Storage Canopy C4040S User manual

SHELTER
ASSEMBLY MANUAL
Model # W12xL12xH 4.5m
C4040S Container Shelter

1
SPECIFICATION
Width:12m Length:12m Height:4.5m
IMPORTANT ---- READ MANUAL FIRST
Improper site preparation, Assembly and Maintenance may invalidate warranty and cause
unnecessary and costly mistake. If you have any questions contact your local dealer.
For User Friendly assembly we have identified each individual component with the part code as
indicated in the parts list. Please refer to the part code numbers and drawing to ensure problem free
assembly.
It’s necessary to tighten the roof fabric enough to avoid “hammocks” on the roof and also re-tighten
once or twice again after a few months of use. This is important when assembly in cold weather
(autumn and winter) because the fabric is stiff then and when we got the sun and warm weather
afterwards it will make the fabric “slack” again and need to be re-tighten before next winter.
It’s the owners responsibility to take of snow immediately if not slide off by itself.
READ ALL INSTRUCTIONS BEFORE ASSEMBLY
1. Keep work area clean. Cluttered areas invite injuries. Do not set up near snow drifts, in
slippery places, in high winds, or wet location.
2. Keep children away. All children should be kept away from the work area.
3. Don’t over reach. Keep proper footing and balance at all times.
4. Do not assemble in under the influence of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or reflexes are impaired while taking drugs. If there
is any doubt, do not assemble.
5. Be aware of possible windy conditions; fasten the bases in concrete if these conditions are likely
to occur. Remove the cover during hurricane.
6. Be careful with power and heat sources. Do not keep heat sources near the tarpaulin. Do not
expose to open flame.
7. Be aware of personal safety during assembly and use. Be careful not to pinch fingers with clips
and tubes when assembling: when using makes sure there is adequate ventilation for exhaust
and other dangerous fumes.

2
Parts List
Part Code
Description
Qty
1
Top Bent Tube
6
2
Side Bent Tube
12
3
Lower Bent Tube
12
4
Purlin
35
5
Top Tension Device
16
6
Clips
32
7A
Left Base Plate
6
7B
Right Base Plate
6
8
Ratchet
12
9
Nylon band for ratchet
12
10
Tensioning Tube
2 组
11
Bolts M8x80
96
12
Bolts M10x80
42
13
Roof Cover
1
14
Knitting Rope for Cover
1
15
∮32 Plastic Plug for end of tensioning tube
4
16
Angle iron
4
17
Angle iron for base plate
12
18
Bolt 12x30
60

3
EQUIPEMNT AND TOOLS FOR INSTALIATION
1. Measuring tape
2. String for alignment
3. Step ladder
4. Welder
5. Sledge hammer
6. Wrench
7. Scissors
INSTALLATION PROCESS
A—BASE INSTALLATION
Please refer to the diagram (Figure 1) to place the base plates.
Figure 1
1. The measurement is from center to center of the tubes. Referring to the above diagram and
confirm the place of the base plates. ENSURE THAT THE FOUNDATIONS IS SQUARE.
2. All the base plates should be welded on the Containers.

4
Figure 2 Sketch Frame

5
B—FRAME INSTALLATION
Figure 3
1. As Figure 3 shown find Roof Bent Tube (No. 1), Side Bent Tube (No.2), Lower Bent
Tube(No.3). To connect them by Bolts M8x80 （No.11）.Which makes one group of arch.
Please NOTE the direction of the bolt. DO NOT install the bolts on the top of the truss where
the fabric will rest.
2. Insert one end of the assembled arch into one base plate and force the other end of the arch into
the opposite base plate.

6
Figure 4
3. After finishing installing the first two arches, connect the Connection purlins onto them by
using screw M10x80（No.12）.There are 7 pieces of Connection Purlins (No.4) between each
arch. Then install the third arch into base plate and connect the purlins. Finally install the Top
Tension Device (No.5) using bolt and Clip (No.6). Assemble the Frame by turns like this.

7
C—ROOF COVER INSTALLATION
NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A
slight breeze is the most advantageous for cover installation. To take advantage of the breeze, pull
the cover up over the arches with breeze blowing in the cover like a sail filled with air.
1. Assemble Tensioning Tube for Roof Cover (No.10) before installing thecover.
2. Put the Roof Cover (No. 13) EVENLY, CAREFULLY AND SLOWLY on the frame. Adjust
the cover so that it is square and evenly centered on the frame.
.
Figure 5

8
Figure 6
3.Weld the Angle Seats (No. 16) on each container and use Ropes (No. 14) to knit the cover on
the two side arches, finally tie the Roof cover to the Angleseats.
4.Cut pockets over each ratchet on the base plates and put the Tensioning Tube for roof cover
(No. 10) into the pocket of roof cover. Then use the Nylon band (No.9) to tie down the Lower
Tensioning Tubes as Figure 6 shown. Finally install the∮32 Plastic Plug (No. 15) into two end
of the Lower tensioning tube.
Please check the below installation detailed pictures:
(A) (B)

9
(C) (D)
NOTE: DO NOT LEAVE THE ROOF COVER UNATTACHED UNDER ANY
CIRCUMSTANCES until the final assembly and tightening has been completed.
The process is quite easy. But some tightening adjustments will be necessary to produce a
flat, tensioned roof cover. Please adjust the roof cover every month.
Please Note:
Please use the tape wrapped around the gap between the steel
skeleton after installing.
