates. ENSURE THAT THE FOUNDATIONS IS SQUARE.
2. All the base plates should be welded on the Containers.

4
Figure 2 Sketch Frame
B—FRAME INSTALLATION

5
Figure 3
Figure 4
C—ROOF COVER INSTALLATION
NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A
slight breeze is the most advantageous for cover installation. To take advantage of the breeze,
pull the cover up over the arches with breeze blowing in the cover like a sail filled with air.

6
.
Figure 5

7
Figure 6
Please check the below installation detailed pictures:
(A) (B)

8
(C) (D)
NOTE: DO NOT LEAVE THE ROOF COVER UNATTACHED UNDER ANY
CIRCUMSTANCES until the final assembly and tightening has been completed.
The process is quite easy. But some tightening adjustments will be necessary to produce a
flat, tensioned roof cover. Please adjust the roof cover every month.
Please Note:
Please use the tape wrapped around the gap between the steel
skeleton after installing.
